BT bt-csiv2 User manual

USER GUIDE
Arm Manikin for IV Access Training
(BT-CSIV2)

1
1. Cautions
⚫This manual describes how to use BT-CSIV Properly.
Read it carefully to avoid damaging the product and injuring yourself.
Pay attention to the following series of warnings.
①Use only components provided or approved by BT Inc.
②Do not disassemble, repair, or modify this product on your own.
③Keep the product away from water. If the product gets wet, do not turn it on. You could be
injured by electric shock.
④Do not use the product near strong magnetic fields or high voltage power lines. The product
might malfunction due to electromagnetic waves.
⑤Do not use the product under a condition of thunder and lightning. It can cause the product
malfunction and increases the risk of electric shock.
⑥Do not use the product in locations with temperatures below 0℃or above 40℃.
(Operation temperature : 0℃~ 40℃, Storage temperature : -10℃~ 50℃)
⑦Do not keep the product near hot places such as heaters. Transformation of product or
internal damage might occur.
⑧Never clean the product with chemical substances such as solvent, benzene or thinner, as
these may cause ignition, electric shock or cause the surface to deteriorate.
⑨BT Inc. can change or adjust the product specification without any notice in order to improve
the product.

2
2. Table of Contents
1. Cautions 1
2. Table of Contents 2
3. Components 3
4. Features and Functions 4
5. Installation 6
6. User Manual 8
7. Cleaning and Storage 10

3
3. Components
(1) Left Arm manikin
①Arm manikin –1ea
②Skin pad (Vein tube installed) –2ea
(2) Pump Driving Device
①Arm manikin mount (Volumetric pump installed) –1ea
②Microcomputer (installed) –1ea
③Volume pump Control –1ea
④Timer Switch –1ea
⑤One-touch fitting for connection tube –2ea
(3) Accessories
①Mount –1ea
②Simulated blood (30ml) –1ea
③Plastic bottle –1ea
④Power source adapter (9VDC) –1ea
⑤Battery Holder –1ea
⑥Connection tube –3ea
⑦Storage case –1ea

4
4. Features and Functions
①Arm manikin
②Skin pad (Vein tube installed)
③Blood circulation controller (Installed in Arm Manikin Manikin Mount)
④Timer switch
⑤Rapid blood circulation switch
⑥Blood IN connector
⑦Blood OUT connector
⑧Power supply connector

5
⑨Plastic bottle
⑩Plastic bottle IN connector
⑪Plastic bottle OUT connector
⑫Connection tube
⑬Mount

6
5. Installation
(1) Please arrange the product as the figure below.
- Either Adapter or Battery can be used as the power supply.
- Drop a few drops of simulated blood in a plastic bottle with some water and shake it.
(2) Installation of Skin-Pad
①Take the separate paper on the back of the Skin-Pad off.
②Insert the Skin-Pad into the gap of the back-side of the hand.
③Insert the Skin-Pad into the gap all the way to the end of Arm manikin.

7
(3) Connect the silicon tube as shown below.

8
6. User Manual
(1) As described in “5. Installation”, connect the power supply and connection tube.
(2) If you connect the power supply properly, You can hear a short buzzer sound.
(3) Press the Rapid Blood Circulation Switch to fill the blood vessel of Skin pad with simulated blood.
(4) The purpose of Rapid Blood Circulation Switch is to fill simulated blood into the empty Skin-pad rapidly.
(5) After you press the Timer Switch once, you can hear one buzzer sound in about two second.
Then the LED lamp turns on and blood flows for 5 minutes.
(6) When you press the Timer Switch more than once, you can hear buzzer sounds as shown in
the chart below. Then, blood will flow for several minutes as shown below.
(7) When you press the Timer Switch 7 times, you can hear three buzzer sounds. Then blood
circulation will stop.
No. of counts for
pressing timer switch
Total Operating
time(min)
Buzzer Sound
Remark
1
5
1
beep
2
10
2
beep-beep
3
15
3
beep-beep-beep
4
20
4
beep-beep-beep-beep
5
25
5
beep-beep-beep-beep-beep
6
30
6
beep-beep-beep-beep-beep-beep
7
Automatic Stop
3
beep-beep-----beep

9
(8) When you press the Timer Switch for 3 seconds, blood circulation will stop automatically.
(9) After termination of the operation, you can hear the three buzzer sounds. (beep –beep --- beep)
(10) If you want to restart, just press the Timer Switch again.
(11) After finishing the practice, please keep the product as described in “Chapter 7. Cleaning
and Storage”.

10
7. Cleaning and Storage
(1) After finishing the practice, you need to disconnect the white connector from the Plastic
Bottle and then press the Rapid Blood Circulation Switch to remove blood in the tube.
(2) Fill the bottle with clean water after expelling simulated blood.
(You can reuse the simulated blood if you keep the blood in an empty container)
(3) Reconnect the white connector to the Plastic bottle.
(4) Press the Rapid Blood Circulation Switch in order to circulate the clean water to clean up the tube.
(5) Disconnect the white connector from the Plastic Bottle and then press the Rapid Blood
Circulation Switch to remove clean water in the tube just as “(1)”.
(6) After pouring the water out of the bottle, disconnect the connection tubes.
(7) If water leaks out from the end of connector, remove water with the tissue paper or soft cloth.
(8) Please keep the product carefully in the Storage case.
