Build RC 3M Gliderman User manual

3M Gliderman
1
To finish, you still need the following accessories:
• Remote control unit with receiver (5 channels)
• 4x servo D-200 BX (or D-250 BX with metal gears)
• Motor DYMOND AL-4260
• 60-amp motor controller
• 5S LiPo battery with 5000 mAh
• 14 x 6 prop, spinner diameter 45 mm
• Servo Extensions
• MPX connector for tail servo cable
• Superglue liquid medium
• Epoxy e.g. 5-minute epoxy
• Rudder Horn, INSTRUCTIONS. 03150100, 1x M2 clevis, threaded coupler M2, a little
spring steel wire 1.5 mm

3M Gliderman
2
Before construction starts, it may be necessary to model the film with a heat gun and or
iron. retighten This is used in the film without any problems. Make sure the area of
Aileron hinges to be careful. The hinge used is non-heat-sensitive than the covering can
quickly and curl. ince the underside of the wing has a concave curvature, care must be
taken that the covering remains stuck to the ribs and not replace, and so the profile is
changed.
Template for
rudder cover
1. Completion of the tail:
The servos for the elevator and rudder are built directly into the vertical
stabilizer. To save weight in the tail, it makes sense as light servos,
so that without using metal gears (D-200 BX). Due to the large control
surfaces then a greater risk of breakage of the gear. In metal gear
servos but later the addition of lead in the nose be required. Here, the
owner may find the perfect model for him compromise. The
elevator linkage is at the recommended Dymond servos D-200/250 BX in the
second hole from the inside, hung the rudder pushrod into the third hole from the
inside. Be drilled for the elevator pushrod to the hole must be 2.5 mm.

3M Gliderman
3
The pre-servo mounts have to be reworked at the top with a cutter. These apply to both
the servo mounting locations and record the contours.

3M Gliderman
4
The rudder linkage consists of a control horn (Article No.: 03.1501 million), a crown and
an M2 Threaded coupler into which a short piece of 1.5mm steel wire is soldered. To
mount the control horn in the rudder a Hole made of 4 mm and glued in the threaded
sleeve of the horn from the back with epoxy. The hole in the rudder is best carry out
carefully by hand and in several steps, since that is hardly "material resources" are
available.

3M Gliderman
5

3M Gliderman
6
Before attaching the servos still need the cable can be extended. It is useful to realize the
future connector with a pair of MPX connector that is soldered on the installation of the
servos to be solid lines.
The elevator pushrod just like the picture in the servo output arm in the second hole
hung from the inside, which was drilled to 2.5 mm, mounted. It needs no fixing. The
servo arm must be ground down nearly as possible, so as not to scratch the cover.

3M Gliderman
7
The elevator servo is secured by the enclosed, showing wooden cover, the rudder servo
is to be held only by opening the plastic cover in place. In the plastic cover must holes
(1.5 - 2.5 mm) drilled and cut for the Rudder to be cut. For this is the template at the
beginning of this manual. For weight reasons, it may be useful to replicate the coverage
of 0.3 mm thick P or AB .
1. Completing the wings
Please make sure the C.G place:
o shall the elevator pushrod
extending in the vertical fin. In
the installed state, it is then
prevented by the timber
attachment to the slipping out
of the servo arm
The two halves of the elevator are
stuck with the default aspect ratio.
In-house here, a removable solution
be implemented.

3M Gliderman
8
The ailerons are hinged with the supplied parts. Use the horns as a template for the
three holes in the rudder area. The diameter of the holes is 1.5 mm. Also look here to
please volatile pushrods.
The aileron servos are like the elevator servo with the included pieces of wood secured
in the shafts. Here, too, need to be modified with the mill if necessary, the mounting
frame. The extension of the power cord plug can be done with an extension cord. It is
also worthwhile here MPX connectors to be used for the outer wings as comfortable as
possible and de-install to. The aileron servos are like the elevator servo with the
included pieces of wood secured in the shafts. Here, too, need to be modified with the
mill if necessary, the mounting frame. The extension of the power cord plug can be done
with an extension cord. It is also worthwhile here MPX connectors to be used for the
outer wings as comfortable as possible and de-install to.

3M Gliderman
9
Default to the outer wings are secured with tape. In-house here, a more complex
solution can be realized.
The covers for the aileron servos are also to be secured with tape.

3M Gliderman
10
2. Drive installation
On a 14 x 6 prop and 5 lipo at 18.5 V, this engine develops an almost brutal power. Thus,
the model is to always start safely. Due to the relative rather heavy tail problem, a very
large battery of 5000 mAh is used. E.G. a DYMOND XC-5000 5 fits very well.
The engine installation must be noted that the cable can rub against the rotating casing
of the engine. To secure the cable with something tape in the fuselage.
The available space in the boat hull is great. Therefore, the controller can be placed next
to the battery. The hood of the model is to be attached with tape. Built in Director but
may, for example, a spring steel wire are glued.

3M Gliderman
11
By default, the two fuselage parts are secured with tape. The conical shape of the fit is
guaranteed a very secure hold. On their own but here is a more complex solution can be
realized.
Thus, the mere assembly operations are completed. The wing can now be assembled
with the help of the wing joiner and assembled with the plastic screws on the fuselage.
Make sure that the power cables are not pinched! Plug the remote control system
according to the instructions the aileron cable into the receiver. The motor controller
according to the manufacturer's instructions to connect to the motor. With the flight
battery is now the center of gravity (center of gravity 75 - 90 mm measured from the
leading edge) is determined. The model is supported with one finger right and left of the
wing at the previously marked position of the centroid. The model is properly balanced
when settles the fully assembled model with a slightly tilted nose. By shifting the focus

3M Gliderman
12
of the drive battery can be accurately adjusted.
Load before the first flight of the battery and set all the components according to
manufacturer's instructions. Always check the function of the rudder. The first flight of
the model should be done on a windless or slightly windy day. The model starts with the
engine running and with a flourish against the wind. The engine is chosen so that the
model is increasing and powerful with good speed in a medium angle. Possibly slight
trim adjustments are required. After switching off the engine, the model should
continue to fly at a slower rate in horizontal flight.
Safety note:
For security reasons, you should always fly safety conscious. The taxes demanded by the
pilot of flight models big responsibility. Bear in mind that you are putting in any situation
or harass other people. Get to know your model, you feel their way to the possibilities
offered by the model approach. Experience the fascination of flying with this beautiful
electric glider. If the rudder adjusted according to the instructions, the model reacts
quite soft to the control commands.
Attention!
This model is not a toy! If you have an electrically powered model, no experience, you
should contact an experienced model flyer who can assist you. It could cause injury if the
model without prior knowledge of operation. Think about your health and safety.
Security advice and warning about flight models
Before construction starts, make sure you read the instructions and become familiar with
the various phases. Make It has gone to considerable effort to make the construction cost
as simple as possible, without compromising safety compromising. These safety
instructions are part of this manual and must be stored carefully and in case of passed on
to subsequent users to be handed out. Radio controlled models may be used only for the
purpose intended by the manufacturer. A model can only work properly and meet the
expectations when it carefully in accordance with the building was built and installed.
Unauthorized modification of design and materials are not permitted. Necessarily have

3M Gliderman
13
the information and focus on the control surface to be observed. Make before turning on
the remote control that your frequency is free. Only then switch on! You are solely
responsible for the safe operation of your model and engine. Propellers and all rotating
parts, which are driven by a motor, represent a risk of injury to dar. Be touched by any
body part! A rapidly rotating propeller is able to cut off a finger. You have purchased a kit
which, together with appropriate accessories, a fully functional RC Modell can be
completed. Compliance with the installation and operating instructions related to the
model and the installation, the operation, use and maintenance of associated with the
model components cannot be monitored by the company LEADER . Therefore, the
Company assumes no liability LEADER for any loss, damage or expense resulting from
the faulty operation of faulty behavior or in any way connected with the foregoing.
Unless the legislature necessarily required, the obligation of the Company LEADER to
pay damages for any reason be excluded.
