Bromic Heating TUNGSTEN SMART-HEAT BH3130010-2 User manual

Version 1.0
Doc. T757.01_EN
TVRCL916A02F7BK7
TUNGSTEN SMART-HEAT™
WIRELESS ON/OFF CONTROL
BY BROMIC
USER MANUAL
IMPORTANT
READ THIS MANUAL CAREFULLY.
SEE INSIDE COVER FOR IMPORTANT
INFORMATION ABOUT THIS MANUAL.KEEP
INSTRUCTION WITH APPLIANCE FOR FUTURE
REFERENCE.
!

2www.bromicheating.com
!
IMPORTANT
This manual contains important information about the installation, and operation of Tungsten
Electric controller. Please pay close attention to the important safety information shown
throughout this instruction manual. Any safety information will be accompanied by the following
safety alert symbols:
DANGER, WARNING, IMPORTANT
• READ THIS MANUAL CAREFULLY before installing or
servicing this product.
• Improper installation or operation can result in death, severe
injury, or property damage.
• Use this controller only as described in this manual. Any other
use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons
• This controller is intended for fixed installation with 110 - 230
volt power supply.
• Installation MUST be carried out by a licensed and authorised
technician in accordance with local electrical codes.
• For Commercial Use Only
NOTE: IMPORTANT INSTRUCTIONS, SAVE THESE
INSTRUCTIONS
!
!
!
BROMIC HEATING
Head Office: 10 Phiney Place, Ingleburn, NSW, 2565, Australia
Telephone: [phone] Fax: [phone]
Email: [e-mail] Web: www.bromicheating.com
Note: Bromic Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification.
This Installation, operation and service manual may not be reproduced in any form with prior written consent from Bromic Heating.
Manufactured by Teleco Automation s.r.l. - Italy - www.telecoautomation.com
WARNING
• WARNING: The outputs are NOT protected against short circuits or extra-currents which can damage the electronic board.
Evaluate the characteristics of the connected loads and apply the appropriate safety devices to the power line.
• The radio signal reception of the device can be affected by the presence of electrical disturbances being transmitted by other
appliances working on the same frequency or if the product is shielded by metal parts.
• Do not use the remote in places where systems are sensitive to radio emissions.
• Do not keep or use the remote in places that are damp, where there is steam, high air humidity, dust or where it is exposed to
direct sunlight or similar environmental conditions.
• Do not drop the remote. This could damage or reduce the range of action of the remote.
• Do not use your nails to press remote buttons.
• Keep remote batteries out of reach of children.
• Call a doctor immediately if a battery is swallowed.
• See remote instruction manual for more details on the included remote.
!

3
www.bromicheating.com
CONTENTS
IMPORTANT NOTES & WARNINGS 4
PRODUCT OVERVIEW 5
INSTALLATION & OPERATION 6-7
TECHNICAL SPECIFICATIONS 7
TROUBLESHOOTING 7
WIRING DIAGRAM 8

4www.bromicheating.com
IMPORTANT NOTES AND WARNINGS
WARNING
• Read all instructions before installing or using this heater
• Use this controller only as described in this manual. Any other
use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons.
• Improper installation, adjustment, or alteration and failure to
follow the warnings and instructions in this manual could result in
severe personal injury, death or property damage.
• The manufacturer is not responsible for any damage that could
happen from improper use. The manufacturer emphasises that
this controller should be used in a responsible manner and that
all procedures, warnings, and safety instructions contained in this
booklet be followed strictly.
• The product must be fixed on surfaces which cannot be
damaged by the high temperature. It must be placed in a well
ventilated location. It cannot be hermetically closed. It must be
fixed vertically, with cable glands downward.
• The connection cables must be protected against any accidental
impacts, using proper pipes.
• This controller is not intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate controller where
it may fall into a bathtub or other water container.
• Do not install the controller directly near a bathtub, shower or
swimming pool. Any switches or controls must not be within
reach of a person in the bathtub, shower or swimming pool.
• Extreme caution is necessary when any controller is used by or
near children or invalids and whenever the controller or heater is
left operating and unattended.
• This controller is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Keep packaging materials out of reach of children
• Children and adults should be alerted to the hazards of
electrocution and should stay away to avoid serious personal injury
• Children should be carefully supervised when they are in the area
of the controller.
• Do not attempt to alter the controller in any manner.
• Do not paint any surface of the controller.
• Do not touch the controller with wet hands at any time.
• Do not use or store flammable materials near this appliance.
• Do not spray aerosols or flammable materials in the vicinity of the
controller while it is in operation
• Never operate the controller in an explosive environment such
as areas where petrol or other flammable liquids or vapours are
stored.
INSTALLATION
• IMPORTANT - Installation must be carried out by a licensed and
authorised person.
• The installer is to ensure that the requirements of the local authority,
local electrical installation code, municipal building codes, and any
other relevant statutory regulations are carried out.
• After unpacking, make sure the controller shows no signs of
visible damage or tampering. If the controller appears damaged,
contact the place of purchase for assistance.
• Remove transit protection before use.
• This appliance must only be used on a 110 - 230 Volt AC Single
Phase electricity supply.
• This controller is NOT intended to be installed on recreational
vehicles and/or boats.
• Do not run cord under carpeting. Do not cover with throw rugs,
runners or the like arrange cord away from traffic area and
where it will not be tripped over
• A controller has hot and arcing or sparking parts inside. Do not
use it in areas where gasoline, paint or flammable liquids are
used or stored.
• This Installation and Operation manual should not be removed
from the site of installation. Installer should leave manual with
the customer for future reference.
• Any guard or other protective device removed for servicing
(conducted by an authorised person) must be replaced before
operating the controller.
• If the controller has not been used, or will not be used, for a
long period of time, disconnect power supply
• For the disconnection from the power line, use an all-pole
switch with contacts having a dimension of at least 3,5mm.
MAINTENANCE/ REPAIR
• Installation and repair must be carried out by a qualified &
licenced service person only. The controller should be inspected
before use and at least annually serviced & inspected by a
qualified & licenced service person.
• Do not perform maintenance until controller has been turned
off and power disconnected.
• Check for damage to the controller regularly. If damage to
the appliance is suspected, discontinue use immediately and
contact the supplier or qualified person to repair.
• If the supply cord is damaged, it must be replaced by an
authorised and licenced person in order to avoid a hazard.
• At the end of this product’s useful life, it must not be disposed
of as domestic waste, but must be taken to a collection
centre for waste electrical and electronic equipment. It is the
user’s responsibility to dispose of this appliance through the
appropriate channels at the end of its useful life. Failure to do
so may incur the penalties established by laws governing waste
disposal. Proper differential collection and the subsequent
recycling, processing and environmentally compatible
disposal of waste equipment avoids unnecessary damage to
the environment and possible related health risks, and also
promotes recycling of the materials used in the appliance. For
further information on waste collection and disposal, contact
your local waste disposal service, or the place of purchase
ELECTRICAL CONNECTIONS
• All connections must be rated for a single-phase 110 - 230VAC
power supply, with an earth connection.
• Arrange all the necessary safety devices and use only materials
that comply with standard electrical installations.
• Signal and power voltage wiring (110 - 230Vac) must be
separated one from the other.
• The protective device (ln = 32A) must protect the building from
overcurrents and short circuit
• A readily accesible disconnect device shall be incorporated in
the building installation wiring.
• The cable must have a section properly rated according to the
load connected and nominal temperature range up to 90°C.
!

5
www.bromicheating.com
PRODUCT OVERVIEW & INSTALLATION
1 DESCRIPTION
The Wireless ON/OFF control is for resistive and infrared heaters. The controller allows the power output of the
heater to be turned on/off. The wireless control can be used with 110 - 230VAC supply voltages.
1.1FEATURES
• Controls TWO 3400W heaters at 230VAC (1500W at 110VAC) cos φ = 1.
• ON/OFF function with dual output control
1.2KIT CONTENTS
• Wireless controller enclosed in a protective box.
• 4-channel remote
2.1 INSTALLATION
Study the WIRING DIAGRAM at the end of this document before starting installation.
WARNING: Isolate mains before installing. Use only with a properly secured heater.
PLUG AND SUPPLY CORD: Use an appropriately rated plug and supply cord - check the power
requirements of the connected loads. Socket outlet used must be near the equipment.
OVERCURRENT DEVICE: The outputs are NOT protected against short circuits or extra-currents which
can damage the electronic board. Evaluate the characteristics of the connected loads and apply the
appropriate safety devices to the power line.
The wireless control must be mounted using the following guidelines:
• It must be fixed on surfaces which cannot be damaged by high temperature.
• It must be placed in a well-ventilated location.
• It must be fixed vertically, with cable glands downward.
• Connection cables must be protected against any accidental impacts, using proper pipes.
• Do not cover the product.
• Do not use or store flammable materials close to the product.
1. Open cover to the box.
2. Wire in power and heater as per the wiring diagram.
3. Power on the wireless control.
4. Program the wireless control as per ‘OPERATION’ section.
5. Refit cover to the box.
2.2 OPERATION
Before programming, select the output L1 or L2, using the switch as outlined in the ‘WIRING DIAGRAM’.
The following programming will be ONLY applied to the selected output.
It is possible to associate a single or double channel function to both of the outputs by repeating the procedure.
WARNING: The receiver automatically saves the setting 5 seconds after button release.
IMPORTANT: The included 4-channel remote functions as a 4 x single channel remote OR a 2 x double channel remote
(paired Ch1 with Ch2 and Ch3 with Ch4). Functions are:
Single Channel Functions – On/Off with the same button
Double Channel Functions – On with Ch1 or Ch3. Off with Ch2 or Ch4
!
!

ON
OFF
ON
OFF
CH1
CH2
CH3
CH4
P3
ON
OFF
ON
OFF
CH1
CH2
CH3
CH4
ON
OFF
ON
OFF
CH1
CH2
CH3
CH4
ON
OFF
ON
OFF
CH1
CH2
CH3
CH4
To be deleted
6www.bromicheating.com
OPERATION
2.2.1 Setting relay function - ON/OFF
1. Press the ‘SET’ button twice and hold it down until the ‘ON-OFF’ LED turns on.
2. Wait until the LED turns o to confirm the memorisation of the data.
Twice and hold
2.2.2 Programming of a double channel
1. Press the ‘MEM’ button two times and hold the button on the second time. There will be 2 beeps and followed by a
continuous sound.
2. While holding ‘MEM’ the button (during continuous sound), press the button on the remote that will be programmed.
The programming is confirmed by an intermittent sound.
Note: in case of commanding an output with TIMER function, it’s possible to stop the counter before the set time using
buttons CH2, CH4 or CH7.
2.2.3 Copying a function of remote to a new remote. See remote manual for detail on P3 button.
1. Press the P3 button inside the already programmed remote. The active receiver will sound continuously. If there is no
sound, the remote is not programmed into the receiver.
2. Within 5 seconds, press a button of the already programmed remote, relative to the function to copy. The sound will be
interrupted, and continue for another 5 seconds.
3. During the sound, press a button of the new remote that requires to be programmed. The programming is indicated by
an intermittent sound.
Twice and hold
Before starting select the output L1 or L2, using the switch (see picture at page 8). The following memorization/deletion will
be applied only to the selected output. Anyway it’s possible to associate a double channel to both of the output, repeating
the procedure.
Memorised New
Memorised
2.2.4 Deleting a double channel function from the receiver
1. Press the DEL button once and hold it down. There will be a slow and intermittent sound.
2. During the sound, press the button of the remote that will be deleted. The deletion is indicted by a continuous sound.
Once and hold

ON
OFF
ON
OFF
CH1
CH2
CH3
CH4
P3
7
www.bromicheating.com
OPERATION
WIRELESS CONTROLLER
Power Supply 110/230VAC, 31A
Max Output Power with resistive load 3400W each relay @ 230VAC
1500W each relay @ 110VAC
Reception Frequency 916MHz (AUS/US)
Operating Temperature Range -20/+50°C
Maximum Remotes Memorised 42
Dimensions 205 x 145 x 85mm
Protection Class IP54
Manufactured by Teleco Automation s.r.l. - Italy - www.telecoautomation.com
The manufacturer reserves the right to modify design features and technical data without notice.
PROBLEM POSSIBLE CAUSE REMEDY
Control box does not receive
signals from remote
No battery in remote Change/Replace with
CR2430 battery.
Control box memory full Delete a remote from control
box memory.
Remote not programmed
into control box
Program remote as per ‘2.2
OPERATION’ section.
All other Contact your dealer or quali-
fied technician.
TECHNICAL SPECIFICATION
TROUBLESHOOTING
2.2.5 Deleting all remotes
1. Press the DEL button two times and hold the DEL button on the second time until there will be a continuous sound after
a quick and intermittent sound.
2. Hearing the sound sequence above indicates that the whole memory of the receiver is deleted.
2.2.6 Deleting a remote from a remote. See remote manual for detail on P3 button.
1. Press the P3 button inside the remote three times. There will be slow and intermittent sound.
2. During the intermittent sound, press a button of the remote relative to the function to be deleted. The deletion is indi-
cated by a continuous sound.
2.3 RECOMMENDED PROGRAMMING
The recommended programming for the 4-channel remote is as follows:
• Ch1 & Ch2 to be used as a DOUBLE CHANNEL FUNCTION for output L1
• Ch3 & Ch4 to be used as a DOUBLE CHANNEL FUNCTION for output L2
Twice and hold
To be deleted
Memorised

L N L N
L N T T1 T2
LINE IN
(110/230Vac - 31A) OUT L1
(110/230Vac - 15A)
3400W max. @ 230Vac
1500W max. @ 110Vac
OUT L2
(110/230Vac - 15A)
3400W max. @ 230Vac
1500W max. @ 110Vac
GND
110-230Vac IN
L
GND
E
N
L
E
N
Out L1 ↑
Out L2 ↓
≤1.5KW (110Vac)
≤3.4KW (230Vac)
≤1.5KW (110Vac)
≤3.4KW (230Vac)
HOT, BLACK (120V)* / L
HOT, RED (120V)* / N
Notes:
-Neutral (N) is not used when using split-phase 220-240V.
-Each OUTPUT can be one of the following Bromic products;
-2000W/3000W heater (208Vac)
-2000W/3000W/3400W heater (240Vac)
-2 x Bromic Gas Heater (110Vac)
8www.bromicheating.com
WIRING DIAGRAM
Aerial
connection
seconds LED
minutes LED
hours LED
Switch for
output
selection
Mount the product vertically
with the cable glands downward
Box opening
Impulsive LED
ON/OFF LED
Section ≥1.5 mm
Section ≥4 mm
OUTPUT 2
OUTPUT 1
