Bush DFTA47HDR User manual

Quick Star t Infor mation:
1.Connect your aerial cable to your unit.
2.Connect Power Supply to your unit & wall outlet.
3.Connect the supplied composite & audio cable
(Yellow, Red, White) between the STB & Television
4.Insert batteries in the remote control.
5.Switch on and follow on screen instructions.
High Definition
Digital Set Top Box
www.bushaustralia.com.au
DFTA47HDR

2
DFTA47HDR

Contents
Introduction…………………………………………......
Main features and functions……………………............
Features……………………………………………........
Remote control.....................................................
Battery installation................................................
Programming your learning remote control…….......
Front and rear panels……………………………............
Rear panel............................................................
Front panel...........................................................
Installation…………………………………………...........
Connecting the receiver……………………................
Installation guide…………………………………............
Basic operation……………………………………...........
Program settings...................................................
Picture setting......................................................
Channel search.....................................................
Time setting..........................................................
Option..................................................................
System setting......................................................24
USB.....................................................................25
Specifications………………………………………......... 34
Product warranty…………………………………........... 37
...
3
4
4
4
5
8
8
9
9
10
10
10
14
15
16
17
19
21
23
DFTA47HDR

Introduction
This user manual is intended to guide you through the operation
for the Bush DFTA47HDR High Definition DVBT Terrestrial
Receiver.
.
Main features and functions
This product is a high definition digital set top box. It fully complies
with DVB-T receiver requirement specifications. It provides users
with free to air high definition and standard definition digital terrestrial
television and radio signals being broadcast.
Features:
1. Fully compatible with DVB-T FTA digital standard
2. Fully compatible with MPEG-4 H.264/AVC High Definition
Digital TV
3. Fully compatible with MPEG-2 High Definition and
Standard Definition Output
4. Fully compatible with MPEG-1 Layer I & II, Dolby Digital Audio
5. Complies with Australian Standards and MEPS requirements
6. Universal Remote Control - capable of operating the set top box
7.
8. VHF & UHF Input and Loop Out
9. Fully supported 7 Day Electronic Program Guide(EPG)
10. Automatic and Manual search
11. Parental Control
12. Plug and Play installation with an easy to use Menu System
13. Coaxial SPDIF Digital audio output interface
14. 576i, 576P, 720P, 1080i Video Resolution supported
4
The password may be required when you attempt to
modify some advanced settings. The default password is“000000”.
DFTA47HDR
Record digital television FTA program to a USB Flash Drive or an external
USB portable hard disk and playback via USB2.0 compatible.

Remote control
The remote control is shown below and the button functions are listed
in the table on page 6.
15. Supports 4:3 and 16:9 Aspect Ratios
16. Supports Teletext (where broadcast)
17. Subtitles supported based upon availability on the network
18. Channel editing functions (Favorites, Move, Lock, Delete)
19. Supports HDMI High Definition Multimedia Interface(HDMI 1.3 )
20. USB 2.0 Input supports mp3, wma, jpeg and bmp media
playback and Software Upgrade.
5
21.Audible feedback supported.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
DFTA47HDR

Key legend Description
Home Press at any time to return to the first scanned in Channel
TV/Radio Switch between TV and Radio mode
Swap Reverts to the previously viewed channel
Repeat Switch between repeat off,repeat one,repeat random,repeat
the folder.
Vol + / Vol - Increases/Decreases the set top box volume
P+ /P- Changes the channel up/down
Moves the cursor up/left/right/down and scrolls through menus
OK Press to confirm selection
Guide Accesses Electronic Programme Guide
Back When accessing the menu, returns to previously displayed screen
Info Displays information of the current channel being viewed
Exit Exits the item being viewed
Help Press to display basic remote control function information
Text Displays teletext (where available)
Menu Accesses the set top box menu
Press to Mute all audio
To select different options in the menu
ColourButtons
(red, green,
yellow, blue)
For direct channel input, or selection of sub menus in the menu
Numbers
(0-9)
FAV Press to display the list of selected favourite TV channels
SUB Turns subtitles on or off
6
Power Switches the Set Top Box between On and Standby
DFTA47HDR

REC Press REC key to record the current program
while watching TV program
PREV/
NEXT Previous/Next track
FR/FF Press these keys to fast forward or rewind during playback
STOP Press STOP key to stop recording program or stop a
program during playback
PLAY/
PAUSE Play or pause the program during playback
GOTO select the time for multimedia playingGoto
TIME
SHIFT
AUDIO Changes the audio language when available
DFTA47HDR
7
Press to start timeshifted Television.Please note you will need a
USB driver or HDD Plugged into the unit

Battery installation
Insert the batteries while observing the correct (+) and (-)
polarities as illustrated below:
About the batteries:
Notes:
Caution: Keep batteries out of children s reach. If batteries
are swallowed, contact a physician immediately.
,
If the remote control unit fails to work even when it is
operated near the set top box, please replace the batteries.
Use size 2 x (AAA) batteries.
Do not use rechargeable batteries.
Do not place the batteries near a heat source such as a
heater or fireplace.
Do not mix old and new batteries.
If the remote control unit is not going to be used for a long
time, remove the batteries.
DFTA47HDR
8

Front and rear panels
Rear panel
RF IN Aerial Input
LOOP OUT Output of Digital Terrestrial TV Broadcast signal
- e.g. to VCR/DVD Recorder
USB
HDMI
CVBS
YPbPr High Definition Component video output
S/PDIF
R (Audio)
L (Audio)
AC
230V/50Hz
televisions with a HDMI input. HDMI version 1.3
CVBS video output or YPbPr video output is used
CVBS video output or YPbPr video output is used
USB 2.0 Port for media playback and firmware upgrade
High Definition Digital video and audio output for use with
Composite Video signal output
Digital audio output
Audio Output for the right speaker, to be used when either
Audio Output for the left speaker, to be used when either
Power Cable: 230V AC, 50Hz
RF IN LOOP OUT
SPDIF
HDMI
USB
Y Pb Pr
CVBS RAUDIO L
DFTA47HDR
High Definition Digital Set Top Box
POWER SUPPLY:AC 230V~50Hz
MAX POWER CONSUMPTION:8WATTS
DFTA47HDR
9

Front panel
green LED with a channel number is an indication that the set top
box is operational.
You can access basic functions via these keys including:
Power, CH-, CH+.
Installation
Connecting the receiver
How to get good reception
If your antenna is not in good condition, you should consider
replacing it to ensure uninterrupted digital television viewing.
Viewers in areas of poor analogue reception may require a
specialist's advice about antenna requirements for digital
reception in their area.
The antenna to the television.
Connections to a TV
and TV must be either YPbPr Component or HDMI.
Warning: Please switch OFF the mains power before plugging
or unplugging connected cables otherwise it may damage the
receiver.
A red LED indicator on the front panel with the clock displaying the
time will indicate if the set top box is in standby mode whilst the
It is recommended that viewers use quad shielded cable from
There are several ways of connecting your STB receiver to a television.
For High Definition viewing your TV must support either 576p, 720p
or 1080i resolution. Also the connection between the STB receiver
Other connections will provide Standard Definition viewing.
DFTA47HDR
10

Connect the STB receiver via composite video and audio
(For standard definition viewing)
1. Connect the antenna to the RF IN socket on the receiver.
2. Connect the receiver to the TV set via the red, white and
yellow composite AV cables.
AC 230V
~50HZ
OPTION 1
DFTA47HDR
11

Connect the STB receiver via YPbPr output and audio output
(For standard definition viewing)
1.
2.
AC 230V
~50HZ
OPTION 2
Connect the receiver to the TV set via the green, red and blue
component AV cables (this will provide video), and the
composite red and white cables (which will provide audio).
Connect the antenna to the ANT IN socket on the receiver.
DFTA47HDR
12

Connect the STB receiver via HDMI
(For optimum high definition viewing)
1.
2.
OPTION 3
Connect the antenna to the ANT IN socket on the receiver.
Connect the receiver to the TV set via a HDMI cable.
This will provide both video and audio.
DFTA47HDR
13

Installation guide
TV and make sure the receiver is connected to the Main Power.
Menu will appear on your TV screen.
1.
Press the RIGHT/LEFT key to modify the language.
2.
your country of residence.
3. Select Channel Search and press RIGHT or OK key to
begin Automatic channel search.
4.
watch TV.
14
Ensure that all connections have been made properly, turn on the
Make sure that the on/off switch on the back panel of the set top
box is switched to on. Press the Power button on the front panel of
the receiver to switch receiver on. If you are using the receiver for
The first time or restored to Factory Default, the Installation Guide
Select the On Screen Display language (OSD Language).
Select the Country. Press the RIGHT/LEFT key to select
Once channel tuning is complete, you are now ready to
DFTA47HDR

Basic operation
Program settings
To access the Menu,
1. Press the MENU button.
To access the program settings,
1. Select Program.
2. Press OK.
The Menu provides options to adjust the Program settings.
1. Select an option.
2. Press OK or RIGHT to adjust that setting.
3. Press the EXIT button to exit the Menu.
DFTA47HDR
15

Program Edit
default password '000000'.
EPG (Electronic program guide)
Press the GUIDE button on the Remote Control to access guide Directly.
16
To edit your program preferences (Move, Skip, Lock, Delete or
set as a Favourite), you will need to enter the Program Edit
Menu.This Menu requires a password to access. Enter the
The EPG is an on-screen TV guide that shows scheduled programs
seven days in advance for every tuned channel (when broadcast).
DFTA47HDR

You can use the LEFT/RIGHT to view what is on other channels.
Press the red key to skip forward 24 hours, and the green key
to skip back 24 hours. Press the INFO key to book programme
reminders .
Sort
Sort your channels from the following options:
[LCN] Sort the channels in ascending order
[ONID] Group the channels by broadcaster
[Service Name] Sort the channels in alphabetical order
[Service ID] Sort the channels according to the station
LCN (Logical channel number)
Set LCN on or off.
Picture setting
1. Press MENU then select Picture, and then press OK.
2. The Menu provides options to adjust the video settings.
3. Press UP/DOWN to select an option.
4. Press RIGHT/LEFT to adjust that setting.
5. Press EXIT to exit the menu.
DFTA47HDR
17

Aspect Ratio
Set the display format to one of the following to select the best
display for your television
4:3 Full
4:3 Pan & Scan
4:3 Letter Box
16:9 Full Screen
Auto
Resolution
If the video does not appear correctly, change the setting. The
default setting is to match the most common setting for HDMI,
is 1080i.
The resolution options include 576i, 576P, 720P and 1080i.
TV Format
If the video does not appear correctly, you need to change the
settings. PAL is the standard format for Australia. NTSC is the
other settings option.
18
DFTA47HDR

Channel search
1. Press MENU and select Channel.
2. Press OK.
The Menu provides options to adjust the channel search
settings.
1. Select an option and press RIGHT/LEFT to adjust the
settings.
2. Press EXIT to exit the Menu.
Auto search
DFTA47HDR
19

This option will search and install all channels automatically.
This option overwrites all preset channels.
1. Select Auto Search and press OK or RIGHT to start
channel search.
2. To cancel channel search at any time, press EXIT.
Manual search
This option allows you to install new channels manually. This
option adds new channels without changing the current
channels list.
1.
search screen will appear.
2.
3. Press OK to start searching channels.
If a channel is found, it is saved and added to the channels list.
20
Select Manual Search then press OK or RIGHT. The channel
Press the RIGHT/LEFT key to select the channel frequency.
DFTA47HDR
