TD4, TD4T
ICED TEA/COFFEE
DISPENSERS
USE & CARE INSTRUCTIONS
INTRODUCTION
These dispensers are designed to hold and serve up to 4-gallons of iced tea or iced coffee.
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: (217) 529-6601 FAX: (217) 529-6644
10334.0000K 06/09 ©1998 Bunn-O-Matic
210334 012609
BUNN-O-MATIC COMMERCIAL PRODUCT WARRANTY
Bunn-O-Matic Corp. (“BUNN”) warrants equipment manufactured by it as follows:
1) All equipment other than as specified below: 2 years parts and 1 year labor.
2) Electronic circuit and/or control boards: parts and labor for 3 years.
3) Compressors on refrigeration equipment: 5 years parts and 1 year labor.
4) Grinding burrs on coffee grinding equipment to grind coffee to meet original factory screen sieve analysis:
parts and labor for 3 years or 30,000 pounds of coffee, whichever comes first.
These warranty periods run from the date of installation BUNN warrants that the equipment manufactured by
it will be commercially free of defects in material and workmanship existing at the time of manufacture and
appearing within the applicable warranty period. This warranty does not apply to any equipment, component or
part that was not manufactured by BUNN or that, in BUNN’s judgment, has been affected by misuse, neglect,
alteration, improper installation or operation, improper maintenance or repair, damage or casualty. This warranty is
conditioned on the Buyer 1) giving BUNN prompt notice of any claim to be made under this warranty by telephone
at (217) 529-6601 or by writing to Post Office Box 3227, Springfield, Illinois 62708-3227; 2) if requested by
BUNN, shipping the defective equipment prepaid to an authorized BUNN service location; and 3) receiving prior
authorization from BUNN that the defective equipment is under warranty.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTY, WRITTEN OR
ORAL, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF EITHER
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. The agents, dealers or employees of BUNN
are not authorized to make modifications to this warranty or to make additional warranties that are binding on
BUNN. Accordingly, statements by such individuals, whether oral or written, do not constitute warranties and
should not be relied upon.
If BUNN determines in its sole discretion that the equipment does not conform to the warranty, BUNN, at its
exclusive option while the equipment is under warranty, shall either 1) provide at no charge replacement parts
and/or labor (during the applicable parts and labor warranty periods specified above) to repair the defective
components, provided that this repair is done by a BUNN Authorized Service Representative; or 2) shall replace
the equipment or refund the purchase price for the equipment.
THE BUYER’S REMEDY AGAINST BUNN FOR THE BREACH OF ANY OBLIGATION ARISING OUT OF THE SALE OF
THIS EQUIPMENT, WHETHER DERIVED FROM WARRANTY OR OTHERWISE, SHALL BE LIMITED, AT BUNN’S
SOLE OPTION AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND.
In no event shall BUNN be liable for any other damage or loss, including, but not limited to, lost profits, lost sales,
loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute
equipment, facilities or services, or any other special, incidental or consequential damages.
BrewWISE, BrewLOGIC, BrewMETER, BrewWIZARD, Bunn Gourmet, BUNN Gourmet Ice, BUNN Pour-O-Matic,
BUNN, Bunn-OMatic, Bunn-O-Matic, BUNNlink, BUNNserve, BUNNSERVE, BUNN Espress, Cool Froth, DBC, Dr.
Brew, Dual, EasyClear, EasyGard, Easy Pour, FlavorGard, Gourmet Ice, Gourmet Juice, High Intensity, IMIX, In-
fusion Series, Intellisteam, Quality Beverage Equipment Worldwide, The Mark of Quality in Beverage Equipment
Worldwide, My Café, PowerLogic, Safety-Fresh, Scale-Pro, Silver Series, Single, Smart Funnel, Smart Hopper,
SmartWAVE, Soft Heat, SplashGard, System III, ThermoFresh, 392, AutoPOD, AXIOM, Beverage Profit Calcula-
tor, Beverage Bar Creator, BUNNsource, Coffee At Its Best, Digital Brewer Control, Nothing Brews Like a BUNN,
Pouring Profits, Pulse Wave, Signature Series, Smart Heat, Tea At Its Best, The Horizontal Red Line, Titan, Ultra,
are either trademarks or registered trademarks of Bunn-O-Matic Corporation.
310334 121007
CLEANING
CAUTION - CLEAN AND SANITIZE YOUR ICED TEA/COFFEE DISPENSER DAILY
1. Twist the faucet wing nut in a clockwise direction and remove the faucet from the dispenser.
2. Thoroughly clean the entire inside surface of the dispenser and the faucet shank with the #00674.0000 brush
using a mild detergent and water solution. Rinse the dispenser and shank with warm water.
3. Disassemble the faucet. The faucet cleaning procedure requires a 3-compartment sink. Thoroughly wash all
faucet parts in a mild detergent and water solution in the first sink. Rinse the parts in hot water in the second
sink. Sanitize the parts for one minute in 75° warm chlorine solution (50-100 ppm) in the third sink. Do not
use full strength bleach, but a solution with water, 50-100 ppm of chlorine.Reassemble the faucet and attach
it to the dispenser.
4. Sanitize all exposed surfaces of the dispenser with a 75° warm chlorine solution (at least 100 ppm). Empty
the dispenser and thoroughly rinse everything.
5. Wash the entire outside surface of the dispenser with a clean damp cloth.
CAUTION - DO NOT KEEP BREWED ICED TEA OR ICED COFFEE OVERNIGHT.
4
gal
gal
1 1
22
33
BUNN
BUNN
® TD4
TD4T
2
1
3
6
7
8
9
10
11
4
20
5
22
19
18
16 15 21 17 14 13 12 P649.90
ICED TEA/COFFEE DISPENSER REPLACEMENT PARTS
10334 052008
5
ITEM PART NO. QTY. DESCRIPTION
1 03255.0000 1 Lid, Reservoir (Solid)(Includes Decal Not illustrated)
00778.0000 1 Decal, BUNN (Not illustrated)
03255.0002 1 Lid, Reservoir (Brew-thru)(Includes item 2)
2 03285.0002 1 Bushing, Lid
3 03078.1002 1 Reservoir
01364.0000 2 Screw, pan head #6 x .312”(self-tapping)
4 - - - - - - - - 1 Housing (Not available)
5 03260.0000 1 Faucet Assy, Brown (Includes items 6 thru 11)
03260.0001 1 Faucet Assy, Black (Includes items 6 thru 11)
03260.0002 1 Faucet Assy, Black (Sweet / Unsweet) (Includes items 6 thru 11)
6 29163.0000 1 Faucet Handle, Brown
29163.0001 1 Faucet Handle, Black
29163.0003 1 Faucet Handle, Black (Sweet / Unsweet)
7 29165.0000 1 Faucet Bonnet, Brown
29165.0001 1 Faucet Bonnet, Black
8 00601.0000 1 Faucet Spring
9 29164.0000 1 Faucet Stem
10 00600.0000 1 Faucet Cup
11 - - - - - - - - 1 Faucet Body (Not available order item 5)
12 03093.0000 1 Faucet Wing Nut, Brown
03093.0002 1 Faucet Wing Nut, Black
13 03362.0002 1 Faucet Shank, Brown
03362.0004 1 Faucet Shank, Black
14 03092.0000 1 Nut, flanged - Brown
03092.0001 1 Nut, flanged - Black
15 00958.0000 2 Nut, hex brass .50”-14 NPSM
16 03099.0000 1 Gasket
17 39786.0002 1 Gauge, Sight W/Markings - Black
18 01175.0000 4 Foot Kit
19 03710.0000 2 Handle, Brown
03710.0002 2 Handle, Black
02325.0000 4 Screw, pan head .25”-20 x .312”
20 03043.0002 1 Decal, Fresh Brewed Iced Tea
21412.0000 1 Decal, Fresh Brewed Iced Coffee
21 00651.0000 1 Decal, BUNN
22 27294.0000 1 Decal, Reservoir Cleaning
The Following Items Are Not Illustrated
23 03362.1004 1 Faucet Shank Kit, Black (Includes items 12 thru 16)
24 00674.0000 1 Brush, cleaning
25 29166.0000 1 Faucet Repair Kit, Brown (Includes items 6, 8, 9 & 10)
29166.0001 1 Faucet Repair Kit, Black (Includes items 6, 8, 9 & 10)
29166.0002 1 Faucet Repair Kit, Black (Sweet / Unsweet) (Includes items 6, 8, 9 & 10)
41183.0000 1 Faucet Repair Kit, Black (Sweet / Unsweet) (Includes items 5 & 12)
10334 121007
