Bryan Boilers Knockdown RV-500 User manual

EFFECTIVE DATE:
REPLACES:
4. DIMENSIONS ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
1. ALL DIMENSIONS ARE IN
INCHES. THOSE IN PARENTHESES
2. LOCATION DIMENSIONS
3. GAS TRAIN, CONTROL AND
BURNER CONFIGURATION WILL
VARY DEPENDING ON JOB
SPECIFICATIONS & CONDITIONS.
NOTES:
CONSULT FACTORY FOR
CERTIFIED DIMENSIONS.
ARE ALL ±1/2".
ARE CENTIMETERS.
BRYAN BOILERS
ORDERNO.:
PERU, INDIANA 46970
783 NORTH CHILI AVE
FORM NO.: 1770
RV SERIES FORCED DRAFT INDIRECT
WATER HEATERS (RV500 - RV800)
CONSULT FACTORY FOR BURNER EXTENSION APPLICATIONS
25 1/2"
B
A
(64.8)
9 1/4"
(23.5)
20"
50"
(127.0)
(50.8)
(81.3)
32" MINIMUM TUBE
REMOVAL CLEARANCE
48"
BURNER
SERVICE AREA
(121.9)
80 1/8"
90"
33 1/2"
(203.5)
(228.6)
(85.1)
17
19
18
14 3
7
13
9
REAR VIEW LEFT SIDE VIEW FRONT VIEW
PLAN VIEW
D
H
C
G
2
15
510
4/18/01
7/24/03
UNLESS OTHERWISE NOTED.
5. ALL FLANGES ARE 150#
5. CONTROL TAPPINGS 3/4" NPT
2. FORCED DRAFT BURNER
4. EXPANSION TANK (LOOSE)
3. RELIEF VALVE
1. PROBE TYPE L.W.C.O.-
19. COMB. CHAMBER DRAIN 1" NPT
18. FLAME OBSERVATION PORT
17. HEIGHT OVER SUPPLY
16. INDIRECT HEAT EXCHANGER
15. DRAIN CONNECTION 2" NPT10. VENT/EXP. TANK CONN. 1" NPT 20. DRAIN VALVE (BY OTHERS)
14. LIFTING LUGS
13. OIL PUMP LOCATION
12. FILL VALVE
9. ELEC. ENCLOSURE-
8. CLNOUT./INSP. OPNG.-1 1/2"NPT
7. PRESS./TEMP. GAUGE
6. JACKET ACCESS PANELS
ORDER REV. NO.:
G-SUPPLY / RETURN NOZZLE SIZE
D-LENGTH OVER BASE
C-FLUE DIAMETER
B-FLUE LOCATION
A-LENGTH OVER JACKET
BOILER MODEL
H-BURNER EXTENSION
16"
(40.6)
6" FLG
(152)
130 1/4"
(330.8)
18 3/4"
(47.6)
18 3/4"
(47.6)
16"
(40.6)
(152)
6" FLG
(15.2)
6" FLG
143 1/4"
(363.9)
152 3/4"
(388.0)
175 1/4"
(445.1)
16"
(40.6)
20 3/4"
(52.7)
20"
(50.8)
163"
(414.0)
175 3/4"
(446.4)
185 1/4"
(470.5)
214 1/2"
(544.8)
RV500WT RV550WT RV600WT RV700WT
6
4 1/2"
2 1/8"
3" NPT
1/2"
NPT
DRAIN
4 PASS EXCH. HEAD (STD.)
(SEE NOTE #6)
6. SEE FORMS 1594 AND 1595
FOR FLOW RATES AND PRESS.
DROPS OF 2 AND 4 PASS
HEAT EXCHANGERS.
6 1/4"
4" NPT
2 PASS EXCH. HEAD (OPT.)
(SEE NOTE #6)
DETAIL 1
(222.3)
87 1/2"
4
12
16
20
9"
(22.86)
(SEE DETAIL 1)
G
J2
RV800WT
197 3/4"
(502.3)
20 3/4"
(52.7)
20"
(50.8)
237 1/4"
(602.6)
6" FLG
(15.2)
J1-HT. EXCH. REMOVAL CLR.
75"
(1905)
75"
(1905)
88"
(223.5)
101"
(256.5)
101"
(256.5)
STOP
VALVE
McDONNELL
REMOTESENSOR
J2-HT. EXCH. REMOVAL CLR.
75"
(1905)
88"
(223.5)
88"
(223.5)
101"
(256.5)
114"
(289.6)
6" FLG
(152)
J1
18 3/4"
(47.6)
(SEE DETAIL 1)
16
RETURN
SUPPLY

BRYAN BOILERS RV SERIES FORCED DRAFT
INDIRECT WATER HEATERS
Form # >> 1770
Date >> 9/5/2003
BOILER MODEL RV500 RV550 RV600 RV700 RV800
INPUT MBH 5,000 5,500 6,000 7,000 8,000
(KW) 1,465.0 1,611.5 1,758.0 2,051.0 2,344.0
OUTPUT* MBH 4,000 4,400 4,800 5,600 6,400
(KW) 1,172.0 1,289.2 1,406.4 1,640.8 1,875.2
BOILER HORSEPOWER HP 119 131 143 167 191
(KW) 1,171.0 1,288.1 1,405.2 1,639.4 1,873.6
TUBE DIAMETER INCHES 1.50 1.50 1.50 1.50 1.50
(CM) 3.81 3.81 3.81 3.81 3.81
NUMBER OF TUBES 67 75 81 95 109
PRESSURE VESSEL
VOLUME GAL 200 216 236 278 309
(L) 757.0 817.6 893.3 1,052.2 1,169.6
HEATING SURFACE SQ FT 597 668 722 847 973
(SQ M) 55.5 62.1 67.1 78.7 90.4
INDIRECT HEAT EXCHANGER
HEAT EXCHANGER #1 INCHES 66 79 79 92 92
UTF2-68-(#) OR UTF4-64-(#) (CM) 167.6 200.7 200.7 233.7 233.7
HEAT EXCHANGER #2 INCHES 66 66 79 92 105
UTF2-68-(#) OR UTF4-64-(#) (CM) 167.6 167.6 200.7 233.7 266.7
OPERATING WEIGHT LBS 11,167 12,151 13,138 15,028 16,811
(KG) 5,065.5 5,511.6 5,959.2 6,816.6 7,625.5
SHIPPING WEIGHT LBS 9,500 10,350 11,170 12,710 14,235
(KG) 4,309.2 4,694.8 5,066.7 5,765.3 6,457.0
RELIEF VALVE TYPICAL - 30 PSIG (206.8 KPA)
QUANTITY (2) 740 (2) 740 (2) 740 (2) 740 (2) 740
SIZE INCHES 2 x 2½ 2 x 2½ 2 x 2½ 2 x 2½ 2 x 2½
(CM) 5.08 x 6.35 5.08 x 6.35 5.08 x 6.35 5.08 x 6.35 5.08 x 6.35
CAPACITY-TOTAL MBH 10,500 10,500 10,500 10,500 10,500
(KW) 3,076.5 3,076.5 3,076.5 3,076.5 3,076.5
RELIEF VALVE TYPICAL - 125 PSIG (861.8 KPA)
QUANTITY (1) 174A (2) 174A (2) 174A (2) 174A (2) 174A
SIZE INCHES 1½ x 1½ 1¼ x 1¼ 1¼ x 1¼ 1¼ x 1¼ 1¼ x 1¼
(CM) 3.81 x 3.81 3.17 x 3.17 3.17 x 3.17 3.17 x 3.17 3.17 x 3.17
CAPACITY-TOTAL MBH 6,460 10,740 10,740 10,740 10,740
(KW) 1,892.8 3,146.8 3,146.8 3,146.8 3,146.8
* Output based on nominal 80% of input. Actual combustion efficiencies will vary and are fuel dependant.
(#) - - Indicates length of exchanger.
