Operating instructions b r o n c o l o r
M i n i p u l s C200
Before use
Please read all the information contained in these operating instructions carefully.
They contain important details on the use, safety and maintenance of the appliance.
Keep these operating instructions in a safe place and pass them on to further users if
necessary.
Observe the safety instructions.
Contents page
Safety information 3
Controls and displays 4
Front panel for Minipuls C200 5
1. Minipuls C200 6
2. Application 6
3. Commissioning 6
4. Flash tube 7
5. Protecting glass 7
6. Modelling light 7
7. Fuse 7
8. Heating/temperature monitor 7
9. Afterglow block 8
10. Mounting 8
11. Umbrella bracket 8
12. Flash release 8
13. Accessories 9
14. Service and repair 9
15. Technical data 10
16. Order numbers for diverse spare parts/accessories 10

2

3
Safety information
Attention: Read before start up
- Prior to replacing the fuse, light bulb or flash tube, discharge the unit and
disconnect from power. Allow the unit to cool off for 10 minutes before replacing
the bulb or flash tube.
- Only those types of fuses indicated on the fuse label may be used. This is
particularly important for fusing the halogen lamp which may burst if the wrong
fuse is used.
- Only sand-filled fuses may be used. Sand-filled fuses can be identified by the
opaque body of the fuse.
- The devices are designed for use in dry rooms. Protect them against splash
water and against excessive exposure to dust.
- The devices are not suitable for use in an explosions-hazard environment.
- The accessories mounted to the unit may heat up to high temperatures under
specific conditions. Handle with care !
- To protect against the effects of radiated heat, the unit must not be pointed at
flammable surfaces from less than 1 meter away.
- Do not block the cooling louvers on the unit.
- Flash light contains, similar to sunlight, a specific portion of UV light. The
undesirable side effects on skin and eyes are considerably reduced by using
flash tubes with UV coating. Without these or other protective filters, use extreme
care when shooting.
- Even when disconnected from power, dangerous voltages may remain within the
interior of the device. For this reason, devices should only be opened by our
broncolor repair service.
- For safety reasons, never operate a unit without the protecting glass in place.

4
Controls and displays
1. Flash release key
2. Jack for synchronous cable
3. Flash ready control lamp
4. Connection socket for mains cable
5. Fuse
6. Switch for modelling light (proportional/full)
7. Switch for modelling light (on/off)
8. Main switch (on/off)
9. Slave cell (on/off)
10. Infrared receiver (on/off)
11. Rotary switch for power control
12. Switch for dim function (flash release control)
13. Reflector release

5
Front panel for Minipuls C200

6
1. Minipuls C200
We are delighted that you have chosen the high quality product broncolor
Minipuls C200. With proper care it will render you many years of good
service.
2. Application
This mains supplied studio flash unit is designed for professional
photography only. In countries with earthed mains systems, use a three-
wire extension cable.
3. Commissioning
3.1 Remove grey plastic hood by rotating. Insert the flash tube in accordance
to point 4 and plug in the modelling lamp. Press desired reflector and
protecting glass into the mounting and rotate in any direction.
3.2 Please check that the mains supply corresponds to the information on the
label of the unit. Connect unit to earthed power.
3.3 Switch on main switch (8) and modelling light (7).
3.4 The modelling light can be switched off or on during charging (dim
function) by pushing in switch (12) with a small screwdriver. This option
allows the photographer to confirm visually that all the Minipuls C200 units
have fired.
3.5 Set desired flash output via control knob (11).
3.6 Green control lamp (3) will illuminate: this is how the unit shows that it is
ready
3.7 Release test flash by pressing key (1).
3.8 Switch photocell (9) or infrared receiver (10) on or off.
3.9 If needed, plug in synchronous cable (2).

7
4. Flash tube
The flash tube is pluggable. To replace it, fire a flash, disconnect unit from
power, and allow to discharge and cool off for ten minutes. Then press the
spring radially inward and carefully remove or plug in the flash tube. The
spring acts as the electrical contact and also prevents the tube from falling
out.
For Minipuls C200 following 1500 J flash tubes are available.
coating for 5500 K art. no. 34.310.55
5. Protecting glass
For safety reasons, never operate a unit without the protecting glass in
place.
- Clear protecting glass for Minipuls C200 art. no. 34.336.59
6. Modelling light
The unit is equipped with a very bright halogen modelling light. The
maximum tolerated modelling light output supplies:
Minipuls C200 650 W 220 - 240 V, 300 W 110 - 120 V
In order to meet the European security standard, the modelling lamps
which are offered by the manufacturer must be used.
7. Fuse
The fuse (5) is located on the rear of the unit. Sand-filled fuses with a
value 3.15 AF may only be used (sand-filled fuses can be identified by
their opaque fuse container). Using an incorrect fuse is dangerous: it may
cause the halogen lamp to burst. The correct fuse is therefore included
with each original broncolor replacement lamp.
8. Heating/temperature monitor
In the proximity of the halogen lamp, the unit, depending on adapters
used, can acquire high temperatures. For this reason, we recommend
touching the unit on the handle behind or on the stand adapter only. Due
to the intense heat radiation when a modelling light is in operation, keep
the unit at a minimum distance of 1 m from flammable surfaces.

8
The unit contains a temperature sensor which protects the electronic
circuitry from overload during long flash sequences. If the safety system is
activated, the modelling light goes out and charging is blocked. The ready
indicator light changes to red until the unit has cooled off. The fan will
continue to operate to promote faster cooling.
9. Afterglow block
The unit is equipped with an automatic afterglow block. If the flash tube
begins to exhibit afterglow (at the end of its service life, for example), this
block stops further charging to prevent any additional damage. The ready
indicator light also glows continuously red to indicate this condition. To
cancel the block, switch the unit off and then on again.
10. Mounting
The stand adapter is located below the housing. The adapter will accept
standard broncolor®bolts and Manfrotto®pins.
Make sure the lamp is firmly attached to the stand before operating. The
click-stops of the locking handle can be adjusted by pulling it out.
The enclosed locking pin has to be screwed into the lower part of the
stand adapter so it can be hung from a broncolor®bolt; this is not required
for stand mounting. A safety cable must be installed whenever the
lamphead is suspended.
11. Umbrella bracket
The umbrella reflector (art. no. 33.496.00) is used in conjunction with
umbrella diffusers and reflectors. The umbrella handle is inserted into the
special holder in the stand adapter.
12. Flash release
The release is possible via sync cable, infrared, photocell or with manual
trigger button.
The units are fitted with a synchronous circuit with low working voltage to
protect the camera contact. This synchronous contact may not be
switched parallel with outside brands since the latter work with high
synchronous voltage.

9
The infrared receiver integrated in the unit is used for a wireless release
by the following units
- IRX 2 transmitter } Available as from
- FCM 2 lightmeter and contrast photometer } shipping date
- FCC flash colormeter chronoscope } 1/1995
When in use, make sure that the receiver cell of the unit is not blocked by
obstacles.
13. Accessories
The Pulso bayonet system allows you to use the full line of broncolor
reflectors. For a complete summary, please consult the broncolor system
catalogue, "Be Creative with Light. And with System."
14. Service and repair
Your broncolor compact unit is a precision device which will work for many
years without malfunctions if you take proper care of it. If malfunctions do
arise, please do not attempt to open the unit to repair it yourself. Even
when the unit is shut off, dangerous voltages may remain within the
interior of the device. Leave service and repairs to our broncolor repair
service.

10
15. Technical data
Minipuls C200
Flash energy 1500 J
F-stop at distance of 2 m,
100 ISO, reflector P70 64
Flash duration t 0.1
t 0.5 1/250 s 1/1000 s
Charging time (for 100 %
of selected energy) 0.6 - 2.4 s
Ready display optical
Control range 4 f-stops
Modelling light halogen max. 650 W (off, prop, dim, full)
Flash release wireless via infrared transmitter IRX 2, FCM 2*, FCC*,
photocell, sync cable, manual release button
Reflector mounting Pulso bayonet
Stabilized flash voltage +/- 1 %
Power requirements 220-240 V, 50 Hz, 10 A or
110-120 V, 60 Hz, 16 A
Interference suppressor SEV, VDE
Dimensions 120 x 195 x 495 (mm)
Weight 4.5 kg
* From year of production 1995, serial number begins with C (=compatible with
Minipuls C200).
Subject to change in the interest of technical development.
16. Order numbers for diverse spare parts/accessories
flash tube 5500 K for Minipuls C200 art. no. 34.310.55
halogen modelling light (650 W / 240 V) art. no. 34.226.XX
halogen modelling light (300 W / 120 V) art. no. 34.225.XX
halogen modelling light "longlife"
(300 W / 120 V) art. no. 34.232.XX
protecting glass, clear 5900 K art. no. 34.336.59
protecting glass, mat 5900 K art. no. 34.337.59
protecting glass 5500 K art. no. 34.336.55
protecting glass, mat 5500 K art. no. 34.337.55
fuse 3.15 AF art. no. 37137.00
transport protecting cap, grey art. no. Z3620.00
mains cable Europe 200-240 V art. no. 39086.00
mains cable CH 200-240 V art. no. 39084.00
mains cable USA 100-120 V art. no. 39085.00
