Bromic Heating WATERBOY Series User manual

Bromic Waterboy™ Submersible Pump Range
Instruction Manual
V3.8 - 12/2022
Submersible-Range-Instruction-Manual-2022-V3.7.indd 1Submersible-Range-Instruction-Manual-2022-V3.7.indd 1 21/12/2022 3:15:06 PM21/12/2022 3:15:06 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
2
Dear Customer,
We thank you for the trust you’ve placed in our products!
Your new appliance was designed and manufactured with state of the art pumping
technology.
Read these instructions for use carefully before using the appliance for the first time.
These instructions contain all information necessary to safely use this appliance in a
manner that will maximise its lifespan. Please make sure to observe all safety information
included in these instructions.
BROMIC Pty Ltd
10 Phiney Place, Ingleburn, NSW 2565 Australia
P: 1300 276 642 E: [e-mail] W: bromicplumbing.com
Submersible-Range-Instruction-Manual-2022-V3.7.indd 2Submersible-Range-Instruction-Manual-2022-V3.7.indd 2 21/12/2022 3:15:07 PM21/12/2022 3:15:07 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
3
Table of Contents
Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Additional Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Your Appliance At A Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setup & Preparation - Universal Adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setup & Preparation - L-Shape Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setup & Preparation - Float Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation & Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operation, Cleaning & Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Storing & Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Malfunctions & Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
What Do the Symbols Used Mean?
Danger notices and safety information has been clearly marked throughout these instructions. The following symbols
are used to draw your attention to these important warnings:
Type and Source of Danger!
Failure to observe this danger notice may cause physical injury or death.
!
Submersible-Range-Instruction-Manual-2022-V3.7.indd 3Submersible-Range-Instruction-Manual-2022-V3.7.indd 3 21/12/2022 3:15:08 PM21/12/2022 3:15:08 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
4
Electrical Safety
WARNING! When using mains-powered tools, basic safety precautions, including the following,
should always be followed to reduce risk of fire, electric short circuit, personal injury and material
damage. Read and understand the manual prior to operating this pump.
Save these instructions and other documents supplied with this pump for future reference. The electric motor has
been designed for 230V-240V/50Hz. Always check that the power supply corresponds to the voltage on the rating
plate.
NOTE: The power outlet used for the water pump must be protected by a 30mA residual current device or
earth leakage circuit breaker. If the power outlet is external, ensure that it is weather proof. If the supply cord is
damaged, it must be replaced by an electrician to avoid a hazard. The water pump has a built-in thermal protection
overload switch. The water pump stops if an overload occurs. The motor restarts automatically after it has cooled
down.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this product. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective. Then
using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the
power input of this product or which is damaged or defective may result in a risk of fire and electric short circuit.
General Safety Warnings
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in failure.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate pumps in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
Pumps create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a pump. Distractions can cause you to lose control.
2. Electrical safety
a. Pump plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed
(grounded) pumps. Unmodified plugs and matching outlets will reduce risk of electric short circuit.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is
an increased risk of electric short circuit if your body is earthed or grounded.
c. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the pump. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric short circuit.
d. When operating a pump, use an extension cord suitable for wet conditions. Use of a cord suitable for wet use
reduces the risk of electric short circuit.
e. This pump must be used with a residual current device with rated residual current of 30mA or less. Use of an RCD
reduces the risk of electric short circuit.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a pump. Do not use a pump while
you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating a pump
may result in serious personal injury.
b. Avoid accidental starting. Ensure the switch is in the o position before plugging in. Carrying pump with your
finger on the switch or plugging in pumps that have the switch on invites accidents.
c. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is
an increased risk of electric short circuit if your body is earthed or grounded.
d. When operating a pump outdoors, use an extension cord
4. Pump use and care
a. Disconnect the plug from the power source before making any adjustments, changing accessories, or storing
pumps. Such preventive safety measures reduce the risk of starting the pump accidentally.
b. Maintain pumps. Check for misalignment or binding of moving parts, breakage of parts and any other condition
that may aect the pumps operation. If damaged, have the pump repaired before use. Many accidents are caused by
poorly maintained pumps.
c. Use the pump, and accessories etc., in accordance with these instructions and in the manner intended for the
particular type of pump, taking into account the working conditions and the work to be performed. Use of the pump
for operations dierent from intended could result in a hazardous situation.
5. Service
a. Have your pump serviced by a qualified repair person using only identical replacement parts. This will ensure that
the safety of the pump is maintained.
a. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
!
!
Submersible-Range-Instruction-Manual-2022-V3.7.indd 4Submersible-Range-Instruction-Manual-2022-V3.7.indd 4 21/12/2022 3:15:08 PM21/12/2022 3:15:08 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
5
Additional Safety Instructions for Pumps
WARNING! This product is intended for pumping water in domestic and commercial applications.
Do not use it for corrosive, abrasive, explosive or dangerous liquids. Fluids other than water will
damage the water pump and/or create a fire hazard. Failure to follow all instructions listed below
may result in electric short circuit, fire and/or serious injury.
This appliance is not intended for use by person (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Ensure the water pump is disconnected from mains power when installing.
• Do not install or operate the water pump in an explosive environment or near flammable material.
• Do not operate the water pump without liquid.
• Do not run the water pump dry.
WARNING! The water pump together with associated pipework operate under pressure. Do not
disconnect water pump or pipework until internal pressure has been released. Failure to do
this could result in personal injury and damage to property.
• Avoid inserting hands into the inlets/outlets of the water pump while it is connected to power.
• Before using the water pump, always inspect it visually. Do not use the pump if it is cracked and/or damaged. If
the water pump is damaged, contact customer service.
• The water pump has a built-in thermal protection overload switch. The water pump stops if an overload occurs.
The motor restarts automatically after it has cooled down.
• The pump must not be used when people or animals are in the water.
• Never work or perform maintenance on the pump without first making sure it has been disconnected from the
• mains power.
• Pollution of the liquid could occur due to leakage of lubricants
Important:
• Avoid inserting hands into the mouth of the pump if it is connected to the mains.
• The electrical connection must always be made in a dry area. Make sure that electrical connections are
protected
• from inundations.
• Protect the plug and the power cable from heat, oil or sharp edges.
• If damaged, The power cable must be replaced by a qualified electrician.
Caring for the environment
Power tools that are no longer usable should not be disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check with your local council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw materials. Reuse of recycled material decreases pollution
in the environment. Please recycle packaging where facilities exist. Check with your local council authority for
recycling advice.
Spare Parts
Spare parts can be ordered from Bromic or your point of purchase for further information on spare parts, please
contact Bromic 1300 276 642 or email [e-mail]
!
!
Submersible-Range-Instruction-Manual-2022-V3.7.indd 5Submersible-Range-Instruction-Manual-2022-V3.7.indd 5 21/12/2022 3:15:08 PM21/12/2022 3:15:08 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
6
Your Appliance At A Glance
1. Carrying handle
2. Float switch height adjustment
3. Hose adapter for pressure connection
4. Float switch
5. Pump casing
6. Mains cable and plug
2
4
6
5
3
1
2
4
6
5
3
1
Accessories
7. L-Shape Connector
8. Universal Adaptor
7.
8.
Clean Water Pump
(50L) Dirty Water Pumps
(400W & 900W)
Submersible-Range-Instruction-Manual-2022-V3.7.indd 6Submersible-Range-Instruction-Manual-2022-V3.7.indd 6 21/12/2022 3:15:08 PM21/12/2022 3:15:08 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
7
Setup & Preparation
1. Universal Adaptor
Ensure the pump is disconnected from the power supply before performing any of
the following operations. The universal adaptor is designed to fit various sizes of
pipes and fittings.
To fit a 25mm (1’’) rigid pipe or flexible tubing (temporary
or permanent application).
• No cutting of the universal adaptor is required. It is
ready to be fitted with a 25mm (1’’) rigid pipe or flexible
tubing (not included).
To fit a 25mm (1’’) tap adaptor (temporary application
only)
1. Cut the universal adaptor using a hack saw
To fit a 32mm (1¼’’) rigid pipe or flexible tubing (tempo-
rary or permanent application)
• Cut the universal adaptor using a hack saw. It is now
ready to be fitted with a 32mm (1¼’’) rigid pipe or
flexible tubing (not included).
2. It is now ready to be fitted with a 25mm (1’’) screw on tap
adaptor (not included).
NOTE: TO USE THE PUMP IN PERMANENT INSTALLATIONS WITH
RIGID PIPES, INSTALL A NON-RETURN VALVE TO AVOID THE WATER
FLOWING BACK THROUGH THE PUMP WHEN IT HAS STOPPED.
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
Submersible-Range-Instruction-Manual-2022-V3.7.indd 7Submersible-Range-Instruction-Manual-2022-V3.7.indd 7 21/12/2022 3:15:09 PM21/12/2022 3:15:09 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
8
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
Setup & Preparation
2. L-Shape Connector
1. Screw the L-shape connector into the pump housing
by rotating in a clockwise direction
2. Make sure the L-shape connector is firmly tightened
so that the O-ring is compressed between the pump
housing and the L-shape connector. This ensures no
leakage will occur at this point.
3. Screw the prepared universal adaptor clockwise onto
the L-shape connector Note: The hose/tube/tap adaptor
should not be connected at this stage.
4. Securely attach the hose/tube/tap adaptor to the
universal adaptor, fit hose clamps if you are using flexible
hose or tube, and tighten well.
CAUTION: THIS PRODUCT IS INTENDED FOR PUMPING WATER IN A
HOME DOMESTIC APPLICATION. DO NOT USE IT FOR CORROSIVE,
ABRASIVE, EXPLOSIVE OR DANGEROUS LIQUIDS.
Submersible-Range-Instruction-Manual-2022-V3.7.indd 8Submersible-Range-Instruction-Manual-2022-V3.7.indd 8 21/12/2022 3:15:09 PM21/12/2022 3:15:09 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
9
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
PUSH
100mm
minimum
30°
30°
Setup & Preparation
3. Float Switch
The pump is fitted with a float switch, which controls how the pump switches on and
switches o.
1. When the float switch cable is able to move freely, the
pump will function down to a water depth of 50mm and
automatically shut o
2. To set the pump to switch o at a higher water level, insert
the float switch cable into the adjuster
Note: There must be a minimum of 100mm of cable from the
adjuster to the float.
3. When the float switch is about 30° higher than horizontal
(start up level) or above the handle, the pump will turn ‘on’
and operate
4. When the float switch is 30° lower than the horizontal or
below the handle, the pump will turn ‘o’.
Submersible-Range-Instruction-Manual-2022-V3.7.indd 9Submersible-Range-Instruction-Manual-2022-V3.7.indd 9 21/12/2022 3:15:10 PM21/12/2022 3:15:10 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
10
4. Setup
CAUTION: Never carry, lift or pull up the pump by the power cord. This will damage
the unit.
MIN. 50x50CM
MAX. IMMERSION
(b) METRES
MAX. HEAD
(a) METRES
1. Ensure the distance from the lowest point to the highest point that you wish to
distribute the water does not exceed the below graphs as per model.
2. Ensure that the container is large enough to allow the float switch to move freely
and function eectively. A minimum area of 50cm is required on either side of the
pump.
3. Ensure the pump is placed on a flat and level surface, there are no obstructions to
the suction base and out of mud or sediment.
Model Code Max. Head (a) metres Max. Immersion (b) metres
Dirty Water (400W) 5m 7m
Dirty Water (900W) 8.5m 5m
Clean Water (50L) 30m 7m
Submersible-Range-Instruction-Manual-2022-V3.7.indd 10Submersible-Range-Instruction-Manual-2022-V3.7.indd 10 21/12/2022 3:15:10 PM21/12/2022 3:15:10 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
11
5. Installation & Operation
IMPORTANT: Before submerging the pump in water, unwrap the power cable and
ensure the plug is clear of any damp locations.
The pump must be used with a residual current device
with rated residual current of 30mA or less.
1. Immerse the pump in the water. For deep water, use
a rope (not included) and secure it to the handle. Set
the pump in the desired position within the work area
or tank.
2. Insert the plug into the mains power socket. Avoid
using extension cords as this can lead to a voltage
drop which may cause power loss and overheating.
Switch on the mains power to commence operation.
3. To stop operation, turn o the mains power. The
pump will also stop operation automatically once the
float switch reaches the minimum water depth.
CAUTION: Your pump has the capacity to pump water with a non solid particle size
of up to 0.5mm (50L), 5mm (400W, 900W only) 30mm (400W) or 35mm (400W,
900W only)
Float Switch
Water Level
PumpWater
Container
Power
Cable:
Submersible-Range-Instruction-Manual-2022-V3.7.indd 11Submersible-Range-Instruction-Manual-2022-V3.7.indd 11 21/12/2022 3:15:10 PM21/12/2022 3:15:10 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
12
Operation, Cleaning And Maintenance
Risk of damage to the appliance!
Do not lift the pump with the cable or pressure hose as these are not designed with the
tensile strength required to lift the pump’s weight.
– Submerge the pump at an angle into the liquid to be delivered so that no air pocket forms on the underside of the
appliance. Suction would be prevented by this. Once the pump is submerged, it can be righted again.
– Leave the pump on the bottom of the liquid container. Use a strong rope attached to the carrying handle of the
pump for lowering.
– Tighten the end of the rope firmly after lowering.
The pump can also be operated while suspended on a rope.
Note:
For operation with rope:
Do not operate the pump without pressure hose.
Avoid the pump twisting around its longitudinal axis.
Operation
After the appliance has been connected to the
mains power supply, the pump is ready to operate.
Switch on the mains power supply with the pump
submerged to pump liquid as required.
Risk of damage to the appliance!
The float switch must be able to move so that the submersible pump cannot run dry.
Cleaning and maintenance
Cleaning and maintenance overview
Before every use
What? How?
Check casing and cables for damage. Visual inspection.
Check float switch for damage. Lift and shake the switch to ensure free
movement of the contained metal balls.
2
4
6
5
3
1
!
!
Submersible-Range-Instruction-Manual-2022-V3.7.indd 12Submersible-Range-Instruction-Manual-2022-V3.7.indd 12 21/12/2022 3:15:10 PM21/12/2022 3:15:10 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
13
Cleaning And Maintenance
After Every Use
Cleaning the appliance externally
Rinse with clean water. Remove stubborn contamination with a brush and detergent.
Submerge the pump in a container with clean water and switch on for a short time to rinse the inside of the pump.
Cleaning the suction area
– Clean all accessible insides of the casing. Remove fibres which have wound around the rotor shaft by opening the
pressure connection. Remove stubborn contamination with a brush and detergent.
Note:
Before using the pump again, first “soak” it so that any possible dirt residues do not
block the appliance.
Storing
If there is a risk of frost, dismantle the appliance and accessories, clean them and store in a place protected from
frost.
Risk of damage to the appliance!
Frost destroys the appliance and accessories
Disposal
Disposing Of The Appliance
Products which are labelled with the adjacent symbol must not be disposed of in household rubbish. You must
dispose of such old electrical and electronic equipment separately.
Please check with your local authority regarding correct disposal methods. Through separate disposal, old
equipment is recycled or subjected to other forms of re-use. This, in turn, helps to avoid introducing damaging
materials into the environment.
Disposal Of Packaging
The packaging consists of cardboard and correspondingly marked plastics that can be recycled.
– Make these materials available for recycling.
Malfunctions and Troubleshooting
In the event of a malfunction…
Danger of physical injury and death!
Improperly conducted repairs may prevent your appliance from working safely. Such
repairs will endanger you and your surroundings.
What? How?
Clean the appliance. As described in the instructions below
!
!
Submersible-Range-Instruction-Manual-2022-V3.7.indd 13Submersible-Range-Instruction-Manual-2022-V3.7.indd 13 21/12/2022 3:15:10 PM21/12/2022 3:15:10 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
14
Malfunctions and troubleshooting
Minor faults will often cause a malfunction. In most cases, you will be able to correct these faults easily yourself.
Please start by referring to the following table before contacting a technical support representative. For simple
faults, this will save you both the eort of organising a technician and the expense associated with such a visit.
Fault/malfunction Cause Remedy
Pump does not run.
No mains voltage? Check cables, plug, socket and fuse.
Motor overheats due to:
• liquid temperature too high?
• blocked by foreign bodies?
Eliminate the cause of the
overheating
(max. temperature of liquid
Technical data – p. 16).
Residual current circuit breaker
(RCCB) triggered?
Reset RCCB.
Contact qualified electrician if RCCB
triggers again & discontinue use.
Motor defective? Contact service partner.
Pump runs but does
not pump.
Suction openings blocked? Rectify blockage.
Pump draws in air?
Keep the pump at an angle while
submerging.
Switch the pump on and o several
times in order to expel air.
Pump blocked by foreign bodies? Clean the pump (Cleaning the
suction area – p. 13).
Delivery rate too low.
Delivery height too great? Comply with maximum delivery height
(Technical data – p. 16).
Pressure line diameter too
small? Use pressure line of a larger diameter.
Pressure line blocked? Rectify blockage.
Suction openings blocked? Clean suction opening.
Pressure line kinked? Straighten pressure line.
Pressure line leaks? Seal pressure line, tighten threaded
connections.
Pump runs very loudly. Pump draws in air?
Ensure there is sucient liquid
present.
Keep the pump at an angle while
submerging.
Submersible-Range-Instruction-Manual-2022-V3.7.indd 14Submersible-Range-Instruction-Manual-2022-V3.7.indd 14 21/12/2022 3:15:10 PM21/12/2022 3:15:10 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
15
Notes
Submersible-Range-Instruction-Manual-2022-V3.7.indd 15Submersible-Range-Instruction-Manual-2022-V3.7.indd 15 21/12/2022 3:15:10 PM21/12/2022 3:15:10 PM

AU 1300 276 642 NZ 0508 276 642 | W BROMICPLUMBING.COM | E [e-mail]
16
Technical data
If you are unable to correct a fault yourself, please contact our technical support directly. Please note that improperly
conducted repairs will void your warranty and may result in additional expenses.
BROMIC Pty Ltd
10 Phiney Place, Ingleburn, NSW 2565 Australia
AU 1300 276 642 NZ 0508 276 642 [e-mail] Wbromicplumbing.com
CLEAN WATER DIRTY WATER
50L 400W 900W
Item number 7575127 7575125 7575126
Rated voltage 230-240V/50Hz 230-240V/50Hz 230-240V/50Hz
Rated power 800W 400W 900W
Protection type IPX8 IPX8 IPX8
Max. supply height 30m 5m 8.5m
Max. flow rate 5500 l/h 8000 l/h 14000 l/h
Max. submersion depth 7m 7m 5m
Max. temperature of liquid 35C35C35C
Pressure pipe diameter
Pipe connection 1¼”G1”1¼” 1”G1”1¼”G1½” 1”G1”1¼”G1½”
Cable length 10 m 10 m 10 m
Grain size 0.5mm 30mm 35mm
Warranty 2 Years
Submersible-Range-Instruction-Manual-2022-V3.7.indd 16Submersible-Range-Instruction-Manual-2022-V3.7.indd 16 21/12/2022 3:15:11 PM21/12/2022 3:15:11 PM
