Brother MFC-9760 User manual

FACSIMILE EQUIPMENT
PARTS REFERENCE LIST
MODEL: MFC9760 / MFC9860 / MFC9880
(For Germany / United Kingdom / France /
Norway / Belgium / Netherlands /
Switzerland / Ireland / Denmark /
Austria / Spain / Italy / Sweden /
Euro Generic )
( For Australia / New Zealand / Asia )

© Copyright Brother 2001
All rights reserved
No part of this publication may be reproduced in any form
or by any means without permission in writing from the
publisher.
Specifications are subject to change without prior notice.

NOTES FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q' ty
(3) Description
Note: No orders without Parts Code or Tool No. can be accepted.
[Example] (1) (2) (3)
REF.NO. CODE Q' TY DESCRIPTION
RECOMMEND
REMARKS
2. Parts change will be informed by the technical information.
COUNTRIES
GERMANY ---- GER
UNITED KINGDOM ---- UK
FRANCE ---- FRA
NORWAY ---- NOR
BELGIUM ---- BEL
NETHERLANDS ---- NLD
SWITZERLAND ---- CHE
IRELAND ---- IRE
DENMARK ---- DEN
AUSTRIA ---- AUS
SPAIN ---- SPA
ITALY ---- ITA
SWEDEN ---- SWE
EURO GENERIC ---- GNR
AUSTRALIA ---- ARL
NEW ZEALAND ---- NZ
ASIA ---- ASA

LIST1(MAIN FRAME)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 LE1744001 1 MAIN MOTOR ASSY
2 087320616 4 TAPTITE, CUP S M3X6
3 LJ5701001 1 SOLENOID ASSY
4 000300415 1 SCREW, BIND M3X4
5 UL8984001 1 FRONT COVER LIN
K
6 LJ5704001 1 TONER SENSOR
(
LED
)
PCB
7 087320616 6 TAPTITE, CUP S M3X6
8 LE1166001 1 THERMISTOR FILM
9 LG2423001 1 IN CASING TEMPERATURE THERMISTOR
10 LJ4745001 1 FAN
11 UL9104001 1 TONER SENSOR
(
RECEIVER
)
PCB
12 LG2438001 1 PAPER EJECTION SENSOR PCB
13 087320616 21 TAPTITE, CUP S M3X6
14 LJ7403001 4 RUBBER FOOT
15 LJ8031001 1 2ND CASSETTE RELAY PCB
16 085411215 5 SCREW, BIND B TITE M4X12
17 LJ5703001 1 SOLENOID RELEASE SPRING
18 UL8972001 1 P/R CLUTCH LEVER
19 UL8971001 1 F/R CLUTCH LEVER
20 UL8982001 1 DEVELOP JOINT
21 UL8983001 1 JOINT SPRING
22 UL8959001 1 FRICTION SPRING
MFC9760, MFC9860, MFC9880

LIST2(LASER UNIT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 LJ5828001 1 LASER UNIT
(
SP
)
1
2 087321615 3 TAPTITE, CUP S M3X16
MFC9760, MFC9860, MFC9880

LIST3(PAPER TRANSPORT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 UL9059001 1 JOINT
2 UL9060001 1 PAPER FEED ROLLER ASSY
3 UL9062001 1 PAWLED BUSHING
4 UL9066001 1 PAPER PICK-UP ROLLER
5 UL9062001 1 PAWLED BUSHING
6 UL9069001 1 CONDUCTOR BUSHING
7 LJ4499001 1 ELECTRODE SPRING
8 LJ4843001 1 OUTER CHUTE 1
(
SP
)
9 LJ5591001 1 PICKUP ROLLER PLANETARY GEAR ASSY (SP)
10 UL9070001 1 GEAR 21
11 UL8985001 1 GEAR 59
12 LJ5705001 1 GEAR 21 PRESSURE PLATE
13 LJ5838001 1 FEED ROLLER PLANETARY GEAR ASSY (SP)
14 UL9049001 1 MANUAL INSERTION SENSOR ACTUATOR
15 UL9050001 1 REGISTRATION SENSOR ACTUATOR
16 UL9051001 1 REGISTRATION SENSOR SPRING
17 UU2042001 1 CASSETTE SENSOR ACTUATOR
18 UL9053001 2 TRANSFER ARM ADD
19 UL9052001 2 TRANSFER SPRING ADD
MFC9760, MFC9860, MFC9880

LIST4(PAPER TRAY)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 LJ4181001 1 PAPER TRAY ASSY
(
SP
)
1
1-1 UL9078001 1 SIDE GUIDE L, BLUE
(
6155
)
1-2 UL9079001 1 SIDE GUIDE R, BLUE
(
6155
)
1-3 U73515001 2 SCREW, CUP B M2.6X5
1-4 UL9083001 1 PAPER REAR GUIDE, BLUE
(
6155
)
1-5 UL9084001 1 SEPARATION PAD SUPPORT ASSY
1-6 UL9090001 1 SEPARATION PAD SPRING
MFC9760, MFC9860, MFC9880

LIST5(HEAT FIXING UNIT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 LJ7162001 1 FIXING UNIT, 230V
(
SP
)
1
1-1 LJ5682001 1 CLEANER ASSY
1-2 UH3635001 1 CLEANER SPRING 30
1-3 LJ5684001 1 HEAT ROLLER 25
1-4 UL8908001 2 HR BEARING 25
1-5 LJ5695001 1 HALOGEN LAMP, 230V
1-6 LJ5276001 2 EJECT PINCH ROLLER HOLDER L
1-7 LJ5277001 2 EJECT PINCH ROLLER HOLDER R
1-8 LJ5278001 8 EJECT PINCH ROLLER
1-9 LJ5279001 4 EJECT PINCH SPRING
1-10 LJ7877001 4 PICK OFF FINGER ASSY C CHG
1-11 087310615 4 TAPTITE, CUP B M3X6
1-12 LJ5686001 1 THERMISTOR ASSY
1-13 085311216 1 SCREW, BIND B TITE 3X12
1-14 LJ5734001 1 EJECT ACTUATOR 2
1-15 LJ5732001 1 EJECT ACTUATOR SPRING 2
1-16 LJ5736001 1 ACTUATOR HOLDE
R
1-17 LJ5735001 1 EJECT ACTUATOR 3
1-18 085311015 6 SCREW, BIND B TITE 3X10
1-19 UL8916001 2 PR BUSHING
1-20 LJ5690001 2 PR SPRING
1-21 LJ5268001 5 CLEANER PINCH ROLLER ASSY
1-22 LJ5287001 1 PRESSURE ROLLER 25
1-23 UL8920001 1 PAPER EJECT ACTUATOR
1-24 UL8921001 1 EJECT ACTUATOR SPRING
1-25 087312015 2 TAPTITE, CUP B M3X20
1-26 UL8923001 1 FU DRIVER GEAR
1-27 LM2047001 2 IDLE GEAR 13 chg
1-28 UL8910001 1 HR GEAR 34 add
2 087320815 1 TAPTITE, CUP S M3X8
3 LJ4740001 2 SHOULDER SCREW
4 LJ4432001 2 TAPE 32X12
5 LJ8841001 1 JAM SENSOR PCB ASSY
6 085311015 1 SCREW, BIND B TITE 3X10
MFC9760, MFC9860, MFC9880

LIST6(COVER)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 LJ5751001 1 MAIN COVER ASSY, GRAY
(
1495
)
2 UL9122001 4 PINCH ROLLER ASSY
3 UL9125001 4 PINCH ROLLER SPRING
4 LJ5763001 1 OUTER CHUTE, GRAY
(
1495
)
5 UL9127001 1 CHUTE SPRING L
6 UL9128001 1 CHUTE SPRING R
7 UU2102003 1 FRONT COVER ASSY, GRAY
(
1495
)
7-1 UU2094001 1 FRONT SUB COVER, GRAY
(
1495
)
7-2 087310815 1 TAPTITE, CUP B M3X8
8 LE1197001 1 PAPER SUB TRAY, GRAY
(
1495
)
9 LE1198001 1 PAPER SUB TRAY COVER, GRAY
(
1495
)
10 LE1291001 1 TRAY COVER ADHESIVE TAPE
11 UU2002001 1 REAR COVER, GRAY
(
1495
)
12 0A5401006 3 SCREW, PAN
(
S/P WASHER
)
M4X10
13 LE1200001 1 SCANNER MOUNT, GRAY
(
1495
)
14 UL9142001 1 EXIT ROLLER ASSY
15 LJ4125001 3 ANTI-STATIC BRUSH
16 LG2425001 1 SPEAKER UNIT
17 085320816 6 TAPTITE, BIND S M3X8
18 087321015 4 TAPTITE, CUP S M3X10
19 ---- NOT USED
20 UF9823001 2 SHOULDER SCREW
21 LE1202001 1 UPPER REAR COVER
22 087411216 2 TAPTITE, CUP B M4X12
23 LE1368001 2 SHOULDER SCREW BIND B M4X8
24 LG3260001 1 RELAY PCB ASSY 1
25 087311016 2 TAPTITE, CUP B M3X10
26 ---- NOT USED
27 ---- NOT USED
28 UU2045001 1 SWITCH COVER, MFC9860/9880
29 LG3360001 1 MAIN-PANEL HARNESS
30 LG3361001 1 MAIN-CCD HARNESS
31 LG3362001 1 MAIN-MOTOR HARNESS
32 ---- NOT USED
(33) UF5745000 1 MJ COVER, MFC9860, MFC9880 FOR
GER/UK/FRA/BEL/DEN/AUS/ITA/SWE
(34) LE8190001 1 SUB BACK COVER, MFC9860
MFC9760, MFC9860, MFC9880

LIST7(DOCUMENT SCANNER)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 LE7574001 1 SCANNER UNIT
(
SP
)
1
1-1 LE3338001 1 CCD MOTOR
(
INCLUDING HARNESS
)
1-2 0A4300605 2 SCREW, PAN
(
S/P WASHER
)
M3X6
1-3 LG2025001 1 PANEL HARNESS
1-4 LE3417001 1 PULLEY ASSY
1-5 LE7777001 1 CCD UNIT ASSY
(
SP
)
1
1-6 LE8487001 1 CCD FLAT CABLE ZLE
1-7 LE3423001 1 CCD DRIVE BELT
1-8 LE2082001 1 CCD LOC
K
1-9 LE2079001 1 COMPRESSION SPRING
1-10 087310815 10 TAPTITE, CUP B M3X8
1-11 LE2805001 2 TAPTITE, PAN B M3X10
1-12 LG2020001 2 FLAT CORE
(
CCD
)
1-13 087411216 4 TAPTITE, CUP B M4X12
1-14 087310815 1 TAPTITE, CUP B M3X8
1-15 LE2542001 1 FERRITE CORE SUPPORT
2 LE3500001 1 HARNESS SUPPORT CHG
3 LG2737001 1 DOCUMENT COVER SWITCH
4 LE0832001 1 TAPTITE, PAN P 1.6X8
5087311016 1 TAPTITE, CUP B M3X10
6 087310815 3 TAPTITE, CUP B M3X8
7LE7638001 2 SPACER del
MFC9760, MFC9860, MFC9880

LIST8(ADF&TRAY)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER
TO BIUK
1 LE1525001 1 ADF UNIT
(
SP
)
1
1-1 UG6609001 1 DOCUMENT SENSOR PCB
1-2 LG2014001 1 DOCUMENT SENSOR HARNESS
1-3 UF7026001 1 DOCUMENT FRONT SENSOR ACTUATO
R
1-4 LE2008001 1 DOCUMENT REAR SENSOR ACTUATO
R
1-5 LE2011001 1 COMPRESSION SPRING
1-6 LE2551001 1 RUBBER HOLDER
A
1-7 UU2055001 1 SEPARATION RUBBER
1-8 LE2550001 1 SPRING PLATE A ASSY
1-9 LE2470001 1 ADF FILM
1-10 UF6116001 1 TAPTITE, PAN B M3X6
1-11 UF9009001 2 PRESSER ROLLER
1-12 LE2471001 1 PRESSURE ROLLER SHAFT
1-13 LE2472001 2 PRESSURE ROLLER SPRING
1-14 LE1215001 1 ADF MOTO
R
1-15 LG2201001 1 ADF MOTOR HARNESS
1-16 0A4300605 2 SCREW, PAN
(
S/P WASHER
)
M3X6
1-17 LG2016001 1 GROUNDING WIRE
1-18 087310815 2 TAPTITE, CUP B M3X8
1-19 LE2026001 1 UPPER LF ROLLER
(
GRAY
)
1-20 LE2029001 1 LOWER LF ROLLER
(
BLACK
)
1-21 LE2028001 1 DOCUMENT EJECTION ROLLE
R
1-22 UF8105001 3 CONDUCTIVE BUSHING
1-23 UU7039001 4 LF ROLLER GEAR 27
1-24 LE2030001 1 WHITE ROLLER
1-25 LE2032001 2 WHITE ROLLER BUSHING
1-26 LE2033001 2 EXTENSION SPRING
1-27 LE2919001 1 DOCUMENT FEED ROLLER HOLDER ASS
Y
1-27-1 LE2037001 2 DOCUMENT FEED ROLLER
(
RUBBER
)
1-28 UU1290001 4 CONDUCTIVE BUSHING
1-29 UU7505001 1 ANTI-STATIC BRUSH
1-30 087320616 3 TAPTITE, CUP S M3X6
1-31 UF0208001 1 ADF ARM
1-32 LE2048001 1 DOCUMENT EJECTION CHUTE ASSY
1-32-1 LE2582001 2 PINCH ROLLER, GRAY
(
1267
)
1-32-2 UU2009001 2 PINCH ROLLER SPRING
1-33 LE2050001 1 ADF SIDE COVER F, GRAY
(
1495
)
1-34 LE2051001 1 ADF SIDE COVER R, GRAY
(
1495
)
1-35 LE2534001 1 ADF COVER ASSY, GRAY
(
1495
)
1-36 087320816 2 TAPTITE, CUP S M3X8
2 UF8088001 1 PLASTIC RETAINING RING
3 LE2053001 2 ADF SUPPORT
4 087310816 2 TAPTITE, CUP B M3X8
5 LE2056001 1 DOCUMENT TRAY, GRAY
(
1495
)
6 LE2487001 1 DOCUMENT SPONGE
7 LE3426001 1 DOCUMENT TRAY ASSY
8 LE2567001 2 HINGE A, BLACK
9 087311015 6 TAPTITE, CUP B M3X10
10 LE2777001 1 DOCUMENT SUPPORT, GRAY
(
1495
)
11 087320816 1 TAPTITE, CUP S M3X8
12 LE2568001 2 HINGE HOLDER
A
13 LE1568001 1 DOCUMENT TRAY REINFORCEMENT PLATE
14 UF6116001 1 TAPTITE, PAN B M3X6
MFC9760, MFC9860, MFC9880
