Brocade Communications Systems VDX 6940 Series Manual

53-1003495-02
25 June 2015
Brocade VDX 6940
Hardware Installation Guide

© 2015, Brocade Communications Systems, Inc. All Rights Reserved.
ADX, Brocade, Brocade Assurance, the B-wing symbol, DCX, Fabric OS, HyperEdge, ICX, MLX, MyBrocade, OpenScript, The Effortless
Network, VCS, VDX, Vplane, and Vyatta are registered trademarks, and Fabric Vision and vADX are trademarks of Brocade
Communications Systems, Inc., in the United States and/or in other countries. Other brands, products, or service names mentioned may be
trademarks of others.
Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning any
equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to this document
at any time, without notice, and assumes no responsibility for its use. This informational document describes features that may not be
currently available. Contact a Brocade sales office for information on feature and product availability. Export of technical data contained in
this document may require an export license from the United States government.
The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the
accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that
accompany it.
The product described by this document may contain open source software covered by the GNU General Public License or other open
source license agreements. To find out which open source software is included in Brocade products, view the licensing terms applicable to
the open source software, and obtain a copy of the programming source code, please visit http://www.brocade.com/support/oscd.

Contents
Preface.....................................................................................................................................7
Document conventions......................................................................................7
Text formatting conventions.................................................................. 7
Command syntax conventions.............................................................. 7
Notes, cautions, and warnings.............................................................. 8
Brocade resources............................................................................................ 9
Contacting Brocade Technical Support.............................................................9
Document feedback........................................................................................ 10
About This Document.............................................................................................................. 11
Supported hardware and software.................................................................. 11
Fan assemblies and power supplies................................................... 11
Rack mount kits...................................................................................12
What's new in this document...........................................................................13
Device Overview......................................................................................................................15
Hardware features...........................................................................................15
4x10 GbE breakout mode support...................................................... 15
Brocade trunking support.................................................................... 16
Supported transceivers....................................................................... 17
License support...................................................................................18
Example deployments.........................................................................18
Hardware components.................................................................................... 21
Port-side view......................................................................................22
Non-port-side views............................................................................ 24
Port numbering....................................................................................27
Device Installation.................................................................................................................. 29
Items included with the device........................................................................ 29
Site preparation and installation requirements................................................29
Items required for the installation........................................................ 30
Power precautions.............................................................................. 30
Environmental precautions..................................................................31
EIA rack considerations...................................................................... 31
Recommendations for cable management......................................... 32
Providing power to the device............................................................. 32
Rack installation.............................................................................................. 38
Universal Four-Post Rack Kit Installation Procedure...................................... 39
Contents..............................................................................................39
Introduction......................................................................................... 39
Installation requirements..................................................................... 39
Lifting requirements.............................................................................40
Tool requirements and parts list..........................................................40
Installation procedure for flush-front mounting....................................42
Installation procedure for flush-rear (recessed) mounting...................47
Universal Two-Post Rack Kit Installation Procedure.......................................52
Contents..............................................................................................52
Brocade VDX 6940 Hardware Installation Guide 3
53-1003495-02

Installation requirements...................................................................53
Tool requirements and parts list........................................................53
Installation procedure for flush mounting.......................................... 54
Installation procedure for mid-mounting the switch...........................58
Standalone installation .................................................................................62
Verifying operation........................................................................................ 63
Initial Configuration.............................................................................................................. 65
Configuration overview..................................................................................65
Establishing a serial connection....................................................................65
Assigning permanent passwords ................................................................. 66
Changing the default account passwords ........................................ 66
Configuring the device IP address................................................................ 67
Using DHCP to set the IP address....................................................67
Setting a static IP address................................................................ 67
Stateless IPv6 autoconfiguration...................................................... 68
Setting stateless IPv6 autoconfiguration...........................................68
Changing the RBridge ID.............................................................................. 68
Changing the VCS ID....................................................................................69
Setting the date and time ............................................................................. 70
Time zones........................................................................................70
Time synchronization........................................................................ 70
Synchronizing local time using NTP..................................................70
Setting the clock (date and time) manually....................................... 71
Setting the time zone........................................................................ 71
Network device connections......................................................................... 71
Ethernet or Fast Ethernet hubs.........................................................72
Workstations, servers, or routers...................................................... 72
Network device..................................................................................72
Testing connectivity...........................................................................72
Operation............................................................................................................................. 73
Interpreting LED activity................................................................................73
LED locations....................................................................................73
Port-side LED patterns......................................................................76
Non-port-side LED patterns for VDX 6940-36Q................................78
Non-port-side LED patterns for VDX 6940-144S.............................. 79
POST and boot specifications.......................................................................81
POST................................................................................................ 81
Boot...................................................................................................81
Interpreting POST results..............................................................................82
Diagnostic tests.............................................................................................82
Device management..................................................................................... 83
Powering off the device.................................................................................83
Thermal operations....................................................................................... 83
Removal and Replacement Procedures................................................................................. 85
Before beginning replacement ..................................................................... 85
VDX 6940-36Q FRU replacement.................................................................86
Determining the need to replace a power supply..............................87
Time and items required to replace a power supply......................... 87
Power supply replacement................................................................87
Determining the need to replace a fan assembly..............................92
Time and items required to replace a fan assembly......................... 93
Replacing a fan assembly.................................................................93
4Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

VDX 6940-144S FRU replacement................................................................. 94
Determining the need to replace a power supply................................95
Time and items required to replace a power supply........................... 95
Power supply replacement..................................................................95
Determining the need to replace a fan assembly..............................101
Time and items required to replace a fan assembly......................... 101
Replacing a fan assembly................................................................. 101
QSFP transceiver removal and replacement................................................ 102
Removing a QSFP transceiver..........................................................102
Replacing a QSFP transceiver..........................................................103
SFP transceiver removal and replacement................................................... 103
Time and items required................................................................... 104
Removing a transceiver.................................................................... 104
Replacing a transceiver.....................................................................105
Brocade VDX 6940 Switch Technical Specifications.............................................................. 107
Regulatory Statements..........................................................................................................117
BSMI statement (Taiwan)..............................................................................117
Canadian requirements.................................................................................117
CE Statement................................................................................................117
China ROHS................................................................................................. 118
FCC warning (US only)................................................................................. 118
KCC statement (Republic of Korea)..............................................................118
VCCI statement.............................................................................................118
Germany....................................................................................................... 119
Cautions and Danger Notices................................................................................................121
Cautions........................................................................................................ 121
Danger notices.............................................................................................. 129
Index.................................................................................................................................... 133
Brocade VDX 6940 Hardware Installation Guide 5
53-1003495-02

6 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

Preface
● Document conventions......................................................................................................7
● Brocade resources............................................................................................................ 9
● Contacting Brocade Technical Support.............................................................................9
● Document feedback........................................................................................................ 10
Document conventions
The document conventions describe text formatting conventions, command syntax conventions, and
important notice formats used in Brocade technical documentation.
Text formatting conventions
Text formatting conventions such as boldface, italic, or Courier font may be used in the flow of the text
to highlight specific words or phrases.
Format Description
bold text Identifies command names
Identifies keywords and operands
Identifies the names of user-manipulated GUI elements
Identifies text to enter at the GUI
italic text Identifies emphasis
Identifies variables
Identifies document titles
Courier font Identifies CLI output
Identifies command syntax examples
Command syntax conventions
Bold and italic text identify command syntax components. Delimiters and operators define groupings of
parameters and their logical relationships.
Convention Description
bold text Identifies command names, keywords, and command options.
italic text Identifies a variable.
value In Fibre Channel products, a fixed value provided as input to a command
option is printed in plain text, for example, --show WWN.
Brocade VDX 6940 Hardware Installation Guide 7
53-1003495-02

Convention Description
[ ] Syntax components displayed within square brackets are optional.
Default responses to system prompts are enclosed in square brackets.
{ x | y | z } A choice of required parameters is enclosed in curly brackets separated by
vertical bars. You must select one of the options.
In Fibre Channel products, square brackets may be used instead for this
purpose.
x | yA vertical bar separates mutually exclusive elements.
< > Nonprinting characters, for example, passwords, are enclosed in angle
brackets.
... Repeat the previous element, for example, member[member...].
\Indicates a “soft” line break in command examples. If a backslash separates
two lines of a command input, enter the entire command at the prompt without
the backslash.
Notes, cautions, and warnings
Notes, cautions, and warning statements may be used in this document. They are listed in the order of
increasing severity of potential hazards.
NOTE
A Note provides a tip, guidance, or advice, emphasizes important information, or provides a reference
to related information.
ATTENTION
An Attention statement indicates a stronger note, for example, to alert you when traffic might be
interrupted or the device might reboot.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause
damage to hardware, firmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or
extremely hazardous to you. Safety labels are also attached directly to products to warn of
these conditions or situations.
Notes, cautions, and warnings
8 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

Brocade resources
Visit the Brocade website to locate related documentation for your product and additional Brocade
resources.
You can download additional publications supporting your product at www.brocade.com. Select the
Brocade Products tab to locate your product, then click the Brocade product name or image to open the
individual product page. The user manuals are available in the resources module at the bottom of the
page under the Documentation category.
To get up-to-the-minute information on Brocade products and resources, go to MyBrocade. You can
register at no cost to obtain a user ID and password.
Release notes are available on MyBrocade under Product Downloads.
White papers, online demonstrations, and data sheets are available through the Brocade website.
Contacting Brocade Technical Support
As a Brocade customer, you can contact Brocade Technical Support 24x7 online, by telephone, or by e-
mail. Brocade OEM customers contact their OEM/Solutions provider.
Brocade customers
For product support information and the latest information on contacting the Technical Assistance
Center, go to http://www.brocade.com/services-support/index.html.
If you have purchased Brocade product support directly from Brocade, use one of the following methods
to contact the Brocade Technical Assistance Center 24x7.
Online Telephone E-mail
Preferred method of contact for non-
urgent issues:
•My Cases through MyBrocade
•Software downloads and licensing
tools
•Knowledge Base
Required for Sev 1-Critical and Sev
2-High issues:
• Continental US: 1-800-752-8061
• Europe, Middle East, Africa, and
Asia Pacific: +800-AT FIBREE
([phone])
• For areas unable to access toll
free number: [phone]
•Toll-free numbers are available in
many countries.
[email protected]
Please include:
• Problem summary
• Serial number
• Installation details
• Environment description
Brocade OEM customers
If you have purchased Brocade product support from a Brocade OEM/Solution Provider, contact your
OEM/Solution Provider for all of your product support needs.
• OEM/Solution Providers are trained and certified by Brocade to support Brocade® products.
• Brocade provides backline support for issues that cannot be resolved by the OEM/Solution Provider.
Brocade resources
Brocade VDX 6940 Hardware Installation Guide 9
53-1003495-02

• Brocade Supplemental Support augments your existing OEM support contract, providing direct
access to Brocade expertise. For more information, contact Brocade or your OEM.
• For questions regarding service levels and response times, contact your OEM/Solution Provider.
Document feedback
To send feedback and report errors in the documentation you can use the feedback form posted with
the document or you can e-mail the documentation team.
Quality is our first concern at Brocade and we have made every effort to ensure the accuracy and
completeness of this document. However, if you find an error or an omission, or you think that a topic
needs further development, we want to hear from you. You can provide feedback in two ways:
• Through the online feedback form in the HTML documents posted on www.brocade.com.
• By sending your feedback to [email protected].
Provide the publication title, part number, and as much detail as possible, including the topic heading
and page number if applicable, as well as your suggestions for improvement.
Document feedback
10 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

About This Document
● Supported hardware and software.................................................................................. 11
● What's new in this document...........................................................................................13
Supported hardware and software
This document is applicable to the following devices and operating systems.
Device First supported OS
Brocade VDX 6940-36Q Network OS v6.0.0
Brocade VDX 6940-144S Network OS v6.0.1
The following tables provide information on supported Field Replaceable Units (FRUs).
Fan assemblies and power supplies
The following tables provide information on supported fan assemblies and power supplies.
Fan assemblies TABLE 1
Part number Short description Where used First supported
(OS)
Last supported
(OS)
Fan assemblies
XBR-FAN-40-F 40 MM nonport side
exhaust fan
Brocade VDX
6940-36Q
Network OS 6.0.0 Active
XBR-FAN-40-R 40 MM port-side
exhaust fan
Brocade VDX
6940-36Q
Network OS 6.0.0 Active
XBR-FAN-80-01-F 80 MM nonport side
exhaust fan
Brocade VDX
6940-144S
Network OS 6.0.1 Active
XBR-FAN-80-01-R 80 MM port side
exhaust fan
Brocade VDX
6940-144S
Network OS 6.0.1 Active
Brocade VDX 6940 Hardware Installation Guide 11
53-1003495-02

Power supplies TABLE 2
Part number Short description Where used First supported
(OS)
Last supported
(OS)
XBR-500WPSAC-01
-R
AC 500W power
supply, port side
exhaust
Brocade VDX
6940-36Q, Brocade
VDX 6740T
Network OS 6.0.0 Active
XBR-500WPSAC-01
-F
AC 500W power
supply, nonport side
exhaust
Brocade VDX
6940-36Q, Brocade
VDX 6740T
Network OS 6.0.0 Active
RPS9DC DC 500W power
supply, exhaust
Brocade VDX
6940-36Q
Network OS 6.0.0 Active
RPS9DC+1 DC 500W power
supply, intake
Brocade VDX
6940-36Q
Network OS 6.0.0 Active
XBR-1100WPSAC-F AC 1100W power
supply, nonport side
exhaust
Brocade VDX
6940-144S
Network OS 6.0.1 Active
XBR-1100WPSAC-R AC 1100W power
supply, port side
exhaust
Brocade VDX
6940-144S
Network OS 6.0.1 Active
XBR-1100WPSDC-0
1-F
DC 1100W power
supply, nonport side
exhaust
Brocade VDX
6940-144S Network OS 6.0.1 Active
XBR-1100WPSDC-0
1-R
DC 1100W power
supply, port side
exhaust
Brocade VDX
6940-144S Network OS 6.0.1 Active
Rack mount kits
The following table provides information on supported rack mount kits.
Rack mount kitsTABLE 3
Part number Short description Device where used First supported
(OS)
Last supported
(OS)
XBR-R000296 Universal four-post
rack kit
Brocade VDX
6940-144S and
Brocade VDX
6940-36Q
N/A Active
XBR-R000294 Universal two-post
rack kit
Brocade VDX
6940-144S and
Brocade VDX
6940-36Q
N/A Active
Rack mount kits
12 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

What's new in this document
This document has been updated to include the following new information:
• Details on the Brocade VDX 6940-144S throughout most sections of this guide.
• Universal Four-Post Rack Kit and Universal Two-Post Rack Kit Installation Procedures.
• NEBS-compliant grounding procedures using the two-hole ground lug.
What's new in this document
Brocade VDX 6940 Hardware Installation Guide 13
53-1003495-02

What's new in this document
14 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

Device Overview
● Hardware features...........................................................................................................15
● Hardware components.................................................................................................... 21
Hardware features
The following Brocade VDX 6940 devices extend VCS technology in a spine and leaf architecture:
• The Brocade VDX 6940-36Q provides up to 36 40 GbE quad small form-factor pluggable (QSFP)
ports for connecting devices in a VCS fabric. The base model of this 1U form-factor device contains
twenty-four 40 GbE ports. A single 40G Port Upgrade license can add 12 additional ports to provide
the full complement of 36 40 GbE ports. Each 40 GbE port can be reconfigured as four 10 GbE ports
in QSFP breakout mode to provide a total of 144 10 GbE ports for the device.
• The Brocade VDX 6940-144S provides up to 12 40 GbE quad small form-factor pluggable (QSFP)
ports and 96 fixed 10 GbE ports for connecting devices in a VCS fabric. The base model of this 2U
form-factor device contains 64 fixed 10 GbE base ports and no 40 GbE ports. Two 10G Port Upgrade
licenses can provide the full complement of 96 fixed 10 GbE ports in two 16-port increments. Two
40G Port Upgrade licenses provide up to 12 40 GbE ports in two six-port increments.
Multiple fan and power supply field replaceable units (FRUs) in these devices allow redundant operation
in the event of FRU failure.
A key feature of these devices is Brocade VCS™ technology, which includes virtual cluster switching, a
set of technologies that allows users to create flatter, virtualized, and converged data center networks.
VCS fabrics are scalable, permitting users to expand at their own pace, and simplified, allowing users to
manage the fabric as a single entity. VCS-based Ethernet fabrics are convergence-capable with
technologies such as Fibre Channel over Ethernet (FCoE) for storage.
4x10 GbE breakout mode support
Each 40 GbE port on the Brocade VDX 6940-36Q can be configured for breakout mode to provide four
10 GbE interfaces. The Brocade VDX 6940-144S does not support breakout mode at Network OS 6.0.1
release.
You can administer and operate the 10 GbE interfaces as any other SFP port. Optical and twinaxial
copper 4x10 GbE breakout cables provide a connection from the 40 GbE port to four 10 GbE SFP ports
on other devices. Breakout connections are primarily used for edge port connectivity, but can also
support ISL trunking with VDX 8770 and VDX 6740 platforms.
The 40 GbE ports support dynamic QSFP breakout configuration. For more information on configuring
breakout mode, refer to the Network OS Layer 2 Switching Configuration Guide.
For a information on QSFP transceivers that support 4x10 GbE breakout mode, refer to the online
matrices and data sheets referenced in Supported transceivers on page 17.
Brocade VDX 6940 Hardware Installation Guide 15
53-1003495-02

Brocade trunking support
Network OS supports Brocade trunks (hardware-based link aggregation groups, or LAGs). These
trunks are dynamically formed between two adjacent devices with connected interswitch link (ISL)
ports unless trunking is disabled on connecting ports. Traffic is evenly distributed along all links in a
trunk.
Brocade trunking is supported on the following port types:
• 10 GbE ports
• 40 GbE ports in 40 GbE mode
• 10 GbE interfaces when 4x10 GbE breakout mode is configured on 40 GbE ports. Note that 4x10
GbE breakout mode is only supported on the Brocade VDX 6940-36Q with Network OS 6.0.1.
Following are general limitations and considerations of this feature:
• Ports forming a trunk must be configured at the same speed as follows:
‐40 GbE ports configured in 40 GbE mode - 40 Gbps
‐10 GbE interfaces on 40 GbE ports configured in 4x10 GbE breakout mode - 10 Gbps. Note that
4x10 GbE breakout mode is only supported on the Brocade VDX 6940-36Q with Network OS
6.0.1.
‐10 GbE ports - 10 Gbps
• Ports forming a trunk must be in the same trunk group. Trunk groups are different for the Brocade
VDX 6940-36Q and Brocade VDX 6940-144S.
• Any port in a trunk group can belong to a specific trunk, but ports do not need to be contiguous. For
example, port 1, 2, and 7 can form a trunk with a remote device. If ports 3 and 4 are connected
later, they will form a separate trunk.
• The maximum number of ports that can form a trunk are as follows:
‐12 fixed 10 GbE ports
‐12 10 GbE interfaces on 40 GbE ports on Brocade VDX 6940-36Q in 4 x 10 GbE breakout mode.
‐Three 40 GbE ports (40 GbE mode)
• Trunking is not supported between Brocade VDX 6940 device 40 GbE ports and Brocade VDX
8770 devices when the 40 GbE ports are configured in 40 GbE mode. Trunking is supported on 40
GbE ports in 4x10 GbE breakout mode between the Brocade VDX 8770 and Brocade VDX
6940-36Q.
• 40 GbE and 10 GbE trunking is supported between Brocade Brocade VDX 6940 and Brocade VDX
6740 devices.
• MCAST LAG spraying is not supported on trunks.
• Standard 802.1ag LAG and Brocade vLAG functions are supported on fixed 10 GbE ports, 40 GbE
ports in 40 GbE mode, and on 10 GbE interfaces on 40 GbE ports when in 4x10 GbE breakout
mode. However, all ports in the LAG or vLAG must be configured at the same speed, 10 GbE or 40
GbE. If the port speeds do not match, the port will not be logically online and will fail to become a
member of the LAG or vLAG.
Ports forming a trunk must be in the same trunk group. The following tables show the port numbers
that belong to each trunk group for Brocade VDX 6940 devices. Colored labels attached above and
below ports on the port-side of the device designate ports that belong to the same trunk group.
Trunk groups in the Brocade VDX 6940-36QTABLE 4
Trunk group Color label by port GbE port number Port speeds
TG1 Blue 1 through 9 40 Gbps - 40 GbE mode
10 Gbps - 4x10 GbE breakout
mode
Brocade trunking support
16 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

Trunk groups in the Brocade VDX 6940-36Q (Continued)TABLE 4
Trunk group Color label by port GbE port number Port speeds
TG2 Yellow 10 through 18 40 Gbps - 40 GbE mode
10 Gbps - 4x10 GbE breakout
mode
TG3 Purple 19 through 27 40 Gbps - 40 GbE mode
10 Gbps - 4x10 GbE breakout
mode
TG4 Green 28 through 36 40 Gbps - 40 GbE mode
10 Gbps - 4x10 GbE breakout
mode
Trunk groups in the Brocade VDX 6940-144STABLE 5
Trunk group Color label by port GbE port number Port speeds
TG-1 Blue 1 through 24
61 through 72
10 Gbps
10 Gbps
TG-2 Yellow 25 through 48
73 through 84
10 Gbps
10 Gbps
TG-3 Green 85 through 96 10 Gbps
TG-3A Green 103 through 108 40 Gbps - 40 GbE mode
TG-4 Purple 49 through 60 10 Gbps
TG-4A
NOTE
Ports in this group
cannot be trunked
with TG-4 ports.
Purple 97 through 102 40 Gbps - 40 GbE mode
NOTE
For a diagram and information on Brocade VDX 6940 device port numbering, refer to VDX 6940-36Q
port numbering on page 27.
For more information on Brocade trunking and enabling and disabling trunking, refer to the "Configuring
Brocade VCS Fabrics" chapter in the Network OS Administration Guide.
Supported transceivers
For details on supported transceivers, refer to the following publications on www.brocade.com:
Supported transceivers
Brocade VDX 6940 Hardware Installation Guide 17
53-1003495-02

•Brocade VDX Transceiver Support Matrix.
•Brocade Fibre Channel Transceiver Support Matrix.
DANGER
All fiber-optic interfaces use Class 1 lasers.
DANGER
Use only optical transceivers that are qualified by Brocade Communications Systems, Inc. and
comply with the FDA Class 1 radiation performance requirements defined in 21 CFR
Subchapter I, and with IEC 825-2. Optical products that do not comply with these standards
might emit light that is hazardous to the eyes.
License support
Brocade VDX 6940-36Q supports devices the following licenses:
• 40 GbE Port Upgrade - Increases the number of 40 GbE ports provided in a base configuration. For
the Brocade VDX 6940-36Q, a single license increases the 24 ports enabled in a base configuration
to 36.
• FCoE Base - Enables FCoE functionality on the 10 GbE links formed when configuring 40 GbE
ports in 4x10 GbE breakout mode.
The Brocade VDX 6940-144S supports the following licenses:
• 40 GbE Port Upgrade - Increases the number of 40 GbE ports provided in a base configuration. For
the Brocade VDX 6940-144S, each license increases the 0 ports enabled in a base configuration to
12 in two 6-port increments.
• 10 GbE Port Upgrade - Increases the number of fixed 10 GbE ports provided in a base
configuration. For the Brocade VDX 6940-144S, each license increases the 64 ports enabled in a
base configuration to 96 in two 16-port increments.
• FCoE Base - Enables FCoE functionality on the fixed 10 GbE ports.
Additional licenses supported by Brocade VDX 6940 devices:
• Layer 3 - enables Layer 3 features.
• Advanced Services - Single license that provides a combination of FCoE Base and Layer 3 license
functionality.
For more information on these licenses, refer to the Network OS Software Licensing Guide.
Example deployments
Smaller data-center deployments can initially deploy the Brocade VDX 6940-36Q as spine devices
and Brocade VDX 6740 as leaf devices, and as the data center grows, easily transition to a
heterogeneous deployment using Brocade VDX 6940-144S, Brocade VDX 6940-36Q. and Brocade
VDX 6740 devices to provide a scalable solution.
Following are example deployments for the Brocade VDX 6940-36Q and Brocade VDX 6940-144S:
•Using the Brocade VDX 6940-36Q or Brocade VDX 6940-144S as a spine device in smaller VCS
deployments. The Brocade VDX 6940-36Q 40 GbE ports in 40 GbE mode can uplink to core
devices, such as the Brocade VDX 8770. 40 GbE ports configured in 4x10 GbE breakout mode to
provide 10 GbE links and the fixed 10 GbE ports ( Brocade VDX 6940-144S only) can downlink
through a leaf device, such as the Brocade VDX 6740, to edge nodes, such as servers.
License support
18 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02

FIGURE 1 Brocade VDX 6940 in smaller deployments
•Using the Brocade VDX 6940-144S as a spine device and Brocade VDX 6940-36Q as a leaf device
in medium-size VCS deployments. As a spine device, the Brocade VDX 6940-144S can uplink to a
core device, such as the Brocade VDX 8770, using its 40 GbE ports in 40 GbE mode. The fixed 10
GbE ports can downlink through a Brocade VDX 6940-36Q, functioning as a leaf device, to edge
nodes, such as servers.
Device Overview
Brocade VDX 6940 Hardware Installation Guide 19
53-1003495-02

FIGURE 2 Brocade VDX 6940 in medium deployments
•Using the Brocade VDX 6940-36Q or Brocade VDX 6940-144S as leaf devices in larger VCS
deployments. The Brocade VDX 6940 40 GbE ports can uplink to spine devices, such as the
Brocade VDX 8770. The Brocade VDX 6940-36Q40 GbE ports configured in 4x10 GbE breakout
mode to provide 10 GbE links and the fixed 10 GbE ports on the Brocade VDX 6940-144S can
downlink to edge nodes, such as servers.
Device Overview
20 Brocade VDX 6940 Hardware Installation Guide
53-1003495-02
