Bushnell Elite Tactical LMSS2 User manual

Model #s: ET884060H / ET884060T
SPOTTING SCOPE OWNER’S GUIDE
LMSS2
Архангельск [phone]
Астана (7172)727-132
Астрахань [phone]
Барнаул [phone]
Белгород [phone]
Брянск [phone]
Владивосток [phone]
Волгоград [phone]
Вологда [phone]
Воронеж [phone]
Екатеринбург [phone]
Иваново [phone]
Ижевск [phone]
Иркутск [phone]
Казань [phone]
Калининград [phone]
Калуга [phone]
Кемерово [phone]
Киров [phone]
Краснодар [phone]
Красноярск [phone]
Курск [phone]
Липецк [phone]
Магнитогорск [phone]
Москва [phone]
Мурманск [phone]
Набережные Челны [phone]
Нижний Новгород [phone]
Новокузнецк [phone]
Новосибирск [phone]
Омск [phone]
Орел [phone]
Оренбург [phone]
Пенза [phone]
Пермь [phone]
Ростов-на-Дону [phone]
Рязань [phone]
Самара [phone]
Санкт-Петербург [phone]
Саратов [phone]
Севастополь [phone]
Симферополь [phone]
Смоленск [phone]
Сочи [phone]
Ставрополь [phone]
Сургут [phone]
Тверь [phone]
Томск [phone]
Тула [phone]
Тюмень [phone]
Ульяновск [phone]
Уфа [phone]
Хабаровск [phone]
Челябинск [phone]
Череповец [phone]
Ярославль [phone]
Киргизия [phone]-47 Россия [phone] Казахстан (772)734-952-31
https://bushnell.nt-rt.ru || [e-mail]
Зрительная труба LMSS2 Elite
Tactical

2
TRIPOD MOUNTING
Your Elite Tactical LMSS2 spotting scope should be mounted on a high quality, stable tripod (not included) to ensure safe
operation and a vibration-free viewing experience. Attach the scope’s mounting base (I) (1/4”-20 thread) to the screw on the
tripod’s platform, so that the scope is held securely in place and provides a level view (adjust tripod as needed).
USING THE ZOOM EYEPIECE AND FOCUSING
Turn the focus ring (C) in either direction until your subject appears as sharp as possible. To reduce the need to readjust
focus when zooming, set the zoom to its highest power and focus on your subject. When you zoom back down to lower
powers, it will minimize the need for additional focus adjustment.
Rotate the zoom ring (D) on the eyepiece to change magnifying power from low to high. The throw lever (E) provides faster
operation when rapid changes in magni cation are needed (it can be removed if necessary). Lower power settings will
provide a brighter image with a wider  eld of view; higher powers allow observing smaller details on more distant subjects.
Note: the eyepiece section of the scope is not interchangeable. Do not attempt to remove the eyepiece from the scope.
USING THE TWIST-UP EYECUP AND DIOPTER ADJUSTMENT
1. Twist the rubber eyecup (B) clockwise to retract it into the scope, allowing access to the diopter ring (A).
2. If the reticle appears blurry, rotate the diopter adjustment ring (A) with the scope aimed at a blank wall or empty sky to
ensure the reticle is sharp for your eyesight.
3. Twist the eyecup out (counter-clockwise) to adjust it for a comfortable view, ensuring that you can see the entire image
(full  eld of view). If you wear eyeglasses, you may prefer to retract it back down.
Thank you for purchasing your new Bushnell® Elite Tactical LMSS2 Spotting Scope. The LMSS2 (lightweight modular spotting
scope) is a low pro le 60mm spotting scope with an extended 5:1 magni cation ratio (8 to 40 power) with a choice of two
reticles designed by Horus Vision®. Other signi cant features include:
•ED (Extra Low Dispersion) Prime Glass providing dramatic improvement in color correction with superior contrast and
resolution, even in low-light conditions.
•O-ring sealed, waterproof/fogproof, lightweight but rugged aluminum chassis, constructed of the  nest materials and
assembled to the highest quality standards.
•User con gurable accessory mounting rail (Picatinny/Weaver standard).
This manual will help you optimize your viewing experience by explaining how to utilize the scope’s controls and features,
and how to care for it. Read the instructions carefully before using your scope.
NEVER LOOK DIRECTLY AT THE SUN WITH YOUR SPOTTING SCOPE,
AS IT MAY CAUSE SERIOUS DAMAGE TO YOUR EYES
ENGLISH
PARTS GUIDE
Diopter Adjustment A Accessory Mounting Rail F
Twist-Up Eyecup B Objective Lens w/Cover G
Focus Ring C Optional Acc. Rail Location H
Zoom Ring D Tripod Mounting Base I
Throw Lever E
PARTS GUIDE
B
C
D
E
F
H
I
A
G

3
Once set, the eyepiece diopter should not need further adjustment, and the eyecup can be extended again if desired. Do
not use the eyepiece diopter to focus on your subject, only to focus the reticle. Use the main focus ring if the subject is not
sharp.
ACCESSORY MOUNTING RAIL
The LMSS2 includes a Picatinny/Weaver mounting rail (F) for accessories (red dot sights, lasers, night vision, illumination,
etc.). This rail can be positioned to the user’s preference on the scope’s top, left side or right side. Simply remove the two
short screws from the preferred position, then attach the rail using the provided pair of long screws. Torque to 12-15 lbf*in.
HORUS VISION® TACTICAL RETICLES
Model# ET884060H has a Horus H322™ reticle, model# ET884060T has a Horus T4 (Tremor4™) reticle. The H322 reticle
is an ideal parallel reference when working with a shooter using a riescope with the Horus H58™ or H59™ reticle. The T4
reticle provides a calibrated reference for riescopes with Horus Tremor2™ or Tremor3™ reticles. Images of each reticle are
shown on the next page.
Full technical specications and key features/facts for each reticle can be found on the Horus Vision website:
https://horusvision.com.
WATERPROOF / FOGPROOF
Getting caught in a heavy downpour of rain with your spotter won’t be a problem. Elite Tactical LMSS2 spotting scopes are
manufactured and tested to withstand water exposure to IPX7 standards. Fogproof protection is achieved from dry argon
gas purging that displaces all internal air, which can retain moisture.
All exterior lens surfaces have our new EXO Barrier™ coating (in addition to full multi-coating). EXO Barrier, quite simply,
is the best protective lens coating technology Bushnell has ever developed. Added at the end of the coating process, EXO
Barrier molecularly bonds to the lens and lls the microscopic pores in the glass. The result is an ultra-slick coating that repels
water, oil, fog, dust and debris - rain, snow, ngerprints and dirt will not stick. EXO Barrier is built to last: the bonded coating
will not fade with the passage of time or normal wear and tear.
CLEANING AND GENERAL CARE
The lenses of your Bushnell Elite Tactical LMSS2 spotting scope are fully multi-coated for highest light transmission. As with
any multi-coated optics, special care must be taken in cleaning the lenses. Follow these tips for proper lens cleaning:
• Blow away any dust or debris on the lens (or use a soft lens brush).
•To remove dirt or nger prints, clean with the supplied micro-ber cloth rubbing in a circular motion. Use of a coarse
cloth or unnecessary rubbing may scratch the lens surface and eventually cause permanent damage. The included
washable microber cleaning cloth is ideal for the routine cleaning of your optics. Simply breathe lightly on the lens to
provide a slight amount of moisture, then gently rub the lens with the microber cloth.
•For a more thorough cleaning, photographic lens tissue and photographic-type lens cleaning uid or isopropyl alcohol
may be used. Always apply the uid to the cleaning cloth – never directly on the lens.
Never disassemble your spotting scope. Irreparable damage can result from unauthorized service attempts, which also void
the warranty.
H322 and Tremor4 are trademarks of Horus Vision Reticle Technologies
SKU
Magnication Range
Objective Diameter
Reticle
Field of view
ft@100yds / m@100m
Exit Pupil (mm)
@Lo x/Hi x
Eye Relief (mm)
Close Focus (ft)
Length (in/mm)
Weight (oz /g)
ET884060H 8-40x 60 MM H322 250 ft /83m @8x
50 ft/17m @40x
5.0/1.5 30 30 12.7/323 37.1 / 1053
ET884060T 8-40x 60 MM Tremor4 250 ft /83m @8x
50 ft/17m @40x
5.0/1.5 30 30 12.7/323 37.1 / 1053
Technical Specications
Both Models: ED Prime objective lens, Fully multi-coated optics, with EXO Barrier™ on exterior lens surfaces.

-4-5 -2 03- -1
+5
+4
+1
+2
+3
-4-5
-1
-2-3 -1
+3+2 5+1+ +4
+5
+4
+1
+2
+3
+3+2 5+1+ +4
-1
-2-4-5 -3 -1
-2
-3
-4
-5
+5+4+3+2+1
-2
-3
-4
-5
+6 +7 +8 +9 +10 +12+11 [phone]-17 -16 -14-15 +15+14 +16 +17
.9
.8
.7
.6
.5
.9 .8 .7 .6 .5
The H322™ reticle features a square HORUS Grid and HORUS Rapid Range Bars.
Designed for use with the H59 and H58 riescope reticles. Mil radian calibration.
Horus H322™ Spotting Reticle
Model ET884060H

Horus H322™ Spotting Reticle
SPECIFICATIONS
KEY FEATURES
•The H322 reticle is designed to be used with the H58 or H59 riescope reticle, allowing the shooter and spotter to view a target
with the same common frame of reference.
•Patented Horus Rapid Range Bars, for quickly estimating range to targets of known size. Numbers indicate distance in mils of
specic range bar from the horizontal line beneath it.
• Spotting reticle for observational measurement.
•Mil line across the center of the reticle grid is to facilitate target measurement, target speed estimation, Second Shot Correction,
and to help with target location.
• The H322 is not currently available with illumination.
•Secondary horizontal lines allow precise elevation holds. The standard spacing between the secondary horizontal lines is exactly
1 mil.
•To compensate for wind, drift, speed of target, etc.: each secondary horizontal stadia line is calibrated with “large hash marks”
spaced exactly 1 mil apart; between each of the large hash marks, there are smaller evenly spaced hash marks that are exactly 0.2
mils apart.
•The Horus Grid allows you to quickly and accurately make a Second Shot Correction if your rst shot misses.
KEY FACTS
• The H322 spotting scope reticle is located below the central viewing area.
•Central targeting grid calibrated in USMC mils (6283 mils/circle) (1 mil = 3.60 inches at 100 yards) (10cm at 100 meters).
•Precise calibration of measurements to within less than 0.5%.

6
Horus Tremor4™ (T4) Spotting Reticle
Model ET884060T
The Tremor4™ reticle combines a square HORUS Grid with patented Wind Dots and
rened milling “chevrons” found in the Tremor family of reticles.
Designed for use with the Tremor3 and Tremor2 riescope reticles. Mil radian calibration.

Horus Tremor4™ (T4) Spotting Reticle
SPECIFICATIONS
KEY FEATURES
•The Tremor4 reticle is designed to be used with the Tremor3™ or Tremor2™ riescope reticle, allowing the shooter and spotter to
view a target with the same common frame of reference.
•Very ne reticle to aid in precise aiming at high power and distant ranges. Rened “chevron” mil markers subtend to 0.1 mils.
• Patented Wind Dots allow for fast and accurate wind holds.
• Spotting reticle for observational measurement.
• Mil line across the center of the reticle grid is to facilitate target measurement, target speed estimation, Second Shot Correction, and
to help with target location.
•Secondary horizontal lines allow precise elevation holds. The standard spacing between the secondary horizontal lines is exactly 1 mil.
•To compensate for wind, drift, speed of target, etc.: each secondary horizontal stadia line is calibrated with “large hash marks” spaced
exactly 1 mil apart; between each of the large hash marks, there are smaller evenly spaced hash marks that are exactly 0.2 mils apart.
•The Horus Grid allows you to quickly and accurately make a Second Shot Correction if your rst shot misses.
• Not available with illumination.
KEY FACTS
• Ability to perfectly calibrate wind dots to ballistics of your choice.
•Excellent milling capability with 0.1 mil resolution milling chevrons, allowing extremely ne mil estimation.
•The Tremor4 spotting scope reticle pattern is located below the central viewing area, allowing clear observation, while maintaining
measurement capability.
•Central targeting grid calibrated in USMC mils (6283 mils/circle) (1 mil = 3.60 inches at 100 yards) (10cm at 100 meters).
•Precise calibration of measurements to within less than 0.5%.
Measurements are in mils
