FACSIMILE EQUIPMENT
PARTS REFERENCE LIST
MODEL: FAX8070P / MFC9030 / MFC9070
(For Germany / United Kingdom / France /
Norway / Belgium / Netherlands /
Switzerland / Ireland / Finland / Denmark /
Austria / Spain / Italy / South Africa /
Sweden / Poland / Euro Generic )

© Copyright Brother 2001
All rights reserved
No part of this publication may be reproduced in any form
or by any means without permission in writing from the
publisher.
Specifications are subject to change without prior notice.

NOTES FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q' ty
(3) Description
Note: No orders without Parts Code or Tool No. can be accepted.
[Example] (1) (2) (3)
REF.NO. CODE Q' TY DESCRIPTION RECOMMEND REMARKS
2. Parts change will be informed by the technical information.
COUNTRIES
GERMANY ---- GER
UNITED KINGDOM ---- UK
FRANCE ---- FRA
NORWAY ---- NOR
BELGIUM ---- BEL
NETHERLANDS ---- NLD
SWITZERLAND ---- CHE
IRELAND ---- IRE
FINLAND ---- FIN
DENMARK ---- DEN
AUSTRIA ---- AUS
SPAIN ---- SPA
ITALY ---- ITA
SOUTH AFRICA ---- ZAF
SWEDEN ---- SWE
POLAND ---- POL
EURO GENERIC ---- GER

LIST1(PAPER DRIVE)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK
1 LE1793001 1 DRIVE UNIT
1-1 UL6573000 1 PAPER PICK-UP SOLENOID LEVER
1-2 UL6574000 1 CLUTCH RELEASE LEVER
1-3 UL6575001 1 SOLENOID LEVER RETURN SPRING
1-4 LE7280001 1 SOLENOID LEVER SHEET
1-5 LE7015001 1 PAPER FEED SOLENOID ASSY
1-6 LE7419001 1 CLUTCH GEAR SPRING
1-7 UL6579001 1 CLUTCH HOLDER SPRING
1-8 LE1806001 1 MAIN MOTOR ASSY
1-9 087320616 2 TAPTITE, CUP S M3X6
1-10 LE1807001 1 ELECTRODE
1-11 087311016 2 TAPTITE, CUP B M3X10
1-12 LE1795001 1 MOTOR BRACKET
1-13 087321615 2 TAPTITE, CUP S M3X16
2 087411415 4 TAPTITE, CUP B M4X14
FAX8070P, MFC9030, MFC9070

LIST2(LASER UNIT)
REF No.
CODE
Q'TY
DESCRIPTION
RECOMMEND
REMARK
1
LE7197001
1
LASER SCANNER ASSY(SP)
1
1-1
UL6614001
1
SCANNER SHEET 1
1-2
UL6615001
1
SCANNER SHEET 2
2
LG3162001
1
TONER SENSOR PCB ASSY
3
087310815
1
TAPTITE, CUP B M3X8
4
085411215
3
SCREW, BIND B TITE 4X12
5
UU7043001
1
SCANNER SEAL SPONGE
6
UL6740001
1
LASER CAUTION LABEL
7
UL6741001
1
TONER CAUTION LABEL
FAX8070P, MFC9030, MFC9070

LIST3(PAPER FEED)
REF No.
CODE
Q'TY
DESCRIPTION
RECOMMEND
REMARK
1
LE1833001
1
PAPER FEED BASE ASSY, GRAY(1495)
1-1
LE1844001
1
PLATE SPRING
1-2
LE1943001
1
SEPARATION PAD ASSY
1-3
UL5184001
1
SEPARATION PAD SPRING
1-4
LE1945001
1
PAPER PULL-IN ROLLER
1-5
UL6642000
1
PAWLED BUSHING L
1-6
LE1845001
1
REGISTRATION SENSOR ACTUATOR
1-7
UL6654001
1
PAPER FEED ROLLER
1-8
UF0026001
2
PAWLED BUSHING R
1-9
UL6659001
1
CHUTE FILM
1-10
LJ5219001
1
ANTI-STATIC BRUSH
1-11
U04887001
3
TAPTITE, BIND B M2.6X8
1-12
LE7019001
1
BLACK FILM
2
LE1834001
1
RELEASE LEVER, PURPLE(6255)
3
LE7136001
1
RELEASE LEVER LABEL
4
LE1835001
1
RELEASE LEVER SPRING
5
085411015
1
TAPTITE, BIND B M4X10
6
085411215
2
TAPTITE, BIND B M4X12
7
LE1837001
1
RELEASE CAM
FAX8070P, MFC9030, MFC9070

LIST4(FIXING UNIT)
REF No.
CODE
Q'TY
DESCRIPTION
RECOMMEND
REMARK
1
LE7343001
1
FIXING UNIT, 230V(SP)
1
1-1
LE1849001
1
THERMISTER ASSY
1-2
087311415
1
TAPTITE, CUP B M3X14
1-3
LE7302001
1
HEAT ROLLER CLEANER FELT
1-4
LE1850001
1
HEAT ROLLER
1-5
UH3178000
2
HEAT ROLLER SHAFT HOLDER
1-6
LE7133001
1
TUNGSTEN HOLOGEN LAMP, 230V
1-7
UH3182000
1
FEEDER ELECTRODE PLATE
1-8
083311017
1
TAPTITE, PAN B M3X10
1-9
LJ4820001
1
SCREW, PAN(WASHER) M2.6X6DA
1-10
UH3323001
2
EJECT PINCH ROLLER ASSY
1-11
UL6682001
4
PINCH SPRING
1-12
085311216
2
TAPTITE, BIND B M3X12
1-13
LE7043001
1
CLEANER ASSY
1-14
----
NOT USED
1-15
UH3324001
2
EJECTION PRESSURE ROLLER
2
087411616
2
TAPTITE, CUP B M4X16
FAX8070P, MFC9030, MFC9070

LIST5(MAIN COVER)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK
1 LE1786001 1 MAIN COVER, GRAY
(
1495
)
2 LE7299001 2 RUBBER FOOT
(
FRONT
)
3 LE1863001 1 EL BOARD
4 LE7059001 1 FAN MOTOR ASSY
5 LE1865001 1 HIGH-VOLTAGE INSULATOR SHEET
6LE1866001 1TOP COVER SENSOR ACTUATOR
7 LG3166001 1 SPEAKER UNIT
8 LE1868001 1 BOTTOM PLATE
9 LE1870001 1 PAPER EJECTION TRAY
10 LE1871001 1 PAPER EJECTION SUB TRAY
11 LJ5599001 1 PAPER STOPPER
12 LE1872001 2 PAPER EJECT TRAY HOLDER
13 UH2208001 2 RUBBER FOOT
(
REAR
)
14 085411215 12 SCREW, BIND B TITE 4X12
15 UF6559001 1 SCREW, PAN
(
WASHER
)
M4X8DB
16 LE1874001 1 PAPER EJECT SENSOR ACTUATOR
17 LE1968001 1 SCANNING GROUND SPRING
18 087310815 2 TAPTITE, CUP B M3X8
19 LE1876001 1 ANTI-STATIC BRUSH
20 LE1877001 1 BOARD ACCESS COVER
21 LG3168001 1 REGISTRATION SENSOR PCB ASSY
22 087320616 18 TAPTITE, CUP S M3X6
23 ---- NOT USED
24 LE1881001 1 LOW VOLTAGE INSULATOR SHEET
25 083321216 2 TAPTITE, PAN S M3X12
26 LE7141001 1 ACCESS COVER SHEET, FAX8070P
27 LE7898001 1 PROTECTION FILM
28 UF5745000 1 MJ COVER, EXT FOR
GER/UK/FRA/BEL/FIN/DEN/AUS/ITA/ZAF/SWE/GNR
FAX8070P, MFC9030, MFC9070

LIST6(TOP COVER)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK
1 LE1950001 1 TOP COVER ASSY, GRAY
(
1495
)
1-1 LE1814001 1 SEPARATION ROLLER GEAR
1-2 LE7296001 1 SEPARATION ROLLER
1-3 LE6325001 2 BUSHING L
1-4 LE6326001 1 BUSHING R
1-5 LE1808001 1 SCANNER DRIVE UNIT
1-5-1 LE7039001 1 SCANNER MOTOR
1-5-2 0A4300605 1 SCREW, PAN
(
S/P WASHER
)
M3X6
1-6 087310815 2 TAPTITE, CUP B M3X8
1-7 UF9009001 2 PRESSURE ROLLER
1-8 LE2472001 2 PRESSURE ROLLER SPRING
1-9 LE2471001 1 PRESSURE ROLLER SHAFT
1-10 LE1816001 1 DOCUMENT FEED ROLLER
1-11 UL6642000 1 PAWLED BUSHING
1-12 LE7135001 1 DOCUMENT EJECTION ROLLER ASSY
1-13 UF9949001 1 EJECTION ROLLER BUSHING
1-14 LE1196001 2 DOCUMENT FEED/EJECTION ROLLER GEAR
1-15 LG3171001 1 SCANNER MOTOR HARNESS
1-16 UU7364001 1 SEPARATION ROLLER FILM
2 LG3157001 1 CIS UNIT 1
3 UU2028001 2 CIS SPRING
4 LG3207001 1 FG WIRE
5 LG3741001 1 CIS HARNESS
6 LE4199001 2 TAPTITE, PAN B M4X6D10
7 LE1884001 2 LINK STOPPER
8 LE7134001 1 W/O HANDSET COVER
9 LG3397001 1 HOOK PCB ASSY, FAX8070P/MFC9070
9 LG3735001 1 HOOK PCB ASSY, MFC9030
10 UF8167008 1 ACTUATOR HOOK
11 LE1885001 1 DOCUMENT BASE ASSY, GRAY
(
1495
)
12 LE1889001 1 SIDE COVER L
13 LE1890001 1 SIDE COVER R
14 085411215 4 SCREW, BIND B TITE 4X12
15 LE1891001 1 DOCUMENT EJECTION TRAY
16 LE1892001 1 DOCUMENT EJECTION SUB TRAY
17 LE8109001 1 FEED ROLLER GROUNDING SPRING
FAX8070P, MFC9030, MFC9070

LIST7(CONTROL PANEL)
REF No. CODE Q'T
Y
DESCRIPTION RECOMMEND REMAR
K
1 LE7229001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR GER/AUS 1
1 LE8033001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9030 FOR GER 1
1 LE7244001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR GER/AUS 1
1 LE7235001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR UK/BEL/CHE/IRE/POL 1
1 LE8042001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9030 FOR U
K
1
1 LE7252001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR UK/BEL/CHE/IRE/ZAF/POL/GNR 1
1 LE7241001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR FR
A
1
1 LE8046001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9030 FOR FR
A
1
1 LE7255001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR FR
A
1
1 LE7507001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR NOR 1
1 LE7484001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR NO
R
1
1 LE7525001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR NLD 1
1 LE7497001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR NLD 1
1 LE7705001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR FIN 1
1 LE7544001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR DEN 1
1 LE7513001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR DEN 1
1 LE7549001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR SP
A
1
1 LE7520001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR SP
A
1
1 LE7553001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR IT
A
1
1 LE7529001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR IT
A
1
1 LE7557001 1 CONTROL PANEL ASSY, GRAY(1495),
FAX8070P FOR SWE 1
1 LE7534001 1 CONTROL PANEL ASSY, GRAY(1495),
MFC9070 FOR SWE 1
1-1 LE7126001 1 CONTROL PANEL, FAX8070P FOR GER/AU
S
1-1 LE7123001 1 CONTROL PANEL, MFC9030/MFC9070 FOR GER/AUS
1-1 LE7128001 1 CONTROL PANEL, FAX8070P
FOR UK/BEL/CHE/IRE/POL
1-1 LE7125001 1 CONTROL PANEL, MFC9030/MFC9070
FOR UK/BEL/CHE/IRE/ZAF/POL/GNR
1-1 LE7127001 1 CONTROL PANEL, FAX8070P FOR FR
A
1-1 LE7124001 1 CONTROL PANEL, MFC9030/MFC9070 FOR FR
A
1-1 LE7508001 1 CONTROL PANEL, FAX8070P FOR NO
R
1-1 LE7485001 1 CONTROL PANEL, MFC9070 FOR NO
R
1-1 LE7526001 1 CONTROL PANEL, FAX8070P FOR NL
D
1-1 LE7498001 1 CONTROL PANEL, MFC9070 FOR NLD
1-1 LE7706001 1 CONTROL PANEL, FAX8070P FOR FIN
1-1 LE7545001 1 CONTROL PANEL, FAX8070P FOR DEN
1-1 LE7514001 1 CONTROL PANEL, MFC9070 FOR DEN
1-1 LE7550001 1 CONTROL PANEL, FAX8070P FOR SP
A
1-1 LE7521001 1 CONTROL PANEL, MFC9070 FOR SP
A
1-1 LE7554001 1 CONTROL PANEL, FAX8070P FOR IT
A
1-1 LE7530001 1 CONTROL PANEL, MFC9070 FOR IT
A
1-1 LE7558001 1 CONTROL PANEL, FAX8070P FOR SWE
1-1 LE7535001 1 CONTROL PANEL, MFC9070 FOR SWE
1-2 LE4073003 1 KEY, TEN, GRAY
(
1495
)
1-3 LJ4285004 1 KEY, START, PURPLE
(
6255
)
1-4 LE6171002 1 KEY, COPY, GREEN
(
5159
)
1-5 LE6171004 1 KEY, STOP, PINK
(
2205
)
1-6 LE6168001 2 KEY, CURSOR L, PURPLE
(
6255
)
1-7 LE6169001 2 KEY, CURSOR S, PURPLE
(
6255
)
1-8 LE6350001 1 KEY, MENU FOR GER/AUS <GERMAN>
1-8 LE6079001 1 KEY, MENU
FOR UK/FRA/NOR/BEL/NLD/CHE/ IRE/FIN/DEN/SPA/
ITA/ZAF/POL/GNR <ENGLISH>
FAX8070P, MFC9030, MFC9070

LIST7(CONTROL PANEL)
REF No. CODE Q'T
Y
DESCRIPTION RECOMMEND REMAR
K
1-9 LE7276001 13 KEY, CYLINDER 6, GRAY
(
1495
)
1-10 LG3394001 1 PANEL PCB ASSY, FAX8070P/MFC9070
1-10 LG3173001 1 PANEL PCB ASSY, MFC9030
1-11 LG3393001 1 LCD, FAX8070P/MFC9070
1-11 LG3393001 1 LCD, MFC9030
1-12 LE7129001 1 BACKLIGHT HOLDER, FAX8070P/MFC9030
1-13 LE7130001 1 BACKLIGHT DIFFUSER, FAX8070P/MFC903
0
1-14 LG3248001 1 KEY, FPC ASSY
1-15 LE1925001 1 PANEL REAR COVE
R
1-16 LE6342001 1 DOCUMENT PRESSURE BAR ASS
Y
1-17 UU2057001 1 DOCUMENT PRESSURE BAR SPRING
1-18 LE1926001 1 SEPARATION RUBBE
R
1-19 UU7105001 1
A
DF PLATE SPRING
1-20 LE1961001 1 FRONT PLATE SPRING
1-21 UF5034001 1 TAPTITE, B 3X6
1-22 LE6176001 1
A
CTUATOR F
1-23 LE6177001 1
A
CTUATOR
R
1-24 UF9009001 2 PINCH ROLLE
R
1-25 LE1927001 1 PINCH ROLLER SPRING
1-26 LE2471001 1 PRESSURE ROLLER SHAF
T
1-27 LE1071001 1
A
NTI-STATIC BRUSH 79MM
1-28 LE7298001 1
A
NTI-STATIC BRUSH 65MM
1-29 087310815 2 TAPTITE, CUP B M3X8
2 LE7132001 1 PANEL SHEET, FAX8070P
2 LE8034001 1 PANEL SHEET, MFC9030
2 LE7131001 1 PANEL SHEET, MFC9070
3 LE5308001 1
A
DDRESS LABEL, FAX8070P
FAX8070P, MFC9030, MFC9070

LIST8(PCB)
REF No. CODE Q'T
Y
DESCRIPTION RECOMMEND REMAR
K
1 LG3388001 1 MAIN PCB ASSY, FAX8070P 1
1 LG3736001 1 MAIN PCB ASSY, MFC9030 1
1 LG3385001 1 MAIN PCB ASSY, MFC9070 EXCEPT FOR GN
R
1 CHG
1 LG3385002 1 MAIN PCB ASSY, MFC9070 FOR GNR 1
A
DD
2 LG3490031 1 NCU PCB ASSY FOR GER/CHE 1
2 LG2810014 1 NCU PCB ASSY FOR UK/NOR/FIN/DEN/ZAF/SWE/GNR 1
2 LG3490032 1 NCU PCB ASSY FOR FRA/BEL/NLD/IRE/AUS/SPA/IT
A
1
2 LG2821001 1 NCU PCB ASSY FOR POL 1
3 LG3491001 1 NCU HARNESS
4 LG3478001 1 LOW-VOLTAGE POWER SUPPLY PCB ASSY 1
5 LG3195001 1 LV HARNESS
6 LG3196001 1 HEATER HARNESS
7 LG3197001 1 HIGH-VOLTAGE POWER SUPPLY PCB ASSY 1
8 LG3198001 1 HV HARNESS
(
9
)
LG3429001 1 BATTER
Y
FAX8070P, MFC9030, MFC9070
