Buhler Round Bale Carrier 1500 User manual

Round Bale Carrier Specifications
MODEL 1500 2500
Shipping weight (approx.) 2,498 kg (5,495 lb) 4,252 kg (9,375 lb)
Hitch weight Empty vertical drawbar load 6,071N (1,365lbf) Empty vertical drawbar load 10,653N (2,395lbf)
Transportation width 2.6 m (8.5') 3.9 m (12.75')
Deck length / overall length 11.3 m (37') / 13.4 m (44') 11.3 m (37') 13.7 m (45')
Hydraulics:
• Lift cylinder
• Tilt cylinder
Two double acting circuits required
One - 3" diameter
One - 3" diameter
Hydraulic motors: (two) 22.0 cu.in
Two double acting circuits required
Two - 3" diamether
Two - 3" diameter
Hydraulic motors: (four) 22.0 cu.in
Tires (Four) 12.5L x 15FI tires, load range F,
intermittent unloaded highway use
Capacity: 2,130 kg (4,680 lb) at 90 PSI ination
Hub: 6 bolt with twine guard
Wheel: heavy-duty implement style
(Eight) 12.5L x 15FI tires, load range F,
intermittent unloaded highway use
Capacity: 2,130 kg (4,680 lb) at 90 PSI ination
Hub: 6 bolt with twine guard
Wheel: heavy-duty implement style
Tractor requirements 45 kW (60 HP) at 5,660 kg (12,480 lb)
Maximum recommended speed when loaded is
32 km/hr (20 mph)
60 kW (80 HP) at 11,340 kg (25,000 lb)
Maximum recommended speed when loaded is
32 km/hr (20 mph)
Hand held remote control Power: 12v
Fuse: 15 amp
Power: 12v
Fuse: 15 amp
Capacity GVW: 8,491 kg (18,720 lb)
Eight - 4' wide bales
Seven - 5' wide bales
GVW: 16,983 kg (37,440 lb)
Sixteen - 4' wide bales
Fourteen - 5' wide bales
