Burcam 503121S User manual

FACTORY SET VOLTAGE 115 V
CONNECTION VOLTAGE
CHANGING:
Before changing the
voltage connection:
A) Ensure the power to
the pump is disconnected.
B) Open motor junction box cover.
C) Please select the up knob
position for 115V or down
knob position for 230V.
D) Connect to appropriate voltage.
E) Close motor junction box.
WWW.BURCAM.COM
2190 Boul. Dagenais West TEL: [phone]
LAVAL (QUEBEC) FAX: [phone]
CANADA
H7L 5X9 [email protected]
Your pump has been carefully packaged at the
factory to prevent damage during shipping.
However, occasional damage may occur due
to rough handling. Carefully inspect your
pump for damages that could cause failures.
Report any damage to your carrier or your
point of purchase.
INSTALLATION
INSTRUCTIONS
MODELS
503121S/503221S
AND
BY- PRODUCTS LIKE
503127S, 503128S,
503228S, 503131S,
503231S, ETC.
JET PUMP
Please read these
instructions
carefully. Failure
to comply to
instructions and
designed
operation of
this system,
may void
the warranty.
© 2014 BUR-CAM Printed in Canada 510059
Suction connection
Discharge connection
PRIMING PROCESS
Follow all these inside step by step instructions to install your pump. Use teon tape on
all threads. (1) Fill the suction line with water and connect it to the suction inlet.
(2) Remove the priming plug and ll the pump body with water. (3) Screw the plug to
the priming inlet. (4) Turn the power on. The pump should deliver water to the plumbing
line within 30 seconds. If not, unplug the pump and repeat the process at step 2.
4
1
2-3

2
Safety Instructions:
This ne pump that you have just purchased is designed from the latest in material and workmanship.
Before installation and operation, we recommend the following procedures:
CHECK WITH YOUR LOCAL ELECTRICAL AND PLUMBING CODES TO ENSURE YOU COMPLY
WITH THE REGULATIONS. THESE CODES HAVE BEEN DESIGNED WITH YOUR SAFETY IN
MIND. BE SURE YOU COMPLY WITH THEM.
WE RECOMMEND THAT A SEPARATE CIRCUIT BE LEAD FROM THE HOME ELECTRICAL
DISTRIBUTION PANEL PROPERLY PROTECTED WITH A FUSE OR A CIRCUIT BREAKER. WE
ALSO RECOMMEND THAT A GROUND FAULT CIRCUIT BE USED. CONSULT A LICENSED
ELECTRICIAN FOR ALL WIRING.
THE GROUND TERMINAL ON THE THREE PRONG PLUGS SHOULD NEVER BE REMOVED.
THEY ARE SUPPLIED AND DESIGNED FOR YOUR PROTECTION.
NEVER MAKE ADJUSTMENTS TO ANY ELECTRICAL APPLIANCE OR PRODUCT WITH THE
POWER CONNECTED. DO NOT ONLY UNSCREW THE FUSE OR TRIP THE BREAKER, REMOVE
THE POWER PLUG FROM THE RECEPTACLE.
A
B
C
D
Material required for drilled well application(indoor use only)
Shallow well pump installation
• Desired length of polyethylene 1” pipe, 100 PSI, CSA or
UL approved, to link up from pumping level to pump.
• 1 1” foot valve (750756 or 750752P).
• 1 well seal, as per well casing diameter
(750929 6” x 1”).
• 1 1” well seal elbow (750860).
• 1 1” male adaptor (750865 or 750871) and 1 1¼’’ to 1’’
male adaptor (150181).
• 8 1” stainless steel clamps (750885).
• Teon tape.
Tank installation
• Desired length of 1” braided hose (750919) to link up
from pump to tank. Keep tank as close as possible from
pump.
• 1 tank T (650651).
• 1 drain valve (650659)
• 2 1” female adaptor.
• 1 1” male adaptor (750865 or 750871).
• 3 1” stainless steel clamps (750885).
• Teon tape.
Tools
Screwdrivers, hacksaw to cut pipe, knife to assist in pipe cutting, round le to smooth pipe ends, pipe wrench,
adjustable wrench to tighten ttings, propane torch and welding material.
Monthly Mandatory check-up:
1. Inspect the pump for any obvious condition that necessitates cleaning, correction, adjustement or repair.
2. Clear the surrounding of any paper, leaves or other debris.
3. Assure that the pump is secure for proper operation.
4. Assure that there is adequate clearance from any combustible materials or stucture. Stored materials
must be kept away from the pump. Shelves or cabinet structures must not be in close proximity over
the pump.
5. Assure that the motor is securely plugged into a proper GFCI electrical outlet.
6. Test the GFCI outlet by pressing its test switch. This should prove that the outlet is energized and will trip
off to protect against a ground fault. Be sure to reset the GFCI by pressing its reset switch.
7. Observe that the plumbing can carry the water safely into the residence.

APPLICATION
• This pump is designed for shallow well
installation for water level up to 25 feet.
• CAPACITY:
5’ 815 865 US GPH
10’ 715 755 US GPH
15’ 630 665 US GPH
20’ 550 575 US GPH
25’ 500 530 US GPH
FEATURES
• Easy tu prime pump body.
• Totally enclosed, fan cooled motor,
bearing to bearing. Built for a continuous use.
• Full time connected run capacitor, to eliminate
starting wear vs regular motor.
• Thermal and overload protection.
• Noryl impeller, built-in injector
• 1/2 HP, 115 / 230 VAC, 60 Hz, 8.6 A / 4.3 A
(at start:15 A / 7.5 A).
• 3/4 HP, 115 / 230 VAC, 60 Hz, 8.8 A / 4.4 A.
(at start:15 A / 7.5 A).
FRICTION LOSS IN
PIPE NOT INCLUDED
INSTALLATION STEPS
We recommend that you install your pump in a clean and dry location where
there is adequate room for servicing at a later date. Protection from freezing
temperatures and good ventilation should be considered as well, to provide the
pump an environment for long life. Locating the pump as close as possible to the
water source will reduce friction losses encountered in the suction pipe.
Friction losses in the suction pipe must be taken into consideration when the
horizontal offset is greater than 50 feet. The suction pipes should be increased
from 1” to 1 1/4”. This will reduce friction losses and allow the pump to give
maximum performance.
A new well should be checked to determine that it is free from sand. Sand will
damage the seal and the impeller. Have your well driller clean the well before
your installation.
Never run the pump dry. Damage to the seal may occur. Fill pump body and
suction pipe with water before turning on the power.
THE RUN OF HORIZONTAL PIPE FROM THE TOP OF YOUR WELL
INTO THE HOUSE, WHERE YOUR PUMP WILL BE LOCATED,
MUST BE INSTALLED IN A TRENCH, BELOW THE FROST LEVEL
OF YOUR AREA.
STEP 1
3
1/2 HP 3/4HP

SHALLOW WELL APPLICATION
SEE DIAGRAM ON PAGE 7
Cut the desired length of poly pipe to run from the top of the well to the pumping level.
Smooth the pipe cuttings with your round le. (Check that no cut-out parts are left inside of
the pipe. This may block pump injector or impeller). Tape male adaptor threads with teon
tape and thread adaptor into the foot valve. Slide 2 stainless steel clamps over one end of
pipe and use torch to soften pipe. Insert the male adaptor and foot valve into this pipe end.
Tighten clamps with screwdriver when cool. For security against leaks, we suggest to
install 2 stainless steel clamps on each adaptor.
Insert the well seal elbow through the opening of the seal.
Slide 2 stainless steel clamps over the free end of the previously cut pipe and soften pipe
with your torch. Attach pipe to the well seal elbow (end protruding at bottom of well seal).
Tighten clamps with screwdriver when cool.
Install the well seal and piping assembly into your well casing. Tight down the well seal bolts
using your adjustable wrench.
Install your pump in the house, on a sound foundation, as close as possible to the basement
wall. Locate the suction inlet in the front of the injector. Thread an adaptor into inlet using
teon tape. Do not over tighten.
Cut the desired length of pipe from pump location to the well seal and connect both ends
using the previous way, with stainless steel clamps and torch. Do not ll in your trench to
the house until you have checked for any leaks in your connections or trouble in your
water system.
Sand or well points are limited to areas where water bearing sand or gravel lies below the
surface, and where there are no boulders or rocks to interfere with the driving into the ground
of the point.
The amount of water any “one” well point will supply is usually rather limited. Sometimes, it is
necessary to use more than one point to increase the supply of water, entering to the pump’s
suction.
THE IMPORTANT INSTALLATION STEP IN USING WELL POINTS IS THAT A CHECK
VALVE MUST BE USED IN THE SUCTION PIPE LEADING TO THE SUCTION INLET,
AS CLOSE TO THE PUMP AS POSSIBLE, TO KEEP SUCTION LINE AND PUMP WELL
PRIMED.
To facilitate servicing at a later date, you may use a pitless adaptor and a sealed well cap
instead of an elbow and a well seal as describe in steps 3 and 4.
CONTINUE ON PAGE 5 & 6 FOR TANKS AND ELECTRICAL INSTALLATION STEPS
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
STEP 7
for sand
or well
points
4

TANK INSTALLATION
SEE DIAGRAM ON PAGE 8
Packaged systems have the pump mounted directly to the tank. The pump to tank plumbing
ttings are pre-assembled in factory. You only have to connect the discharge line of your
system to your home’s plumbing distribution line. When using a separate tank from your
pump, we recommend to install a captive air tank as shown in our typical installation diagram,
that is air injected into the tank at the factory. This air, which is in addition to atmospheric
pressure, increase the ability of the tank to deliver more water between on/off cycles, this
increasing the efciency of your water system. Connect the pump discharge to the tank T,
using adaptors and braided hose, then, connect the other side of tank T to your home’s
plumbing distribution line.
Make sure that the precharged air pressure (before connecting the tank) is 2 PSI less
than the starting pressure setted on the pressure switch of your pump. If you adjust the
air pressure after the installation, follow these steps:
- Check the starting pressure of the pump on the pressure gauge;
- Disconnect the power to the pump;
- Open nearest fawcet to the tank and relieve all pressure in tank, then close
the fawcet;
- Adjust the air pressure of the tank (by pumping or removing air at the snifter valve)
2 PSI below pressure switch “ON” setting;
- Turn power back on to pump.
Your tank is now well precharged. Run the pump through a few cycles to verify that it works
properly.
Other types of tanks may be used, as galvanized standard tanks, epoxy or glass lined tanks.
These products do not achieve the benets of the captive air tanks.
Epoxy or glass lined tanks with oat have to be precharged by the installer. Assuming tank is
plumbed to pump and all connections are checked for leaks, follow these steps:
- Run pump through one complete cycle, until pump shuts off;
- Disconnect the power to the pump;
- Open nearest fawcet to the tank and relieve all pressure in tank, then close
the fawcet;
- Close service line gate valve;
- With a car tire pump, inject air into the snifter valve located in tank. Watch pump
pressure gauge and stop pumping air when pressure reach 2 PSI below pressure
switch “ON” setting;
- Return power back on to pump;
- Run pump through one complete cycle;
- Open service line gate valve.
Your tank is now well precharged. Run the pump through a few cycles to verify that it works
properly.
Galvanized standard tanks require an air volume control to be used with jet pump. We do not
recommend the installation of this type of tank with your jet pump. This type of galvanized
tank is recommended with piston pumps.
STEP 8
for captive
air tanks
STEP 8
for epoxy or
glass lined
tanks
Not
recommended
for galvanized
tanks 5

ELECTRICAL INSTALLATION
STEP 9
6
We recommend that a licensed electrician be employed to do the proper wiring to the pressure switch,
and to permanently ground the motor in accordance to the electrical codes in your area.
Do not use an extension cord to connect your pump to the power source. From your
distribution panel to the pressure switch, we recommend a wire gauge not smaller than 14 gauge.
This is a dual voltage 115/230 pump. The voltage selection switch is located inside the terminal box.
The motor is factory wired on 115V. For 230V selection, please open the terminal cover and set the switch to
the proper voltage. (See above drawing on right ).
Pressure switch setting (start/stop 20/40 or 30/50) has been made at the factory. Adjustments may be done
to give other operating pressures.
Adjustment or modication of start/stop setting of pressure switch have to be done carefully.
Turn adjustment nut half turn at a time.
Turn nut 1 clockwise to raise start and stop pressure setting. Never turn nut 2. This will change the 20
PSI range between start and stop presssure and may damage your tank’s bladder or modify the
efciency of your water system. Check system operation after each adjustment.
VOLTAGE SELECTION SWITCH
1. POWER off.
2. Please SELECT the up knob position
for 115 V or down knob position for 230 V.
3. CONNECT to appropriate power source.
1
2
Electrical line
from home
distribution
panel.
BLACK
RED
GREEN
GROUND
To motor lead

SHALLOW WELL APPLICATION
Well point optional installation
7
STEP 6 Cut poly
pipe and connect both ends.
STEP 4 Install well seal
and piping into well casing.
STEP 2 Cut poly pipe
and install the check valve.
Check valve,
close to pump.
STEP 3 Insert well
seal elbow through the seal
and attact to pipe.
STEP 7 You may install one or more sand
points to increase the supply of water.
STEP 5 Install your pump
and thread an adaptor into inlet.

TANK INSTALLATION
8
STEP 8 Connect the pump
discharge to the tank 'T'
Snifter valve to
adjust air pressure
To home’s plumbing
distribution line
Pressure switch
1/4" connection
if not included
with the pump.
Pressure gauge
1/4" connection
Drain valve
1/2" connection
1" MNPT or 3/4"
FNPT connection
Relief valve for
pumps with more
than 75 PSI of
capacity 1/2"
connection
From well

REPAIR PARTS
Ref Part Description
1 510054 Motor 1/2 HP
1 510054-2 Motor 3/4 HP
2 510055 Motor Screws (4)
3 750957S Pressure Switch
4 510056 1/4" NPT 1/4" Barb Elbow
5 750748 Hose
6 510053 Seal Plate O-Ring
7 510052 Mecanical Seal
8 510048 Impeller
9 510047 Diffuser
Ref Part Description
10 510065 Diffuser Plate
11 510051 Diffuser Plate O-Ring
12 510050 Diffuser Plate Washers (3)
13 510049 Diffuser Plate Screws (3)
14 510069 Venturi
15 510046 Nozzle
16 510056 1/4" NPT 1/4" Barb Elbow
17 510045 Pump Body
18 750769 1/4" Pressure Gauge(not shown)
19 510077 Capacitor (not shown)
Repair parts may be ordered from your autorized point of sale or from
BUR-CAM PUMPS
9
01
11
10
02
12
03
13
04
14
05
15
06
16
07
17
08
09
503121S / 503221S 2011

TROUBLE SHOOTING GUIDE CHECKLIST
NEVER MAKE ADJUSTMENTS TO ANY ELECTRICAL APPLIANCE OR PRODUCT WITH THE POWER
CONNECTED. DON’T JUST UNSCREW THE FUSE OR TRIP THE BREAKER, REMOVE THE POWER
FROM THE RECEPTACLE.
TROUBLE PROBABLE CAUSE ACTION
Switch is off position
Blown fuse
Tripped breaker
Dirty pressure switch
Defective pressure switch
Defective motor
Pump not primed
Leaky suction line
Foot valve plugged
Ejector nozzle clogged
Water level below foot valve
Suction lift to great
Improper voltage
Water level below foot valve
Ejector nozzle clogged
Excessive friction in pipe
Improper voltage
Leaky discharge line
Motor not up to normal speed
Improper setting of pressure switch
Ejector nozzle clogged
Pressure tank waterlogged
Leaky foot valve
Leaky suction line
Foot valve do not close properly
Pressure switch out of adjustment
Leaky discharge line (toilet etc.)
Leaky suction line
Gaz in water
Airlogged tank (galvanized)
Turn switch to on position
Replace
Reset
Clean
Replace
Replace
Prime with clean water
Check pipe and pipe connections
Clean
Clean
Check foot valve level
Water level lower than lift capacity
Check voltage
Check foot valve level
Clean
Too small or dirty pipe
Check voltage
Check all pipes for leak
Check power cable and voltage
Reset or replace
Clean
Drain tank and restart
Replace
Check pipe and pipe connections
Clean or replace
Adjust on/off setting
Check all pipes for leak
Check pipe and pipe connections
Check and consult factory
Replace air volume control
Motor does not
run.
Motor runs but
no water is
delivered.
Pump does not
deliver to full
capacity.
Pump does not
shut off.
Pump starts and
stop too often.
Air spurts from
fawcets.
TO THE END CONSUMER
If you have any problems with the product, before advising the store, where
you’ve purchased the pump, please contact us at 514 337-4415 , and ask for
our sales department, and they will be pleased to help you with any questions
you might have, concerning your installation.
10
