Burnham V8H Series User manual

• Modern, Energy Saving, Cast Iron Design
• 8 Sizes: 70-299 MBH (0.6 to 2.6 GPH)
• Multiple Oil Burner Options
• Quiet Operation with Burner Cover
(Included with Beckett and Riello Burners)
• Durable Push-Nipple Construction
• Easy to Clean with Side and Top
Cleanouts - Provides Complete Access
• Optional Tankless Heater
High Efficiency Oil-fired Boiler
85+% AFUE
ENERGY STAR®Certified

© 2007 U.S. Boiler Company, Inc. - Lancaster, PA
Phone: [phone]
www.burnham.com Printed in the U.S.A.
Form No. PL81401281000-11/07-10M
Ratings
*I=B=R Gross Outputs
1. V8H2 is available as a packaged water boiler only and is not available with tankless heater.
2. The I=B=R Burner Capacity is based on oil having a heating value of 140,000 BTU/GAL.
3. DOE Heating Capacity and Annual Fuel Utilization Efficiency (AFUE) are based on U.S. Government tests at 13.0% CO2with No. 1 maximum smoke and 0.02 inches water column
over fire draft on standard equipment package.
4. Net I=B=R Ratings are based upon a pick-up allowance of 1.15. Consult manufacturer with unusual piping and pickup requirements before selecting boiler.
5. Net I=B=R Ratings are based upon a pick-up allowance of 1.333. Consult manufacturer with unusual piping and pickup requirements before selecting boiler.
6. As an ENERGY STAR®partner, Burnham has determined that those models with an AFUE of 85% and higher meet the ENERGY STAR®guidelines for energy efficiency.
7. Used for sizing flue connection materials. Maximum Working Pressure: 15 PSI steam; 30 PSI water, standard; 40 psi water optional; 50 psi water optional— USA only.
Boiler
Model
Burner
Capacity
(GPH) (2)
DOE
Heating
Capacity
(MBH) (3)
I=B=R Net Ratings Flue
Collar
Dia.
(In) (8)
Minimum Chimney Req. AFUE % Approx.
Shipping
Weight
(Lbs)
Water
(MBH) (4)
Steam
(MBH) (5)
Steam
(Sq. Ft.)
Round
Dia.
Rectangle
In x In
Height
Feet Steam Water
V8H2 Water 0.60 70 61 — — 5 6 8 x 8 15 — 82.1 450
V8H3 Steam
V8H3 Water
0.75
1.05
91
125
—
109
68
—
283
—6 6 8 x 8 15 85.1 —
—
85.0 542
V8H4 Steam
V8H4 Water
1.05
1.35
127
162
—
141
95
—
396
—66 78 x 8 15 85.3 —
—
85.3 634
V8H5 Steam
V8H5 Water
1.35
1.65
164
198
—
172
123
—
512
—7 7 8 x 8 15 85.4 —
—
85.3 726
V8H6 Steam
V8H6 Water
1.65
1.90
201
228
—
198
151
—
629
—77 88 x 8 15 85.7 —
—
85.3 818
V8H7 Steam
V8H7 Water 2.10 252 219 189 787 8 8 8 x 8 15 84.7 85.0 910
V8H8 Steam
V8H8 Water
2.35
2.35
275*
266*
239
—
—
200
—
833 8 8 8 x 12 15 — — 1002
V8H9 Steam
V8H9 Water
2.60
2.60
299*
298*
260
—
—
224
—
933 8 9 8 x 12 15 — — 1094
Boiler
Model ‘A’ ‘B’ ‘C’
V8H2 12-1/8” 6-5/8” 5”
V8H3 17-1/8” 9-1/8” 6”
V8H4 22-1/8” 11-5/8” 6”
V8H5 27-1/8” 14-1/8” 7”
V8H6 32-1/8” 16-5/8” 7”
V8H7 37-1/8” 19-1/8” 8”
V8H8 42-1/8” 21-5/8” 8”
V8H9 47-1/8” 24-1/8” 8”
FRONT VIEW RIGHT SIDE VIEW
(6)
