Brullen i91 PLUS User manual
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
i91 PLUS
BRULLEN
www.brullen.com.au
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Counter Top model
Model:Brullen i91 Plus
Italian gear pump, high capacity,
45% overrun adjustable.
Agitator in hopper and pre-cool fresh keep system
Overnight Keep Fresh system
Voltage: 220V/50-60Hz or 380V/50-60Hz
Installation Precautions
1) 15A plug base. The max length of electric cable from
distribution cabinet to plug base is 20m.
2) In order to ensure Brullen i91 Plus works normally,
the distribution cabinet should supply 4kw power.
3) The distance between the machine and the wall or to
other objects nearby should be more than 80mm(better
20CM). The ventilation of the machine should be keep
fluent and free from dust, its free space should be as
large as possible and channels present so that hot air
can be ventilated away easily. (Ref. figure 1)
4) The beater direction should be anti-clockwise.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Dimensions of Brullen i91 Plus
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Keyboard and Button Function
Notices:
Three button function. Only press
button then
You can change other function, otherwise the button is invalid.
1 ) Button Function
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
2 ) LCD Symbol Indicators
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Keyboard for Machine Protection Alerts
Failure light
On
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Note: During washing, all parts of discharge door and pump need
to be clean, then assembled according to figure 2. And figure 3.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Discharge Door Assembly
Assembled discharge door must be assembled according to
diagram.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Pump Assembly
Regulating valve of the percentage of air and mixtures. 4marks on the
valve. The smallest mark, more air and less mix into cylinder, so high
overrun. The biggest mark, less air and more mix into cylinder, so
lower overrun.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Beater Assembly
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
How to make Soft Serve
1）Connecting the power, should be 15A plug base.
2) Turn power switch to “ON”, the LCD screen is on
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
3）Removed pump injection pipe
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
4) Pour about 4L of water to each hopper and press
washing button. Meanwhile, press two pump button to
check if pumps can suck water. If suck water, ok. Otherwise
need to install pumps until it can suck water.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
5）cleaning the hopper and dispense dirty water out.
repeat step 4) until clean the machine is thoroughly clean
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
6) Put ice cream mixtures into both hoppers and press
washing button. Meanwhile press both pump buttons to
check if the pump sucks water. If so, ok.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
7) Install injection pipe with hopper, but don’t connect with
pump. Then dispense out 500ml ice cream mix from each
flavour and put back into the hopper. Then connect the
injection pipe with pump, and then press two air pump
button to let pump such mixtures into cylinder until pump
stops.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
Press two air pump button to let pump such mixtures into cylinder until it pump
stops.
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
9) Press Ice Cream making button to make Ice Cream
Australian Design - German Engineering
Soft Serve Ice Cream & Frozen Yogurt Machines
Ice Cream Machine
OPERATOR MANUAL
10）If the ready light is on,You can dispense ice cream.
