BROKIS Dome Nomad User manual

CM14132

DOME
Table light, Floor light
1x assembled light
1x pair cotton gloves
1x installation manual
1x charging cable
1x hex key size 6
1x wrench size 7
The manufacturer assumes no liability for
damage resulting from incorrect assembly.
When unpacking the light, do so with regard
for its material composition – the main
components are made of glass. Wear the
cotton gloves included with the light when
unpacking and assembling it.
The light must be charged before first use.
EXERCISE EXTRA CARE WHEN MOVING THE
LIGHT. THE LIGHT MUST BE SUPPORTED FROM
BENEATH AT ALL TIMES AND MUST NEVER BE
PICKED UP BY THE TOP RING ONLY. THE
MANUFACTURER WILL NOT ACCEPT DAMAGE
CLAIMS ARISING FROM INCORRECT
HANDLING.
INSTALLATION
MANUAL
COMPONENTS INCLUDED
WITH UNIT:
WARNING:
Installation time: 5 minutes / 1 person
BROKIS S.R.O.
ŠPANIELOVA 1315/25
163 00 PRAHA 6 - ŘEPY
CZECH REPUBLIC
ORG. ID 64940799
VAT ID CZ64940799
C 42174 MĚSTSKÝ SOUD
V PRAZE
TEL [phone]
[e-mail]
[e-mail]
WWW.BROKIS.CZ PAGE 2
Download

CLEANING THE GLASS:
BROKIS upholds only the highest possible quality standards. Prior to shipping, the light undergoes several
quality controls and stages of cleaning. Because transportation, storage, and the amount of time that passes
between packing at our plant and subsequent unpacking by the client can affect the light in different ways, we
strongly recommend cleaning it prior to assembly.
The glass must first be rinsed in warm water, and a dish detergent may be used to remove all foreign particles,
dust, and grease. Repeat the process if necessary and then dry the glass thoroughly with a paper towel.
Recommendation: Do not use mineral spirits, highly concentrated thinners, or other substances not intended for
use on glass surfaces. Do not use any cleaning agents containing silicone, as they may leave a film and attract
dust and smudges.
PRIOR TO SHIPPING, THE FUNCTIONALITY OF THE LIGHT AND ITS COMPONENTS ARE CHECKED THOROUGHLY.
THE MANUFACTURER ASSUMES NO LIABILITY FOR THE MISHANDLING OF PRODUCTS.
DOME
Table light, Floor light
INSTALLATION
MANUAL
BROKIS S.R.O.
ŠPANIELOVA 1315/25
163 00 PRAHA 6 - ŘEPY
CZECH REPUBLIC
ORG. ID 64940799
VAT ID CZ64940799
C 42174 MĚSTSKÝ SOUD
V PRAZE
TEL [phone]
[e-mail]
[e-mail]
WWW.BROKIS.CZ PAGE 3
Cleaning information

Place a finger on the side of the base to switch the light on and off or adjust the brightness.
SWITCHING THE LIGHT ON AND OFF / DIMMING
1.
PAGE 4

Prior to cleaning the internal parts, the light must be disconnected from all power sources.
Place the light on its side on a soft surface to prevent damage to the glass. Use the supplied size 6 hex key to remove the
M10 screw from the bottom of the light. Next, tilt the metal cover out and disconnect the ground wire. Thread the screw back
into the hole, turning it 3–4 times. In the next step, the screw will be used to hold the heat sink with light source in the
upright position.
CLEANING / DISASSEMBLING THE LIGHT AND REPLACING THE GLASS 1/3
2.
PAGE 5

Holding the centre screw firmly to prevent damage to the light, use the supplied size 7 wrench to remove the M4 nuts around
the circumference of the heat sink and then remove the stainless-steel ring. Do not let go of the screw!
CLEANING / DISASSEMBLING THE LIGHT AND REPLACING THE GLASS 2/3
3.
PAGE 6

Holding the heat sink with light source in the upright position, move it into the glass shade, turn it sideways 90 degrees, and
then pull it out through the indentations in the glass.
After cleaning, reassemble the light by following the steps in reverse order.
CLEANING / DISASSEMBLING THE LIGHT AND REPLACING THE GLASS 3/3
4.
PAGE 7

Charge the light by placing the magnetic connector of the charging cable on the light.
Charging is indicated by a blinking green diode, which changes to solid green when charging is complete.
Time to full charge: 6.5 hours
Battery life from full charge: 4.5 hours
Recommended charging adapter: 5V / 1.4A
CHARGING THE LIGHT
5.
PAGE 8
