Brunswick 51906535000 Installation guide

ASSEMBLY
INSTRUCTION MANUAL
CORNER KICK
FOOSBALL TABLE
ITEM NO. 51906535000
REV.1 DATE: March 2021

1) Your table is designed for use indoor only. Damage can occur if the table is
exposed to water, dampness, high humidity, freezing temperatures, etc.
2) The foosball table is heavy. Two or more people are required for assembly.
3) Only use the table for its intended purpose.
4) Damaged or worn parts may be dangerous for users and the integrity of the table.
will void the warranty.
6) Check all screws, bolts, etc. on a regular basis to ensure that they are in good working
p.1
Please keep the balls, lubricant and other parts out of reach of children and pets.
7)
8)
9) Please use care when pushing or pulling the rods so people or objects nerby do not get
injured or damaged.
This is not a toy. Adult supervision is recommended when being used by children.
Congratulations! we hope you will have many hours to use
your new Foosball table and enjoy the pleasure it brings to
you!
Supplier

Part List
#1 #2 #3 #4 #5
#6 #7 #8 #9 #10
#11 #12 #13 #14 #15
Legs
4PCS
#16
#21
#26
5/16”*3/4”Washers
20PCS
2PCS
Side Apron
2PCS
End Apron
2PCS
Playfield
1PC
5/16”*1-3/8”Bolts
8PCS
F3.5*35mm Screws
8PCS
5/16“*2-1/4”mm Bolts
12PCS
Counters
2PCS
p.2
Connecting Long Bolt
720mm 2PCS
2PCS
#18 #19 #20
#17
#23 #24 #25
#22
#28
#27
8#*1-1/4" Bolts
22PCS
3-Man Rods 1142mm
#29 #30
#31 #32 #33
8#*1" Bolts
4PCS
#34 #35
#36
5-Man Rods 1028mm
Goalie Rods 1097mm
2PCS
2PCS 2PCS 2PCS
2-Man Rods 1271mm
5/16” Nuts
12PCS
Bumpers
16PCS
Plastic Washers
16PCS
Bushings
4PCS
Triangle Blocks
4PCS
Rod Handles
8PCS
Wrench
1PC
Leg Levelers
4PCS
Rod End Caps
8PCS
5mm Allen Keys
2PCS
Ball Collectors
2PCS
8PCS
Bracket
Leg Panels
8PCS
WP4*65mm White
M8*22mm Bolts
4PCS
Nuts
26PCS
Players
22PCS
#37 #38 #39 #40
1PC
Lubricant
F4*1” Screws
4PCS
T4x15mm Screws
16PCS
T4*12 mm Screws
32PCS
Bracket
4PCS
Soccer Balls
4PCS
Playfield Support Beam

Attach the other #1 Side Apron and #2 End Apron using #19 Bolts and #18 Flat Washer
as shown in FIGURE 1. Using #39 Wrench to tighten all #19 Bolts on this time.
p.3
#19
#18
#1
#2
STEP 1
Attach #1 Side Apron onto #2 End Apron using # 19 Bolt and #18 Flat Washer as shown
in FIGURE 1. Using #39 Wrench to tighten the #19 Bolt. Do not overtighten #19 Bolt on this time.
Attach #3 Playfield onto the #1 Side Apron and #2 End Apron as shown in FIGURE 1.
Find a clean, level place to begin the assembly of your foosball table. We recommend building the
table on the box top to protect the parts during assembly.
It is very important to assemble table on a level and flat surface. This will keep the end aprons and
side aprons “FLUSH” on the top and bottom edges.
FIGURE 1
#3
#3

p.4
#3
#13
#2
#3
#13
#2
d
#35
#35
#13
STEP 2
Attach #1 Side Apron onto #2 End Apron using #10 Bracket and pre-drilled holes with #9 Screws
as shown in FIGURE 2.
Attach #3 Playfield onto #2 End Apron using #13 Screws as shown in FIGURE 2.
Attach #3 Playfield onto #1 Side Apron using #35 Triangle Blocks as shown in FIGURE 2.
FIGURE 2
#11
#12
#11
#12
Attach #11 Connecting Long Bolts onto the table cabinet using #12 Bolts as shown in FIGURE 2.
Using #39 Allen wench to tinghten the #12 Bolts.
#10
#9

p.5
STEP 3
FIGURE 3
#8
#7
#6
#10
#9
#40
Attach #6 Playfield Support Beam onto the table cabinet using #7 Bracket and #8 Screws as
shown in FIGURE 3.
Attach #40 Ball Collectors onto the table cabinet using #9 Bracket and #10 Screws as shown
in FIGURE 3.

p.6
STEP 4
THIS STEP REQUIRES FOUR OR MORE ADULTS.
VERY CAREFULLY TURN THE TABLE OVER AND SET IT ON
ITS LEGS. BE CAREFUL. THE TABLE IS VERY HEAVY.
DO NOT LEAN THE
TABLE ON ITS LEGS
HOLD TABLE
CABINET DO NOT HOLD THE LEGS
Attach the #4 Legs onto the #1 Side Apron using #16 Bolts, #18 Washers and #17 Nuts as shown
in FIGURE 4.Use #38 Wrench and #39 Allen Wrench to tighten all legs.
Attach the #5 Leg panels onto the #4 Legs using #24 Screws as shown in FIGURE 4.
#20
#5
#4
#24
#16
#17
#18
Screw #20 Leg Levelers into the bottom of each leg as shown in FIGURE 4.
Very carefully turn the table over and set it on its legs.
FIGURE 4

p.7
STEP 5
Attach the #29 Players on to the Player Rods(#25-28), using #21 Bolts and #23 Nuts as
shown in FIGURE5.
Attach the #34 Bushings onto the #25 Player Rods, using #22 Bolts and #23 Nuts as
shown in FIGURE5.
FIGURE 5
Slide the Player Rods (#25-28) through the table bushings at one side of the table in the
order shown in FIGURE 5.
#25
Length Comparison
#28
#30
#31
#21
#23
#29
#27
#25
#26
#28
#22
#34
#23
Hole
Short
Long
Hole
Place one #30 Bumper, and one #31 Plastic washer on either side of each Player
Rod (#25-28) shown in FIGURE 5.
Now slide the Player Rods (#25-28) through the bushings at the other side of the table.

p.8
STEP 6
FIGURE 6
#33
#32
#15
#14
TABLE MAINTENANCE
TABLE
SURFACE
Keep your table covered. If there is dust on the playfield or the aprons, use a vacuum or wipe
RODS or press the rods too aggressively, as this may cause damage . We recommend the use of
lubricant to wipe the Player Rods and Bearings from the outside of the game so as not to drip
onto the playfield.
LEGS
METHOD hit by external force or used rough.
down squarely on the legs, do not drag the table.
#37 b c
a
DETAIL A
Attach the #14 Counters onto #2 END Aprons using #15 Screws. Tighten but DO NOT Strip out
screws.
Insert the #33 Rod Handles onto the rods end.
Insert the #32 Rod Ende Cape onto the rods end.
Spray the #37 lubricant into a clean, soft cloth and then use the cloth to wipe the player rods
where they come into contact with the bearings as shown in DETAIL A.

p.9
Flip A Coin
is scored, the rule is that the team who was last scored on gets to serve the next ball. This rule keeps the
game fair for both opponents. The foosball must be touched by a man before the ball goes into a goal for
a legal goal to occur.
No Spinning
This is deemed an illegal move in the rules of foosball.
No Jarring - Jarring is a rule for when a player slams his or her rods against the wall of the foosball table in
no jarring allowed at any point during a game. This is not the same as when a player on the opposite team
player hits the wall of the table with enough force to jar the ball or distract the opponent. That is why this
Dead Balls - If a foosball stops in the middle of two opposing team rods, the ball must be picked up and
reserved. The serve goes back to the team that was last scored on. If a dead ball occurs on the defensive
side of the table behind the defensive 2 bar, the defensive player must move the ball back into playing
Out of Play - If a ball comes off the table area or hits a top rail and comes back into the table area, the
ball is ruled out of play and must be reserved by the team that was last scored on.
5 Bar Passing
These passing rules do not apply to the other foosball rods, just the 5 bar. You are required to pass the ball
serve,
you then are allowed 15 seconds to pass from the 5 bar. A ball cannot be completely stopped on the
5 bar and passed forward to the 3 bar, it must be moving and touch 2 men on the 5 bar before being
GAME RULES:
--
-
---
-
-
-
the
