Brocade Communications Systems SERVERIRON ADX 1000 User manual

53-1002405-01
September 2011
®
Brocade ServerIron ADX
Installation Guide
Supporting ServerIron ADX 1000, ServerIron ADX 1000F,
ServerIron ADX 4000, ServerIron ADX 8000 and ServerIron ADX 10000
Model: SI1000, SI1000F, SI4000, SI10000

Copyright © 2011 Brocade Communications Systems, Inc. All Rights Reserved.
Brocade, the B-wing symbol, BigIron, DCX, Fabric OS, FastIron, NetIron, SAN Health, ServerIron, and TurboIron are registered
trademarks, and Brocade Assurance, Brocade NET Health, Brocade One, CloudPlex, MLX, VCS, VDX, and When the Mission Is
Critical, the Network Is Brocade are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other
countries. Other brands, products, or service names mentioned are or may be trademarks or service marks of their respective
owners.
Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning
any equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to
this document at any time, without notice, and assumes no responsibility for its use. This informational document describes
features that may not be currently available. Contact a Brocade sales office for information on feature and product availability.
Export of technical data contained in this document may require an export license from the United States government.
BrocadeCommunicationsSystems,Incorporated
DocumentHistory
Corporate and Latin American Headquarters
Brocade Communications Systems, Inc.
130 Holger Way
San Jose, CA 95134
E-mail: [e-mail]
Asia-Pacific Headquarters
Brocade Communications Systems China HK, Ltd.
No. 1 Guanghua Road
Chao Yang District
Units 2718 and 2818
Beijing 100020, China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
European Headquarters
Brocade Communications Switzerland Sàrl
Centre Swissair
Tour B - 4ème étage
29, Route de l'Aéroport
Case Postale 105
CH-1215 Genève 15
Switzerland
Tel: [phone]
Fax: [phone]
E-mail: emea-i[email protected]
Asia-Pacific Headquarters
Brocade Communications Systems Co., Ltd. (Shenzhen WFOE)
Citic Plaza
No. 233 Tian He Road North
Unit 1308 – 13th Floor
Guangzhou, China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Title Publicationnumber Summaryofchanges Date
Brocade ServerIron ADX Series
Installation Guide 53-1002405-01 New document September 2011

Brocade ServerIron ADX Installation Guide iii
53-1002405-01
Contents
AboutThisDocument
In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Supported hardware and software . . . . . . . . . . . . . . . . . . . . . . . . . . vii
What’s new in this document. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Document conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Text formatting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Command syntax conventions . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Notes, cautions, and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Getting technical help or reporting errors . . . . . . . . . . . . . . . . . . . . . . ix
Web access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
E-mail and telephone access . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Chapter1 ProductOverview
ServerIron ADX fixed configuration devices . . . . . . . . . . . . . . . . . . . . 1
ServerIron ADX 1000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
ServerIron ADX 1000F. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ServerIron ADX chassis devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ServerIron ADX 4000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ServerIron ADX 10000 (ADX 10K) chassis. . . . . . . . . . . . . . . . . . 4
ServerIron ADX Chassis device modules. . . . . . . . . . . . . . . . . . . . . . . 5
Ethernet interface modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Application Switch Module (ASM) . . . . . . . . . . . . . . . . . . . . . . . . . 6
Management Module (MM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Switch Fabric Module (SFM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
SSL Expansion Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ServerIron ADX 1000 and ServerIron ADX 1000F power
supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ServerIron ADX chassis device power supplies . . . . . . . . . . . . . . 9
Cooling systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ServerIron ADX 1000 and ServerIron ADX 1000F
cooling system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ServerIron ADX 4000 and ServerIron ADX 8000
cooling systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ServerIron ADX 10000 cooling systems. . . . . . . . . . . . . . . . . . .12
Rack mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

iv Brocade ServerIron ADX Installation Guide
53-1002405-01
Chapter2 InstallingServerIronADX
Installation precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
General precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Lifting precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installing ServerIron ADX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Preparing the installation site. . . . . . . . . . . . . . . . . . . . . . . . . . .18
Installing the ServerIron ADX chassis in a rack . . . . . . . . . . . . .18
Installing modules in ServerIron ADX chassis devices . . . . . . . 21
Installing an SSL Expansion module onto a management
module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installing power supplies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Connecting AC power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Connecting DC power to a chassis . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting DC power to ServerIron ADX chassis devices. . . . .34
Attaching a management station. . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Attaching a PC or terminal to the Console port or
Ethernet port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Attaching the management module Ethernet port to a network37
Powering On the power source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Uninstalling ServerIron ADX modules . . . . . . . . . . . . . . . . . . . . . . . .38
Uninstalling ServerIron ADX 4000, 8000 & 10000 interface
modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Uninstalling an Application Switch module . . . . . . . . . . . . . . . .39
Uninstalling a Management module . . . . . . . . . . . . . . . . . . . . .40
Uninstalling a Switch Fabric module . . . . . . . . . . . . . . . . . . . . .40
Uninstalling a Fan module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Uninstalling a Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Installing ServerIron ADX modules in a running system. . . . . . . . . . 41
Installing a management module in a running system . . . . . . . 41
Installing an ASM module in a running system . . . . . . . . . . . . . 41
Installing an SFM module in a running system . . . . . . . . . . . . . 41
Installing an Interface module in a running system . . . . . . . . .42
Installing an Power Supplies in a running system . . . . . . . . . . .42
Installing an fan trays in a running system . . . . . . . . . . . . . . . .42
Verifying proper operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Observing the LEDs - ServerIron ADX 1000 and
ServerIron ADX 1000F. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Matching LEDs to locations on the ServerIron ADX 1000
and ServerIron ADX 1000F . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Observing the LEDs - ServerIron ADX chassis devices . . . . . . .46
Matching LEDs to locations on ServerIron ADX chassis
device modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Brocade ServerIron ADX Installation Guide v
53-1002405-01
Replacing a Fan Tray. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Replacing the ServerIron ADX 1000 or
ServerIron ADX 1000F Fan Tray . . . . . . . . . . . . . . . . . . . . . . . . .53
Replacing the ServerIron ADX 4000 or
ServerIron ADX 8000 Fan Tray . . . . . . . . . . . . . . . . . . . . . . . . . .53
Replacing the ServerIron ADX 10000 Fan Tray . . . . . . . . . . . . .54
Replacing the air filter in the ServerIron ADX 10000 . . . . . . . .56
AppendixA HardwareSpecifications
In this appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Hardware specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Physical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Operating environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Storage environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Safety agency approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Electromagnetic approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Port specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Console Port Pin assignments . . . . . . . . . . . . . . . . . . . . . . . . . .60
Management Port Pin assignments . . . . . . . . . . . . . . . . . . . . . . 61
AppendixB ServerIronADX8000
ServerIron ADX 8000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
ServerIron ADX 8000 slot assignments . . . . . . . . . . . . . . . . . . .64
AppendixC RegulatoryStatements
U.S.A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Industry Canada statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Europe and Australia. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Germany. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Power cords (Japan Denan) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
BMSI STATEMENT (TAIWAN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
AppendixD CautionsandDanger
Cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Danger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

vi Brocade ServerIron ADX Installation Guide
53-1002405-01

Brocade ServerIron ADX Installation Guide vii
53-1002405-01
AboutThisDocument
Inthischapter
•Audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
•Supported hardware and software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
•What’s new in this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
•Document conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
•Getting technical help or reporting errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Audience
This document is designed for system administrators with a working knowledge of Layer 2 and
Layer 3 switching and routing.
If you are using a Brocade Layer 3 Switch, you should be familiar with the following protocols if
applicable to your network – IP, RIP, OSPF, BGP, ISIS, IGMP, PIM, DVMRP, and VRRP.
Supportedhardwareandsoftware
In those instances in which procedures or parts of procedures documented here apply to some
switches but not to others, this guide identifies exactly which switches are supported and which are
not.
The following hardware platforms are supported by this release:
•ServerIron ADX 1000
•ServerIron ADX 1000F
•ServerIron ADX 4000,
•ServerIron ADX 8000
•ServerIron ADX 10000 (ADX 10K)
What’snewinthisdocument
For further information about new features and documentation updates for this release, refer to
the release notes.

viii Brocade ServerIron ADX Installation Guide
53-1002405-01
Documentconventions
This section describes text formatting conventions and important notice formats used in this
document.
Textformatting
The narrative-text formatting conventions that are used are as follows.
For readability, command names in the narrative portions of this guide are presented in mixed
lettercase: for example, switchShow. In actual examples, command lettercase is often all
lowercase. Otherwise, this manual specifically notes those cases in which a command is case
sensitive.
Commandsyntaxconventions
Command syntax in this manual follows these conventions:
bold text Identifies command names
Identifies the names of user-manipulated GUI elements
Identifies keywords and operands
Identifies text to enter at the GUI or CLI
italic text Provides emphasis
Identifies variables
Identifies paths and Internet addresses
Identifies document titles
code text Identifies CLI output
Identifies command syntax examples
command Commands are printed in bold.
--option, option Command options are printed in bold.
-argument, arg Arguments.
[ ] Optional element.
variable Variables are printed in italics. In the help pages, values are underlined or
enclosed in angled brackets < >.
... Repeat the previous element, for example “member[;member...]”
value Fixed values following arguments are printed in plain font. For example,
--show WWN
| Boolean. Elements are exclusive. Example: --show -mode egress | ingress

Brocade ServerIron ADX Installation Guide ix
53-1002405-01
Notes,cautions,andwarnings
The following notices and statements are used in this manual. They are listed below in order of
increasing severity of potential hazards.
NOTE
A note provides a tip, guidance or advice, emphasizes important information, or provides a reference
to related information.
ATTENTION
An Attention statement indicates potential damage to hardware or data.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause
damage to hardware, firmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely
hazardous to you. Safety labels are also attached directly to products to warn of these conditions
or situations.
Gettingtechnicalhelporreportingerrors
Brocade is committed to ensuring that your investment in our products remains cost-effective. If
you need assistance, or find errors in the manuals, contact Brocade using one of the following
options.
Webaccess
The Knowledge Portal (KP) contains the latest version of this guide and other user guides for the
product. You can also report errors on the KP.
Log in to my.Brocade.com, click the Product Documentation tab, then click on the link to the
Knowledge Portal (KP). Then click on Cases > Create a New Ticket to report an error. Make sure you
specify the document title in the ticket description.
E-mailandtelephoneaccess
Go to http://www.brocade.com/services-support/index.page for the latest e-mail and telephone
contact information.

xBrocade ServerIron ADX Installation Guide
53-1002405-01

Brocade ServerIron ADX Installation Guide 1
53-1002405-01
Chapter
1
ProductOverview
ServerIronADXfixedconfigurationdevices
This section describes the ServerIron ADX 1000 and ServerIron ADX 1000F fixed configuration
devices..
ServerIronADX1000
Figure 1 shows the ServerIron ADX 1000 fixed configuration device for each model.
FIGURE1 ServerIronADX1000Chassis
ServerIron ADX 1000 is shipped in one of these base configurations:
•8 x 1 Gigabit Ethernet ports with 1 application core
•16 x 1 Gigabit Ethernet ports with 2 application cores
•16 x 1 Gigabit Ethernet ports with 4 applications cores
•16 x 1 Gigabit Ethernet ports and 2 x 10 Gigabit Ethernet ports with 4 Application Cores
•16 x 1 Gigabit Ethernet ports with 2 application cores and hardware SSL Acceleration
•16 x 1 Gigabit Ethernet ports with 4 applications cores and hardware SSL Acceleration
•16 x 1 Gigabit Ethernet ports and 2 x 10 Gigabit Ethernet ports with 4 Application Cores and
hardware SSL Acceleration
Each of these configurations corresponds to a base license. ServerIron ADX provides the ability for
On-Demand Upgrades which allows you to upgrade the features from any of the base license
configurations to the more advanced configurations. This is done by purchasing a license from
Brocade which enables more ServerIron ADX 1000 features.
ServerIron ADX 1000 basics (all models):
•1 RU form factor
•Two hot-pluggable AC or DC power supplies (one+one redundant)
By default, the system ships with one power supply.
•One hot-pluggable fan tray
•Front-to-back air cooling
Mgmt
Lnk
Act
Lnk
Act
12345678
Con
P1 P2 Fn 12 12
IN OUT
Aux Con
USB 1
910 11 12 13 14 15 16
Aux1 Aux2

2Brocade ServerIron ADX Installation Guide
53-1002405-01
ServerIron ADX chassis devices
1
ServerIronADX1000F
Figure 1 shows the ServerIron ADX 1000F fixed configuration device for each model.
FIGURE2 ServerIronADX1000FChassis
ServerIron ADX 1000F is available in these four configurations:
•ServerIron ADX 1008F-1: One Application Core, Eight 10/100/1000 Mbps Ethernet copper
ports, Eight 1 Gigabit Ethernet fiber SFP ports, and one AC power supply (Note: An equivalent
system with DC power instead is also orderable).
•ServerIron ADX 1016F-2: Two Application Cores, Eight 10/100/1000 Mbps Ethernet copper
ports, Sixteen 1 Gigabit Ethernet fiber SFP ports, and one AC power supply.
•ADX 1016F-4: Four Application Cores, Eight 10/100/1000 Mbps Ethernet copper ports,
Sixteen 1 Gigabit Ethernet fiber SFP ports, and one AC power supply.
•ADX 1216F-4: Four Application Cores, Eight 10/100/1000 Mbps Ethernet copper ports,
Sixteen 1 Gigabit Ethernet fiber SFP ports, Two 10 Gigabit Ethernet fiber SFP+ ports, and one
AC power supply.
The capacity-on-demand facilitates pay-as-you-grow with ServerIron ADX 1000F, and enables you to
add performance, ports and features (SSL, IPv6, GSLB and routing) through a simple
software-based license upgrade without requiring hardware replacement.
ServerIron ADX 1000F basics (all models):
•1 RU form factor
•Two hot-pluggable power supplies (one+one redundant)
By default, the system ships with one power supply.
•One hot-pluggable fan tray
•Front-to-back air cooling
•Optics modules (SFP and SFP+) are not included with any model
ServerIronADXchassisdevices
This section describes the ServerIron ADX 4000 and ServerIron ADX 10000 chassis devices. The
ServerIron ADX 8000 chassis device has been replaced by the ServerIron ADX 10000 chassis
device. Although no longer available for purchase, it is still supported by Brocade and is described
in Appendix B, “ServerIron ADX 8000”.
ServerIronADX4000
Figure 3 shows the ServerIron ADX 4000 chassis.
FIGURE3 ServerIronADX4000Chassis
12345678910 11 12 13 14 15 16 17 18 19 21
20 22 24
23 26
25
Mgmt
USB Aux1 Aux2
12
12
Con
Aux
In Out
Con
P1 P2 Fn

Brocade ServerIron ADX Installation Guide 3
53-1002405-01
ServerIron ADX chassis devices 1
ServerIron ADX 4000 chassis basics:
•4 RU form factor
•Two hot-pluggable AC or DC power supplies (one+one redundant)
One power supply is required, and one is optional for redundancy. By default, the system ships
with one power supply.
•One hot-pluggable fan tray with three fans
•Side-to-side air cooling - left-to-right
•Card slots to accommodate modules
A fully-loaded ServerIron ADX 4000 can accommodate the following components:
•Two Ethernet Interface Modules
•Two Application Services Modules (ASM)
•One Management Module (MM)
•One Switch Fabric Module (SFM)
•One fan tray
•Two AC or DC power supplies (one required, one redundant)
Slot ordering for ServerIron ADX 4000 is important. Refer to “Installing modules in ServerIron ADX
chassis devices” on page 21.
SI-12GC
SI-SFM
Lnk / Act Lnk / Act
SI-12GC
Lnk / Act Lnk / Act
100-240 VAC
48 VDC
SEE REAR LABEL
PS1 PS2
ASM1
ASM2
MM1
LC1
LC2
SF1
F
A
N
Console
Pwr
SI-MM Mgmt
USB
Aux1 Aux2 Aux
Console
Act
BP
In
Out
ASM
Console
Pwr
SI-ASM
1 2 3 4 5 6 7 8
Application Switch Module
BP
In
Out
ASM
Console
Pwr
SI-ASM
1 2 3 4 5 6 7 8
Application Switch Module
Pwr
Pwr
Pwr
2
1
12
11
2
1
12
11

4Brocade ServerIron ADX Installation Guide
53-1002405-01
ServerIron ADX chassis devices
1
ServerIronADX10000(ADX10K)chassis
Figure 4 shows the ServerIron ADX 10000 chassis.
FIGURE4 ServerIronADX10000Chassis
ServerIron ADX 10000 chassis basics:
•10RU form factor
•Four hot-pluggable AC or DC power supplies (two+two redundant)
Two power supplies are required, and two are optional for redundancy. By default, the system
ships with two power supplies.
•One hot-pluggable fan tray with six fans
•Front-to-Back air cooling -
•Card slots to accommodate modules
A fully-loaded ServerIron ADX 10000 can accommodate the following components:
•Four Ethernet Interface Modules
•Four Application Services Modules (ASM)
•Two Management Modules (MM)
•Two Switch Fabric Modules (SFM)
•One fan tray
Brocade ServerIron ADX 10000
rwP
elosnoC
MSA
PB 12345678
nI
tuO
eludoMhctiwSnoitacilppA
MSA-IS
rwP
elosnoC
MSA
PB 12345678
nI
tuO
eludoMhctiwSnoitacilppA
MSA-IS
rwP
MSA
PB 12345678
nI
tuO
eludoMhctiwSnoitacilppA
MSA-IS
rwP
elosnoC
MSA
PB 12345678
nI
tuO
eludoMhctiwSnoitacilppA
MSA-IS
MFS-IS
rwP
MFS-IS
rwP
CG21-IS
rwP
/knLtcA/knLtcA
1
2
11
21
CG21-IS
rwP
/knLtcA/knLtcA
1
2
11
21
CG21-IS
rwP
/knLtcA
1
2
11
21
CG21-IS
rwP
/knLtcA
1
2
11
21
AC OK DC OK ALM
SYSTEM
AC OK DC OK ALM
SYSTEM
AC OK DC OK ALM
SYSTEM
AC OK DC OK ALM
SYSTEM
Pwr
Pwr
Pwr
Pwr
Act Act
SI-MM
Console
Console
Console
USB
Mgmt
Mgmt
USB
Aux1 Aux1
Aux2
Aux2
Aux
Aux
Console
Console
SI-MM
/knLtcA
/knLtcA
Console
Console

Brocade ServerIron ADX Installation Guide 5
53-1002405-01
ServerIron ADX Chassis device modules 1
•Four AC or DC power supplies (two required, one or two redundant)
Slot ordering for ServerIron ADX 10000 is important. Refer to “Installing modules in ServerIron ADX
chassis devices” on page 21.
ServerIronADXChassisdevicemodules
The ServerIron ADX chassis devices accommodate the modules described in this section:
•“Ethernet interface modules”
•“Application Switch Module (ASM)”
•“Management Module (MM)”
•“Switch Fabric Module (SFM)”
Ethernetinterfacemodules
The following Ethernet interface modules are supported:
•4 x 10G XFP fiber
•12 x 1G copper
•12 x 1G SFP fiber
4x10GXFPFiber
Figure 5 shows the front panel of the 4 x 10G XFP fiber module.
FIGURE5 4x10GXFPFiberModularEthernetInterfaceModule

6Brocade ServerIron ADX Installation Guide
53-1002405-01
ServerIron ADX Chassis device modules
1
12x1GCopper
Figure 6 shows the front panel for the 12 x 1G copper module.
FIGURE6 12x1GCopperModularEthernetInterface Module
12x1GSFPFiber
Figure 7 shows the front panel for the 12 x 1G SFP fiber module.
FIGURE7 12x 1GSFPFiberModularEthernetInterfaceModule
ApplicationSwitchModule(ASM)
Figure 8 shows the Application Switch Module (ASM) front panel.
FIGURE8 ASMFrontPanel
NOTE
Starting with Brocade ServerIron ADX release 12.2.1, the label for the Application Switch Module
(ASM) is changed from 'SI-ASM8' to 'SI-ASM'. Note that both represent the same underlying
hardware. The number of available application cores in the ASM module can be verified from the
output of the show version and the show license commands.
SI-12GC Lnk / Act
Pwr
Lnk / Act
11
12
Lnk / Act
1
2
Lnk / Act
Pwr
11
12
Lnk / Act
BP
In
Out
ASM
Console
Pwr
SI-ASM
1 2 3 4 5 6 7 8
Application Switch Module

Brocade ServerIron ADX Installation Guide 7
53-1002405-01
ServerIron ADX Chassis device modules 1
ServerIron ADX 4000 systems accommodate up to two ASMs. ServerIron ADX 8000 and ServerIron
ADX 10000 systems accommodate up to four ASMs. Each ASM has the following features:
•Eight Application Cores (the number of application cores avaialable depends on the license
that is bound to the module)
•One front-panel DB9 console port for Application Core access
There are two versions of the ASM.
ASM4 – Available only with the ServerIron ADX 4000 bundle, the ASM4 has 4 of the available 8
Application Processors enabled. It will only work in a ServerIron ADX 4000 chassis and only in
a single ASM configuration. If an additional ASM4 module is installed, only the ASM4 module
installed in the ASM 1 slot will be accepted. If an ASM8 module is installed in a system with an
ASM4 module, the ASM4 will be rejected and the ASM8 module will be accepted by the
system. You can purchase an upgrade license to increase the capability of an ASM4 to that of
an ASM8. The ASM4 license is tied to the ASM module and not to the chassis. Consequently, a
license can be purchased to upgrade the ASM4 to use all eight available Application
Processors with all functionality and performance options enabled. With this license installed,
the ASM module functions and is recognized as an ASM8 module
ASM8 – All 8 Application processors are enabled on an ASM8 module. It can be installed in any
ServerIron ADX chassis configuration in any ASM designated slot.
ManagementModule(MM)
Figure 9 shows the Management Module (MM) front panel.
FIGURE9 MMFrontPanel
ServerIron ADX 4000 systems accommodate one MM. ServerIron ADX 8000 and ServerIron ADX
10000 systems accommodate up to two MMs. Each MM includes the following:
•Dual core management processor
•One dedicated out-of-band management port (10/100/1000 Ethernet)
•One front-accessible USB port
•One front-panel DB9 console port for access to the MM
•One optional hardware-based SSL processing module
NOTE
The auxiliary console port on the right and the ethernet ports labeled Aux1 & Aux2 are not
currently available. They are reserved for future use.
Console
Pwr
SI-MM
Mgmt
USB
Aux1 Aux2 Aux
Console
Act

8Brocade ServerIron ADX Installation Guide
53-1002405-01
ServerIron ADX Chassis device modules
1
SwitchFabricModule(SFM)
Figure 10 shows the Switch Fabric Module (SFM) front panel. One SFM is required for ServerIron
ADX 4000. Two are required for ServerIron ADX 8000 and ServerIron ADX 10000.
FIGURE10 SwitchFabricModuleFrontPanel
The front panel includes a LED that, when lit, indicates that the module is receiving power.
SSLExpansionModule
A ServerIron ADX management module can be upgraded to provide hardware-based, SSL
acceleration. This is available through installation of the SSL Expansion Module onto a ServerIron
ADX Management module. Figure 9 shows the Management Module (MM)
FIGURE11 SSLExpansionmoduleInstalledonServerIronADX management module
1ServerIronADXmanagement module 2 SSL Expansion module
Pwr
SI-SFM
2
1

Brocade ServerIron ADX Installation Guide 9
53-1002405-01
Power supplies 1
Powersupplies
This section describes the supported power supply configurations.
DANGER
The power supplies are hot swappable, which means they can be removed and replaced while
the ServerIron ADX chassis is powered on and running. However, Brocade recommends that you
disconnect a power supply from its power source before removing and replacing the supply. The
ServerIron ADX 4000, ServerIron ADX 8000 and ServerIron ADX 10000 chassis can be running
while a power supply is removed and replaced, but the power supply itself should not be
connected to a power source.
ServerIronADX1000andServerIronADX1000Fpowersupplies
ServerIron ADX 1000 and SServerIron ADX 1000F raccommodate up to two power supplies (AC or
DC) with one required and one redundant.
You install the power supplies (AC or DC) at the back of the chassis. Each power supply has one
LED on its faceplate to provide status. For more information about operation of the power supply
LED, refer to Table 2 on page 43. For power supply specifications, refer to “Power specifications”
on page 57.
ServerIronADXchassisdevicepowersupplies
ServerIron ADX 4000 accommodates up to two power supplies (AC or DC) with one required and
one redundant.
ServerIron ADX 8000 and ServerIron ADX 10000 accommodate up to four power supplies (AC or
DC) with two required and one or two redundant. Because power is supplied over a common power
bus, any power supply purchased in addition to the two required will provide backup for any supply
that fails. Equipping a ServerIron ADX 8000 or ServerIron ADX 10000 with two additional power
supplies provides full redundancy for both of the required power supplies.
For power supply specifications, refer to “Power specifications” on page 57.
You install the power supplies (AC or DC) in the slots along the bottom of the chassis (ServerIron
ADX 4000 or ServerIron ADX 8000) or along the right side of the chassis (ServerIron ADX 10000).
The installed power supplies provide power to all chassis components, sharing the workload
equally and reporting their status to the Management Module (MM). If the MM detects that one of
these power supplies has failed or overheated, the MM will redistribute the failed power supply
workload to the remaining power supplies.
Each power supply has three LEDs on its faceplate that provide status for the input power, output
power and notification of alarms sent. If the input power and output power LEDs are on (a steady
green), the power supply is providing power to the chassis components. For more information about
operation of the power supply LEDs, see the AC and DC power supply sections in Table 3 on
page 46. The power supplies are hot swappable, which means you can remove and replace them
without powering down the system.

10 Brocade ServerIron ADX Installation Guide
53-1002405-01
Cooling systems
1
NOTE
After a power supply is removed from a ServerIron ADX 4000, ServerIron ADX 8000 or ServerIron
ADX 10000 chassis, the software determines if there is enough power to power-on the interface
modules. If it determines that there is not enough power, some interface modules are powered off.
Coolingsystems
Upon system startup, the fans in ServerIron ADX run at medium speed, and the speed is changed
to low. The fans switch to high speed only if the temperature sensors detect a need for additional
cooling.
By default, ServerIron ADX polls the temperature sensor on each module every 60 seconds to get a
temperature reading. Depending on the temperature readings for the modules, the system can do
the following:
•Leave the fan speed as is
•Increase the fan speed
•Decrease the fan speed
•Shut down a module to prevent damage
If the temperature exceeds specified high temperature thresholds, the system generates a syslog
message and Simple Network Management Protocol (SNMP) trap. The system can also shut a
module down if the temperature exceeds the highest threshold. You can change default low and
high temperature thresholds for modules and fan speeds through software.
ServerIronADX1000andServerIronADX1000Fcoolingsystem
The ServerIron ADX 1000 and ServerIron ADX 1000F are equipped with a fan tray containing
variable-speed fans and fan controllers. Figure 12 shows how the fan assembly slides into the back
of the chassis.
FIGURE12 FanTrayfortheServerIronADX1000
