Broyhill Sandpointe H21GT722VS User manual

ASSEMBLY INSTRUCTION
ITEM#: H21GT722VS
SKU#: 810554528
SANDPOINTE SIDE TABLE
Need help? We are here for you! 1(877) 800-6021 • Toll Free
[email protected] • Email Address

Read all instructions before starting
Clear a flat covered space to begin assembly
Always best to do it with a friend
Note that hardware required is provided for every step
Pay attention to orientation
Letter of the part corresponds to a sticker on the product
Number of the hardware corresponds to its letter in the package
MAINTENANCE:
WARNINGS:
GENERAL BEST PRACTICES FOR ASSEMBLY:
Helpful hints provided along the way
Retain these assembly instructions for future reference
PAGE 1 OF 4
Regularly check hardware and tighten if necessary.
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
Do not sit or stand on this table.
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Table is not to be used as a seating surface. Improper use of this product or failure to use may result in injury.
Do not place hot objects over 80 degrees on surface. Do not allow glasses to stand on the table surface under
the sun for a long time to avoid damage caused by high temperatures. Do not use abrasives or sharp tools when
cleaning surface.
Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or
other solvents on the frame parts.
Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and safety of your table.
When moving the table, lift. Do not drag this table.
We recommend the use of furniture covers when not in use.
In order to prolong the life and beauty of your table, we recommend that it be stored in a dry and protected area
during off season periods.
To Ensure Alignment & Easy Assembly, Secure All Bolts & Washers In Place Before Fully Tightening

PAGE 2 OF 4
PARTS LIST
STEP 1
PARTS REQUIRED: 1, 2, 4, & 6
Keep the bolts loose.
x8 x8
4 6
H21GT722VS-ZM
H21GT722VS-JG
TABLE TOP
LEG
PART
NO. MATERIAL CODE PART Q’TY
1 1
1
22
3
CENTER CONNECTOR
H21GT722VS-ZJ 612
DP-d6.5-D13
WASHER d6.5*D13*1.0
4LS-M6-15 8
BOLT M6*15
500 10 20 30 40 60 70 80 90
mm 100
Tools
1
2
2
5LS-M6-30 4
BOLT M6*30
PART
NO. MATERIAL CODE PART Q’TY
44
66
Note:
The arrows marks on the legs (#2) should coincide with
Figure 1 to ensure proper assembly.

PAGE 3 OF 4
STEP 3
STEP 2
PARTS REQUIRED: 2, 3, 5, & 6
Tighten all bolts by using the supplied Hex key.
x4 x4
5 6
Warranty
• One–year limited warranty.
• Proof of purchase (dated register receipt) is required for warranty claims.
• It remains the customer’s responsibility for freight and packing charges to and from the service center.
2
2
3
5
6

The store where you made your purchase does not stock parts for this item.
If you need parts, whether they are missing or damaged,
STOP!
Missing A Part? No Need To Go Back To The Store
Call us between 9:00 AM and 4:30 PM Eastern Time Monday through Friday
For further assistance, please visit us at [email protected]
Call Toll Free:
TEL: [phone]
PAGE 4 OF 4
