16104 Backsaver Auger Specifications
specifications Y16104
Tubing Tubes #1 and #2: 10 gauge
Tubes #3, #4, #5: 11 gauge
Flighting ¼" on swing and main auger
Flighting shaft 3" diameter, ³⁄16" wall
Undercarriage 5" x 5" x ¼" square tube
Lift arms ¼" formed tubing
Bridging Upper bridging (cable) ¾"
Side bridging (cable) ½"
Wheel and hubs 8 bolt hubs, 16.5 L x 16.1 x 10 ply
Hopper dimensions 48" x 60" x 13 ½" tall
Clearance in down position 14' 10"
Below spout to ground @ maximum lift 77' 4"
Below spout to ground in down position 12' 5"
Reach - edge of wheels to center of spout down position 57' 8"
Reach - edge of wheels to center of spout ½ up position (44' 3" spt-grd) 52'
Reach - edge of wheels to center of spout up position 36' 1"
Tube angle, up position 44°
Tube angle, down position 5°
Wheel track center to center 13' ½"
Wheel track outside of wheels 14' 5 ½"
Hitch weight in down position 2,700 lbs
Overall weight 13,000 lbs
Tractor requirements
Minimum PTO horsepower (w/1000 RPM PTO)
Approximate hydraulic requirements for lift
175 HP
1500 PSI
