TUNGSTEN SMART-HEAT™
WIRELESS ON/OFF CONTROL
BY BROMIC
USER MANUAL
Version 1.2 US

2 3
www.bromicheating.com www.bromicheating.com
!
IMPORTANT
This manual contains important information about the installation, and operation of Tungsten
Electric controller. Please pay close attention to the important safety information shown
throughout this instruction manual. Any safety information will be accompanied by the following
safety alert symbols:
DANGER, WARNING, IMPORTANT
• READ THIS MANUAL CAREFULLY before installing or
servicing this product.
• Improper installation or operation can result in death, severe
injury, or property damage.
• Use this controller only as described in this manual. Any other
use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons
• This controller is intended for fixed installation with 120 volt,
208 volt or 240 volt power supply.
• Installation MUST be carried out by a licensed and authorised
technician in accordance with local electrical codes.
• For Commercial Use Only
NOTE: IMPORTANT INSTRUCTIONS, SAVE THESE
INSTRUCTIONS
!
!
!
BROMIC HEATING
Head Office: 1 Suttor Street, Silverwater, Sydney, NSW 2128 Australia
Telephone: [phone] (within Australia) or [phone] (from overseas) Fax: [phone]
Email: [email protected] Web: www.bromicheating.com
Note: Bromic Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification.
This Installation, operation and service manual may not be reproduced in any form with prior written consent from Bromic Heating.
CONTENTS
IMPORTANT NOTES & WARNINGS 4
PRODUCT OVERVIEW 5
INSTALLATION & OPERATION 6-8
TECHNICAL SPECIFICATIONS 8
TROUBLESHOOTING 8
WIRING DIAGRAM 9
WARNING
• WARNING: The outputs are NOT protected against short circuits or extra-currents which can damage the electronic board.
Evaluate the characteristics of the connected loads and apply the appropriate safety devices to the power line.
• The radio signal reception of the device can be affected by the presence of electrical disturbances being transmitted by other
appliances working on the same frequency or if the product is shielded by metal parts.
• Do not use the remote in places where systems are sensitive to radio emissions.
• Do not keep or use the manual remote in places that are damp, where there is steam, high air humidity, dust or where it is
exposed to direct sunlight or similar environmental conditions.
• Do not drop the remote. This could damage or reduce the range of action of the remote.
• Do not use your nails to press remote buttons.
• Keep remote batteries out of reach of children.
• Call a doctor immediately if a battery is swallowed.
• See remote instruction manual for more details on the included remote.
!

4 5
www.bromicheating.com www.bromicheating.com
IMPORTANT NOTES AND WARNINGS PRODUCT OVERVIEW & INSTALLATION
1 DESCRIPTION
The Wireless ON/OFF control is for resistive and infrared heaters. The controller allows the power output of the
heater to be turned on/off, impulsive or timer controlled. The wireless control can be used with 120, 208 and 240VAC
supply voltages.
1.1FEATURES
• Controls TWO 3000W heaters at 230VAC (1500W at 110VAC).
• Programmable relay functions: ON/OFF, impulsive and timer controlled up to 8hours, 59minutes and 59seconds.
1.2KIT CONTENTS
• Wireless controller enclosed in a protective box.
• 4-channel remote
2.1 INSTALLATION
Study the WIRING DIAGRAM at the end of this document before starting installation.
WARNING: Isolate mains before installing. Use only on with a properly secured heater.
PLUG AND SUPPLY CORD: Use an appropriately rated plug and supply cord - check the power
requirements of the connected loads. Socket outlet used must be near the equipment.
OVERCURRENT DEVICE: The outputs are NOT protected against short circuits or extra-currents which
can damage the electronic board. Evaluate the characteristics of the connected loads and apply the
appropriate safety devices to the power line.
The wireless control must be mounted using the following guidelines:
• It must be fixed on surfaces which cannot be damaged by high temperature.
• It must be placed in a well-ventilated location.
• It must be fixed vertically, with cable glands downward.
• Connection cables must be protected against any accidental impacts, using proper pipes.
• Do cover the product.
• Do not use or store flammable materials close to the product.
1. Open cover to the box.
2. Wire in power and heater as per the wiring diagram.
3. Power on the wireless control.
4. Program the wireless control as per ‘OPERATION’ section.
5. Refit cover to the box.
2.2 OPERATION
Before programming, select the output L1 or L2, using the switch as outlined in the ‘WIRING DIAGRAM’.
The following programming will be ONLY applied to the selected output.
It is possible to associate a single or double channel function to both of the outputs by repeating the procedure.
WARNING: The receiver automatically saves the setting 5 seconds after button release.
IMPORTANT: The included 4-channel remote functions as a 4 x single channel remote OR a 2 x double channel remote
(paired Ch1 with Ch2 and Ch3 with Ch4). Functions are:
Single Channel Functions – On/Off with the same button
Double Channel Functions – On with Ch1 or Ch3. Off with Ch2 or Ch4
!
!
WARNING
• Read all instructions before installing or using this heater
• Use this controller only as described in this manual. Any other
use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons.
• Improper installation, adjustment, or alteration and failure to
follow the warnings and instructions in this manual could result
in severe personal injury, death or property damage.
• The manufacturer is not responsible for any damage that could
happen from improper use. The manufacturer emphasises that
this controller should be used in a responsible manner and that
all procedures, warnings, and safety instructions contained in
this booklet be followed strictly.
• This controller is not intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate controller
where it may fall into a bathtub or other water container.
• Do not install the controller directly near a bathtub, shower or
swimming pool. Any switches or controls must not be within
reach of a person in the bathtub, shower or swimming pool.
• Extreme caution is necessary when any controller is used by or
near children or invalids and whenever the controller or heater
is left operating and unattended.
• This controller is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• Keep packaging materials out of reach of children
• Children and adults should be alerted to the hazards of
electrocution and should stay away to avoid serious personal
injury
• Children should be carefully supervised when they are in the
area of the controller.
• Do not attempt to alter the controller in any manner.
• Do not paint any surface of the controller.
• Do not touch the controller with wet hands at any time.
• Do not use or store flammable materials near this appliance.
• Do not spray aerosols or flammable materials in the vicinity of
the controller while it is in operation
• Never operate the controller in an explosive environment such
as areas where petrol or other flammable liquids or vapours are
stored.
INSTALLATION
• IMPORTANT - Installation must be carried out by a licensed and
authorised person.
• The installer is to ensure that the requirements of the local
authority, local electrical installation code, municipal building
codes, and any other relevant statutory regulations are carried
out.
• After unpacking, make sure the controller shows no signs
of visible damage or tampering. If the controller appears
damaged, contact the place of purchase for assistance.
• Remove transit protection before use.
• This appliance must only be used on a 120, 208 or 240 Volt AC
Single Phase electricity supply.
• This controller is NOT intended to be installed on recreational
vehicles and/or boats.
• Do not run cord under carpeting. Do not cover with throw rugs,
runners or the like arrange cord away from traffic area and
where it will not be tripped over
• A controller has hot and arcing or sparking parts inside. Do not
use it in areas where gasoline, paint or flammable liquids are
used or stored.
• This Installation and Operation manual should not be removed
from the site of installation. Installer should leave manual with
the customer for future reference.
• Any guard or other protective device removed for servicing
(conducted by an authorised person) must be replaced before
operating the controller.
• If the controller has not been used, or will not be used, for a
long period of time, disconnect power supply
• A means for disconnection of the controller must be
incorporated in the fixed wiring according to the local electrical
codes.
MAINTENANCE/ REPAIR
• Installation and repair must be carried out by a qualified &
licenced service person only. The controller should be inspected
before use and at least annually serviced & inspected by a
qualified & licenced service person.
• Do not perform maintenance until controller has been turned
off and power disconnected.
• Check for damage to the controller regularly. If damage to
the appliance is suspected, discontinue use immediately and
contact the supplier or qualified person to repair.
• If the supply cord is damaged, it must be replaced by an
authorised and licenced person in order to avoid a hazard.
• At the end of this product’s useful life, it must not be disposed
of as domestic waste, but must be taken to a collection
centre for waste electrical and electronic equipment. It is the
user’s responsibility to dispose of this appliance through the
appropriate channels at the end of its useful life. Failure to do
so may incur the penalties established by laws governing waste
disposal. Proper differential collection and the subsequent
recycling, processing and environmentally compatible
disposal of waste equipment avoids unnecessary damage to
the environment and possible related health risks, and also
promotes recycling of the materials used in the appliance. For
further information on waste collection and disposal, contact
your local waste disposal service, or the place of purchase
ELECTRICAL CONNECTIONS
• All connections must be rated for a single-phase 120/240VAC
power supply, with an earth connection.
• Arrange all the necessary safety devices and use only materials
that comply with standard electrical installations.
• The cable must have a section properly rated according to the
load connected and nominal temperature range up to 90°C.
!

6 7
www.bromicheating.com www.bromicheating.com
OPERATION
OPERATION
IMPULSE FUNCTION
Long press the ‘SET’ button once and hold it down until
the ‘IMP’ LED turns on. Wait until the LED turns o to
confirm the memorisation of the data.
ON/OFF Function
Long press the ‘SET’ button twice and hold it down until
the ‘ON-OFF’ LED turns on. Wait until the LED turns o
to confirm the memorisation of the data.
TIMER Function
Setting the seconds (1 – 59)
The starting value of the seconds is 1.
a) Long press the ‘SET’ button three times – the ‘SEC’
LED will turn on.
b) Adjust the seconds by increasing with ‘MEM’ button
or decreasing with ‘DEL’ button. Each adjustment is rec-
ognised by a flash of the ‘SEC’ LED button.
Wait until the led turns o or proceed with the next
timer setting.
Setting the minutes (1 – 59)
The starting value of the minutes is 1.
c) Long press the ‘SET’ button another time – the ‘MIN’
LED will turn on.
d) Adjust the minutes by increasing with ‘MEM’ button
or decreasing with ‘DEL’ button. Each adjustment is rec-
ognised by a flash of the ‘MIN’ LED button.
Wait until the led turns o or proceed with the next
timer setting.
Setting the hours (1 – 8)
The starting value of the minutes is 1.
e) Long press the ‘SET’ button another time – the ‘HOU’
LED will turn on.
f) Adjust the hours by increasing with ‘MEM’ button or
decreasing with ‘DEL’ button. Each adjustment is recog-
nised by a flash of the ‘HOU’ LED button.
Wait until the led turns o or proceed with the next
timer setting.
NOTE: Once the maximum or minimum limits is reached
the value will no longer be increased or decreased. Start
over from ‘a)’ to continue working on the timer function.
Starting over will clear the last known programming of
the timer.
2.2.1 Setting relay function (on/o, impulse, timer) 2.2.2 Programming of a single channel
1. Long press the ‘MEM’ button two times and hold the button on the second time. There will be a beep and followed
by a continuous sound.
2. While holding ‘MEM’ the button (during continuous sound), press the button on the remote that will be
programmed. The programming is confirmed by an intermittent sound.
2.2.3 Copying a function of remote to a new remote. See remote manual for detail on P3 button.
1. Press the P3 button inside the remote. The active receiver will sound continuously. If there is no sound, the remote
is not programmed into the receiver.
2. Within 5 seconds, press a button of the already programmed remote. The sound will be interrupted, and continue
for another 5 seconds.
3. During the sound, press a button of the new remote that requires to be programmed. The programming is indi-
cated by an intermittent sound.
2.2.4 Deleting a single/double channel function
1. Press the P2 button once and hold it down. There will be a slow and intermittent sound.
2. During the sound, press the button of the remote that will be deleted. The deletion is indicted by a continuous
sound.
The following is a brief explanation of each function:
IMPULSE – Heater is only turned on while holding a programmed remote.
ON/OFF – Heater is turned ON or OFF at each button press of a programmed remote.
TIMER – Heater is turned ON for a set duration that the function is programmed to. It is possible to override the
TIMER function by a button press of a programmed remote.

8 9
www.bromicheating.com www.bromicheating.com
OPERATION
WIRELESS CONTROLLER
Power Supply 110/230VAC, 28A
Max Output Power 3000W each relay @ 230VAC
1500W each relay @ 110VAC
Reception Frequency 916MHz
Operating Temperature Range -20/+50°C
Maximum Remotes Memorised 42
Dimensions 205 x 145 x 85mm
Protection Class IP54
2.2.5 Deleting all remotes
1. Long press the P2 button two times and hold the P2 button on the second time until the following sound sequence is
heard.
2. Hearing the sound sequence above indicates that the whole memory of the receiver is deleted.
2.2.6 Deleting a remote from a remote. See remote manual for detail on P3 button.
1. Press the P3 button inside the remote three times. There will be slow and intermittent sound.
2. During the intermittent sound, press a button of the remote to be deleted. The deletion is indicated by a continuous
sound.
2.3 RECOMMENDED PROGRAMMING
The recommended programming for the 4-channel remote is as follows:
• Ch1 & Ch2 to be used as a DOUBLE CHANNEL FUNCTION for output L1
• Ch3 & Ch4 to be used as a DOUBLE CHANNEL FUNCTION for output L2
The manufacturer reserves the right to modify design features and technical data without notice.
PROBLEM POSSIBLE CAUSE REMEDY
Control box does not receive
signals from remote
No battery in remote Change/Replace with
CR2430 battery.
Control box memory full Delete a remote from control
box memory.
Remote not programmed
into control box
Program remote as per ‘2.2
OPERATION’ section.
All other Contact your dealer or
qualified technician.
TECHNICAL SPECIFICATION
TROUBLESHOOTING
WIRING DIAGRAM
a. The will be one beep and then followed by a quick and intermittent sound.
b. Continuous sound.
