bsw SPL-MHL-380BSW User manual

- 1 -
BSW MOVING HEAD
USER MANUAL
SPL-MHL-380BSW
Please read and keep this manual carefully for further use!

- 2 -
Thank you for buying our professional Beam moving head.
This user manual includes important information for installation and operation, so please read this
user manual carefully before installation and operation, and keep this user manual well for further use.
In order to install , operate, and maintain the lighting safety and correctly. We suggest that the
installation and operation should be done by the verified technician and follow the instruction strictly.
Spare part includes:
Please check carefully that there is no damage caused by transportation. Should there be any, consult
your local dealer.
Cautions
Before delivery, this device has passed strict inspection, Please follow the user manual
strictly for operation, if this fixture is damaged by improper operation and mistake, the
fixture will be out of warranty, and manufacture or dealer won’t be responsible for it. In case
of any technology change in this manual,we won’t advise in further .
Silkscreen symbol on light
Installation
Name
QTY
Unit
Fixture
1
PC
User manual
1
PC
Power cable
1
PC
DMX signal cable
1
PC
Safety rope
1
PC
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
Warning!
Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems.

- 3 -
►This fixture is not suitable for direct installation on combustible material surface, please keep the
fixture surface at least 0.5m from any combustible material.
►If you use the quick lock cam in hanging up the fixture, please make sure the quick lock fasteners
turned in the quick lock holes correctly.
►The applicable temperature for the fixture is between -25°C to 45°C. Do not use the lighting under or
above this temperature range.
►The truss for hanging the fixture should be able to hold 10 times weight of this fixture and no
deformation after 1 hour hang.
►Please don’t stand under the fixture when install, uninstall, move or repair the fixture.
►Please ensure the light is connected correctly and invite professional technician to check and
confirm the electrical data before installation.
►Please invite professional technician to check the fixture and installation each year.
Rigging：
Insert the quick-lock fasteners of the first holder into the respective holes on the bottom of the
device.Tighten the quick-lock fasteners fully clockwise.
Fix the clamp on truss or other fixture bracket.
Pull the safety rope through the holes on the bottom of the base and fasten it on the truss or other
fixing point.
Note:This step is quite important to ensure that fixture will not drop down for the clamp damage.
Product specification
1. Voltage：100-240V，50/60HZ；
2. Power Consumption：580W；
3. Lamp:Philips 380W
4.Fuse:8A/250V，￠5*20
5.DMX Channel: 24CH
Safety rope
Quick lock
Clamp
Bracket

- 4 -
6.Operation mode: master-slave/DMX/Auto
7. Focus/Zoom: Yes
8. Fixed gobo: 11 gobos+open+ Filter
Flame plate: 2+1+1 gobos
9. Strobe: 25Hz
10. Color: 12 colors+open
11. Prism 1: 8+16-facet
12. Prism 2:16-facet
13. Pan: 540°
14. Tilt: 270°
15.Frost / Six-color effect: Yes
16. RDM: Yes
17. Display: LCD touch screen
Display and operation
Setting:
Touch button
Function
Up
Option, Edit
Down
Option, Edit
Left
Backtrack, Edit
Right
Backtrack, Edit
OK
Enter to edit , confirm
Main Menu
Menu 1
Menu 2
DMX setting
DMX Channel
24CH
DMX signal
Hold
Clear
RDM
On

- 5 -
Off
DMX monitor
Fixture test
Auto
Off
On
Manual
1.Color
000-255
2.Shutter/strobe
000-255
……
19.frost
000-255
Reset
XY Reset
MT Reset
System Info
Temperature
Display panel temperature
Motor board temperature
Fan
Fan speed
system version
System time
Total usage time
time of this use
Total lamp-on time
Time of this lamp-on
Sensor
monitoring
X hall
Y hall
color hall
Pattern Hall
effect pattern hall
Glass gobo hall
Focus Hall
Zoom Hall
Prism 1 Hall
Prism 2 Hall
X encoding status
Y encoding status
X encoding step value
Y encoding step value
system error
Fixture setting
Language
English
Chinese
screen flip off
off
on
screen saver
on
off
X reverse
off
on
Y reverse
off
on
XY swap
off
on

- 6 -
24 DMX channel
XY encoder
on
off
Linear change of
color wheel
on
off
reset
Factory setting
(The password is
"up up down
down". )
Motor Calibration
X
Y
Color
Pattern
effect pattern
Glass gobo
focus
zoom
Dimming zero
Dimming stroke
Prism 1 Zero
Prism 1 stroke
Prism 2 Zero
Prism 2 stroke
Forst stroke
Stroke calibration
X stroke
Y stroke
Focus stroke
Zoom stroke
XY speed
adjustment
X speed
Y speed
Fan adjustment
White-on fan
Color-on fan
White-off fan
Color-ff fan
24CH
Function
Value
Details
CH1
Color wheel
000-004
005 -009
010 - 014
015 - 019
020 - 024
025 - 029
030 - 034
035 - 039
040 - 044
045 - 049
050 - 054
White
White+Color 1
Color 1
Color 1+color 2
Color 2
Color 2+color 3
Color 3
Color 3+color 4
Color 4
Color 4+color 5
Color 5

- 7 -
CH4
gobo wheel
000 - 004
005 - 009
010 - 014
015 - 019
020 - 024
025 - 029
030 - 034
035 - 039
040 - 044
045 - 049
050 - 054
055 - 059
060 - 064
065 - 069
070 - 074
075 - 079
080 - 084
085 - 089
090 - 094
095 - 099
100 - 104
105 - 109
110 - 114
115 - 119
120 - 187
188 - 255
gobo 1
gobo 2
gobo 3
gobo 4
gobo 5
gobo 6
gobo 7
gobo 8
gobo 9
gobo 10
gobo 11
gobo 12
gobo 1 shake slow to fast
gobo 2 shake slow to fast
gobo 3 shake slow to fast
gobo 4 shake slow to fast
gobo 5 shake slow to fast
gobo 6 shake slow to fast
gobo 7 shake slow to fast
gobo 8 shake slow to fast
gobo 9 shake slow to fast
gobo 10 shake slow to fast
gobo 11 shake slow to fast
gobo 12 shake slow to fast
Reverse flow (from fast to slow)
Forward flow (from slow to fast)
CH5
Effect gobo
000 - 009
010 - 019
020 -029
030 - 114
gobo 1 (blank)
gobo 2
gobo 3
gobo 4 (water pattern)
055 - 059
060 - 064
065 - 069
070 - 074
075 - 079
080 - 084
085 - 089
090 - 094
095 - 099
100 -104
105 -109
110 -114
115 -119
120 -124
125-129
130 -192
193 - 255
Color 5+color 6
Color 6
Color 6+color 7
Color 7
Color 7+color 8
Color 8
Color 8+color 9
Color 9
Color 9+color 10
Color 10
Color 10+color 11
Color 11
Color 11+color 12
Color 12
Color 12+White
Forward flow (from fast to slow)
Reverse flow (from slow to fast)
CH2
Shutter
/strobe
000-003
004-250
251-255
Shutter closed
Strobe from slow to fast
Open the shutter → (controlled by the dimming channel)
CH3
dimmer
000-255
dimmer from dark to bright

- 8 -
115 - 134
135 - 154
155 - 255
gobo 2 shake slow to fast
gobo 3 shake slow to fast
gobo 4 (water pattern) slow to fast
CH6
Glass gobo
000 - 009
010 - 019
020 -029
030 -039
040 - 049
050 -059
060 - 069
070 - 079
080 - 089
090 - 099
100 - 109
110 - 119
120 - 129
130 - 139
140 - 149
150 - 200
201 - 255
gobo 1
gobo 2
gobo 3
gobo 4
gobo 5
gobo 6
gobo 7
gobo 8
gobo 2 shake slow to fast
gobo 3 shake slow to fast
gobo 4 shake slow to fast
gobo 5 shake slow to fast
gobo 6 shake slow to fast
gobo 7 shake slow to fast
gobo 8 shake slow to fast
Forward flow (from fast to slow)
Reverse flow (from slow to fast)
CH7
Glass gobo
rotation
000-127
128-191
192-255
Angle adjustment
Forward rotation fast to slow
Reverse rotation slow to fast
CH8
Prism 1
000-127
128-255
no effect
prism 1
CH9
Prism1
rotation
000-127
128-191
192-255
prism angle adjustment
Reverse rotation fast to slow
Forward rotation slow to fast
CH10
Prism 2
000-127
128-255
no effect
prism 2
CH11
Prism2
rotation
000-127
128-191
192-255
prism angle adjustment
Reverse rotation fast to slow
Forward rotation slow to fast
CH12
Zoom
000-255
Pattern clarity from far to near
CH13
focus
000-255
Pattern clarity from far to near
CH14
pan
000-255
0-540 degree
CH15
pan fine
000-255
0-1.2 degree
CH16
tilt
000-255
0-270 degree
CH17
tilt fine
000-255
0-1.2 degree
CH18
XY speed
000-255
speed fast to slow
CH19
frost
000-127
128-255
no function
frost
CH20
Lamp
control &
Reset
000-099
100-105
200-205
250-255
no function
Lamp off
Lamp on
all motors reset
CH21
Hold
000-255
CH22
Color
speed
000-255
Speed from slow to fast

- 9 -
CH23
Dimmer
speed
000-255
Speed from slow to fast
CH24
gobo speed
000-255
Speed from slow to fast
Gobo wheel Flame plate
Color wheel Rotation wheel
DMX-512 connection
Connect the provided XLR cable to the male 3-pin XLR output of your controller and the other side
to the female 3-pin XLR input of the light.then connect the DMX signal to the first fixture to the 2nd
fixture, after all fixtures are connected,

- 10 -
The signal cable should be two - core with screened cable with XLR input and output connectors.
Please refer to the diagram below
DMX terminator connection
If there are many lines or lights, it is recommended to use a DMX terminator to prevent DMX signal
corruption, the DMX terminator is an simple XLR plug with a 120 Ω resistor connected between pins 2
and 3,which is then plugged into the output XLR socket of the last fixture in the chain.
3-Pins connection

- 11 -
Cleaning and maintenance
Cleaning should be performed every 15-day period, by using a sponge which is dipped with
alcohol, rather than wet cloth or other chemical liquid, to clean the mirror.
Attention
Do not see directly light source when open the light, and make sure power off before do any
installation or maintenance.
Cautions
Before delivery, this device has passed strict inspection, Please follow the user manual strictly for
operation, if this fixture is damaged by improper operation and mistake, the fixture will be out of
warranty, and manufacture or dealer won’t be responsible for it. In case of any technology change in
this manual,we won’t advise in further .
Common issues instruction
Issues
Solve instruction
No power
Check power’s voltage
When power in, output light but the
device cannot accept control signal
Check address setting and the control DMX cable
connection well or not
The effect have light shadow
Check electronic focus DMX channel value, if it’s
suitable distance
Light beam dim
The lamp maybe arrived end of using life, should
change new lamp, and also check light source cleaning
Cut off power before cleaning and maintenance!
CAUTION
Wires connection must be done professional person!
CAUTION

- 12 -
or not
Note: the maintenance should be done by the verified technician.
Warranty Card
This product is made of high-brightness transistor. We will provide 1 year warranty
under the condition that user has operated the light normally and lifetime service. We
won't provide warranty if the damage is caused by artificial or force majeure event.
Cost of fittings should be charged by user if product need maintenance after 1
year .Please cut this warranty card and shipped it along with the product to our
factory when applying for warranty.
Product：
Purchasing date：
Code of invoice：
Warranty date: From To
User’s name：Add：
Company：Tel：
