QUICK START GUIDE
Secondary Electronics
0250 Series
Single and Four Channel
Secondary Electronics
Model 0251
Single Channel
Secondary Electronics
Model 0254
Four Channel
Secondary Electronics
Panel Mount Cut-Out Dimensions -Model 0251 Panel Mount Cut-Out Dimensions -Model 0254
Equipment Receipt and Return Procedures, Assembly and Installation
19” Rack Mount Kit Assembly and Power Supply Bracket and Bezel -Model 0254 Only
Table Top Mount Installation -Models 0251 and 0254
Global Headquarters
Brooks Instrument
407 West Vine Street
Hateld, PA 19440-0903 USA
Toll Free (USA): 888-554-FLOW
Tel [phone]
Fax [phone]
[email protected]
A list of all Brooks Instrument locations and contact details can be found
at www.BrooksInstrument.com
Brooks is a trademark of Brooks Instrument, LLC.
All other marks are property of their respective owners.
Quick-Start-0250-Series-EN-03-2023
PN: 541B130AAG/C
Reference: 834z986
© Copyright 2023, Brooks Instrument, LLC,
All rights reserved. Printed in USA.
Receipt of Equipment
If the packing case is damaged, the local carrier should be notied
at once regarding their liability. Carefully remove the equipment
from the packing case and inspect for damage or missing parts. If
damaged, please visit www.BrooksInstrument.com for necessary
forms and instruction.
Return Shipment
Please note that prior to returning any instrument to the factory
Brooks Instrument requires the completion of Form RPR003-1,
a Brooks Instrument Decontamination Statement, as well as
a Materials Safety Data Sheet (MSDS) for uid(s) used in the
instrument. Copies of these forms can be found online at
www.BrooksInstrument.com along with complete details on how
to process your return shipment or you can contact your nearest
Brooks location for the necessary forms and instruction.
4
Dear Customer,
Thank you for your purchase. We appreciate this
oppurtunity to service your ow measurement and
control needs with a Brooks Instrument device.
Brooks’ award-winning meters and controllers
consistently rank at the top of their category for
accuracy, reliability and user preference, as judged
by the audience that matters - real users of ow
instrumentation, like you.
This Quick Start Guide provides an overview of the
steps needed to get your Brooks Instrument device
up an running. For the complete Installation &
Operation Manual, please visit
www.BrooksInstrument.com
Should you require any additional information
concerning our products and support services,
please contact us by phone or via our website:
www.BrooksInstrument.com
Sincerely,
Brooks Instrument

Operation
Signal Wiring
Signal Wiring - Model 0251
User Interface Screen Map
Model 0251
User Interface Screen Map
Model 0254
5
After the 0250 Series has been assembled and installed in the
system, it is ready for operation. Refer to User Interface Screen
Maps at right for details regarding operation.
Notes:
1. The following modes are directly connected inside
the 0251:
Pin 12 (COM PWR) of DA15S channel
Pin 5 (GND) of the SERIAL PORT connector
Pins 1, 2, and 6 (GND) of the ±12-24 Vdc 9-Pin
SUB D connector
All hex shield screwlocks for all SUB-D connectors
2. For DA15S channel, Pins 6 (CMD RTN) and
8 (RATE RTN) are directly connected, are
connected via approximately 10KΩ to Pin 12
(COM PWR).
3. For all connectors, all unlisted pins are not
internally connected.
Notes:
1. The following modes are directly connected inside
the 0251:
Pin 12 (COM PWR) of DA15S channel
Pin 5 (GND) of the SERIAL PORT connector
Pins 1, 2, and 6 (GND) of the ±12-24 Vdc 9-Pin
SUB D connector
All hex shield screwlocks for all SUB-D connectors
2. For DA15S channel, Pins 6 (CMD RTN) and
8 (RATE RTN) are directly connected, are
connected via approximately 10KΩ to Pin 12
(COM PWR).
Pins 6 and 8 are not directly connected between
channels.
3. For all connectors, all unlisted pins are not
internally connected.
Signal Wiring - Model 0254
