Broyhill CRESTFIELD GBO23-904-2 User manual

ASSEMBLY INSTRUCTIONS
ITEM# : GBO23-904-2
SKU# : 810580411
CRESTFIELD ALL WEATHER WICKER ARMLESS
SOFA WITH CUSHIONS
Need help? We are here for you! 1-888-733-8169 Toll Free
Or email us at [e-mail],[e-mail]
[e-mail]

Read all instructions before starting
Clear a flat covered space to begin assembly
Always best to do it with a friend
Note that hardware required is provided for every step
Pay attention to orientation
Number of the hardware corresponds to its letter in the package
Helpful hints provided along the way
Retain these assembly instructions for future reference.
WARNINGS:
Use the correct bolts as indicated. All bolts should be hand tightened until the complete piece is assembled ( This will make the assembly
process much easier ). Once the piece is fully assembled, then go back and tighten all bolts with provided tool.
Regularly check hardware and tighten if necessary.
Use the correct bolts as indicated. Do not tighten any of the bolts until the sofa is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
Keep children and pets away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Sofa is for sitting purposes only. Standing on or misuse of sofa may result in damage or injury.
Weight limit is 300 lbs ( 136.4 kg). Not intended for commercial use.
MAINTENANCE
Wash frame and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or other solvents on
the frame or fabric parts.
The cushions may be washed on the surface only by using mild soap and water or a commercial foaming upholstery cleaner if necessary.
If washed, rinse well and hang to dry. Do not machine wash or dry.
Well recommend the use of furniture covers when not in use.
Inspect and tighten all of the bolts and fasteners on a regular basis to ensure the proper performance and safety of your sofa.
In order to prolong the life and beauty of your sofa, we recommend that it be stored in a dry and protected area during off season periods.
GENERAL BEST PRACTICE FOR ASSEMBLY:
WARNINGS:
MAINTENANCE:

PARTS LIST
Part No. Part Qty Image
Part
No.
Part Qty Image
1Left Sofa Back 1 6Long Bolt
(M6x40mm) 12
2Right Sofa Back 1 8Washer 12
3Seat Panel 1 10 Seat Cushion 1
4Side Panel 1 11 Left Back Cushion 1
14 Left Side Panel 1 12 Right Back Cushion 1
5Connection Lock 2
Tools
PARTS LIST FOR CORNER SOFA:

STEP 1
PART REQUIRED: 1, 2
Keep the bolts loose.
STEP 1
X2
X2
PRODUCT FRAME MAP
8
1
6
2
3
14
4
2
1
8
6

STEP 2
PART REQUIRED: 1, 2 & 3
Keep the bolts loose.
STEP 3
PART REQUIRED: 14
STEP 2
X2
X2
STEP 3
6
2
3
1
8
X2
X4
8
8
6
6
8
6
8
6
14

STEP 3
PART REQUIRED: 4
Keep the bolts loose.
STEP 3
PART REQUIRED: 10, 11 & 12
Finished!
STEP 5
STEP 4
X4
X4
8
6
4
12
10
11
8
6

REQUIRED: Sectional Set CTN#1 - Right Arm Sofa & Left Arm Sofa and CTN# 2 - Corner Sofa
Two other connection locks are included in the hardware pack for sectional sofa set CTN#1 - Right Arm
Sofa & Left Arm Sofa.
PLEASE FIX SOFA SEAT TOGETHER WITH PROVIDED.
Warranty
One year limited warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
It remains the customer's responsibility for freight and packing charges to and from the service center.
REMINDER
12
5
FIX ONE SIDE OF CONNECTION LOCK (5) FIRSLY,
THEN FIX ANOTHER SIDE
