BSL EM-R100 User manual
1
Think Like A Customer! CONFIDENTIAL
EM-R100 User Manual
We think people
We think healthy hearing
We think people
We think healthy hearing
2
Think Like A Customer!
EM-R100 Table of Content
We think people
We think healthy hearing
2. Power / Pairing
3. Hearing Through
Remote Microphone
4. Battery Check/
Recharge
1. EM-R100 Structure
5. EM-R100 Specification
We think people
We think healthy hearing
3
Think Like A Customer!
1. EM-R100 Structure
We think people
We think healthy hearing
Bottom
LEDButton Charging Port
Clip
⑤
①Upper ② ③ ④
⑥
We think people
We think healthy hearing
4
Think Like A Customer!
2. Power / Pairing
•Power
➢Power On / Off operates even when USB cable is connected
➢Plugging and unplugging the charger does not affect the Power On / Off status.
➢LED blinks 3 times according to the battery level after Power On
➢Red LED blinks 4 times every 5 seconds when battery is low.
•Pairing
➢Auto Pairing : When there is no connection history, the EM-R100 automatically enters Pairing Mode after Power
On
➢Manual Pairing : When you are trying to connect to another device with a connection history.
Function State Key LED
Power On
Power On
Button Press 1
Second
Blue
1 Second On
→ Battery level LED
Power Off
Power Off
Button
Press 3 Seconds
Red
1 Second On
Function State Key LED
Auto Pairing OFF(Connection histroy
X)
Button 1s
-
Pairing →Red/Blue blinks alternately
-
Auto power off after 3 minutes
-
Connected →Blue
blinking 2 times
Manual Pairing
OFF(Connection
history
O)
Button 3s
We think people
We think healthy hearing
5
Think Like A Customer!
3. Hearing Through Remote Microphone
•Sink device (EM-C110) connected with Mic input sound playback automatically
➢Place the EM-R100 and EM-C110 closely when in pairing mode.
➢Be sure to turn off the BeethoSOL mode of the EM-C110 when using the EM-R100.
➢When EM-R100 and EM-C110 are paired and connected, it will automatically play the sound.
➢After EM-R100 or EM-C110 is rebooted, it will pair automatically, and sound will be played back.
•EM-C110 <-> Connect with Smartphone
➢When RM-R100 and EM-C110 are connected and EM-C110 and smartphone are connected, rebooting
the EM-C110 will connect both EM-R100 and smartphone. EM-R100 mic sound will be played by
default.
➢EM-C110 plays a call sound without playing the EM-R100 sound when calling / receiving a call with
smartphone.
➢At the end of the call, the EM-R100 sound will be played again.
•Volume Adjustment
➢You can adjust the volume of the Mic sound played when connecting EM-R100 and EM-C110 with the
jog switch of EM-C110.
Function State Key LED Audio Indication
(Voice Prompt / Tone)
Volume Up
Every Status
‘Vol.Up’ press
up -
Vol 0: long low beep 1 time
Vol 1~14: short beep 1 time
Vol 15: short high beep 1 time
Volume
Down
‘Vol.Down’ pre
ss down
We think people
We think healthy hearing
6
Think Like A Customer!
4. Battery Check / Charging
•Manual Battery Check
•Charging
➢Open the USB port on the bottom and charge USB
Function State Key LED
Battery Check
Power
on (Charger not
connected)
Button
Press 2 Times
100 ~ 70%
-> Blue 3 Times
70 ~ 20% -> Purple 3 Times
20 ~ 0% -> Red 3 Times
Function Key Remaining Battery LED
Charging Charger
Connected
100% Blue
80% Above Purple
80% Below Red
We think people
We think healthy hearing
7
Think Like A Customer!
5. EM-R100 Specification
Feature Spec.
EM-R100
H/W
AUDIO DSP X
Mic Amp Applied
Microphone 1 Mic
LED 3-Color, Side view (Blue, Purple, Red)
Button & Key 1EA (TACTILE)
Charger I/O Micro USB B
Bluetooth Version 5.0V
Body
Clip Clip Type
Color Navy Blue / Black
Weight (mm) 12g
Size (mm) 49.05 x 30.37 x 7.81 (Except Clip Thickness)
Time
Battery DC 3.7V / 210mAh
Operation Time 10Hrs
Charging Time 2.5Hrs
Output power E.I.R.P 4.00 dBm @2402~2480 MHz
Function Sound Amplifying Function
We think people
We think healthy hearing
9
Think Like A Customer!
FCC Warning Statement
FCC Part 15.19
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Part 15.21
Any changes or modifications (including the antennas) to this device that are not expressly approved by the
manufacturer may void the user's authority to operate the equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment.
This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
FCC Part 15.105
Note : This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications, However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void your authority to operate the
equipment under FCC rules.
