Burgmer TFB 240 User manual

BWM TFB page [1] state: 05.2018
ORIGINAL OPERATION, MAINTENANCE
AND ASSEMBLY INSTRUCTION
HAZARDOUS MATERIAL VALVE TFB
Important!
Read these instructions carefully
before initial operation!

BWM TFB page [2] state: 05.2018
IMPRINT
All rights reserved.
Subject to alterations without prior notice.
Copyright 2018 by BURGMER Apparatebau GmbH 42327 Wuppertal
Details in this documentation are provided to specify products,
not to warrant any specific qualities.

BWM TFB page [3] state: 05.2018
CONTENTS DIRECTORY
1 Introduction..................................................................................................................................... 4
2 Description ...................................................................................................................................... 6
2.1 Validity of these operating instructions .................................................................................. 6
2.2 Responding documents........................................................................................................... 6
2.3 Marking of Hazardous material valves.................................................................................... 7
3 Intended use.................................................................................................................................... 7
4 Safety hints...................................................................................................................................... 8
4.1 General safety hints ................................................................................................................ 8
4.2 Safety hints for operator ......................................................................................................... 8
4.3 Special hazards ........................................................................................................................ 9
4.4 Qualified staff .......................................................................................................................... 9
5 Transport and storage ................................................................................................................... 10
6 Assembly, initial operation, handling, disassembly ...................................................................... 10
6.1 Assembly ............................................................................................................................... 10
6.2 Initial operation phase .......................................................................................................... 12
6.3 Handling ................................................................................................................................ 12
6.4 Disassembly........................................................................................................................... 13
6.4.1 Switching off the system ............................................................................................... 13
6.4.2 Carrying out of disassembly .......................................................................................... 13
6.5 Troubleshooting .................................................................................................................... 13
7 Maintenance ................................................................................................................................. 16
7.1 Safety hints............................................................................................................................ 16
7.2 Inspection list and maintenance works................................................................................. 17
8 Annex............................................................................................................................................. 17
8.1 Torques.................................................................................................................................. 17
8.2 Permitted internal working pressure “MWP“ of valves........................................................ 18
8.3 Material compatibility of valve ............................................................................................. 18

BWM TFB page [4] state: 05.2018
1Introduction
The valves described below are type tested and fulfil the requirements of DIN EN
14432:2014 “Tanks for the transport of dangerous goods. Tank equipment for the transport
of liquid chemicals. Product discharge and air inlet valves”. The following standards were
also applied: DIN EN 12266-1, DIN EN 10213, DIN EN 12516-2, DIN EN 10222-5, DIN EN
10026-2.
Name and address of notified body:
TÜV Nord Systems GmbH & Co. KG
Technikzentrum
Langemarck Str. 20
45141 Essen
Testing specifications are detailed in the accompanying manufacturer’s declaration. In case
of use outside Germany, the operating company is responsible for ensuring the compliance
with all national regulations.
ATTENTION!
The valves are not suitable for use in potentially explosive atmospheres (according to -
ATEX-regulation 2014/34/EU!
For the application range of the Pressure Equipment Directive – DGRL 2014/68/EU, only
valves which bear a CE marking can be used! (observe category!)
ATTENTION!
When removing and / or disguising our nameplate, all guarantee and liability will expire.
If the nameplate is replaced by the costumer, it is his responsibility to ensure the
traceability of the product!
It is not allowed to remove or replace nameplates of valves provided with
CE markings!
The use of these operating instructions requires a proper qualification by the user. Please
refer to chapter 4.4 “Qualified staff”
Operating staff is to be instructed according to operating instructions.
These instructions shall help you to install, operate and maintain the Hazardous material
valves and provide you with all the necessary information for performing these tasks.
They should be read and kept very carefully. Hints and warnings must be strictly observed!

BWM TFB page [5] state: 05.2018
ATTENTION!
The following symbols are used to indicate warnings and other important notes in these
operating instructions:
Means that death, severe body injuries or considerable material damage will ensue if the
corresponding precautions are not taken.
Means that death, severe body injuries or considerable material damage may ensue if the
corresponding precautions are not taken.
Means that light body injuries or material damage may ensue if the corresponding
precautions are not taken.
These operating instructions are subject to technical improvements and
alterations at any time.

BWM TFB page [6] state: 05.2018
2Description
Hazardous material valves can be used for shutting off, conduction or regulation of liquid
chemicals.The valves can be attached to tanks, containers and pipelines.
However, this requires that the Hazardous material valves are designed and manufactured
in accordance with the working conditions and the consumer specification.
Materials, types of actuation and driving power must be suitable for the respective
application.
The applications listed above are grouped below under the term “system”.
2.1 Validity of these operating instructions
These operating instructions are valid for all BURGMER Hazardous material valves of type
TFB designed for use in the areas described under chapter “1. Introduction“.
Included are the following different types of design:
Hazardous material valves
•without actuation provided by manufacturer
•manual actuation
•foreign operated (pneumatic-/ electric driven)
2.2 Responding documents
The offer/work order form drawn up for each Hazardous material valve as well as all
pertinent documents are an integral part of the internal documentation.
It contains the following information:
•medium / pressure / temperature / state of aggregation
•temperature class
•identification no. of operator or facility (if required)
•nameplate(s)
•manufacturer’s declaration according to DIN EN 14432:2014
•technical information concerning the Hazardous material valve and its application
Further responding documents are:
•Assembly, operating and maintenance instructions for all specified attached parts
•Declarations of manufacturer and certificates of conformity

BWM TFB page [7] state: 05.2018
2.3 Marking of Hazardous material valves
All Hazardous material valves are marked according to DIN EN 19. The information is located
on the casing or on a nameplate.
BURGMER Apparatebau GmbH
Refer to imprint in operating instructions for
address
Type
e.g. TFB1-XX
Type of Hazardous material valve
Serial-No
e.g. 218XXXX-1
Digits 1-7: Burgmer order no., digits 8-9: item no.
Date
e.g. 2018
Date of manufacture
DN
numerical value e.g. 100
Diameter of the valve
MWP
numerical value e.g. 10,0 bar
or e.g. 6,0 bar
Max. permitted working pressure (bar)
10,0 bar at temperature range -20°C/+250°C
6,0 bar at temperature range -20°C/+200°C
TS
numerical value e.g. -20°C
/+200°C
Upper / lower temperature range
ATTENTION! TS
is specified only for valves for
temperature range -20°C/+200°C
Body
e.g. 1.0619
Body material
Disk
e.g. 1.4408
Valve disk material
Seat
e.g. PTFE
Material of sealing
DIN EN 14432:2014
Note on the test basis
3Intended use
The noncompliance with the precautions described in this chapter may endanger the life of
the user and cause damage in the system.
Once incorporated into the system, the Hazardous material valves are to be used only for
shutting off, conduction or regulation.
The Hazardous material valves are exclusively intended for the application range described in
the documentation enclosed to order (order/commission number).
It is not permitted to use the Hazardous material valves for other purposes than those
described in the specification.
Don’t exceed by any means the permitted pressure and temperature range of the valves!
Don’t exceed by any means the permitted temperature class.
Chapter 4 “Safety hints” is to be strictly observed.

BWM TFB page [8] state: 05.2018
4Safety hints
4.1 General safety hints
The safety hints applying to the system, into which the Hazardous material valve is
incorporated, apply also to the Hazardous material valve itself.
These operating instructions provide only safety hints to be observed additionally for the
Hazardous material valves. Please ensure to read and observe also the enclosed operating
and maintenance instructions of the attached parts.
4.2 Safety hints for operator
Compliance with the safety hints as listed below lies within the sole responsibility of the
operator:
•Please take care to observe all safety regulations valid for the country of operation
and / or the operating company.
•The Hazardous material valve is to be used solely for the intended purpose as
described in chapter 3 “Intended use”.
•The whole system must be installed and checked periodically by qualified staff.
(Refer to chapter 4.4 “Qualified staff”)
•Appropriate measures are to be taken to avoid human extremities being
entrapped by moving parts of the system!
•Warning signs or barriers must be put up if necessary!
•An accidental starting or stopping of the system is strictly to be avoided!
•Additional pipeline forces or torques acting on the Hazardous material valves are
not permitted and must be previously agreed with the manufacturer.
•The correct function of safety appliances provided by the customer (e.g. emergency
stopping, safety valves, etc.) is to be verified and ensured prior to start-up!
•The Hazardous material valves are to be started up only when fully incorporated
into the system and only by qualified staff of the operating company.
•The valve may conduct only media previously agreed with its manufacturer!
•Abnormal working conditions like vibrations, cavitation, water hammers, etc. are
not permitted.
•The max. permitted ambient temperature for operating the valves is –20°C to
+40°C. Other temperatures must be previously agreed with the manufacturer!
•In case of operating temperatures below -20°C or above +50°C, the valve is to be
provided with a protection against accidental contact.

BWM TFB page [9] state: 05.2018
•ATTENTION! Don’t exceed by any means the max. permitted torques indicated in
item 8.1 “Torques”!
We point out, that there are still risks for the user of Hazardous material valves, even if
they are designed and manufactured with the highest possible care. Nevertheless,
damage to persons and parts can only be a result of improper handling.
4.3 Special hazards
•Please ensure to eliminate completely any pressure existing in the system before
removing the Hazardous material valve or unscrewing any bolted connections on the
attached parts.
•Please ensure to evacuate completely any medium to prevent any escapes when
removing the Hazardous material valve. Proceed with special care in case of hazardous
or harmful substances!
ATTENTION!
Residues may accumulate in any parts of the system and the dead spaces in the
valves.
4.4 Qualified staff
Must be individuals familiarized with transport, assembly, initial operation, operation and
maintenance of valves and provided of the proper qualification for their activities and duties.
This qualification includes, among others:
•Indoctrination and commitment to comply with all national, local and internal
requirements and provisions.
•Indoctrination or training, in accordance to safety standards, in the proper use and
care of the reasonable safety and personal protective equipment.

BWM TFB page [10] state: 05.2018
5Transport and storage
Hazardous material valves are to be handled, transported and stored with absolute care
(protected against shocks, impacts and vibrations)!
All bare parts must be protected against corrosion!
Storage and transport temperature must be within the range of –20°C to +60°C.
ATTENTION! Don’t store the valves in aggressive atmosphere.
The Hazardous material valves should be transported in their protective packaging to the
place of incorporation. The Hazardous material valves are to be stored with the valve disk
slightly open. This doesn’t apply to Hazardous material valves – with single acting pneumatic
actuation, safety position “CLOSED” - mandatorily delivered in closed position. Storage time
may not exceed here 2 weeks. Otherwise the valve must be separated from the actuator.
6Assembly, initial operation, handling, disassembly
SAFETY HINTS!
Read chapters 3 “Intended use” and 4 “Safety hints” before starting to assemble and/or
disassemble the Hazardous material valve.
6.1 Assembly
BURGMER Hazardous material valves are to be installed or attached between or to flanges,
according to EN 1092-1 and DIN EN 1759-1, with sealing bars of shapes B1 or B2, which are
plane parallel machined and have to align. Other types of flanges and sealing bars may only
be used after the manufacturer has checked their technical viability.
The seal faces of body and counter flanges must be smooth and clean.
In BA and collar II seals, the sealing insert acts at the same time as flange seal. Please make
sure to use counter flanges with diameters suited to support the seals of the butterfly valves.
The inner diameter of the counter flanges is intended to cover at least 2/3 of the seal face
and at most the clear width of the valve.
Don’t use additional flange for this type of sealing.
It is forbidden to weld the flanges to the system or other pipeline/conveyor parts after the
Hazardous material valve is installed (seal insert can burn!).

BWM TFB page [11] state: 05.2018
INSTALLATION INSTRUCTIONS!
•Check the Hazardous material valves for transportation damages. Don’t install the
valves if it’s damaged.
•Make sure to install only Hazardous material valves, which technical specifications
(permitted pressure, temperature class, etc.) fulfil the installation requirements.
•The Hazardous material valve must be inserted in a slightly open condition into the
gap between the counter flanges. Seals may otherwise leak later in shaft area.
•The clear width of the counter flanges must provide enough space for the open valve
disk, otherwise it can be damaged while opening.
•The Hazardous material valves can be installed in any position with regard to the
medium flow direction.
•The valve may not serve as fixed point; it is supported by the pipeline system.
•Please ensure to insert the Hazardous material valves centred between the counter
flanges.
•Huge and heavy actuators must be stabilized.
•Clean the flange faces and install flange seals appropriate to the quality of the valve
seal. (IMPORTANT!see also item 6.1.)
•If the valves are provided with grounding screws, shaft and body of the valve must
be integrated mandatorily into the potential equalisation of the whole system. Shaft
and body are provided for this with a specially marked threaded hole. The grounding
cable must have then a cross section of at least 4mm² for nominal widths 50-100
Furthermore, the 90° rotational movement of the shaft is to be taken into account
when dimensioning the length of the shaft grounding cable!
•Thermal expansions in the system are to be compensated through compensators.
•All flange connections are to be tightened with the torques [Ma in Nm] specified in
the following table. The use of torque wrenches ensures that the necessary tightening
torques are adjusted, but not exceeded. Align flanges in plane parallel first. Tighten
then connecting screws crosswise in 3 steps.
Step 1: 50% of the respective tightening torque
Step 2: 80% of the respective tightening torque
Step 3: 100% of the respective tightening torque
Tightening values for DIN flange connections
Diameter DN 50 80 100
Tightening value Ma
[Nm]
60 60 80

BWM TFB page [12] state: 05.2018
Instructions for connecting of pneumatic actuators:
•Make sure to control the system pressure of the control lines when using pneumatic
actuators. The max. control air pressure specified in the order documents must be
strictly observed! Never exceed it!
Instructions for connecting of electric actuators:
•Does the existing connection voltage relate to the rate of the actuator manufacturer!?
(see nameplate and operation instructions)
•Check sense of rotation right after connecting (phase balance). Observe sense of
rotation arrow in the inspection glass.
•Depending on the design of the electric actuators, safety precautions against overload
(thermal switch or torque switch) are to be integrated as well into the control circuit.
Instructions for connecting of ordered accessories:
•Please refer to the corresponding operation instructions of the ordered accessories for
the connecting of solenoid valves, positioners, signalling units as well as the specified
actuators (pneumatic, electric).
6.2 Initial operation phase
ATTENTION! Prior to commissioning, it must be ensured that the system contains no
foreign objects!
A test run without product must be always performed first!
Refer to item 6.5 “Troubleshooting” in case of leaks on the Hazardous material valve!
The Hazardous material valve may only be used after a successful test run has been
performed.
6.3 Handling
The Hazardous material valve can be provided with either a manually operated lever or an
actuator for opening and closing. Normal hand force is sufficient for manual operation.
The functioning of the Hazardous material valve can be monitored by inductive or optic limit
switches.
IMPORTANT! It is not permitted to use extensions to increase actuating moment.
Don’t exceed by any means the max. driving torques specified in Table under “8.1 Driving
torques”!

BWM TFB page [13] state: 05.2018
6.4 Disassembly
IMPORTANT! Disassembly of the Hazardous material valves may be performed only after
authorisation by the responsible company department and only by qualified staff (decision
of the operating company)
6.4.1 Switching off the system
The following points are to be observed mandatorily in addition to the measures indicated
in item 6.1 “Assembly”:
•Relieve pressure in pipeline
•Let the medium cool-off
•Empty plant completely
•Ventilate the pipeline in case of corrosive, aggressive, toxic or inflammable media.
Hazardous material valves with pneumatic or electric actuation must be duly shut down by
“qualified staff” in accordance to the valid occupational safety regulations of country of
operation before disassembly.
6.4.2 Carrying out of disassembly
Remove carefully bolted connections on flanges (IMPORTANT! The system must be
relieved of pressure!).
Remove Hazardous material valve in closed position from the system.
Remove carefully any dirt.
Unrepairable valves are to be disposed of according to the valid environment protection
regulations.
6.5 Troubleshooting
Failure
Reason
Elimination
Flange connections
are leaky
Hazardous material valve
wasn’t centred during
installation
•Switch off system (refer to 6.4.1)
•Remove Hazardous material valve
•Check for damage on sealing and
flange faces
•Replace seal if necessary
•Install Hazardous material valve
(according to assembly
instructions)
•
Carry out function test

BWM TFB page [14] state: 05.2018
Failure
Reason
Elimination
Flange connections
are leaky
Inner diameters of
flanges or flares are too
big
•
Switch off system (refer to 6.4.1)
•Remove Hazardous material valve
•Check for damage on sealing and
flange faces
•Check out inner diameters of
flanges or flares
•If necessary, install flanges or
flares provided of a sufficient
bearing surface
•Install Hazardous material valve
(according to assembly
instructions)
•
Carry out function test
Hazardous material
valve can’t be closed
Solid object between seal
insert and valve disk
•Switch off system (refer to 6.4.1)
•Remove Hazardous material valve
•Remove solid object
•Check for damage on sealing and
valve disk and repair them if
necessary
•Install Hazardous material valve
(according to assembly
instructions)
•Carry out function test
Hazardous material
valve can’t be closed
Seal insert is porous
•Check out if operating
temperature is according to
specification
•Switch off system (refer to 6.4.1)
•Remove Hazardous material valve
•Check for damage on sealing
•Repair with corresponding sealing
•Install Hazardous material valve
(according to assembly
instructions)
Carry out function test
Hazardous material
valve can’t be closed
Additional pipeline forces
are too big! Hazardous
material valve is distorted
•Refer to chapter 4.2.
Hazardous material
valve can’t be closed
Pressure of medium in
pipeline is too high
•
Check out if system pressure of
control line is according to
specification
•Driver power is insufficient
Hazardous material
valve can’t be closed
Cross section of
pneumatic feed lines is
too small
•Checkout lines and replace them if
necessary

BWM TFB page [15] state: 05.2018
Failure
Reason
Elimination
Hazardous material
valve can’t be closed
Choke in solenoid valve is
clogged
•
Remove and clean choke
Hazardous material
valve leaks in closed
position
Sealing is worn out
(natural wear)
•Switch off system (refer to 6.4.1)
•Remove Hazardous material valve
•Checkout if sealing is worn out
and repair with new spare part
•Install Hazardous material valve
(according to assembly
instructions)
•Carry out function test
•Observe maintenance intervals
and shorten them if necessary
Hazardous material
valve leaks in closed
position
Actuator provided by
client: driving torque is
too big, causing distortion
of square
•Use actuator with lower driving
torque (refer to item 8.1. „Driving
torque“)
•Replace shaft
Hazardous material
valve leaks in closed
position
Position of valve disk and
limit switch or valve
control don’t match
•Check out actual position of valve
disk
•The marking of the front side of
upper shaft (“0”) must align to the
markings on valve neck (“0”) and
valve disk (”0”)
•In case of polished or coated valve
disk („0“) the marking on the
outside of the valve must align to
the marking („0“) on the front side
of upper shaft
•Hazardous material valves with
actuators (pneumatic, electric)
check end position adjustment of
actuators (refer to the operation
instructions of the actuators)
Hazardous material
valve leaks in closed
position
Inner diameter of counter
flanges is too small.
Valve disk hits flanges in
open position.
•Replace flanges and if necessary
damaged shaft / valve disk
ATTENTION! Observe the safety hints listed in chapter 4 when performing works of any
kind on the Hazardous material valve!

BWM TFB page [16] state: 05.2018
7Maintenance
BURGMER Hazardous material valves, without attachments, are maintenance-free if
operated correctly.
RECOMMENDATION! Extensive maintenance and repair should be done by the
manufacturer in order to avoid costs of stand-still
Relubrication of bearings is not necessary. Bearings are provided with permanent
lubrication by manufacturer.
ATTENTION! When detecting a defect on a valve or its attachments, the system is to be
shut down immediately and restarted only after elimination of defect!
7.1 Safety hints
Any kind of work on the Hazardous material valves should be done only by
“qualified staff” (refer to chapter 4.4)!
Before starting to work, inform the safety officer.
•Secure the Hazardous material valves against accidental start up, cut off pneumatic
or electric connections!
•Do not grasp into the open Hazardous material valve!
•Hazardous material valves mounted under vessels have to be secured by an
emergency shutoff before working on them!
•Keep vessels, pipes and feeding parts of plant free of product when doing extensive
maintenance or repair works on the Hazardous material valves.
•Avoid after-running of product by closing stop valves or taking other convenient
actions.

BWM TFB page [17] state: 05.2018
7.2 Inspection list and maintenance works
Action weekly monthly (every 4-5 weeks)
Visual control of electric and
pneumatic connections
Check air-tightness of
solenoid valves and
pneumatic connections
Check bolted connections
(actuators, control elements,
flanges) and tighten them if
necessary
Checking for leaks in shaft
exits area (upper and lower
shaft) of valve:
Liquids: Check visually for
leaks!
ATTENTION! When detecting
a leak, shut down plant as
soon as possible and repair
valve!
8Annex
8.1 Torques
Breakaway torques indicated in table applies to liquid and well lubricating media! Values are
to be multiplied by a factor 1, 2 in case of dry non-lubricating media!
Diameter DN
50
80
100
Breakaway torque [Nm]
unpressurized
35 55 65
Don’t exceed by any means the max. permitted driving torques on the valve shaft indicated
in Table!
This is to be taken strictly into account when choosing an actuator and establishing the
system pressure of the actuator control lines!
Diameter DN
50
80
100
Max. perm. driving
torque [Nm]
50 80 90

BWM TFB page [18] state: 05.2018
8.2 Permitted internal working pressure “MWP“ of valves
ATTENTION! Don’t exceed the permitted working pressure values listed below in Table!
Diameter DN
50
80
100
Max. perm. working
pressure MWP (bar)
-20°C/+50°C
10 10 10
Max. perm. working
pressure MWP (bar)
-20°C/+200°C
6 6 6
8.3 Material compatibility of valve
ATTENTION! The valve may conduct only with media agreed previously with its
manufacturer!
