EFFICIENT & ECONOMICAL
GAS -FIRED STEAM OR
HOT WATER HOME HEATING
INDEPENDENCE®/INDEPENDENCE® PV

2
Quality Con truction
Made in the USA
Every Burnham boiler is made
in the U.S.A.
All Burnham
heat ex-
changer
castingsare
produced
“in-house”
to ensure
qualityandavailability.Burnham
is the only boiler manufacturer
that can make that claim.
Rugged cast iron sections
Hundreds of heat extracting
pinsextractthemaximumamount
of heat, reducing fuel consump-
tionand savingyou money.
Steel couplings called nipples
Steel nipples increase the
longevity of the boiler by
resistingpetroleumbased
chemicals, including antifreeze.
Theseinhibitors candeteriorate
the rubber type gaskets which
are commonly found in some
competitors'boilers.
LifetimeTrue-Blue
limitedwarranty
Burnham stands behind every
Independence boiler with a 10-
year limited warranty on the
Long Term Home
Comfort and Quality
steam heat exchanger, and a
lifetime limited warranty on the
water heat exchanger. The
additionalpurchaseofBurnham’s
Winter Warmth Assurance plan
extends the True Blue Warranty
protection of the heat exchanger
to 5 or 10-year blanket coverage.
The program pays 100% for parts
and labor on qualified repairs for
5 or 10 years from the date of
installation.See yourBurnham
Home Heating Team contractor for
moreinformation
Independence Advantage
• With an annual fuel utilization
of 83.2%, the Independence gives
you excellent value for your
dollar.
• A rear drafthood (Indepen
dence models only) installs in low
overhead areas and allows for
clearance and flexibility for
existingpiping.
•Standard oneach Burnham
Independence Series boiler is a
100% safety shutoff, a time-
proven safety feature with its own
backupsystem.
•A fuel saving vent damper
(Independence models only)
automatically closes the flue to
prevent heat from escaping up the
chimney after the burner shuts off
and reopens it again before the
burner comes on.
•The Independence can also
be equipped with a spark-ignited
electronicignitionwhich
improves energy efficiency.
Burnham's Independence®
Series gas-fired boilers offer you
all the benefits of hydronic heat
withthe advantagesof quality
castironconstructionand
advanced engineering. Offered in
steam or hot water, the
Independence is a quiet, reliable,
and efficient boiler.
The Independence natural draft
boiler is available in ten sizes,
and the power vented steam
model is available in four sizes.
Your contractor can size the
Independence boiler to match the
heating requirements of your
home for optimum efficiency.
Independence PV —
Power Vented Model Available
The Independence PV boiler
offers you all the features of
steam heat with the flexibility of a
power vented boiler. The com-
pletely packaged Independence
PV boiler installs almost any-
where because no chimney is
required for installation.
A draft-inducing fan pulls hot
gases through the heat exchanger
at just the right speed for opti-
mum efficiency. Together, the
heat exchanger and fan provide
more heat with less fuel con-
sumption.Noventdamper is
required.
So, if you don't have a chimney
or if your old chimney is deterio-
rated or not up to code, you can
install the Independence PV boiler
andventdirectlyoutsidethrough
the wall.
BURNHAM INDEPENDENCE SERIES
GAS-FIRED STEAM OR HOT WATER BOILER
Burnham Nipple vs. Competitors' Gasket

3
children and safe from accidental
bumpsandtampering.
• Power vented model simplifies
installations when a chimney isn't
available.
One Source for
Total Comfort
Burnham is dedicated to leading
thehydronicheatingindustry
throughproductdevelopmentand
engineering expertise. With years
of proven dependability, and the
broadestproductline,Burnhamis
the one brand you can rely on for
your complete home heating
comfort.
• Burnham uses quality
Honeywell controls on the
Independence and the
Independence PV.
•Industrial quality pressuretrol
for accurate, trouble-free control.
•Stainless steel burners equal
long life with no rusting like
aluminizedburners.
•Step-opening gas valve
enablesthe boiler to start on low
fire and continue on to high fire
safelyandsmoothlyproviding
quiet ignition and long life. The
valve is concealed inside the
boiler jacket, hidden from
Why settle for just a high
efficiency Burnham Independence
boiler, when you can have a
completeBurnhamsystem?
Improveupon yournewboiler’s
efficiency with Burnham’s
complete line of system compo-
nents including: the Alliance™
family of indirect water heaters,
radiant heat pipe and accessories
fromBurnhamRadiantHeating
Company,lowprofilebaseboard,
modernradiators,andelectronic
controls. Burnham also offers the
industry’smostcomprehensive
technicalsupportavailable.Now
is the time to make Burnham the
one source for your total hydronic
heatingsystem.
Dimensions (in inches) and Standard Equipment
StandardEquipment:
Reardrafthood(IndependenceOnly)
CastIronSections
Combustible Floor Certified
Stainless Steel Burners
Flame Roll Out Switch (FRS)
BlockedVent Switch (BVS)
(IndependenceOnly)
Concealed Step Opening Gas Valve
Safety Relief Valve
Pressure Limit Control (Steam)
*Dimensions indicated are for USA only - For Canada, use dimension on next larger model.
LEDOM 'A' 'B' 'C' 'D' 'E' 'F' 'G'
3NI 2/1-41 04 4/3-33 4 4/1-04 4/3-4 4/1-7
4NI 4/3-71 04 4/3-43 5 4/1-04 4/3-4 8/7-8
5NI 12 04 4/3-53 6 4/1-04 4/1-5 2/1-01
6NI 4/1-42 04 4/3-53 *6 4/1-04 *4/1-5 *8/1-21
7NI 2/1-72 04 4/3-63 7 4/1-04 2/1-7 4/3-31
8NI 4/3-03 04 4/3-63 *7 4/1-04 *2/1-7 *8/3-51
9NI 43 04 4/3-73 8 4/1-04 2/1-7 71
01NI 4/1-73 54 4/3-83 *8 2/1-54 2/1-7 8/5-81
11NI 2/1-04 54 4/3-83 9 2/1-54 2/1-7 4/1-02
21NI 4/3-34 54 4/3-83 9 2/1-54 2/1-7 8/7-12
VP3NIP 2/1-41 54 A/N 3 A/N A/N 4
VP4NIP 4/3-71 54 A/N 3 A/N A/N 4/1-8
VP5NIP 12 54 A/N 3 A/N A/N 4/1-9
VP6NIP 4/1-42 54 A/N 3 A/N A/N 4/1-9
Low Water Cut Off (Steam)
Steam Pressure Gauge (Steam)
Pressure Temperature Gauge (Water)
ThermostatIsolation Relay
VentDamper-IN3-IN9(IndependenceOnly)
2"SupplyTapping
2"ReturnTapping
(2) 1-1/4" Indirect Water
Heater Tappings
3"AL29-4C®StainlessSteelVent
Connector/Terminal(IndependencePVOnly)

4
The Money Saving Solution
SinceBurnham's Independence
is one of the most efficient boilers
you can buy - with an annual
efficiency of 83.2% - you can
savehundreds ofdollarsduring
yourfirst heatingseason. Com-
pare this to 60% efficiency for a
typical 20 year old boiler or 50%
for a typical 40 year boiler that
may have been converted from
coal firing. Your local Burnham
dealer can test your current unit
and tell you at what efficiency it
isoperating.
For example, say you spend
$1500 on fuel in one year. To
figure out what your annual
savingswouldbe,simplydivide
your existing boiler's efficiency
rating by that of the Indepen-
dence boiler. Multiply that
amount by $1500 and you'll find
outapproximatelyhowmuchit
will cost to operate your new
Independence boiler. You can see
that much of the heat you're
currently paying for is going right
up the chimney!*
Find out how you can enjoy
winter warmth this year, and for
many years to come. Burnham is
the answer to all your heating
needs.
(*Savings will vary based on
yearly heating degree days.)
A. Rear Drafthood (Independence Only)
B. Large Steam Dome
C. Cast Iron Nipple
D. Deluxe Insulated Jacket
E. Step Opening Gas Valve
F. Combustible Floor Certified
G. Stainless Steel Burners
H. Heavy Duty Base Construction
I. Cast Iron Sections
J. Brand Name Quality Controls
K. Built-in Thermostat Isolating Relay
A
C
D
I
F
G
H
E
J
K
sgnivaSruoYenimreteDotwoH
:alumroF tnerruCruoY s'relioB ycneiciffE gnitaR XruoY tnerruC launnA lliBleuF =ruoY detamitsE leuFweN lliB
2.38 :elpmaxE tadetarsiycneiciffes'reliobtneserpruoY .0051$sillibleuflaunnaruoydna%06 06 X005,1$ =180,1$
2.38 sgnivaSlaunnA914$=
B

5
INDEPENDENCE®
BOILER

6
SPECIFICATIONS
Form No. PL81401101000d-02/03-15Ms
Printed in the U.S.A.
©2003 U.S. Boiler Co., Inc. - Lancaster, PA
Phone: [phone]
www.burnham.com
ORDERING INFORMATION
The Independence is available as:
Packaged - Use prefix PIN (Sizes PIN3-PIN7)
Semi-packaged - Use prefix SIN (Sizes IN3-IN9)
Knocked-down - Use prefix KIN (Sizes KIN3-KIN12)
INDEPENDENCE® PV RATINGS Natural Gas Packaged Only
INDEPENDENCE® RATINGS Natural or LP Gas*
* LP available on IN3-IN9
1.Ratings shown are for installations at sea level and elevations up to 2,000 ft. For elevations above 2,000 ft., ratings should be
reduced at the rate of four percent (4%) for each 1,000 ft. above sea level.
2.Capacities, outputs and ratings are based on steam combustion efficiency of 82.5%. Water combustion efficiency is 83.5%.
3.For Canadian builds only: Reduce input and output by 3%.
4.15 ft. height is measured from top of drafthood to top of chimney.
5.IN6, IN8, & IN10 - Canada only: Increase chimney diameter by 1".
Working Pressure: 15 PSI Steam; 30 PSI Water
1.Capacities and ratings are based on steam combustion efficiency of 83.0%. (84.1% for PIN3PV)
2.The approved venting system for the Independence PV is 3" AL29-4C®stainless steel. Do not substitute other materials.
3.Vent pipe length is listed in equivalent feet. Any elbows or tees used have specific values which must be subtracted from the
total length to determine maximum length of straight pipe. Consult Installation, Operating and Service Instructions for details.
Steam only - 15 PSI Working Pressure
RELIOB REBMUN
TUPNI HBM )1(
EOD GNITAEH YTICAPAC )2()1(HBM
)2(GNITARR=B=I
EUFA
.XORPPA GNIPPIHS THGIEW ).SBL(
MUMINIM DEDNEMMOCER EZISYENMIHC DNUOR ).tF(.tHx).nI(.aiD )5()4(
V42 IE
RETAW HBM MAETS HBM MAETS .TF.QS RETAW MAETS RETAW MAETS
3NI 4NI 5NI 6NI 7NI 8NI 9NI 26 501 041 571 012 542 082 1578 511 441 371 202 132 4467 001 521 051 671 102 835668 801 031 251 471 851 172 853 054 245 336 527 0.18 3.18 6.18 8.18 1.28 1.18 4.18 0.08 0.08 3.08 6.08 9.08 0.08 3.08 1.38 1.38 1.38 2.38 2.38 2.38 2.38 9.18 0.28 0.28 1.28 1.28 2.28 2.28 053 024 584 555 026 096 067 51x4 51x5 51x6 )5(51x6 51x7 )5(51x7 51x8
SSORG TUPTUO HBM )%(YCNEICIFFENOITSUBMOC
RETAW MAETS
)3(01NI )3(11NI 21NI 513 943 583 78.952 29.782 26.713 622 052 672 591 612 932 218 009 699 5.38 5.38 5.38 5.28 5.28 5.28 518 588 559 )5(51x8 51x9 51x9
RELIOB REBMUN TUPNI HBM
EOD GNITAEH YTICAPAC )1(HBM
SGNITARTENR=B=I MUMIXAM HTGNELTNEV TNELAVIUQE )3()2(.TF %EUFA
.XORPPA GNIPPIHS THGIEW ).SBL(
MAETS HBM MAETS .TF.QS
VP3NIP VP4NIP VP5NIP VP6NIP 26 501 041 571 2578 611 541 935678 901 361 172 363 454 54535353 2.38 2.28 2.28 2.28 553 524 094 065
