FACSIMILE EQUIPMENT
PARTS REFERENCE LIST
MODEL: FAX-T72 / T74 / T7 Plus /
T76 / T82 / T84 / T86
(For Germany / United Kingdom / France /
Norway / Belgium / Netherlands /
Switzerland / Ireland / Finland / Denmark /
Austria / Spain / Italy / South Africa /
Sweden / Portugal / Poland /
Czecho / Hungary / Euro Generic )

© Copyright Brother 2000
All rights reserved
No part of this publication may be reproduced in any form
or by any means without permission in writing from the
publisher.
Specifications are subject to change without prior notice.

NOTES FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q' ty
(3) Description
Note: No orders without Parts Code or Tool No. can be accepted.
[Example] (1) (2) (3)
REF.NO. CODE Q' TY DESCRIPTION REMARKS
2. Design-changed parts:
When the parts are changed, any one of the following symbols is mentioned in the REMARKS column.
CNG(cng) : The part is changed to a new part.
ADD(add) : The part is newly added.
DEL(del) : The part is deleted.
Symbol in capital letters indicates that the change is the latest one in the page.
3. Parts change will be informed by the technical information.
COUNTRIES
GERMANY ----- GER
UNITED KINGDOM ----- UK
FRANCE ----- FRA
NORWAY ----- NOR
BELGIUM ----- BEL
NETHERLANDS ---- NLD
SWITZERLAND ---- CHE
IRELAND ---- IRE
FINLAND ---- FIN
DENMARK ---- DEN
AUSTRIA ---- AUS
SPAIN ---- SPA
ITALY ---- ITA
SOUTH AFRICA ---- ZAF
SWEDEN ---- SWE
PORTUGAL ----POR
POLAND ----POL
CZECHO ----CZE
HUNGARY ----HUN
EURO GENERIC ---- GNR

LIST1 (DRIVING)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
*1 LE4001001 1 DRIVE UNIT [FOR THE EARLY LOT]
*1 LF1412001 1 DRIVE UNIT CHG
1-1 LG2581001 1
A
RM HP SWITCH ASSY
1-2 LE4028001 1 MOTOR WITH HARNESS
1-3 08731081
5
2 TAPTITE, CUP B M3X8
√
1-4 U09759001 1 SCREW, PAN (S/P WASHER) M3X6
√
(
1-5
)
LE5629001 1 PLANETARY GEAR SUPPLY ASSY
2 08731101
6
2 TAPTITE, CUP B M3X10
5X4582/5X4583/5X4588 FAX-T72/T74/T7Plus/T76/T82/T84/T86

LIST2 (SCANNING)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
1 LG3076001 1 CIS UNIT, FAX-T72/T7Plus/T76/T86
1 LG3595001 1 CIS UNIT, FAX-T74/T84
√
2 LE4029001 1 CIS HOLDE
R
3 LE4030001 1 CIS FILM(BLACK)
4 08531081
5
1 TAPTITE, BIND B M3X8
5 08731081
5
1 TAPTITE, CUP B M3X8
√
6 LG2557001 1 CIS-MAIN HARNESS
FAX-T72/T74/T7Plus/T76/T82/T84/T865X4582/5X4583/5X4588

LIST3 (RECORDING)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
1 LE4031001 1 RECORDER FRAME
2 08731081
5
2 TAPTITE, CUP B M3X8
√
3 LE5406001 1 RECORDING HEAD ASSY
4 UF8072001 3 HEAD SPRING
√
5 LG2779001 1 MAIN-HEAD HARNESS, FAX-T72/T74/T7Plus/T82/T84
√
5 LG2558001 1 MAIN-HEAD HARNESS, FAX-T76/T86
6 LG2559001 1 HEAD-POWER HARNESS
7 UF9856001 1 HEAD PROTECTOR
8 LE4034001 1 GROUNDING SPRING
FAX-T72/T74/T7Plus/T76/T82/T84/T865X4582/5X4583/5X4588

LIST4 (COVER)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
1 LE5404002 1 MAIN FRAME GREY(1293), FAX-T72
√
1 LE5405002 1 MAIN FRAME GREY(1293), FAX-T74(GRAY)/T7Plus/T7
6
√
1 LE540400
3
1MAIN FRAME GREY(1267), FAX-T82
1 LE540500
3
1MAIN FRAME GREY(1267), FAX-T74(WHITE)/T84/T86
1LE5916002 1 MAIN FRAME GREY(1293), FAX-T76
√
2 LE4036001 1 RIBBON SHAFT STOPPER
3 LE4037001 1 RIBBON STOPPER SPRING
4 LE4038002 1 LOWER COVER, FAX-T72/T74(GRAY)/T7Plus/T76
√
4 LE403800
3
1LOWER COVER, FAX-T74(WHITE)T82/T84/T86
5 LE4326002 1 DUMMY MOUNT, FAX-T7
2
√
5 LE403900
3
1HANDSET MOUNT, FAX-T74(GRAY)/T7Plus/T76
√
5 LE432600
3
1DUMMY MOUNT, FAX-T8
2
5 LE403900
4
1HANDSET MOUNT, FAX-T74(WHITE)T84/T86
√
6 LE4040002 1 HOOK SWITCH ACTUATOR, FAX-T74(GRAY)/T7Plus/T76
√
6 LE4040001 1 HOOK SWITCH ACTUATOR, FAX-T74(WHITE)T84/T86
7 LE4041001 1 COVER SENSOR ACTUATOR(BLACK)
8 LE4042001 1
A
CTUATOR SPRING, FAX-T72/T82
8 LE4042001 2
A
CTUATOR SPRING, FAX-T74/T76/T7Plus/T84/T86
9 LG2630001 1 SPEAKER
10 LG2576001 1 SENSOR PCB ASSY B53K462-101
*
11 LG2778001 1 SENSOR-MAIN HARNESS, FAX-T72/T74/T7Plus/T82/T84
√
11 LG2560001 1 SENSOR-MAIN HARNESS, FAX-T76/T86
12 UF9847001 1 SPEAKER SUPPORT SPRING
13 LE4043001 1 RIBBON SENSOR ACTUATOR
14 LE4044001 1 DOCUMENT LF ROLLER
15 LE4047001 1 GEAR, 23
16 LE4501001 2 DOCUMENT PINCH ROLLE
R
17 LE4048001 2 PINCH ROLLER SPRING
18 LE4049001 1 DOCUMENT EJECTION ROLLER ASSY
19 LE4047001 1 GEAR, 23
20 UF9949001 2 ROLLER BUSHINGS
21 UL624400
2
2DOCUMENT PRESSURE ROLLER
22 UF626700
0
2PRESSURE ROLLER SHAFT
23 04805034
6
2RETAINING RING
24 LE4051001 1 DOCUMENT PRESSURE ROLLER SPRING
25 LE4052001 1 PAPER EJECTION ROLLER
26 LE4054001 1 ROM COVE
R
27 LE4061001 1 COVER STOPPER LINK
28 LE4062001 1 BOTTOM PLATE
29 UF6761001 2 RUBBER FOOT
√
30 LG2861001 1 BATTERY ASSY, FAX-T76
31 LE4204001 1 CIS SPRING
32 LE4205001 1 SUPPORT PLATE
33 LE4214001 1 INSULATION FILM
34 08731081
5
10 TAPTITE, CUP B M3X8
√
35 U2401400
2
1TAPTITE, CUP S M3.0X6
36 LE4199001 1 TAPTITE, PAN B M4X6D10
37 LE0542002 1 PCIF FILM, FAX-T76
38 ---
-
NOT USED
39 ---
-
NOT USED
40 UF4444001 1 SCREW, PAN(P WASHER) M4X6
√
(41) UF5745000 1 MJ COVER
FOR GER/UK/FRA/BEL/NLD/FIN/AUS/ITA/SWE CHG
5X4582/5X4583/5X4588 FAX-T72/T74/T7Plus/T76/T82/T84/T86

LIST5 (CONTROL PANEL)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
1 LE432900
3
1 CONTROL PANEL ASSY, FAX-T72 FOR GER/AUS
√
1 LE438300
3
1 CONTROL PANEL ASSY, FAX-T74/T7Plus FOR GER/AUS
√
1 LE439600
3
1 CONTROL PANEL ASSY, FAX-T76 FOR GER/AUS
√
1 LE432900
4
1 CONTROL PANEL ASSY, FAX-T82 FOR GER/AUS
√
1 LE438300
4
1 CONTROL PANEL ASSY, FAX-T84 FOR /GER/AUS
√
1 LE439600
4
1 CONTROL PANEL ASSY, FAX-T86 FOR GER/AUS
√
1 LE438900
3
1 CONTROL PANEL ASSY, FAX-T74 FOR UK/CHE/IRE/ZAF/GNR
√
1 LE440400
3
1 CONTROL PANEL ASSY, FAX-T76 FOR UK/CHE/IRE/ZAF/GNR
√
1 LE438900
4
1 CONTROL PANEL ASSY, FAX-T84 FOR /UK/CHE/IRE/GNR
√
1 LE440400
4
1 CONTROL PANEL ASSY, FAX-T86 FOR UK/IRE/GNR
√
1 LE437900
3
1 CONTROL PANEL ASSY, FAX-T72 FOR FRA
√
1 LE439300
3
1 CONTROL PANEL ASSY, FAX-T74 FOR FRA
√
1 LE440700
3
1 CONTROL PANEL ASSY, FAX-T76 FOR FRA
√
1 LE437900
4
1 CONTROL PANEL ASSY, FAX-T82 FOR FRA
√
1 LE439300
4
1 CONTROL PANEL ASSY, FAX-T84 FOR FRA
√
1 LE440700
4
1 CONTROL PANEL ASSY, FAX-T86 FOR FRA
√
1 LE443400
3
1 CONTROL PANEL ASSY, FAX-T74 FOR NOR
√
1 LE447800
3
1 CONTROL PANEL ASSY, FAX-T76 FOR NOR
√
1 LE443400
4
1 CONTROL PANEL ASSY, FAX-T74
(
WHITE
)
/T84 FOR NOR
√
1 LE447800
4
1 CONTROL PANEL ASSY, FAX-T86 FOR NOR
√
1 LE443600
3
1 CONTROL PANEL ASSY, FAX-T74 FOR BEL
√
1 LE448000
3
1 CONTROL PANEL ASSY, FAX-T76 FOR BEL
√
1 LE443600
4
1 CONTROL PANEL ASSY, FAX-T84 FOR BEL
√
1 LE448000
4
1 CONTROL PANEL ASSY, FAX-T86 FOR BEL
√
1 LE444000
3
1 CONTROL PANEL ASSY, FAX-T74 FOR NLD
√
1 LE448200
3
1 CONTROL PANEL ASSY, FAX-T76 FOR NLD
√
1 LE444000
4
1 CONTROL PANEL ASSY, FAX-T84 FOR NLD
√
1 LE448200
4
1 CONTROL PANEL ASSY, FAX-T86 FOR NLD
√
1 LE443000
3
1 CONTROL PANEL ASSY, FAX-T72 FOR CHE
√
1 LE443000
4
1 CONTROL PANEL ASSY, FAX-T82 FOR CHE
√
1 LE444600
3
1 CONTROL PANEL ASSY, FAX-T74 FOR FIN
√
1 LE448500
3
1 CONTROL PANEL ASSY, FAX-T76 FOR FIN
√
1 LE444600
4
1 CONTROL PANEL ASSY, FAX-T84 FOR FIN
√
1 LE448500
4
1 CONTROL PANEL ASSY, FAX-T86 FOR FIN
√
1 LE444900
3
1 CONTROL PANEL ASSY, FAX-T74 FOR DEN
√
1 LE448800
3
1 CONTROL PANEL ASSY, FAX-T76 FOR DEN
√
1 LE444900
4
1 CONTROL PANEL ASSY, FAX-T84 FOR DEN
√
1 LE448800
4
1 CONTROL PANEL ASSY, FAX-T86 FOR DEN
√
1 LE454200
3
1 CONTROL PANEL ASSY, FAX-T72 FOR SPA
√
1 LE445200
3
1 CONTROL PANEL ASSY, FAX-T74 FOR SPA
√
1 LE449100
3
1 CONTROL PANEL ASSY, FAX-T76 FOR SPA
√
1 LE454200
4
1 CONTROL PANEL ASSY, FAX-T82 FOR SPA
√
1 LE445200
4
1 CONTROL PANEL ASSY, FAX-T84 FOR SPA
√
1 LE449100
4
1 CONTROL PANEL ASSY, FAX-T86 FOR SPA
√
1 LE445500
3
1 CONTROL PANEL ASSY, FAX-T74 FOR ITA
√
1 LE449400
3
1 CONTROL PANEL ASSY, FAX-T76 FOR ITA
√
1 LE445500
4
1 CONTROL PANEL ASSY, FAX-T84 FOR ITA
√
1 LE449400
4
1 CONTROL PANEL ASSY, FAX-T86 FOR ITA
√
1 LF142700
4
1 CONTROL PANEL ASSY, FAX-T84 FOR POR
√
1 LF143600
4
1 CONTROL PANEL ASSY, FAX-T86 FOR POR
√
1 LE445900
3
1 CONTROL PANEL ASSY, FAX-T74 FOR SWE
√
1 LE449700
3
1 CONTROL PANEL ASSY, FAX-T76 FOR SWE
√
1 LE445900
4
1 CONTROL PANEL ASSY, FAX-T74
(
WHITE
)
/T84 FOR SWE
√
1 LE449700
4
1 CONTROL PANEL ASSY, FAX-T86 FOR SWE
√
1 LE552300
3
1 CONTROL PANEL ASSY, FAX-T74 FOR CZE
√
1 LE553000
3
1 CONTROL PANEL ASSY, FAX-T76 FOR CZE
√
1 LE552300
4
1 CONTROL PANEL ASSY, FAX-T84 FOR CZE/HUN
√
1 LE553000
4
1 CONTROL PANEL ASSY, FAX-T86 FOR CZE/HUN
√
1 LE561100
3
1 CONTROL PANEL ASSY, FAX-T74 FOR POL
√
1 LE561300
3
1 CONTROL PANEL ASSY, FAX-T76 FOR POL
√
1 LE561100
4
1 CONTROL PANEL ASSY, FAX-T84 FOR POL
√
1 LE561300
4
1 CONTROL PANEL ASSY, FAX-T86 FOR POL
√
1-1 LE462800
3
1 CONTROL PANEL, FAX-T72/T82 FOR GER/AUS
√
1-1 LE462900
3
1 CONTROL PANEL, FAX-T74/T7Plus/T84 FOR GER/AUS
√
1-1 LE463000
3
1 CONTROL PANEL, FAX-T76/T86 FOR GER/AUS
√
1-1 LE462900
4
1 CONTROL PANEL, FAX-T74/T84 FOR UK/CHE/IRE/ZAF/GNR
√
1-1 LE463000
4
1 CONTROL PANEL, FAX-T76/T86 FOR UK/CHE/IRE/ZAF/GNR
√
1-1 LE462800
5
1 CONTROL PANEL, FAX-T72/T82 FOR FRA
√
1-1 LE462900
5
1 CONTROL PANEL, FAX-T74/T84 FOR FRA
√
1-1 LE463000
5
1 CONTROL PANEL, FAX-T76/T86 FOR FRA
√
1-1 LE462900
7
1 CONTROL PANEL, FAX-T74/T84 FOR NO
R
√
1-1 LE463000
7
1 CONTROL PANEL, FAX-T76/T86 FOR NO
R
√
1-1 LE462900
8
1 CONTROL PANEL, FAX-T74/T84 FOR BEL
√
1-1 LE463000
8
1 CONTROL PANEL, FAX-T76/T86 FOR BEL
√
FAX-T72/T74/T7Plus/T76/T82/T84/T865X4582/5X4583/5X4588

LIST5 (CONTROL PANEL)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
1-1 LE462900
9
1 CONTROL PANEL, FAX-T74/T84 FOR NLD
√
1-1 LE463000
9
1 CONTROL PANEL, FAX-T76/T86 FOR NLD
√
1-1 LE462801
0
1 CONTROL PANEL, FAX-T72/T82 FOR CHE
√
1-1 LE4629012 1 CONTROL PANEL, FAX-T74/T84 FOR FIN
√
1-1 LE4630012 1 CONTROL PANEL, FAX-T76/T86 FOR FIN
√
1-1 LE462901
3
1 CONTROL PANEL, FAX-T74/T84 FOR DEN
√
1-1 LE463001
3
1 CONTROL PANEL, FAX-T76/T86 FOR DEN
√
1-1 LE462801
5
1 CONTROL PANEL, FAX-T72/T82 FOR SPA
√
1-1 LE462901
5
1 CONTROL PANEL, FAX-T74/T84 FOR SPA
√
1-1 LE463001
5
1 CONTROL PANEL, FAX-T76/T86 FOR SPA
√
1-1 LE462901
6
1 CONTROL PANEL, FAX-T74/T84 FOR ITA
√
1-1 LE463001
6
1 CONTROL PANEL, FAX-T76/T86 FOR ITA
√
1-1 LE462902
6
1 CONTROL PANEL, FAX-T74/T84 FOR SWE
√
1-1 LE463002
6
1 CONTROL PANEL, FAX-T76/T86 FOR SWE
√
1-1 LE462903
7
1 CONTROL PANEL, FAX-T74/T84 FOR CZE/HUN
√
1-1 LE463003
7
1 CONTROL PANEL, FAX-T76/T86 FOR CZE
√
1-1 LE462903
9
1 CONTROL PANEL, FAX-T74/T84 FOR POL
√
1-1 LE463003
9
1 CONTROL PANEL, FAX-T76/T86 FOR POL
√
1-2 LE407300
4
1 KEY, TEN, BLUE
(
6314
)
1-3 LE414600
3
1 KEY, REDIAL, GRAY
(
1251
)
, FAX-T72/T74
(
GRAY
)
/T7Plus/T76
√
1-3 LE4146001 1 KEY, REDIAL, WHITE
(
1485
)
, FAX-T74/
(
WHITE
)
T82/T84/T86
1-4 LE4074002 1 KEY, START, BLUE
(
6314
)
√
1-5 LE407500
3
1 KEY, COPY, GRAY
(
1251
)
, FAX-T72/T74
(
GRAY
)
/T7Plus/T76
√
1-5 LE4075001 1 KEY, COPY, WHITE
(
1485
)
, FAX-T74
(
WHITE
)
/T82/T84/T86
1-6 LE4076001 1 KEY, STOP, PINK
(
2205
)
1-7 LE407700
3
1 KEY, MODE, GRAY
(
1251
)
, FAX-T72/T74
(
GRAY
)
/T7Plus/T76
√
1-7 LE4077001 1 KEY, MODE, WHITE
(
1485
)
, FAX-T74
(
WHITE
)
/T82/T84/T86
1-8 LE407800
3
1 KEY, FUNCTION, GRAY
(
1251
)
√
1-9 LE407900
3
1 KEY, ONE TOUCH, BLUE
(
6314
)
√
1-10 LE4165001 1 KEY, PRINTED FLASH, FAX-T76
√
1-11 LE4150001 1 FLASH KEY SUPPORTER, FAX-T76
1-12 LE4151002 1 KEY, REP, BLUE
(
6314
)
, FAX-T76/T86
1-13 LG2561001 1 CONTROL PANEL PCB ASSY, FAX-T72/T74/T7Plus/T82/T84 B53K463-101
*
1-13 LG2585001 1 CONTROL PANEL PCB ASSY, FAX-T76/T86 B53K487-101
*
1-14 LG2567001 1 LCD
1-15 LG2568001 1 FPC KEY
1-16 08731081
5
1 TAPTITE, CUP B M3X8, FAX-T72/T74/T7Plus/T82/T84
√
1-16 08731081
5
2 TAPTITE, CUP B M3X8, FAX-T76/T86
√
1-17 LG2569001 1 PANEL-MAIN HARNESS, FAX-T72/T74/T7Plus/T82/T84
1-17 LG2580001 1 PANEL-MAIN HARNESS,
(
W/ MICROPHONE
)
, FAX-T76/T86
1-18 UF6916001 1 MIC COVER, FAX-T76
1-19 UF9993001 1 MIC RUBBER, FAX-T76
1-20 LE4081001 1 PANEL REAR COVER
1-21 LE4082001 1
A
DF SEPARATION RUBBER
1-22 LE4190001 1 SEPARATION RUBBER FILM
1-23 LE4083001 1
A
DF HOLDE
R
1-24 LE4084001 1
A
DF SPRING PLATE
1-25 LE4085001 1
A
DF SPRING
1-26 UF6116001 1 TAPTITE, PAN B M3X6
1-27 08731081
5
4 TAPTITE, CUP B M3X8
√
1-28 LE4090003 1 DOCUMENT GUIDE B-L, GRAY(1293), FAX-T72/T74(GRAY)/T7Plus/T76 √
1-28 LE4090004 1 DOCUMENT GUIDE B-L, WHITE(1517), FAX-T74(WHITE)/T82/T84/T86
1-29 LE4091003 1 DOCUMENT GUIDE B-R, GRAY(1293), FAX-T72/T74(GRAY)/T7Plus/T76 √
1-29 LE409100
4
1 DOCUMENT GUIDE B-R, WHITE
(
1517
)
, FAX-T74
(
WHITE
)
T82/T84/T86
1-30 UF441700
0
1 GUIDE GEAR
1-31 UF4418001 1 SPRING, COMPRESSION
1-32 UF6116001 1 TAPTITE, PAN B M3X6
1-33 UU0243001 1
A
NTI-STATIC BRUSH
2 LE4092001 1
A
CF SEPARATION RUBBER
3 LE4093001 1
A
CF PLATE
4 LE4094001 1
A
CF HOLDE
R
5 LE4187001 1
A
CF LEAF SPRING
6 LE4096001 1
A
CF SPRING
7 08531081
5
4 TAPTITE, BIND B M3X8
8 LE409800
3
1 CHUTE COVER, BLACK, FAX-T72/T74
(
GRAY
)
/T7Plus/T76
√
8 LE4098001 1 CHUTE COVER, NATURAL, FAX-T74
(
WHITE
)
/T82/T84/T86
9 LE4102001 1 PLATEN
10 LE4104001 1 PLATEN SHAFT BUSHING L, BLACK
11 LE4105001 1 PLATEN SHAFT BUSHING R, WHITE
12 LE4111001 1 GEAR, 24
13 LE4047001 1 GEAR, 23
FAX-T72/T74/T7Plus/T76/T82/T84/T865X4582/5X4583/5X4588

LIST5 (CONTROL PANEL)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
14 LE4106001 1 PAPER FEED ROLLER 32
15 LE4108001 1 PAPER FEED ROLLER GEAR 37
16 UF6613001 1 SEPARATION ROLLER
17 LE4109001 1 SEPARATION ROLLER GEAR 46
18 LE4147001 2 PAPER PRESSURE ROLLER
19 LE4110001 1 PRESSURE ROLLER SHAFT
20 UF9781001 2 PRESSURE ROLLER SPRING
21 LE4012001 2 GEAR, 32
22 LE4099001 1 REGISTRATION SENSOR ACTUATOR
23 LE4113001 1 LOCK BAR
24 LE4114001 1 LOCK LEVER L, WHITE
25 LE4115001 1 LOCK LEVER R, GREY
(
1473
)
26 LE4373001 1 LOCK SPRING
√
27 LE4117001 1 CHUTE FILM
28 LE4203001 1
A
DF FILM
29 08731081
5
4 TAPTITE, CUP B M3X8
√
30 LE4087001 1 DOCUMENT PRESSURE BA
R
31 LE4088001 1 WHITE FILM
32 UF9781001 3 SPRING
33 LE4300001 1 LCD SHEET, FAX-T72
√
33 LE4384001 1 LCD SHEET, FAX-T74
√
33 LF1342001 1 LCD SHEET, FAX-T82
√
33 LF1352001 1 LCD SHEET, FAX-T84
√
33 LE5620001 1 LCD SHEET, FAX-T7Plus FOR GER/AUS
√
33 LE4399001 1 LCD SHEET, FAX-T76 FOR GER/AUS
√
33 LF1357001 1 LCD SHEET, FAX-T86 FOR GER/AUS
√
33 LE4405001 1 LCD SHEET, FAX-T76 FOR UK/BEL/CHE/IRE/ZAF/SWE/GNR
√
33 LF1361001 1 LCD SHEET, FAX-T86 FOR UK/BEL/IRE/GNR
√
33 LE4408001 1 LCD SHEET, FAX-T76 FOR FRA
√
33 LF1362001 1 LCD SHEET, FAX-T86 FOR FRA
√
33 LE4479001 1 LCD SHEET, FAX-T76 FOR NOR
√
33 LF1363001 1 LCD SHEET, FAX-T86 FOR NOR
√
33 LE4483001 1 LCD SHEET, FAX-T76 FOR NLD
√
33 LF1364001 1 LCD SHEET, FAX-T86 FOR NLD
√
33 LE4486001 1 LCD SHEET, FAX-T76 FOR FIN
√
33 LF1365001 1 LCD SHEET, FAX-T86 FOR FIN
√
33 LE4489001 1 LCD SHEET, FAX-T76 FOR DEN
√
33 LF1366001 1 LCD SHEET, FAX-T86 FOR DEN
√
33 LE4492001 1 LCD SHEET, FAX-T76 FOR SPA
√
33 LF1367001 1 LCD SHEET, FAX-T86 FOR SPA
√
33 LE4495001 1 LCD SHEET, FAX-T76 FOR ITA
√
33 LF1368001 1 LCD SHEET, FAX-T86 FOR ITA
√
33 LF1437001 1 LCD SHEET, FAX-T86 FOR POR
√
33 LE4498001 1 LCD SHEET, FAX-T76 FOR SWE
√
33 LF1369001 1 LCD SHEET, FAX-T86 FOR SWE
√
33 LE5531001 1 LCD SHEET, FAX-T76 FOR CZE
√
33 LF1370001 1 LCD SHEET, FAX-T86 FOR CZE/HUN
√
33 LE5527001 1 LCD SHEET, FAX-T76 FOR POL
√
33 LF1371001 1 LCD SHEET, FAX-T86 FOR POL
√
FAX-T72/T74/T7Plus/T76/T82/T84/T865X4582/5X4583/5X4588

LIST6 (PCB)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
1 LG329302
6
1 MAIN PCB ASSY, FAX-T72 FOR GER/FRA/AUS/SPA B53K550-226
*
√
1 LG3115021 1 MAIN PCB ASSY, FAX-T74 FOR
GER/UK/FRA/NOR/BEL/NLD/IRE/FIN/DEN/AUS/SPA/ITA/ZAF/SWE/CZE/GNR,
FAX-T7Plus FOR GER/AUS
B53K550-221* √
1 LG3473031 1 MAIN PCB ASSY, FAX-T76 FOR
GER/UK/FRA/NOR/BEL/NLD/CHE/IRE/FIN/DEN/AUS/SPA/ITA/
ZAF/SWE/CZE/GNR
B53K531-231* √
1 LG329305
6
1 MAIN PCB ASSY, FAX-T82 FOR /GER/FRA/AUS/SPA B53K550-256
*
√
1 LG3473061 1 MAIN PCB ASSY, FAX-T86 FOR GER/UK/FRA/NOR
/BEL/NLD/IRE/FIN/DEN/AUS/SPA/ITA/POR/SWE/CZE/HUN/GNR B53K531-261* √
1 LG3115051 1 MAIN PCB ASSY, FAX-T84 FOR /GER/UK/FRA/NOR
/BEL/NLD/IRE/FIN/DEN/AUS/SPA/ITA/POR/SWE/CZE/HUN/GNR B53K550-251* √
1 LG329302
8
1 MAIN PCB ASSY, FAX-T72 FOR CHE B53K550-228
*
√
1 LG311502
5
1 MAIN PCB ASSY, FAX-T74 FOR CHE B53K550-225
*
√
1 LG272503
4
1 MAIN PCB ASSY, FAX-T76 FOR CHE
√
1 LG329305
8
1 MAIN PCB ASSY, FAX-T82 FOR /CHE B53K550-258
*
√
1 LG311505
5
1 MAIN PCB ASSY, FAX-T84 FOR /CHE B53K550-255
*
√
1 LG273502
2
1 MAIN PCB ASSY, FAX-T74/T84 FOR POL B53K465-322
*
√
1 LG276203
2
1 MAIN PCB ASSY, FAX-T76/T86 FOR POL B53K472-232
*
√
2 LG287800
3
1 NCU PCB ASSY FOR GER/AUS B53K498-103
*
√
2 LG323800
5
1 NCU PCB ASSY FOR FRA B53K562-105
*
√
2 LG323801
0
1 NCU PCB ASSY FOR CHE B53K562-110
*
√
2 LG272600
4
1 NCU PCB ASSY FOR UK B53K485-104
*
√
2 LG272600
7
1 NCU PCB ASSY FOR NOR/FIN B53K485-107
*
√
2 LG323800
8
1 NCU PCB ASSY BEL/IRE/SPA/ITA/POR/CZE/HUN/GNR B53K562-108
*
√
2 LG272602
6
1 NCU PCB ASSY FOR NLD/SWE B53K485-126
*
√
2 LG272601
3
1 NCU PCB ASSY FOR DEN B53K485-113
*
√
2 LG274703
9
1 NCU PCB ASSY FOR POL B53K486-239
*
√
3 LG4431001 1 POWER SUPPLY PCB ASSY, (W/ AC CORD), FAX-T72/T74/T7Plus/T82/T84
FOR
GER/FRA/NOR/BEL/NLD/FIN/AUS/SPA/ITA/POR/SWE/CZE/HUN/POL/GNR
CHG √
3 LG3495003 1 POWER SUPPLY PCB ASSY, (W/ AC CORD), FAX-T76/T86
FOR GER/FRA/NOR/BEL/NLD/FIN/AUS/SPA/ITA/SWE/CZE/GNR √
3 LG4433001 1 POWER SUPPLY PCB ASSY,
(
W/ AC CORD
)
, FAX-T74/T84 FOR UK/IRE ch
g
√
3 LG349500
4
1 POWER SUPPLY PCB ASSY,
(
W/ AC CORD
)
, FAX-T76/T86 FOR UK/IRE
√
3 LG286301
0
1 POWER SUPPLY PCB ASSY,
(
W/ AC CORD
)
FOR CHE
√
3 LG286301
3
1 POWER SUPPLY PCB ASSY,
(
W/ AC CORD
)
FOR DEN
√
3 LG4435001 1 POWER SUPPLY PCB ASSY,
(
W/ AC CORD
)
, FAX-T74 FOR ZAF ch
g
√
3 LG349502
4
1 POWER SUPPLY PCB ASSY,
(
W/ AC CORD
)
, FAX-T76 FOR ZAF
√
4 UF4444001 1 SCREW, PAN
(
P WASHER
)
M4X6
√
*5 LG014000
3
1 OTPROM, FAX-T72 FOR GER
√
*5 LG025500
3
1 OTPROM, FAX-T72 FOR GER/AUS
[
FOR NEW DRIVE UNIT
]
√
*5 LG016400
3
1 OTPROM, FAX-T74 FOR GER/AUS
√
*5 LG026300
3
1 OTPROM, FAX-T74 FOR GER/AUS
[
FOR NEW DRIVE UNIT
]
√
*5 LG017000
3
1 OTPROM, FAX-T76 FOR GER/AUS
√
*5 LG027900
3
1 OTPROM, FAX-T76 FOR GER/AUS
[
FOR NEW DRIVE UNIT
]
√
5 LG040700
3
1 OTPROM, FAX-T82 FOR GER/AUS
√
5 LG041100
3
1 OTPROM, FAX-T84 FOR GER/AUS
√
5 LG041900
3
1 OTPROM, FAX-T86 FOR GER/AUS
√
*5 LG016600
4
1 OTPROM, FAX-T74 FOR UK/ZAF/GNR
√
*5 LG026500
4
1 OTPROM, FAX-T74 FOR UK/ZAF/GNR
[
FOR NEW DRIVE UNIT
]
√
*5 LG017200
4
1 OTPROM, FAX-T76 FOR UK/ZAF/GNR
√
*5 LG028100
4
1 OTPROM, FAX-T76 FOR UK/ZAF/GNR
[
FOR NEW DRIVE UNIT
]
√
5 LG041300
4
1 OTPROM, FAX-T84 FOR UK/GN
R
√
5 LG042100
4
1 OTPROM, FAX-T86 FOR UK/GN
R
√
*5 LG016200
5
1 OTPROM, FAX-T72 FOR FR
A
√
*5 LG025700
5
1 OTPROM, FAX-T72 FOR FRA
[
FOR NEW DRIVE UNIT
]
√
*5 LG016800
5
1 OTPROM, FAX-T74 FOR FR
A
√
*5 LG026700
5
1 OTPROM, FAX-T74 FOR FRA
[
FOR NEW DRIVE UNIT
]
√
*5 LG017400
5
1 OTPROM, FAX-T76 FOR FR
A
√
*5 LG028300
5
1 OTPROM, FAX-T76 FOR FRA
[
FOR NEW DRIVE UNIT
]
√
5 LG040900
5
1 OTPROM, FAX-T82 FOR FR
A
√
5 LG041500
5
1 OTPROM, FAX-T84 FOR FR
A
√
5 LG042300
5
1 OTPROM, FAX-T86 FOR FR
A
√
*5 LG014400
7
1 OTPROM, FAX-T74 FOR NOR/BEL/CHE/IRE
√
*5 LG026900
7
1 OTPROM, FAX-T74 FOR NOR/BEL/CHE
[
FOR NEW DRIVE UNIT
]
√
*5 LG018000
7
1 OTPROM, FAX-T76 FOR NOR/BEL/CHE/IRE
√
*5 LG029300
7
1 OTPROM, FAX-T76 FOR NOR/BEL/CHE
[
FOR NEW DRIVE UNIT
]
√
5 LG043100
7
1 OTPROM, FAX-T84 FOR NOR /BEL/CHE
√
5 LG044700
7
1 OTPROM, FAX-T86 FOR NOR /BEL
√
*5 LG016600
9
1 OTPROM, FAX-T74 FOR NLD
√
*5 LG028900
9
1 OTPROM, FAX-T74 FOR NLD
[
FOR NEW DRIVE UNIT
]
√
*5 LG017200
9
1 OTPROM, FAX-T76 FOR NLD
√
*5 LG018200
9
1 OTPROM, FAX-T76 FOR NLD/FIN/DEN/ITA/SWE
√
5X4582/5X4583/5X4588 FAX-T72/T74/T7Plus/T76/T82/T84/T86

LIST6 (PCB)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
*5 LG029500
9
1 OTPROM, FAX-T76 FOR NLD
[
FOR NEW DRIVE UNIT
]
√
*5 LG017600
9
1 OTPROM, FAX-T74 FOR NLD/FIN/DEN/ITA/SWE
√
5 LG043300
9
1 OTPROM, FAX-T84 FOR NLD
√
5 LG044900
9
1 OTPROM, FAX-T86 FOR NLD
√
*5 LG014201
0
1 OTPROM, FAX-T72 FOR CHE
√
*5 LG025901
0
1 OTPROM, FAX-T72 FOR CHE
[
FOR NEW DRIVE UNIT
]
√
5 LG042701
0
1 OTPROM, FAX-T82 FOR CHE
√
*5 LG0291011 1 OTPROM, FAX-T74 FOR IRE
[
FOR NEW DRIVE UNIT
]
√
*5 LG0297011 1 OTPROM, FAX-T76 FOR IRE
[
FOR NEW DRIVE UNIT
]
√
5 LG0435011 1 OTPROM, FAX-T84 FOR IRE
√
5 LG0451011 1 OTPROM, FAX-T86 FOR IRE
√
*5 LG027100
9
1 OTPROM, FAX-T74 FOR FIN/SWE
[
FOR NEW DRIVE UNIT
]
√
*5 LG028500
9
1 OTPROM, FAX-T76 FOR FIN/SWE
[
FOR NEW DRIVE UNIT
]
√
5 LG043701
2
1 OTPROM, FAX-T84 FOR FIN/SWE
√
5 LG045301
2
1 OTPROM, FAX-T86 FOR FIN/SWE
√
*5 LG028901
3
1 OTPROM, FAX-T74 FOR DEN
[
FOR NEW DRIVE UNIT
]
√
*5 LG029501
3
1 OTPROM, FAX-T76 FOR DEN
[
FOR NEW DRIVE UNIT
]
√
5 LG043901
3
1 OTPROM, FAX-T84 FOR DEN
√
5 LG045501
3
1 OTPROM, FAX-T86 FOR DEN
√
*5 LG019401
5
1 OTPROM, FAX-T72 FOR SPA
√
*5 LG026101
5
1 OTPROM, FAX-T72 FOR SPA
[
FOR NEW DRIVE UNIT
]
√
*5 LG017801
5
1 OTPROM, FAX-T74 FOR SPA
√
*5 LG027301
5
1 OTPROM, FAX-T74 FOR SPA
[
FOR NEW DRIVE UNIT
]
√
*5 LG018401
5
1 OTPROM, FAX-T76 FOR SPA
√
*5 LG028701
5
1 OTPROM, FAX-T76 FOR SPA
[
FOR NEW DRIVE UNIT
]
√
5 LG042901
5
1 OTPROM, FAX-T82 FOR SPA
√
5 LG041701
8
1 OTPROM, FAX-T84 FOR SPA/POR
√
5 LG042501
8
1 OTPROM, FAX-T86 FOR SPA/POR
√
*5 LG028901
6
1 OTPROM, FAX-T74 FOR ITA
[
FOR NEW DRIVE UNIT
]
√
*5 LG029501
6
1 OTPROM, FAX-T76 FOR ITA
[
FOR NEW DRIVE UNIT
]
√
5 LG044101
6
1 OTPROM, FAX-T84 FOR ITA
√
5 LG045701
6
1 OTPROM, FAX-T86 FOR ITA
√
5 LG026503
7
1 OTPROM, FAX-T74 FOR CZE
[
FOR NEW DRIVE UNIT
]
√
5 LG029303
7
1 OTPROM, FAX-T76 FOR CZE
[
FOR NEW DRIVE UNIT
]
√
5 LG044303
7
1 OTPROM, FAX-T84 FOR CZE/HUN
√
5 LG045903
7
1 OTPROM, FAX-T86 FOR CZE/HUN
√
5 LG026503
9
1 OTPROM, FAX-T74 FOR POL
[
FOR NEW DRIVE UNIT
]
√
5 LG028103
9
1 OTPROM, FAX-T76 FOR POL
[
FOR NEW DRIVE UNIT
]
√
5 LG044503
9
1 OTPROM, FAX-T84 FOR POL
√
5 LG046103
9
1 OTPROM, FAX-T86 FOR POL
√
6 08731081
5
1 TAPTITE, CUP B M3X8
√
7 ---
-
NOT USED
5X4582/5X4583/5X4588 FAX-T72/T74/T7Plus/T76/T82/T84/T86

LIST7 (ACCESSORIES)
REF No. CODE Q'TY DESCRIPTION REMARKS ORDER TO
BIUK
1 LE5499012 1 HANDSET ASSY, GRAY
(
1293
)
, FAX-T74
(
GRAY
)
/T76/T7Plus
√
1 LE549900
9
1 HANDSET ASSY, GRAY
(
1293
)
, FAX-T74
(
WHITE
)
/T86
2 UG3625001 1 TELEPHONE LINE CORD FOR GER
√
2 UG3627001 1 TELEPHONE LINE CORD FOR FRA
√
2 UG346900
0
1 TELEPHONE LINE CORD FOR CHE
√
2 UG3626001 1 TELEPHONE LINE CORD FOR UK
√
2 UG3629001 1 TELEPHONE LINE CORD FOR NO
R
√
2 UG1575001 1 TELEPHONE LINE CORD FOR BEL
√
2 UG3631001 1 TELEPHONE LINE CORD FOR NLD
√
2 LG3077001 1 TELEPHONE LINE CORD FOR IRE/SPA/ZAF/POR/CZE/POL/GNR
2 UG3632001 1 TELEPHONE LINE CORD FOR FIN
2 LG4566001 1 TELEPHONE PLUG FOR DEN
A
DD
√
2 UG1574001 1 TELEPHONE LINE CORD FOR DEN CHG
√
2 UG4205001 1 TELEPHONE LINE CORD FOR AUS
2 UG3634001 1 TELEPHONE LINE CORD FOR ITA
√
2 UG3635001 1 TELEPHONE LINE CORD FOR SWE
√
3 UG354300
4
1 CURLED CORD ASSY, FAX-T74
(
GRAY
)
/T76/T7Plus
3 UG354300
9
1 CURLED CORD ASSY, FAX-T74
(
WHITE
)
/T86
4 LE4375002 1 PAPER TRAY ASSY
√
4-1 LE4234002 2 PAPER GUIDE
5 ---
-
NOT USED
6 UF9869001 1 PAPER WIRE EXTENSION
7 ---
-
NOT USED
8 ---
-
NOT USED
9 LE4537001 1 PRINTING CARTRIDGE EXCEPT FOR UK
√
9 LE4550001 1 PRINTING CARTRIDGE FOR UK
√
(
9-1
)
LE4464001 1 PRINTING CARTRIDGE FRAME
√
(
9-2
)
LE4143001 1 REFILL ROLL
(
10M
)
, EXCEPT FAX-86 FOR UK
5X4582/5X4583/5X4588 FAX-T72/T74/T7Plus/T76/T82/T84/T86
