Bush BSOPT60X INOX Assembly Instructions

I
Issue 1 - 26/05/15
These instructions contain important information which will help you get the best from
your appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call Argos Product Support 01759 487838
Important – Please read these instructions fully before installing or using
Installation & User Instructions - Please keep for future reference
Built-in Ovens
Cooker serial number place sticker here
Cat no Model
4967589 BUSH BSOPT60X INOX
4769268 BUSH BSOPT60B BLACK

1
Contents
Safety Information
Parts
Installation
Electrical connection
User Instructions

Using the oven
Using the grill
Cleaning and Maintenance
Troubleshooting
TechnicalSpecications
Disposal information
Guarantee
2-3
4
5-6
6
7-10
7-8
9
14
15
16
16
17
Place Registration
and waranty label, here
Programmable Timer 10-13

2
Important – Please read these instructions fully before installation
Safety Information
INSTALLATION WARNINGS
Argos Product Support 01759 487838
IMPORTANT: Carefully unpack and examine
the appliance for any damage. If you think there
is a defect, do not use the appliance and contact
Argos Product Support on 01759 487838.
Packaging materials should be collected
together and disposed of immediately as they
may be harmful to children.
IMPORTANT: Keep the electrical cable (not
supplied) of your cooker away from the hot
areas of your cooker; do not let the cable touch
the appliance. Keep the cable away from sharp
edges and heated surfaces.
IMPORTANT: Ensure that the electric supply
cable is not trapped or damaged during
installation.
IMPORTANT: In the event that the cable
connecting your cooker becomes damaged, it
must be replaced by a suitably qualied person.
This cable must not be replaced by an
unauthorised person.
IMPORTANT: Protect your cooker against
atmospheric effects. Do not expose your cooker
to effects such as sun, rain, snow etc.
IMPORTANT: The materials surrounding the
appliance (cabinets) must be able to withstand a
minimum temperature of 100°C
IMPORTANT: When using your oven for
the rst time your oven may give off an
unusual odour and smoking may be evident
from the heating elements and insulation
materials. This is normal for new cookers.
To eliminate this odour run the oven at 250
degrees for 40-60 mins with the oven empty.
DURING USAGE
IMPORTANT: Children and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge should not
be allowed to use the cooker unless supervised
and warned of the hazards involved
WARNING: The appliance and its accessible
parts become hot during use. Care should be
taken to avoid touching hot parts.
WARNING: NEVER try to extinguish a cooking
re with water. Instead switch off the appliance
and cover ame e.g. with a lid or a re blanket.
CAUTION: Do not allow children in the kitchen
when cooking or while cooker parts may still be
hot. Many parts of the cooker will become hot
and present a considerable hazard to children.
CAUTION: When the oven is hot never touch
the oven glass by hand or with tools.
CAUTION: Before starting to use your
appliance, ensure curtains, paper or ammable
items are kept away from your appliance.
Do not keep ammable materials inside of or
around your cooker.
CAUTION: Take care when closing the oven
door that there is nothing obstructing it from
closing as this may break the glass door.
IMPORTANT: When using the grill the oven door
must be kept closed.

3
Important – Please read these instructions fully before installation
Safety Information Argos Product Support 01759 487838
IMPORTANT: Make sure the cooker control
knobs are all in the off position when not in use
IMPORTANT: If you do not intend to use your
cooker for a long period of time turn off the
electric supply to the cooker
CAUTION: Using gas cooking appliances
results in the production of heat, moisture and
the products of combustion. Ensure that the
room where your cooker is installed is well
ventilated particularly while the cooker is in use.
Keep natural ventilation holes open or install a
mechanical ventilation device (extractor hood)
Prolonged intensive use of your cooker may
call for additional ventilation (by opening a
window) or by increasing the level of mechanical
ventilation where present.
GENERAL SAFETY WARNINGS
IMPORTANT: This appliance has been designed
for non-professional, domestic use only. Do not
use this cooker for commercial use or any other
application e.g. room heating
WARNING: Danger of re: do not store
ammable items on or near the cooking surfaces
or inside the oven.
IMPORTANT: Do not try to lift or move this
cooker by pulling on the door handle
WARNING: Ensure that the appliance is
switched off before replacing the lamp to avoid
the possibility of electric shock.
IMPORTANT: Your appliance is produced in
accordance with all applicable local and
international standards and regulations.
IMPORTANT: Maintenance and repair work
must only be performed by authorized service
technicians.
Installation and repair work that is carried out
by unauthorised technicians is dangerous
and could invalidate your guarantee
IMPORTANT: When the door of the oven is
open, do not hang or lean anything on it. You
may unbalance your appliance or damage the
door or door hinges.
IMPORTANT: Do not hang towels, dishcloths or
clothes from the cooker or its handles.
CLEANING AND MAINTENANCE
IMPORTANT: Always turn the appliance off
before operations such as cleaning or
maintenance. You can do this by switching the
cooker off using cooker isolation switch.
IMPORTANT: Do not remove the control knobs
to clean the control panel.
When you have nished cooking check that
all controls are in the OFF position.
-Please check your electrical installation is
earthed. This appliance must be installed by
a qualied engineer.
- Thisappliancemustbettedwithamin
16 A Fuse.
-Please ensure that plug of your oven
is not accidentally pulled or stretched
beyond the extent of the power cord. If
this appliance is installed without proper
earthing the manufacturer dose not accept
any reasonability for any damage caused.
Commissioning of this appliance should only
be attempted by an Authorised competant
person. Connection of this appliance must be
via a cable that is 3 x 2.5 mm2
- For isolation safety the length of the
power cord must not exceed 2 meters.
- Connection diagram can be found on
the rear of the appliance
- Please reset the timer when in the
event of a power failure. The oven will not
operate until the timer is properly set.

4
If you have damaged or missing parts,
call Argos Product Support 01759 487838
Parts
Please familiarise yourself with the parts and accessories listed below
SECTION 1 TECHNICAL FEATURES of OVEN
1. Oven Handle
2. Oven Glassdoor
3. Tray
4. Grid
5. Oven Gasket
6. Control Panel
7. Control Knob
8. Side Panel
9. Inner Body
10. Lower Element
11. Upper Element
12. Indicator Light
13. Signal Lamp
14. Timer
13
14
13

5
Argos Product Support 01759 487838
Installation
Installation
Positioning
The furniture close to the cooker must be
manufactured resistant to temperatures up to
100°C
- Dimensions and materials of
cabinet must be suitable and capabable of
withstanding heat radiation from oven.
- Correct Installation - Cabinet should
not come into contact with any of the ovens
electrical parts.
Isolation materials or parts that used for
isolation must afx strongly to prevent taking
out by any tool.
- It is not recommend you to install
your appliance near refrigator or freezer.
- If a hob is installed with your oven, all
electrical cables of cooker and oven must be
seperate.
- Install your appliance in a position
that allows access to power cable.
- Do not place power cable to close or
in contact with hot surfaces. Do not attach
the cable to the oven door.

6
Argos Product Support 01759 487838
Installation
Electrical Connection
IMPORTANT:
Electrical connections must be carried out by
a suitably qualied person and in accordance
with all relevant local building and installation
regulations.
1. See the rating label at the rear of the
product for the appliance’s load rating.
2. The cooker must be connected to a circuit
suitably rated for the load of the appliance
(see rating label at rear of appliance)
3. The electrical cable should not touch the hot
parts of the appliance.
The electrical cable should not be routed
through any area that may be affected by
heat from the oven, especially the area
directly behind the oven.

7
Argos Product Support 01759 487838
User Instructions
Using the oven
INTRODUCTION of CONTROL PANEL
Front panels and control knobs for Built-In Oven models are at Figure 7. The Knobs control
power and setting of each heating element. Turn Knobs clockwise to activate oven and set at
required cooking temperature. Turn Knob anti-clockwise to decrease cooking temperature and
to deactivate oven.
Thermostatic Control of Oven
The indicator lamp will switch on together with the thermostat. When the heat inside the
oven reaches the set value, the thermostat cuts the circuit and the lamp will go off. When the
heat falls below set value,the thermostat will switch on again and indicator lamp will be lit.
Usage of Oven
For initial operation of your oven, a smell arising from insulation materials and heating
elements will be generated. To help avoid it, operate your oven at 250 C for 45 minutes
without putting any trays in oven.
Functiions Digital Timer Themostat Control
Figure 7.

8
Argos Product Support 01759 487838
User Instructions
Using the oven

9
Argos Product Support 01759 487838
User Instructions
Using the oven
WARNING
To ensure the oven shelves operate safely, correct placement of the shelves A between the
side rails B (positions 1, 2, 3, 4) is important. This will ensure that during careful removal
of the shelf or tray C, hot food items should not slide out.
Using the grill
Grill Function of Oven - Closed Door Grilling
Turn the oven control knob to position
• We advise you to use trivet shelf placed into grill tray when you are
grilling. This will help avoid spills and help keep your oven clean
• If you decide use grill wire on shelf rather than placing in tray, position a
tray below to collect oils. For easy cleaning, put some water in tray.
• Preheat grill with door closed position for 5-10 minutes before use.
• Always pre-heat grill before use and grill with door closed

10
Argos Product Support 01759 487838
User Instructions
Using the timer
Electronic timer, which enables your oven to get the food ready to serve at the desired time.
The only thing to be done is to program the cooking time and ready time. It can also be used
as an alarm clock, where you just give in the amount of time after which it should remind you
by a buzzer tone.
POWER UP:
Upon power up, flashing digits and AUTO icon, the oven is
inoperative. Press M to return to manual mode and adjust the
time of day using up and down buttons.
MANUAL MODE
POWER UP: Upon power up, flashing digits and AUTO icon, the oven is inoperative. Press M to
return to manual mode and adjust the time of day using up and down buttons.
MANUAL MODE
Touching & at the same time, manual m ode is entered.
Any previous cooking program will be cancelled.
ADJUSTING TIME OF DAY
Time of day adjustment is onl y allowed, when no c ooking program is in progress. First enter
manual mode as descr ibed above. The point bet ween the hours and minutes display flashes.
1) Switch into time 2) Adjust the time using 3) After a few seconds,
adjustment mode. the or buttons. screen will stabilize.
BUZZER ALARM:
With this feature, you can program after how much elapsed time you should be warned by a buzzer
sound.

11
Argos Product Support 01759 487838
User Instructions
Using the programmable timer (continued)
1) Touching twice, 2) Using or give in the 3)After a few seconds,
enter buzzer alarm mode duration in minutes screen will return to clock
mode
CANCELLING THE BUZZER SOUND
After the programmed duration is elapsed, buzzer will
sound. Any button touch will cancel the buzzer.
AUTOMATIC COOKING PROGRAM
If you want to start cooking immediately, you just have to give in the cooking time.
Example: We placed our food into the oven and want it to be cooked for 2 hours and
15 minutes
1) Current time is 18:30. 2) Switch into cooking time 3) Adjust the cooking time
mode. using the or buttons.
Now, you have programmed your oven to
cook the food for 2 hours and 15 minutes.
Please do not forget to bring the function
and/or temperature knobs of your oven to
appropriate position .
4) After a few seconds, the screen
will indicate that cooking has
started and show the current time
Note: You may cancel the automatic cooking mode any time by go manuel mode

Argos Product Support 01759 487838
User Instructions
Using the programmable timer (continued)
In the above example, cooking immediately started after giving in the cooking period. By
pressing the button, you can see the r eady time, ie. The time when the food will
be ready t o serve, and if you want, you can also change it. In t he example below, the
ready time will be changed to 21:30.
1) Displayed is the ready 2) Set it to the desired time 3) In a few seconds, screen
time 18:30+2:15=20:45. by using the + or – buttons. switches to clock mode.
We now have programmed our oven to get the food ready at 21:30. Since the cooking
time was preprogrammed as 2 hours 15 minutes, your oven will start cooking at 19:15,
so that the food is ready at 21:30.
Screen just when cooking starts Screen just when cooking ends
When automatic cooking is completed, a buzzer alarm is heared and will sound, if not
stopped, for 7 minutes.
1) Switch your oven OFF 2) Reset the timer
Note: Your oven will be inoperative until you reset the timer.
In the example shown, cooking time has been progr ammed first the ready time was
calculated automatically and was edited by us. It is also possible first to program the
ready time, in that case the cooking time will be calcula ted automatically and should b e
edited thereafter.
12

Argos Product Support 01759 487838
User Instructions
Using the programmable timer (continued)
CHILD LOCK:
When activated in manual mode, your oven and the timer keys are blocked.
When activated as a cooking program is in progress, just the keys are blocked.
1) Touch and at the same time 2) The key symbol appears on the
for 1 seconds until 2 beep tones heard. screen, child lock is active.
To deactivate the child lock, touch and until key symbol disappears.
Exception: A buzzer tone during child lock can be cancelled touching any button.
USER PROGRAMMABLE OPTIONS:
1- Time of day display 12h / 24h
Factory setting is 24 h display. Touching for 5 seconds, a double beep tone
will be heard, the display mode toggles to 12 h mode (am / pm indication) Doing
this again will toggle back to 24 h
2- Touch tones
As a factory setting, touching buttons are accompanied by beep tones. Touching
the button for 5 seconds, a double beep tone will be heard and nt , which
stays for no tone, will appear on the screen. Now, no touch tones will be produced
any more. Doing the same until bt appears on the screen, which stays for button
tone, brings you back to touch tones.
3- Screen Brightness Adjustment:
Touching button for 1 second, until you hear a double beep tone, brings you
into the display brightness mode. Display shows br 0x (x = 1 to 8). Now every
consecutive touch of the same button will reduce the brightness. There are 8
levels, thereafter the brightness starts to increase upon every touch. The same
effect is also seen by holding this button touched. In 5 seconds after releasing the
button, the brightness level is stored. Factory setting is maximum brightness.
4- Buzzer Tone Selection:
Touch button for 1 second, until you hear a double beep tone. Upon
every touch of this button within 5 seconds, you will hear a different tone.
There are 3 different tones available. The tone last heard will be stored in
5 seconds.
Note: Programmed options are nonvolatile. They will not be erased upon a
power interrupt.
13

Argos
Product Support 01759 487838
Cleaning and Maintenance
Cleaning
WARNING! Isolate the power supply to the cooker and make sure that the oven is cool.
Do not clean using caustic creams, abrasive cleaning powders, thick wire wool or hard tools.
Enamelled parts of the oven can be damaged if excess cleaning liquids are not immediately
removed.
After cleaning the interior parts of the oven with a soapy cloth, rinse it and then dry thoroughly
with a soft cloth.
Clean the glass surfaces with special glass cleaning agents.
Never use ammable agents like acid, thinner or petrol when cleaning your oven.
Do not clean your oven with a steam cleaner.
Do not wash any part of your oven in a dishwasher.
Please remove the
screw shown in the
drawing with the help
of a tool, eg: screwdriver,
and remove the rack
)LWWLQJDQG5HPRYLQJ6LGH5DFN
)LWWLQJDQG5HPRYLQJ,QQHU/DPS
Enamelled Parts:
Enamelled parts must only be cleaned with
warm soapy water and then dried with a
cloth. Do not wash them while hot and never
use abrasive powders or abrasive cleaning
materials. Do not leave anything spilled onto
enamelled parts for long periods of time.
Stainless Steel:
Stainless steel parts must be cleaned
frequently with warm soapy water and a
soft sponge and then dried with a soft cloth.
Do not use abrasive powders or abrasive
cleaning materials. Do not leave anything
spilled onto stainless steel parts for long
periods of time.
Remove the glass front door by unscrewing
the xings using a screwdriver, remove the
inside glass, clean and rinse it. After drying
it replace the seal properly and re-install the
glass
Remove the cap of the lamp with the help of a tool e.g.: screwdriver, and then remove the lamp
by turning to the side shown in the drawing. Turn the oven off from the electric supply and make
sure that the oven is cool. Replace the old bulb with a new bulb resistant to 300°C
(230 V, 25 Watt, Type E14).Replace the lamp protective glass. Your oven isnow ready for use.
14

15
Argos Product Support 01759 487838
Troubleshooting
If your cooker does not appear to function correctly
If oven doesn’t heat;
Oven’s plug may not be fitted into an earthed
socket; your fuse may be blown; timer may not
be adjusted (if the model has a timer)
If oven doesn’t operate;
Please check that the switch knob is adjusted to
one of the functions of the oven for multi-function
models
Please check that thermostat control knob is
adjusted.
Please check the fuse oven is connected, and the
main fuse, to make sure it didn’t blow.
If inner lamp doesn’t function;
check if the electricity is on, bulb is not faulty, if it is
change the bulb as per the instructions in the manual.
Upper and lower heaters don’t cook evenly;
Check raw positions, thermostat positions and
timing referring to the manual.
If the problem continues, please call the authorised
service closest to you.
Please do the following controls before calling
authorised service

16
Argos Product Support 01759 487838
Technical Specications
We apologise for any inconvenience caused by minor inconstancies within these instructions that
may occur due to product improvements and development
All images and drawing are for illustration purposes only.
This appliance/tting is marked according to the European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of
this product.
The symbol on the product, or on the documents accompanying the product, the
crossed out wheelie bin symbol, indicates that this appliance/tting may not be
treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must
be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local authority, your household waste disposal service or the retailer where you
purchased the product.
MODEL
COLOUR
ENERGY TYPE
TIMER
INNER CAVITY
COOKING FUNCTION
OVEN VOLUME
OVEN POWER
GRILL POWER
TURBO REZISTANCE
TURBO FAN
TOTAL POWER
THERMOSTAT OVEN
SECURITY
VOLTAGE
FREQUENCY
ENERGY CLASS
ENERGY CONSUMPTION ( CONVENSIONAL-KWH)
ENERGY CONSUMPTION – FORCED AIR- KWH
PRODUCT DIMENSIONS
OUTER WIDTH ( MM )
OUTER DEPTH ( MM )
OUTER HEIGHT ( MM )
STAINLES STEEL
ELECTRIC
DIGITAL TIMER
1
7 FUNCTIONS
67 LITERS
3350 WATTS
3200 WATTS
2000 WATTS
YES
3350 WATTS
0-285 C
160 C
2 0 V
50-60 HZ
A
594
560
594
0,82 Kwh
0,79 Kwh
BMFPROGSS

Argos Product Support 01759 487838
Guarantee
.
Product Guarantee
This product is guaranteed against manufacturing defects for a period of
Year
2
This product is guaranteed for 12 months from the date of original purchase.
Any defect that arises during this period due to faulty materials or workmanship will either
be repaired free of charge or replaced.
The guarantee is subject to the following provisions:
• The guarantee does not cover accidental damage, misuse, cabinet parts, knobs
or consumable items.
• The product must be correctly installed and operated in accordance with the
instructions contained in this manual.
• It must be used solely for domestic purpose.
• The guarantee will be rendered invalided if the product is re-sold or has been
damaged by inexpert repair.
• Specications are subject to change without notice.
• The manufacturer disclaims any liability for the incidental or consequential damages.
• The guarantee is in addition to, and does not diminish your statutory or legal rights.
• In the event of a problem with the product with in the guarantee period call :-
Argos Product Support 01759 487838.
Guarantor: Argos Ltd
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
