The Brocade SilkWorm 3800 Enterprise Fibre
Channel Fabric Switch provides both 1 and
2 Gbit/sec interfaces and includes a wide range
of enhanced features to improve SAN security,
availability, performance, and manageability.
The Brocade®SilkWorm®3800
16-port, auto-sensing Fibre Channel
switch significantly increases
performance and functionality for
Storage Area Networks (SANs).
Based on third-generation Brocade
ASIC technology, the SilkWorm
3800 combines 1 Gbit/sec and
2 Gbit/sec Fibre Channel through-
put with new features that greatly
enhance switch operation.As a
result, organizations can enjoy the
advantages of higher security,
availability, and performance, as well
as centralized data management.
Designed for enterprise environments,
the SilkWorm 3800 integrates a
variety of high-availability hardware
and software features.The SilkWorm
3800 is especially useful for organi-
zations that want to upgrade their
existing environment with minimal
disruption.The switch is fully inter-
operable with existing SilkWorm
1000 and 2000 series switches—
enabling a core-to-edge architecture
that facilitates expansion, higher
performance, and higher availability.
When added to existing fabrics,
the SilkWorm 3800 automatically
assigns individual switch addresses,
establishes frame routes, and configures
the internal name server.
HIGH AVAILABILITY THROUGHOUT
THE FABRIC
The SilkWorm 3800 is designed to
provide high-availability switching at
the core of small-to-medium-sized
storage networks.The core-to-edge
SAN model features high availability
for the entire fabric through redundant
network paths. Combining the
proven reliability of the SilkWorm
family with a wide range of Advanced
Fabric Services, the SilkWorm 3800
provides a SAN fabric capable of
delivering overall system availability
greater than 99.999 percent—the
“five nines” of availability.
In addition, Brocade Fabric Shortest
Path First (FSPF) enables the fabric
to automatically isolate problems
and reroute traffic around failed
links onto alternate paths—ensuring
availability for mission-critical
enterprise applications.
Improved Security, Availability,
Performance, and Manageability
Highlights
• Provides 16 ports in a single
1U enclosure with auto-sensing
1 Gbit/sec and 2 Gbit/sec interfaces
for seamless integration with
existing fabrics
• Includes Brocade Advanced
Fabric Services that increase
security through hardware-enforced
WWN zoning
• Meets high-availability requirements
with redundant, hot-pluggable
components, automatic path
rerouting, and extensive diagnostics
• Employs Brocade Inter-Switch Link
(ISL) Trunking to create an 8 Gbit/sec
data path between switches for
higher performance
• Protects investments through
backward and forward compatibility
with Brocade SilkWorm Fibre
Channel switches
SILKWORM 3800
SILKWORM SWITCH FAMILY

INDUSTRY-LEADING PERFORMANCE
The SilkWorm 3800 provides high perform-
ance with all ports capable of operating at
1 and 2 Gbit/sec (full-duplex) to enable
32 Gbit/sec of uncongested switch through-
put.Auto-sensing and speed matching of
1 and 2 Gbit/sec traffic ensures interoper-
ability between current 1 Gbit/sec devices
and next-generation 2 Gbit/sec devices.
With the Brocade Extended Fabrics feature
and Dense Wave Division Multiplexing
(DWDM) technology, storage networks
can span up to 100 km over Metropolitan
Area Networks (MANs) at full bandwidth—
significantly increasing the level of disaster
protection to help ensure the highest level
of business continuance.
To provide even higher performance—
as well as simplified management—Brocade
ISL Trunking combines up to four ISLs
between a pair of switches into a single,
logical high-speed trunk running at up to
8 Gbit/sec (see Figure 1).
INTELLIGENCE WITHIN THE SWITCH
To improve security and manageability,
a wire-speed Frame Filtering engine is
built directly into the SilkWorm 3800
third-generation ASIC technology.
This design enables new capabilities such
as fabric zoning based on World Wide
Name (WWN) to be enforced through
hardware for greater security. Organizations
can improve end-to-end performance
analysis by measuring resource utilization
on a fabric-wide basis.They can track
data all the way from the source device to
the destination device to quickly identify
bottlenecks, optimize fabric configurations,
and plan for when additional capacity will
be required.
OPEN SAN MANAGEMENT
The SilkWorm 3800 simplifies management
by networking core and edge switches
with Brocade Fabric OS, an embedded
real-time operating system.This approach
enables heterogeneous device connectivity,
automatic discovery, data routing, and
scalable connectivity. In addition, the
Brocade Fabric Access API provides critical
functions for integrating applications
within the SAN environment.The API
layer is currently used by more than 50
independent software vendors to develop
feature-rich management applications that
leverage the distributed intelligence in
Brocade SANs.
SILKWORM 3800
INCREASES
PERFORMANCE

SEAMLESS UPGRADES,
COST-EFFECTIVE MIGRATION,
AND INVESTMENT PROTECTION
To help protect existing investments,
the SilkWorm 3800 provides a seamless
upgrade path along with backward
and forward compatibility with
SilkWorm entry, midrange, and core
fabric switch offerings.
The SilkWorm 3800 integrates with
heterogeneous environments that
include multiple operating systems
such as Windows 2000 and NT,
UNIX, Linux, HPUX, Solaris, AIX,
and others. As a result, organizations
have the flexibility to build cost-effi-
cient, and easy-to-manage enterprise
SAN fabrics.These capabilities make the
SilkWorm 3800 ideal for applications
such as LAN-free backup, server and
storage consolidation, remote mirror-
ing, and data replication.
A NEW LEVEL OF SAN SECURITY
Brocade Advanced Zoning logically
groups a SAN fabric into an unlimited
number of secure private SANs
(zones) to ensure that devices can
access only their authorized storage
resources. Zoning is enabled by the
wire-speed Frame Filtering feature of
the third-generation Brocade ASIC,
which filters and analyzes frames based
on the content of fields in the first
64 bytes of the header. Organizations
can specify hardware-enforced zones
by WWNs on the SilkWorm 3800,
simplifying administration while
providing the highest level of security
to control data access.
SUPERIOR RELIABILITY, AVAILABILITY,
AND SERVICEABILITY
Advanced SilkWorm 3800 reliability
features include the following:
• Highly reliable components
and continuous monitoring of
environmental conditions help
reduce service costs.
• Power-On Self-Test (POST)
and online diagnostics enable
administrators to monitor and test
ports while the switch is operating.
• Per-port statistics help administrators
diagnose and isolate problem ports
without disrupting switch operations.
INTELLIGENT SAN MONITORING
To simplify SAN monitoring and
maintenance, the SilkWorm 3800
provides the following functions:
• Fabric OS enables value-added
Brocade SAN monitoring and
management applications.
• Industry-standard Management
Information Base (MIB) support
enables Simple Network
Management Protocol (SNMP)-
based interfaces to access switch
information.
• Administrators can manage switch
configurations by using a command
line interface, a Web-based Java
application, or a centralized,
multifabric management application.
• Self-learning features enable the
fabric to automatically discover
and register host server and
storage devices.
MAXIMIZING SAN INVESTMENTS
Brocade and its partners offer
complete SAN solutions to meet a
wide range of technology and business
requirements.These solutions include
education and training, support,
service, and professional services to
help optimize SAN investments.
For more information, contact an
authorized Brocade sales partner or
visit www.brocade.com.
SILKWORM SWITCH FAMILY
Figure 1.
ISL Trunking groups multiple ISLs to enable
high-speed data traffic
8 Gbit/sec

Corporate Headquarters
San Jose, CA USA
T: [phone]
[e-mail]
European Headquarters
Geneva, Switzerland
T: [phone]
[e-mail]
Asia Pacific Headquarters
Tokyo, Japan
T: [phone]
[e-mail]
Latin America Headquarters
Miami, FL USA
T: [phone]
[e-mail]
Systems Architecture
Fibre Channel ports 16 universal ports
Scalability Full fabric architecture with 239 switches maximum
Certified maximum 32 switches, 7 hops; larger fabrics certified
as required
Interoperability SilkWorm II, SilkWorm Express, or any
SilkWorm 2000 family switch
Performance 2.125 Gbit/sec line speed, full duplex
Aggregate bandwidth 64 Gbit/sec end-to-end
Fabric latency <2 μ sec. with no contention, cut-through routing
Maximum frame size 2112-byte payload
Classes of service Class 2, Class 3, Class F (inter-switch frames)
Port types FL_Port, F_Port, and E_Port; self-discovery based on
switch type (U_Port)
Data traffic types Fabric switches support unicast, multicast
(256 groups), and broadcast
Media types Hot-pluggable, industry-standard Small Form-Factor
Pluggable (SFP), LC connector; Short-Wavelength
Laser (SWL); Long-Wavelength Laser (LWL);
Extended Long-Wavelength Laser (ELWL); distance
depends on fiber optic cable and port speed)
Laser Short-wave up to 500 m (1,640 ft); long-wave up
to 10 km (6.2 mi)
Fabric services Simple Name Server, Registered State Change
Notification (RSCN), Alias Server (multicast);
and Brocade Advanced Zoning
Optional fabric services include: QuickLoop,
Fabric Watch, Extended Fabrics, Advanced
Performance Monitoring, ISL Trunking,
and Remote Switch
Options Redundant power supply
Management
Supported software Telnet, SNMP, WEB TOOLS,
Fabric Manager (optional)
Management access 10/100 Ethernet (RJ-45), serial port
Diagnostics POST and embedded online/offline diagnostics
Mechanical Specifications
Enclosure Back-to-front airflow, power from rear
1U, 19-in.–EIA compliant
Size Depth: 62.23 cm (24.50 in)
Height: 4.34 cm (1.71 in.)
Width: 42.86 cm (16.87 in.)
Weight Single power supply weight: 11.59 kg (25.6 lbs)
Double power supply weight: 12.94 kg (28.5 lbs)
Environment
Temperature Operating: 10° C to 40° C (50° F to 104° F)
Nonoperating: -25° C to 70° C (-13° F to 158° F)
Humidity Operating: 20% to 85% noncondensing at
40° C (104° F)
Altitude Up to 3,000 m (9,800 ft)
Shock Operating: 80 g's, 2.5 ms duration, half-sine
Vibration Operating: 0.5 g sine, 0.4 grms random, 5-500 Hz
Non-operating: 2.0 g‘s sine, 1.1 grms random,
5-500 Hz
Power
AC Input Nominal: 100 to 240 VAC, 2.5 A
Frequency 47 to 63 Hz
SILKWORM 3800
© 2003 Brocade Communications Systems, Inc. All Rights Reserved. 03/03 GA-DS-135-02
Brocade, the Brocade B weave logo, Secure Fabric OS, and SilkWorm are registered trademarks of Brocade Communications Systems, Inc., in the United States and/or
in other countries. All other brands, products, or service names are or may be trademarks or service marks of, and are used to identify, products or services of their
respective owners.
Notice:This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning any equipment, equipment
feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to this document at any time, without notice, and assumes no
responsibility for its use.This informational document describes features that may not be currently available. Contact a Brocade sales office for information on
feature and product availability. Export of technical data contained in this document may require an export license from the United States government.
FIBRE CHANNEL STANDARDS AND REVISIONS
FC-FG Rev 3.5 FC-AL Rev. 4.5 FC-FLA Rev 2.7 FC-PLDA Rev 2.1 FC-VI Rev 1.5
FC-PH-2 Rev 7.4 FC-GS-2 Rev 5.3 FC-PH-3 Rev 9.4 FC-SW Rev 3.3 IPFC RFC 2625
FC-AL-2 Rev. 7.0 FC-PH Rev 4.3
