Brother MFC 8700 Installation instructions

FAX
LASER PRINTER
COPIER
SCANNER
PC FAX
VIDEO CAPTURE
FAX
LASER PRINTER
COPIER
SCANNER
PC FAX
VIDEO CAPTURE
MFC-8700
TM
This multi-tasking
system increases corporate
communications efficiency
now... and in the future.
©2000 BROTHER INTERNATIONAL CORPORATION

SCANNER
FEATURES
COPIER
FEATURES
VIDEO CAPTURE
FEATURES
PC FAX
FEATURES
LASER PRINTER
FEATURES
FAX
FEATURES PRODUCT SPECIFICATIONS
MFC-8700 Optional Supplies & Accessories†
†Requires additional purchase
▼Based on 5% page coverage
© 2000 BROTHER INTERNATIONAL CORPORATION 100 Somerset Corporate Blvd., Bridgewater, NJ 08807-0911
All specifications subject to change without notice. Printed in the USA. CATMFC8700
All registered trademarks referenced herein are the properties of their respective companies.
MFC-8700
TM
FAX
FEATURES
■Up to 50 page auto document feeder‡
■Super Quick Scan – as fast as
2 seconds per page
■14.4K bps high-speed fax modem
■5 second transmission speed using
JBIG compression
■Broadcasting (up to 182 locations)
■4MB memory (up to 310 pages)**
■Fax Forwarding, Paging and Remote
Retrieval
■132 station auto dialing
■Call Waiting/Caller ID and Distinctive
Ring Detection Ready*
■Dual Access and Simultaneous
Operations
■Automatic Fax/Tel Switch
■Answering machine interface
■Telephone Index
■Automatic legal to letter fax reduction
■Delayed transmission
LASER PRINTER
FEATURES
■Up to 12 pages per minute printing
■True 600 x 600 dpi laser output
■Parallel and USB Interfaces standard
■Dual 250-sheet universal paper
cassettes for 500 sheet total capacity
■Works with Windows®3.1X, 95/98,
NT®Workstation 4.0, DOS Applications
(PCL-4), and iMac™/G3
■Enhanced Memory Management
■Includes Bi-Directional Parallel Cable
(USB cable not included)
■Energy Star Compliant
COPIER
FEATURES
■Up to 12 cpm copy speed
■600 dpi class copy output
■Multi-copying, up to 99, with Sorting
■Reduce or enlarge from 50% to 200%
in one percent increments
SCANNER
FEATURES
■Includes award-winning ScanSoft™
PaperPort®and TextBridge®OCR
software (for use with Windows®only)
■Up to 1200 x 1200 dpi resolution
(interpolated)
■Up to 300 x 600 dpi optical resolution
■Works with Windows®or iMac™/G3
PC FAX
FEATURES
■Send faxes directly from your PC
■Unlimited Fax and Group Number
storage, plus use your own databases
■Broadcasting from your PC
■PC Fax software from SmithMicro
■Requires Windows®3.1X, 95/98 or
NT®Workstation 4.0
(does not work with iMac™/G3)
■Includes NetCentric®PC Internet
Fax software for low-cost faxing
over the Internet▲
VIDEO CAPTURE
FEATURES
■Direct B&W printing of video frames
■Capture color video frames into
your PC from your VCR, camcorder
or digital camera
(for use with Windows®only)
■Print, fax, save, export or manipulate
any video frames captured in the PC
■Uses standard NTSC Video Jack
works with
iMacTM/G3
Windows
®
FOR MORE INFORMATION, PLEASE CALL THE BROTHER FAX-
BACK SYSTEM AT 1-800-521-2846 (USA), 1-800-681-9838
(CANADA) OR VISIT OUR WEB SITE AT http://www.brother.com
SYSTEM REQUIREMENTS
■For Windows®3.1X and 95
• 80486/66 MHz or higher processor
• 8MB RAM (16MB recommended)
• 50MB available hard disk space
• CD-ROM Drive (2x speed or higher)
■For Windows®98 and NT®Workstation 4.0
• Pentium 75 MHz or higher processor
• 16MB RAM (32MB recommended)
• 50MB available hard disk space
•CD-ROM Drive (2x speed or higher)
■For Apple®Power Macintosh G3 or iMac™
• MAC O/S 8.51 or higher
• 5MB available hard disk space
compliant
a
p
p
l
i
e
s
o
n
l
y
t
o
h
a
r
d
w
a
r
e
a
n
d
s
o
f
t
w
a
r
e
i
n
c
l
u
d
e
d
Year
TN430: Standard Toner Cartridge
3,000 pages per cartridge▼
TN460: High Yield Toner Cartridge
6,000 pages per cartridge▼
DR400: Drum Unit
ME8000: 8MB Fax/Printer Memory
ME16000: 16MB Fax/Printer Memory
NC8000: Network (LAN) Board
(10Base-T Ethernet Connection)
* Check with local phone company for availability of
these services.
** Based on Brother #1 chart with JBIG compression
and standard resolution.
▲Requires an account with NetCentric®Internet
Fax Provider.
‡ ADF rating is based on results achieved under the
following conditions: 68° to 86° F (20° - 30° C),
50% to 70% RH, use of quality stock paper.
Approved: FCC & UL
Unit Dimensions: 17.1" x 17.4" x 17"
Carton Dimensions: 21.1" x 22.8" x 27"
Unit/Carton Weight: 34.2 lbs/50.7 lbs
UPC Code: 012502564881
Printing Method/Speed: Electrophotography/12PPM
Compatibility: ITU Group 3
Coding Method: JBIG/MH/MR/MMR
Modulation: 14400/12000/9600/
7200/4800/2400 bps
Transmission Time: 5 seconds (ITU #1 chart, JBIG)
Total Machine Memory: 4MB (upgradable to 12MB or 20MB)
Document Input Width: 5.8" to 8.5"
Recording Paper Size: 8.5" x 11"/8.5" x 14"
Paper Type for Manual Pass: Letter, Legal, A4, A5, A6, B5,
Executive, Envelopes,
Transparencies,
Laser label sheets, Custom Size
2.75" x 5" to 8.5" x 14"
Scanning & Recording Width: 8.2"
Printer Resolution: True 600 x 600 dpi
Fax Resolution: Standard: 203 x 98 lines/inch
Fine: 203 x 196 lines/inch
Superfine: 203 x 392 lines/inch
Gray Scale Shades: 64 Fax, 256 Scanner
Speaker Type: Monitor
Interfaces (standard): High-Speed Bi-Directional
Centronics Parallel (IEEE 1284
cable included) and USB
(USB cable not included)
Emulations: Brother Printing Solution for
Windows®or Apple iMac™/G3, PCL4
Utility Software: Optimized Windows® 95/98, 3.1X,
NT®Workstation 4.0,
Apple iMac™/G3
Power Supply: 120V, 50/60Hz
Power Consumption: Average Operating (Copying): 280W
Peak: 850W or less
Standby: 60W or less
Sleep Mode: 9W or less
Noise Level: 50 dBa (printing)
39 dBa (standby)
Operating Environment: 50° to 90.5° F
