Brother BAS-311F-0 Guide

RECOMMENDABLE SPARE PARTS LIST FOR BAS-311F
NAME P/NO. Q'TY
SET SCREW, SM3.57 144458001 1
SCREW PAN SM4.37-40x5 062680512 2
CROSS ROLLER S42778000 2
LINEAR BUSH S35183000 2
Y-TIMMING BELT S10077100 1
LINEAR GUIDE SET, 311 S59741000 2
X-TIMMINGBELT, A311 S42790000 1
X-TIMMINGBELT, B311 S42793000 1
SCREW S10352101 2
PRESSER FOOT
A
S42843001 1
SCREW, SM3.57x12 S13399001 1
SHUTTLE RACE THREAD GUIDE S02429101 1
DRIVER HR S55215001 1
BOBBIN CASE ASSY, B 152686101 1
TENSION SPRING B 144588001 1
SCREW, BOBBIN CASE SPRING S16492101 1
BOBBIN TENSION SPRING S15667001 1
BOBBIN, L
A
S15665001 4
RIBBER RING 120448051 1
KNIFE 157968001 1
MOVABLE KNIFE ASSY S10205001 1
WASHER, MOVABLE KNIFE(T=0.4) S10208001 1
WASHER, MOVABLE KNIFE(T=0.5) S10208002 1
WASHER, MOVABLE KNIFE(T=0.6) S10208003 1
MOVABLE KNIFE COLLAR S00705001 1
SCREW , SM4.37 S10209101 1
FIXED KNIFE S10210201 1
SCREW, SM2.38 111140002 2
SCREW, FLAT SM4.37 100032004 2
NEEDLE HOLE PLATE, F S10213001 1
WIPER S10470101 1
SCREW , BIND SM4.37-40x5 060680512 1
WIRE ASSY WORK CLAMP LIFTER S42868001 1
SENSOR HARNESS ASSY H/P S56166000 1
SYNCRONIZER ASSY S48666001 1

MAIN PCB ASSY S53884001 2
FUSE, 5A FB S08030000 2
FUSE, 6
A
153242000 2
3.5 MEDIA 2HD S43273000 1
POWER SUPPLY PCB ASSY S49939001 1
PANEL PCB ASSY S56151000 1
FDD 3.5 S43224000 1
2 PEDAL FOOT SW HARNESS ASSY , 3 S42259000 1
FUSE 7A：FB S48580000 3
SOLENOID VALVE S43683001 1
