BW SENSING DIS331 Series User manual

DIS331 Series
Voltage Single-Axis
Inclination Switch
Technical Manual

DIS331
Voltage Single-Axis Inclination Switch
Designed by Bewis Sensing Technology LLC, The DIS331 series is a single-axis inclination switch, with
a measuring range of ±180°. When the measured inclination angle exceeds the alarm threshold, the
output line becomes closed (disconnected is also available). If the measured inclination does not
exceed the alarm threshold, the output line is normally open (also normally closed). Thanks to the
built-in solid state relay, the user does not need to reconfigure the extra relay. The maximum current
in the normally closed state can reach 1A. The alarm threshold can be set according to the actual
situation. The product is small in size, high in consistency and stability, its working temperature
reaches the industrial grade -40℃~+85℃, which is a cost-effective inclination switch.
●Single axis inclination monitoring optional
●Alarm threshold can be set arbitrarily
●Single line output alarm
●Voltage input: 9 ~ 35V
●Product size: 103.8*55.4*26mm
●Vibration resistance>2000g
●Resolution: 0.01°
●Temperature operation: -40 ° C ~ +85 ° C
●Accuracy: dynamic 2 ° / static 0.1 °
●IP67 protection
●Hydraulic lifting platform
●High voltage wire tower monitoring
●Aerial work vehicle
●Cloud platform leveling
●Based on incline
Introduction
Features
Applications
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

Product number DIS331
Alarm axis
Communication cable
100Hz
9-core cable, 0.15mm² for one
220（1.5 m communication cable, package excluded）
-40〜85℃
9
-40
-55
±180
dynamic 2°/ Static 0.1°
0.01
X
X
±0.01
12
80
100
35
+85
+100
Power Supply (V)
Normally closed
maximum current(mA)
DIS331
Voltage Single-Axis Inclination Switch
Specifications
Electrical Specifications
Operating current(mA)
Conditions
Non-loaded
Min Typical Max
Operating
temperature(°C)
Store temperature(℃)
Measuring range(°)
Accuracy(°)
Resolution(°)
Measuring axis
Zero temperature
drift(°/℃)
Frequency response
(Hz)
Weight（g）
Resolution: The measured minimum change value that the sensor can detect and resolve within
the measurement range.
Accuracy: The error between the actual angle and the Root mean square(RMS) of the measured
angle of the sensor (≥16 times).
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

孔Φ 2mm
43
63
69
49
15
5
DIS331
Voltage Single-Axis Inclination Switch
Package size
Product Size：L103.8*W55.4*H26（mm）
4
10 26
Aviation connector：116
Metal connector：105
86
104
96
36
55
86
Top view
Mechanical Characteristic
Connector
Protection level
Shell material
Installation
Metal connector（standard cable is 1.5m）
IP67
Magnesium alloy anodizing
Three M4 screws
Bare plate product size
Product size: L69*W49*H12(mm)
Note: ±1mm error for length and width dimensions, please refer to actual size.
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
the measured surface the measured surface
C D
the measured surface the measured surface
E F
AB
Secondly, the bottom cable of the sensor and the axis of the measured object shouldn't generate the
angle shown in E. When installing, the bottom cable of the sensor should be kept parallel or
orthogonal to the rotation axis of the measured object. This product can be installed horizontally or
vertically (vertical installation requires customization). The correct installation method is shown in
Figure F.
Finally, the installation surface of the sensor must be fixed with the measured surface tightly and
smoothly, to avoid measurement error that may be caused by the acceleration and vibration.
Axis A
Axis B
Parallel
Axis A
Axis B
Installation direction
The correct installation method can avoid measurement error. The following points should be made
when installing the sensor:
First of all, to ensure that the sensor mounting surface and the measured surface completely close,
the measured surface should be as horizontal as possible, can not have the angle shown in Figure A
and Figure C, the correct installation is shown in Figure B and Figure D.
uneven surface
generates the
angle
uneven surface
generates the
angle
Parallel
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
Electrical Connections
RED
1
VCC
DC 9-35V
BLACK
3
GND
GREEN
4
RXD
YELLOW
5
TXD
BEOWN
8
ORANGE
WHITE PURPLE
9
67
NC
U XOUT
9~35V
RXD
TXD
GND
RED
GREEN
YELLOW
BLACK
WHITE
U XOUT
NC NC
Electrical interfaces
Cable color
&
Function
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
无锡北微传感科技有限公司 www.bwsensing.com Tel: [phone]
Debug software
Users can directly download serial assistant on official website (Supports-Download). You can also use
more convenient and intuitive PC software.
DIS331 supporting serial debugging software can be connected to the inclinometer on the computer
for angle display. The software debugging interface is as shown in the figure below. Using the debug
software, it can conveniently display the current X-direction tilt angle, and you can also modify and
set other parameters by yourself.
①
②
③
Correctly connect the inclinometer serial port hardware and connect the power supply.
Select the computer serial port and baud rate and click connect Serial Port.
Click Start and the tilt angle of the tilter in the X direction will be displayed on the screen.
Software use steps:
Note: You can switch to Chinese or English version by the bottom left button.
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
0x77 0x8F 0x00
0x77 0x0F
YY
2.2 Set module address Command: 77 05 00 0F 01 15
0X05
0X05
XX
YY
XX indicates the address before modification, and YY indicates the modified address.
0x77
0x77 0x01
0x77 0x81 SXXX.YY
0x04
0x07
2 Command format:
2.1 Read angle of X axis Command：77 04 00 01 05
Command response：
Command response：
Protocol
Data Format: Hexadecimal
Identifier: Fixed to 77(partly 68)
Frame Length: Length from Frame Length to Checksum（included）
Address Code: Address of acquiring module, default 0x00
Data: Content and length variable according to Command
Checksum: Sum of Frame Length, Address Code, Command and Data. (Please pay attention
that when the command or data changes, the checksum will change. )
Note: Data represents 3 byte angle value in format of compressed BCD code. S is the sign bit (0 positive, 1
negative), XXX is the three digit integer part, YY is the fractional part. The Data of other axis is the same format.
For example, 10 26 80 means -026.80 °.
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Command
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Command
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（3byte） Checksum
（1byte）
Identifier
(1byte) Command
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（0byte） Checksum
（1byte）
Identifier
(1byte) Command
Frame Length
（1byte） Address Code
（1byte） （1byte）
Data
（Nbyte）
Checksum
（1byte）
Identifier
(1byte) Command
1 Data Frame Format： （8 data bits，1 stop bit，No parity check，default baud rate 9600）
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
0x77 0x8B
0x77 0X0B
XX
2.3 Set communication rate command：77 05 00 0B 02 12
Sent data field XX is the baud rate option：00 means 2400，
01 means 4800，
02 means 9600，
03 means 19200，
04 means 115200.
When the baud rate is low, the Angle transmission response is slow.
0X05
0X05
Response command：
Note: XX represents the current address of the product.
0x77 0x1F
0x77 0x1F
Command：77 04 00 1F 23
2.4 Query current address
0x05
0x04 0x00
Response command：
0x00
Command response：
Note: absolute zero：Based on the factory-calibrated zero point.
relative zero: Reference to the zero after the current installation.
0x77 0x85 0x00
0x77 0x05
0x00: absolute zero
0x01: relative zero
2.5 Set the zero type Command：77 05 00 05 01 0B
Identifier
（1byte）
Frame Length
（1byte） Address Code
（1byte） Command
（1byte）
Data
（1byte）
Checksum
（1byte）
Identifier
（1byte）
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（1byte）
Checksum
（1byte）
0x05
0x05
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Command
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Command
Identifier
（1byte）
Frame Length
（1byte） Address Code
（1byte） Command
（1byte）
Data
（0byte）
Checksum
（1byte）
Identifier
（1byte）
Frame Length
（1byte） Address Code
（1byte） Command
（1byte）
Data
（1byte）
Checksum
（1byte）
0xXX 0xXX
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
0x77
2.8 Query alarm angle Command：
0x21
0x77 0xA1
77 05 00 21 00 26
0x05 0x00:+X
0X02:-X
0x08 DSXXX.YY
0x77
2.7 Set alarm angle
0x20
0x77 0xA0 00
Command： 77 08 00 20 00 00 05 00 2D
DSXXX.YY
0x08
0x05
Response command：
Response command：
0x77
Command response：
2.6 Query the zero type Command：77 04 00 0D 11
0x0D
Identifier
（1byte）
Frame Length
（1byte） Address Code
（1byte） Command
（1byte）
Data
（0byte）
Checksum
（1byte）
0x77 0x8D
0x00: absolute zero
0xFF: relative zero
Identifier
（1byte）
Frame Length
（1byte） Address Code
（1byte） Command
（1byte）
Data
（1byte）
Checksum
（1byte）
0x05
0x04
Note: D is the axis position in the data field. For example, 0x00 is the X-axis positive axis alarm angle.0x02 is
the X-axis positive axis alarm angle,S is a sign bit (0 positive, 1 negative), XXX is a three-digit integer value, and
YY is a decimal value. The other axis data is the same.
For example, 01 00 26 80 indicates that the alarm value of the +Y axis is 26.8°.
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Command
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（4byte） Checksum
Identifier
(1byte)
Command
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Command
Frame Length
（1byte）
Address Code
（1byte） （1byte）
Data
（4byte） Checksum
（1byte）
Identifier
(1byte)
Command
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
0x77
2.10 Query alarm delay on time Command :
0x24
0x77 0x92
77 05 00 24 00 29
0x05
0x07 DXXYY
0x00：+X
0x02：-X
Response command：
2.9 Set alarm delay on time Command：77 07 00 23 00 05 00 2F
0x77 0x23
0x77
0x91
00
DXXYY
0x07
0x05
Response command：
0x77
2.11 Set alarm delay off time
0x23
0x77 0x91
Command： 77 07 00 23 01 05 00 30
0x07
0x05
DXXYY
Response command：
Note: D is the axis position in the data field. For example, 0x00 is the X-axis positive axis alarm open delay time,
in seconds. 0x02 is the X-axis positive axis alarm open delay time, in seconds. XX is a two-digit integer value and
YY is a two-digit value. The other axis data is the same.
For example, 00 05 00 in this example indicates that the alarm on delay time for setting +X axis is 5 seconds.
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（3byte） Checksum
（1byte）
Identifier
(1byte)
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（3byte） Checksum
（1byte）
Identifier
(1byte)
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
0x00
Note: D is the axis position in the data field. For example, 0x01 is the X-axis positive axis alarm off delay time in
seconds. 0x03 is the X-axis positive axis alarm off delay time, in seconds. XX is a two-digit integer value and YY is
a two-digit value. The other axis data is the same.
For example, 00 05 00 in this example indicates that the alarm off delay time for setting +X axis is 5 seconds.
Frame Length
（1byte）
Address Code
（1byte）
Command
（1byte）
Data
（3byte） Checksum
（1byte）
Identifier
(1byte)
Frame Length
（1byte）
Address Code
（1byte）
Command
（1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
0x77
2.12 Query alarm delay off time Command：
0x24
0x77 0x92
77 05 00 24 01 2A
0x05
0x07 DXXYY
0x01：+X
0x03：-X
0x77
2.13 Save Settings
0x0A
0x77 0x8A 00
Command： 77 04 00 0A 0E
0x04
0x05
Response command：
Response command：
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（3byte） Checksum
（1byte）
Identifier
(1byte)
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（0byte） Checksum
（1byte）
Identifier
(1byte)
Frame Length
（1byte）
Address Code
（1byte） Command
（1byte）
Data
（1byte） Checksum
（1byte）
Identifier
(1byte)
Note: For the previous parameter modification settings, you need to send the save command again. If the save
setup command is not sent after the setup is completed, these settings will disappear after power off.
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis Inclination Switch
Product number Way of communication Package condition
RS232
TTL
Ordering Information
IP67 Package/Metal Connector
IP67 Package/Metal Connector
Executive standard
●Enterprise Quality System Standard: ISO9001:2008 Standard (Certificate No.:10114Q16846ROS)
●CE certification (certificate number: 3854210814)
●ROHS (certificate number: SO81426003)
●GB/T 191 SJ 20873-2003 General specifications for tiltmeters and spirit levels
●GBT 18459-2001 sensor main static performance index calculation method
●JF 1059-1999 Evaluation and Expression of Measurement Uncertainty
●GBT 14412-2005 mechanical vibration and shock mechanical installation of accelerometer
●General requirements for GJB 450A-2004 equipment reliability
●Quality control of key parts and important parts of GJB 909A
●GJB 899 Reliability Qualification and Acceptance Test
●GJB 150-3A high temperature test
●GJB 150-4A low temperature test
●GJB 150-8A rain test
●GJB 150-12A dust test
●GJB 150-16A vibration test
●GJB 150-18A impact test
●GJB 150-23A Tilt and Swing Test
●GB/T 17626-3A RF electromagnetic radiation immunity test
●GB/T 17626-5A surge (hit) impulse immunity test
●GB/T 17626-8A power frequency magnetic field immunity test
●GB/T 17626-11A voltage dips, short interruptions and voltage changes immunity
DIS331-TTL
DIS331-232
Bewis Sensing Technology LLC www.bwsensing.com Tel：[phone]

DIS331
Voltage Single-Axis
Inclination Switch
Wuxi Bewis Sensing Technology LLC
Address: Building 30, No. 58 Xiuxi Road, Binhu District, Wuxi City
Hotline: [phone]
Tel: [phone]-801
Email: [email protected]
Website: www.bwsensing.com
