Introduction
Features
Package Contents
AT-HDMI-24M is a high performance HDMI™ Matrix with remote control. It offers you maxi-
mum convenience in HDMI™ signal distribution when you have multiple HDMI™ sources and
displays to connect together.
Each of the two HDMI™ sources can be directed to any one of the four outputs, so four dis-
plays can show 4 identical or 2 pairs of different sources at the same time. AT-HDMI-24M
provides a maximum of 8 possible connection scenarios between sources and displays. When
HDMI™ signal progresses through AT-HDMI-24M, it is re-timed, level compensated, phase
error corrected, and data jitter eliminated, so the output is a regenerated brand new HDMI™
signal that can run for another 25 meters and can be cascaded.
1. HDMI™ version 1.3, HDCP 1.1 and DVI 1.0 compliant.
2. HDMI™ input is compensated, clock / phase adjusted, and jitter eliminated so
the output is a well tuned standard HDMI™ signal.
3. Input source LED indicators on each output select.
4. Ideal for home theater integration, conference room and retail stores.
5. Compatible with all HDMI™ sources and displays.
6. Supports high resolution input/output:
PC: VGA, SVGA, XGA, SXGA and UXGA (1600X1200) &
HDTV: 480i, 576i, 480p, 576p, 1080i, and 1080p
7. RS-232 control.
8. IR remote control.
1. AT-HDMI-24M HDMI™ Matrix
2. 5VDC Power Supply Adaptor
3. Operation Manual
1

2
Operation Controls and Functions
4.1. Front Panel
1. Remote control sensor.
2. Power Switch & LED Indicator:
The LED will illuminate when the power is turned on.
3. Input Select/Indicators (A):
Press the “HDMI™ OUT A” button repeatedly to switch to your desired source, and the
LED will illuminate to indicate which input source is being selected, and routed to HDMI™
A display.
4. Input Select/Indicators (B):
Press the “HDMI™ OUT B” button repeatedly to switch to your desired source, and the
LED will illuminate to indicate which input source is being selected, and routed to HDMI™
B display.
5. Input Select/Indicators (C):
Press the “HDMI™ OUT C” button repeatedly to switch to your desired source, and the
LED will illuminate to indicate which input source is being selected, and routed to HDMI™
C display.
6. Input Select/Indicators (D):
Press the “HDMI™ OUT D” button repeatedly to switch to your desired source, and the
LED will illuminate to indicate which input source is being selected, and routed to HDMI™
D display.
1 5 6
Power
HDMI OUT
INPUT
1 2
INPUT
1 2
INPUT
1 2
HDMI OUT
INPUT
1 2
A B C D
AtlonA

2 3
4.2 Rear Panel
4.3 Remote Control
1. IR IN Socket:
Plug the IR extender sensor (optional) into the socket for IR extension control.
2. RS-232 Communication Port:
Connect to the COM port of your PC for the distant control over RS-232 channel.
3. HDMI™ outputs A and B:
Connect each of these output ports to the HDMI™ input of an HDMI™ display.
4. HDMI™ inputs 1 and 2:
Connect to the HDMI™ output of your source equipment such as DVD player or set-top-
box.
5. HDMI™ outputs C and D:
Connect each of these output ports to the HDMI™ input of an HDMI™ display.
6. Power:
Plug the 5VDC power supply into the unit and connect the adaptor to AC wall outlet.
1. Power:
Press the button to turn on/off the unit.
2. Input Select for HDMI™ OUT A:
Press 1 or 2 to select the desired input source for HDMI™ OUT
A.
3. Input Select for HDMI™ OUT B:
Press 1 or 2 to select the desired input source for HDMI™ OUT
B.
4. Input Select for HDMI™ OUT C:
Press 1 or 2 to select the desired input source for HDMI™ OUT
C.
5. Input Select for HDMI™ OUT D:
Press 1 or 2 to select the desired input source for HDMI™ OUT
D.
1346
2
5
A B 1
HDMI
INPUT 2
HDMI
OUTPUT
HDMI
OUTPUT
CD
RS-232
DC 5V
IR IN
OUTPUT
A
OUTPUT
D
OUTPUT
C
OUTPUT
B
POWER
1
2
3
4
5
6

4
4.4 RS-232 Protocol
4.4.1 Pin Denition
4.4.2 Commands
COMMAND ACTION
P0 Power Off (standby)
P1 Power On *
ST System Status *
VR Firmware Version
A1 Output A select Input1
A2 Output A select Input2
B1 Output B select Input1
B2 Output B select Input2
C1 Output C select Input1
C2 Output C select Input2
D1 Output D select Input1
D2 Output D select Input2
*RS-232 transmission format:
Baud Rate: 9600 bps
Data bit: 8 Bits
Parity: None
Stop Bit: 1 bit
AT-HDMI-42M Remote Control Console
PIN Denition PIN Denition
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC

4 5
DVD
PS3
HDTV 1 HDTV 3HDTV 2 HDTV 4
Specifications
Connection and Installation
5.1 General Specication
* Frequency bandwidth: 2.25Gbps (single link)
* HDMI™ v1.3
* Input/Output: 2-in to 4-out HDMI™ female ports
* 5V DC power supply
* Dimensions: 240 (W) x 165 (D) x 49 (H)mm
* Weight: version 1.35Kgs
INTPUT
PC VGA, SVGA, XGA, SXGA, UXGA
TV 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
OUTPUT
PC VGA, SVGA, XGA, SXGA, UXGA
TV 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
