Bucktool SSA16LVF User manual

INSTRUCTION
MANUAL
IMPORTANT:
For your own safety, read and follow all of the Safety
Guidelines and Operating Instructions before operating
this product.
16 VARIABLE SPEED SCROLL
SAW WITH FOOT PEDAL SWITCH
"
GET IT DONE !
Contact Us:
email: [email protected]
https://www.bucktool.com
909-255-1088 (8AM-5PM PST)

2
Specifications 2
Safety guidelines 3
Package contents 11
Key parts diagram 12
Assembly/Mounting 13
Maintenance 19
Troubleshooting 20
Exploded view 21
Parts list 22
Warranty 24
TABLE OF CONTENTS
SPECIFICATIONS
Input 120VAC, 60Hz , 1.2A
16" x 9"
TABLE OF CONTENTS
SSA16LVF
No Load Speed 550-1,600 r/min(RPM)
Table Size
Table tilting
Weight Net (lbs) 0°-45°
32
Saw blade length 5"
Max cutting depth 2"

3
SAFETY GUIDELINES
SAFETY GUIDELINES - DEFINITIONS
SSA16LVF
WARNING: Indicates a potentially hazardous situation which, if not avoided,could
result in death or serious injury.
1. READ AND UNDERSTAND the instruction manual before operating this machine.
2.DO NOT OPERATE THIS MACHINE until it is completely assembled and installed
according to the instructions.
3. OBTAIN ADVICE from your supervisor, instructor, or another qualified person
if you are not thoroughly familiar with the operation of this machine.
4. FOLLOW ALL WIRING CODES and recommended electrical connections.
5. DO NOT OPERATE THIS MACHINE while under the influence of drugs, alcohol,
or medication.
6. USE CERTIFIED SAFETY EQUIPMENT.Eye protection equipmentshould comply
with ANSI Z87.1 standards, hearing equipment should comply with ANSI S3.19
standards, and dust mask protection should comply with MSHA/NIOSH certified
respirator standards.
7. DO NOT WEAR TIE, GLOVES, or loose clothing.REMOVE WATCH, RINGS,and
other jewelry.ROLL UP SLEEVES.
8. USE THE GUARDS WHENEVER POSSIBLE. Check to see that they are in place,
secured,and working correctly.
9. SECURE THE MACHINE TO A SUPPORTING SURFACE.
10.NEVER START THE MACHINE BEFORE CLEARING THE TABLE OF ALL
OBJECTS(tools, scrap pieces,etc.).
11.NEVER START THE MACHINE with the workpiece against the blade.
12.NEVER START THE MACHINE until all handles are locked and the blade is at
13.AVOID AWKWARD OPERATIONS AND HAND POSITIONS.
14.KEEP ARMS, HANDS, AND FINGERS away from the blade.
15.NEVER REACH UNDER THE TABLE while the machine is running.A moving
blade under the table can cause injury.
16.ADJUST THE “HOLD-DOWN” FOOT for each new operation. Loss of control
of the workpiece can cause injury.
17.HOLD THE WORKPIECE FIRMLY AGAINST THE TABLE.
18.DO NOT CUT A WORKPIECE THAT IS TOO SMALL TO BE SAFELY
SUPPORTED.
19.DO NOT CUT A WORKPIECE THAT DOES NOT HAVE A FLAT SURFACE
against the table.
20.MAKE RELIEF CUTS before cutting long curves. Never attempt to cut a curve
that is too tight.
WARNING
!

4
SAFETY GUIDELINES
SSA16LVF
21.NEVER BACK A BOUND BLADE OUT OF A KERF with the saw running.Turn
the saw “OFF”,disconnect the saw from the power source,wedge the kerf and
remove the blade.
22.USE CAUTION WHEN CUTTING IRREGULAR WORKPIECES. This type of
workpiece can pinch the blade before the cut is complete.
23.USE CAUTION WHEN CUTTING ROUND MATERIAL.This type of workpiece
has a tendency to “roll” and can cause the blade to bite.
24. PROPERLY SUPPORT LONG OR WIDE WORK-PIECES.
25. NEVER PERFORM LAYOUT, ASSEMBLY, or set-up work on the table/work
area when the machine is running.
26. TURN THE MACHINE “OFF” AND DISCONNECT THE MACHINE from the
power source before installing or removing accessories, before adjusting or
changing set-ups, or when making repairs.
27. TURN THE MACHINE “OFF”, disconnect the machine from the power source,
and clean the table/work area before leaving the machine.
LOCK THE SWITCH IN THE “OFF” POSITION to prevent unauthorized use.
21.NEVER BACK A BOUND BLADE OUT OF A KERF with the saw running.Turn
the saw “OFF”,disconnect the saw from the power source,wedge the kerf and
remove the blade.
22.USE CAUTION WHEN CUTTING IRREGULAR WORKPIECES. This type of
workpiece can pinch the blade before the cut is complete.
23.USE CAUTION WHEN CUTTING ROUND MATERIAL.This type of workpiece
has a tendency to “roll” and can cause the blade to bite.
24. PROPERLY SUPPORT LONG OR WIDE WORK-PIECES.
25. NEVER PERFORM LAYOUT, ASSEMBLY, or set-up work on the table/work
area when the machine is running.
26. TURN THE MACHINE “OFF” AND DISCONNECT THE MACHINE from the
power source before installing or removing accessories, before adjusting or
changing set-ups, or when making repairs.
27. TURN THE MACHINE “OFF”, disconnect the machine from the power source,
and clean the table/work area before leaving the machine.
LOCK THE SWITCH IN THE “OFF” POSITION to prevent unauthorized use.
SCROLL SAW DISCLAIMER
Read the entire text of the operating instructions prior to the assembly and operation of the
scroll saw. These operating instructions are intended to make it easier for you to get familiar
with your saw and utilize its intended use. The operating instructions contain important notes

5
SAFETY GUIDELINES
on how to work safely, properly and economically with your machine and how to
avoid dangers, save repair costs, reduce downtime, and increase the reliability and
working life of the machine.
In addition to the safety regulations contained herein, you must in any case comply
with the applicable regulations of your country with respect to the operation of the
machine.Put the operating instructions in a clear plastic folder to protect them from
dirt and humidity and store them near the machine. The instructions must be read
and carefully observed by each operator prior to starting the work. Only persons
who have been trained in the use of the machine and have been informed on the
the related dangers and risks are allowed to use the machine.The required minimum
age must be met.
In addition to the safety notes contained in the present operating instructions and
the special regulations of your country, the generally recognized technical rules for
the operation of wood working machines must be observed.
To avoid electrical hazards, fire hazards, or damage to the tool, use proper circuit
protetion.Your scroll saw is wired at the factory for operation. Connect to a branch
circuit and use a 15 amp time delay fuse or circuit breaker.To avoid shock or fire,
replace power cord immediately if it is worn, cut or damaged in any way. Do not
use in wet conditions.
WARNING
!
When using electric tools basic safety precautions should always followed to
reduce the risk of fire,electric shock and personal injury. Read all these instructions
before attempting to operate this product. Save these instructions for future
reference.
GENERAL SAFETY RULES FOR SCROLL SAWS
WARNING
!
• Keep work area clear. Cluttered areas and benches invite injuries.
• Consider work area environment. Do not expose tools to rain. Do not use tools in
damp or wet locations. Keep work area well lit. Do not use tools in the presence to
flammable liquids or gases.
• Guard against electric shock. Avoid body contact with grounded surfaces.
• Keep other people away.Do not let others, especially children,not involved in the
work touch or the power cord and keep them away from the work area.
• Store idle tools.When not use, tools should be stored in a dry locked-up place, out
of reach of children.
• Do not force the tool. It will do the job better and safer at the rate for which it was
intended.
SSA16LVF

6
SAFETY GUIDELINES
SSA16LVF
• Use the right tool. Do not force small tools to do the job of a heavy-duty tool.
Do not use tools for purposes not intended; for example do not use circular
saws to cut tree limbs or logs.
• Dress properly. Do not wear loose clothing or jewelry that can be caught in
moving parts. On-skid footwear is recommended when working outdoors.Wear
protective hair covering to contain long hair.
• Use protective equipment.Use safety glasses.Useface ordust mask if cutting
operations create dust.
• Connect dust extraction equipment. If devices are provided for the connection
of dust extraction and collecting equipment, ensure these are connected and
properly used.
• Do not abuse the power cord. Never pull the power cord to disconnect it from
the socket. Keep the lead away from heat, oil and sharp edge.
• Secure work.Where possible use clamps or a vice to hold the work. It’s safer
than using your hand.
• Don’t over reach. Keep proper footing and balance at all time.
• Maintain tools with care.Keep cutting tools sharp and clean for better and safer
performance. Follow instructions for lubricating and changing accessories.
Inspect power cables periodically and if damaged have they replaced by an
authorized service facility. Inspect extension cables periodically and replace if
damaged.Keep handles dry-clean and free from oil and grease.
• Disconnect tools. When not in use, before servicing and when changing acce-
ssories such as blades, bits,cutters, Disconnect tools from the power supply.
• Remove adjusting keys and wrenches. Form the habit of checking to see that
keys and adjusting wrenches are removed from the tool before turning it on.
• Avoid unintentional starting. Ensure switch is in‘off’position when plugging in.
• Use outdoor extension leads. When the tool is used outdoors, use only exte-
nsion leads intended for outdoor use and so marked.
• Stay alert. Watch what you are doing, use common sense and do not operate
the tool when you are tired.
• Check damaged parts. Before further use of the tools, it should be carefully
checked to determine that it will operate properly and perform its intended
function. Check the alignment of moving parts, binding of moving parts, brea-
kage of parts, mounting and any other conditions that may affect its operation.
A guard or other part that is damaged should be properly repaired or replaced
by an authorized service center unless otherwise indicated in this instruction
manual. Do not use the tool if the switch does not turn on and off.
• Warning. Repaired by a qualified person. This electric tool compliers with the

7
SAFETY GUIDELINES
relevant safety rules. Repairs should only be carried out by a qualified person
using original spare parts; otherwise this may result in considerable danger to
the user.
ELECTRICAL EXTENSION CORDS
Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole
receptacles that accept the product’s plug.When using a power product at a
considerable distance from the power source, use an extension cord heavy enough
to carry the current that the product will draw. An undersized extension cord will
cause a drop in line voltage, resulting in a loss of power and causing the motor to
overheat.Use the chart provided below to determine the minimum wire size required
in an extension cord.Only round jacketed cords listed by Underwriter’s Laboratories
(UL) should be used.
**Ampere rating (on tool data plate)
0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
Cord Length Wire Size (A.W.G.)
25' 16 16 16 16 14 14
50' 16 16 16 14 14 12
100' 16 16 14 12 10 —
**Used on 12 gauge - 20 amp circuit.
NOTE: AWG = American Wire Gauge
SSA16LVF

8
SAFETY GUIDELINES
Keep the extension cord clear of the working area. Position the cord so that it
will not get caught on lumber, products or other obstructions while you are working
you are working with a power product. Failure to do so can result in serious personal
injury.
Check extension cords before each use. If damaged replace immediately.Never
use product with a damaged cord since touching the damaged area could cause
electrical shock resulting in serious injury.
WARNING
!
WARNING
!
ADDITIONAL SAFETY RULES FOR SCROLL SAWS
• This scroll saw is intended for use in dry conditions, and for indoor use only.
• Do not cut pieces of material too small to hold by hand outside the blade guard.
• Avoid awkward hand positions where a sudden slip could cause a hand to
move into the blade.
• Always use the blade guard to avoid possible injury due to blade breakage.
• Do not perform layout, assembly or set up work on the table while the cutting
tool is in operation.
• Never turn your scroll saw on before clearing the table of all objects:(tools,
scraps of wood, etc)expect for the work piece and related feed or support devices
for the operation planned.
PROPER USE
Machines meet all valid CSA/US machines guidelines as well as all
relevant guidelines for each machine.
• The machine must only be used in technically perfect condition in accordance
with its designated use and the instructions set out in the operating manual,
and only by safety-conscious persons who are fully aware of the risks involved
in operating the machine. Any functions disorders, especially those affecting
the safety of the machine, Should therefore be rectified immediatelty.
• The safety, work and maintenance instructions of the manufacturer as well
as the technical data given in the calibrations and dimensions must be adhered
to.
• Relevant accident prevention regulations and other, generally recognized
safetytechnical rules must also be adhered to.
• The machine may only be used, maintained, and operated by persons familiar
with it and instructed in its operation and procedures. Arbitrary alterations to
the machine release the manufacturer from all responsibility for any resulting
damages.
• The machine may only be used with original accessories and tools made by
the manufacturer.
• Any other use excesses authorization. The manufacturer is not responsible
SSA16LVF

9
The installed electric motor is completely wired ready for operation.
The customer’s connection to the power supply system, and any extension cables
that may be used, must conform to local regulations.
Important remark:
Defective electrical connection cables.
Electrical connection cables often suffer insulation damage.
Possible causes are:
• Pinch points when connection cables are run through window or door gaps.
• Kinks resulting from incorrect attachment of laying of the connection cable.
• Cuts resulting from running over the connecting cable.
• Insulation damage resulting from forcefully pulling out of the wall socket.
• Cracks through aging of insulation.Such defective electrical connection cable
must not be used as the insulation damage makes them extremely hazardous.
Check electrical connection cables regularly for damage. Make sure this is dis-
connected from the mains when checking. Electrical connection cables must
comply with the regulations applicable in your country. Single-phasemotor.
• The power voltage must coincide with the voltage specified on the motor’s rating
plate 120V，60Hz.
GROUNDING INSTRUCTIONS
for any damages resulting from unauthorized users are the sole responsibility
of the operator.
• The machine has been built using modern technology in accordance with
recognized safety rules.Some remaining hazards, however, may still exist.
• Long hair and loose clothing can be hazardous when the work piece is rotating.
Wear personal protective gear such as a hair net and tight fitting work clothes.
• Saw dust and wood chips can be hazardous. Wear personal protective gear such
as safety goggles and a dust mask.
• The use of incorrect or damaged power cords can lead to injuries caused by
electricity.
• Even when all safety measures are taken, some remaining hazards which are
not yet evident Mays still be present.
• Remaining hazards can be minimized by following the instructions in “safety
precautions”,” Proper Use” in this operating manual.
• Do not force the machine unnecessarily: excessive cutting pressure may lead
to rapid deterioration of the blade and a decrease in performance in terms of
finish and precision. Avoid accidental starts:
Do not press the start button while inserting the plug into the socket.
SAFETY GUIDELINES
This tool is for indoor use only. Do not expose to rain or use in damp
locations.
In the event of a malfunction or breakdown, grounding providesa path of least
resistance for electric current to reduce athe risk of electric shock. This product
SSA16LVF

10
SSA16LVF
SAFETY GUIDELINES
is equipped with an electric cord having an equipment grounding conductor and
a grounding plug. The plug must be plugged into a matching outlet that is prop-
erly installed and grounded in accordance with all local codes and ordinances.
Do not modify the plug provided. If it will not fit the outlet,have the proper outlet
installed by a qualified electrician.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. The conductor with insulation having an outer surface that is
green with or without yellow stripes is the equipment-grounding conductor. If
repair or replacement of the electric cord or plug is necessary, do not connect
the equipmentmodel grounding conductor to a live terminal.
Check with a qualified electrician or service personnel if the grounding instructions
are not completely understood, or if in doubt as to whether the product is properly
grounded.
In all cases, make certain the receptacle is properly grounded. If you are not
sure, have a qualified electrician check the receptacle.
CAUTION
!
Three-Pronged Plug
Grounding Prong
Properly Grounded
Three-Pronged Receptacle
Grounding Lug
Make sure this
is connected to
a known ground.
Two-Pronged
Receptacle
Adapter
ELECTRICAL SAFETY

11
PACKAGE CONTENTS
No. Description Qty.
1Scroll saw 1
22
31
4
51
6
71
81
1
1
Package contents
LEDLight Assy
Type I Hex Nut
45
2
6
10
Philips Screw
Lamp Holder
Knob
Foot Pedal Switch
T Type Wrench(for pinless blade changing)
9
10 1
1
1
9
7 8
3
Blade
SSA16LVF
The Manual

12
SSA16LVF
KEY PARTS DIAGRAN
No. Description Qty.
ABlade tension knob 1
BBearing covers 2
CWork table 1
D1
E
Dust connection port
Variable speed control knob
1
F1
G
Sawdust Blower Nozzle
1
H
Bevel lock knob
1
ON/OFF switch
I1
Side cover plate
K LEDLight Assy 1
L Pressure Rod Locking Knob 1
M Foot pedal switch 1
J Mounting holes 1
AD
LK
B
C
EJFGHIM

13 The machine is designed to operate in closed rooms and must be placed stable
on firm and levelled surface. The machine can be bolted down if required.
For packing reasons the machine is not completely assembled.
Fig. 2
Fig. 9
LED light lamp
holder
ASSEMBLY/OPERATING
If you notice any transport damage while unpacking, notify your supplier
immediately. Do not operate the machine!
Dispose of the packing in an environmentally friendly manner. Clean all rust
protected surfaces with a mild solvent.
WARNING
!
SSA16LVF
INSTALLATION OF LED LIGHT
1. Open the battery cover. Insert two AAA
batteries into the case. If replacing the
batteries, take out the old batteries and
replace with new AAA batteries.
Dispose off old batteries properly.
As shown in Fig. 2.
3. Install the battery cover.
4. Assembly the lamp holder to the arm
of scroll saw by two screws .
As shown in Fig. 3.
5. Assembly the LED light to the lamp
holder with philips screw and hex
nut. As shown in Fig. 3.
6. Use the red knob to lock the LED
light.As shown in Fig. 3.
All parts needed shown in Fig. 1
16 7
4
2
Fig. 1
35
screwred knob

14
Point the Sawdust Blower Nozzle (Fig 2)
towards to the cutting area.
DUST CONNECTION
Figure. 3
The machine has a 35mm dust port
(Fig 3) where it can be connected to a
dust extractor.
INSTALLATION OF FOOT PEDAL SWITCH
Replace with batteries that have a rating of 1.5volts (Number 7 series andAAA size
or equivalent). When replacing the batteries, the battery guide should be thoroughly
cleaned.Use a soft paintbrush or similar device, to remove all sawdust and debris.
NOTE:
dust port
foot pedal switch
Install foot pedal switch as shown in Fig. 13. First connect the plug of the saw to
the female plug of the foot pedal switch and then connect the foot switch plug to
the power.
ASSEMBLY/OPERATING
SAWDUST BLOWER NOZZLE
Fig. 13
Figure. 2
Sawdust Blower
Nozzle
SSA16LVF

15
BEVEL CUTTING
The table can be tilted between 0° and
45° for bevel cutting.
Loosen the locking knob (1，in Fig11).
Tilt the table to the left until the desired
angle on the scale (2，in Fig11) has been
reached. Fig. 11
Retighten the locking knob.
USING VARIABLE SPEED
• By turning the variable speed knob, the saw’s speed may be adjusted from a
high speed of approximately 1,600 SPM (Strokes Per Minute) to a low speed of
approximately 550 SPM.
• To increase the strokes per minute, turn the variable speed knob clockwise or to
the right.
• To decrease the strokes per minute, turn the variable speed knob counterclock
wise or to the left.
ASSEMBLY/OPERATING
ON /OFF SWITCH
Fig. 12
ON/OFF Switch
1
2
1. Press the on/off switch side marked
“ON” ，Start To Work.
2. Press the power switch side marked
“OFF” to turn the saw off.
3. To lock the switch in the “OFF” position,
grasp the end, of the switch key, and
pull it out.
4. With the on/off switch key removed,
the switch will not operate.
5. If the switch key is removed while
the saw is running, it can be turned
off but cannot be restarted without
inserting the switch key.
Always lock the switch off when the saw is not in use. Remove the key and keep
it in a safe place. In the event of a power failure, blown fuse, ortripped circuit
breaker, turn the switch off and remove the key, preventing an accidental startup
when the power comes on.
WARNING
!
SSA16LVF

16
Before Operation
Mounting the saw on a work bench
• A work bench made from solid wood is better than one made of plywood, As
interfering vibrations and noise are more noticeable with plywood.
• The necessary tools and small parts for assembling the saw on a workbench
are not supplied with the saw.
Correct working position:
In front of the machine standing in the direction of cutting.
Workpiece handling:
Insure that the workpiece does not roll when cutting round pieces.
Use suitable table extensions and supporting aids for difficult to handle work-
pieces.
Never cut pieces that are too small.
Press the workpiece down against the table to avoid uncontrollable lifting.
Remove the workpiece from the blade prior to turning the scroll saw ON.
Feed the workpiece towards the sawblade in the direction of the sawline,
and cut as required by turning to follow the line drawn.
Using Foot Switch
• Easy to operate – press the on/off switch side marked “ON”, power stays on as
long as foot pressure is applied.
• Keep both hands free to control your work at all times.
• Turn machine on and off instantly simply.
ASSEMBLY/OPERATING
No. Description
1Saw body
2Foam rubber base
3Work bench
4Flat seal
5Washer
6Hexagonal nut
7Lock nut
Hexagonal bolt
8
Scroll Sawbase
Workbench
Flat washer
Lock washer
Hex Nut
Jam Nut
Hex Head Bolt
12mm Foam Pad or Carpet (optional)
However,use equipment of at least the following size:
SSA16LVF

17
REMOVING SAW BLADE
Side cover
plate
1. Release the blade tension by lift up the
blade tension handle. If necessary, turn
the handle counterclockwise to loosen
the blade holder further.
3. Open the side cover plate by pulling on the
little handle.
4.Unscrew the inner hex nut of lower blade
holder by TURN CLOCKWISE.
2. Unscrew the inner hex nut of upper blade
holder by TURN CLOCKWISE.
Figure. 4
pull here
ASSEMBLY/OPERATING
5. Remove the blade from the blade holders.
For a pinned blade:
push down on the upper blade holder to remove the blade
from the upper blade
holder and then remove the blade from the lower blade holder.
For a pinless blade:
ensure that there is slack in the blade and it is not tensioned.
Then remove the blade
from the holders.
SSA16LVF
Saw blade
blade tension handle
Fig. 5
Fig. 6
lower blade holder nut
upper blade holder nut

18
WARNING
!
INSTALLING THE BLADE
This saw is also suitable for insetcuts, or cuts not starting at the edge of the work
piece. Proceed as follows:
•Drill a hole in the work piece.
• Loosen the blade tension knob to release the tension in the blade.
• Place the bore hole over the saw blade slot in the work table.
• Install the saw blade through the hole in the piece and through the work blade
slot, and the blade to the holes.
• When you have completed the inside cut, remove the saw blade and then
remove the work piece from the table.
ASSEMBLY/OPERATING
1.Install the blade on the blade holders.
For Pinned Blade:
Hook the blade pins in the recess of the lower blade holder. While pushing down on
the upper blade holder, insert the blade pins into the recess of the upper blade holder.
For Pinless Blade:
Ensure the inner hex nut on the lower blade holder is loose and insert the blade into
the opening of the lower blade holder. Secure the blade in the lower blade holder
by tightening the inner hex nut ANTICLOCKWISE.
Ensure the inner hex nut on the upper blade holder is loose and insert the blade
into the opening of the upper blade holder. Secure the blade in the upper blade
holder by tightening the inner hex nut ANTICLOCKWISE.
2.Gently push down the blade tension handle and try the tension of blade.Adjust
the tension by turn the handle.Tighten by clockwise and loosen by anticlockwise.
3.Install back the side cover
SSA16LVF
NOTE: Install the blade with the teeth pointing downward.
NOTE: A properly-tensioned blade will make a high-C sound (C6, 1047 Hz)
when plucked with a finger. A brand-new blade will stretch when first
tensioned, and may require adjustment.
Switch off the saw and remove the cord from power supply before installing saw
blades in order to avoid injuries caused by unintentional activation of the saw.

19
MAINTENANCE
General notes:
Maintenance, cleaning and repair work may only be carried out after the
machine is protected against accidental starting by pulling the mains plug.
Repair and maintenance work on the electrical system may only be carried out
by a qualified electrician.
Clean the machine regularly.
Inspect the proper function of the dust extraction daily.
All protective and safety devices must be re-attached immediately after completed
cleaning, repair and maintenance work.
Defective safety devices must be replaced immediately.
Regularly clean the machine housing with a soft cloth preferably after each use.
If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammoniac water, etc. These solvents
may damage the plastic parts.
Cleaning:
Saw blades:
Only use sharp saw blades.
Lubrication:
Lubricate the arm bearings after every 50
hours of use.
Remove the 4 bearing covers (B, Fig 14).
Apply a generous amount of light oil .
Fig. 14
Motor brushes:
The collector brushes are due to wear and may need replacement.
1) Disconnect the machine form the power source, pull mains plug.
2) Remove the brush covers.
3) Replace the collector brushes.
4) Reattach the brush covers.
SSA16LVF

20
TROUBLESHOOTING GUIDE
SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION
Saw blades break
Tension incorrectly set Set the correct tension
Load to great Feed the work piece more
slowly
Incorrect saw blade variety Use the correct saw blades
Avoid exerting side pressure
Work piece not fed straight
Change faulty cable
Motor does not
function
NOTE: The saw
vibrates slightly when
the motor is running in
normal operation
Motor faulty
Call customer service. Do
not attempt to repair the
motor yourself as this should
be carried out by trained
personnel.
Power extension cable faulty
Saw incorrectly installed
Unsuitable underlay
Refer to the instructions
in this manual
The heavier the work bench is
the less the vibration. A bench
made from plywood always
vibrates more than one made
from solid wood.Select the
work bench best suited to your
working conditions .
Vibration
The work bench is not
screwed down or is on
the motor Tighten the locking lever
Saw blade swings
out Holder not
aligned straight
Securely screw the motor
in place
The motor is not secured
Loosen the screws with which
the holders are fastened to the
arm. Align the holders to that
they are perpendicular to each
other and retighten the screws.
WARNING
!
In the interests of operational safety, always switch off the saw and remove
the mains plug before carrying out maintenance work.
TROUBLE SHOOTING
Holders not aligned
SSA16LVF
