BWT myPOOL MP-IPH 50 User manual

BWT myPOOL Inverter
Heat Pump
MP-IHP 50 – MP-IPH 62 – MP-IPH 80
MP-IPH 96 – MP-IPH125 – MP-IPH 165

Content
I. Application .......................................................ϰ
II. Features............................................................ϳ
III. Technical Parameter.........................................ϴ
IV. Dimension .......................................................ϵ
V. Installation instruction .....................................ϵ
VI. Operation instruction.......................................ϵ
VII. Testing ..............................................................ϭϲ
VIII. Precautions ......................................................ϭϲ
IX. Maintenance ....................................................ϭϴ
X. Trouble shooting for common faults................ϮϬ
XI. Appendix 1: Heating priority (Optional)...........ϮϭͲϮϮ
XII. Appendix 2: Heating priority (Optional)...........ϮϮͲϮϯ

Warning˖
˖
a. Please read the following tips before installation, use and maintenance.
b. Installation, removal and maintenance must be carried out by professional personnel
in accordance with the instructions.
c. Gas leakage test must be done before and after installation.
1. Use
a. It must be installed or removed by professionals, and it is forbidden to
dismantle and refit without permission.
b. Don’t put obstacles before the air inlet and outlet of the heat pump.
2. Installation
a. This product must be kept away from any source of fire.
b. The installation can’t be in a closed environment or indoors, and must be
kept well ventilated.

c. Vacuum completely before welding, field welding is not allowed, welding can
only be performed by professional personnel in professional maintenance
center.
d. Installation must be stopped if any gas leakage, and the unit must be
returned to professional maintenance center.
3. Transportation & Storage
a. Sealing is not allowed during transportation
b. Transporting goods at a constant speed is needed to avoid sudden
acceleration or sudden braking, so as to reduce the collision of goods.
c. The unit must be far away from any source of fire.
d. Storage place must be bright, wide, open and good ventilation, ventilation
equipment is required.
4. Maintenance Notice
a. If maintenance or scrap is required, contact an authorized service center
nearby
b. Qualification requirement
All operators who dispose gas must be qualified by valid certification which
issued by professional agency.
c. Please strictly comply with the requirement from manufacturer when
maintenance or filling gas. please refer to the technical service manual.

Thank your choosing our product and your trust in our company. To help you
get maximum pleasure from using this product, please read this instruction
manual carefully and operate strictly according to the user manual before
starting the machine, otherwise the machine may be damaged or cause you
unnecessary harm.
I. Application
1- Set swimming pool water temp efficiently and economically to
provide you comfort and pleasure.
2- User may choose the model technical parameter according to
professional guide, this series of swimming pool heater has
been optimized in factory (refer to technical parameter table).
II. Features
1- High efficient titanium heat exchanger.
2- Sensitive and accurate temp control and water temp display.
3- High pressure and low pressure protection.
4- Exceeding low temp auto stop protection.
5- Temp control compulsory defrosting.
6- International brand compressor.
7- Easy installation and operation.

III. Technical Parameter
Model MP-IHP 50 MP-IHP 62 MP-IHP 80 MP-IHP 96 MP-IHP 125 MP-IHP 165
Advised pool volume (m3) 10~24 14~28 20~35 20~40 30~55 35~70
Operating air temperature (ć
ć
)0~43
Performance Condition: Air 26°C, Water 26°C, Humidity 80%
Heating capacity (kW) 5.0 6.2 8.0 9.6 12.5 16.5
Performance Condition: Air 15°C, Water 26°C, Humidity 70%
Heating capacity (kW) 4.0 4.8 6.0 7.3 9.0 12.0
Performance Condition: Air 35°C, Water 28°C, Humidity 70%
Cooling capacity (kW) 2.0 2.2 3.3 3.8 4.9 6.3
Rated input power
at air 15°C (kW) 0.43~0.87 0.29~1.09 0.34~1.4 0.35~1.7 0.36~2.1 0.57~2.7
Rated input current
at air 15°C (A) 1.87~3.78 1.26~4.74 1.48~6.0 1.52~7.39 1.57~8.7 2.48~11.7
Power supply 230V/1 Ph/50Hz
Advised water flux (m³/h) 2~4 2~4 2~4 3~4 4~6 6~8
Water pipe in-out Spec (mm) 50
Net Dimension LxWxH (mm) 744×359×
648
744×359×
648
864×359×
648
864×359×
648
864×359×
648
954×359×
648
Net Weight (kg) 42 42 46 47 49 60
Notice:
1. This product can work well under air temp 0ć+43ć, efficiencywill not be
guaranteed out of this range. Please take into consideration that the pool heater
performance and parameters are different under various conditions.
2. Related parameters are subject to adjustment periodically for technical improvement
without further notice. For details please refer to nameplate.

IV. Dimension
Ć
Ć
Above data is subject to modification without notice.
Note:
The picture above is the specification diagram of the pool heater, for technician’s
installation and layout reference only. The product is subject to adjustment periodically for
improvement without further notice.
UNIT=MM A B C D E F G H
MODEL
MP-IHP 50 334 490 318 359 744 310 74 648
MP-IHP 62 334 490 318 359 744 310 74 648
MP-IHP 80 334 560 318 359 864 250 74 648
MP-IHP 96 334 560 318 359 864 250 74 648
MP-IHP 125 334 560 318 359 864 320 74 648
MP-IHP 165 334 560 318 359 954 350 74 648

V. Installation instruction
1. Drawing for water pipes connection
(Notice ˖ The drawing is just for demonstration, and layout of the pipes is only for reference.)
2. Connecting your power wire
(Note: please open the back panel for power connection. The operation is the same as above.)
䐟Please use cross screwdriver to take off the 2 screws
at the bottom of the right side panel. Take off the lower
half of the panel.
䐠Unscrew the 3 screws on the cover of the electrical box.
䐡Connect the terminals according to the electrical diagram.

Note˖
Must be hard wired, no plug allowed.
The swimming pool heater must be earthed well.
3. Electric Wiring Diagram
Options for protecting devices and cable specification
ĆAbove data is subject to modification without notice.
Note: dŚĞ ĂďŽǀĞ ĚĂƚĂ ŝƐ ĂĚĂƉƚĞĚ ƚŽ ƉŽǁĞƌ ĐŽƌĚ ч ϭϬŵ /Ĩ ƉŽǁĞƌ ĐŽƌĚ ŝƐ˚10m, wire
diameter must be increased. The signal cable can be extended to 50m at most.
4. Installation instruction and requirement
The heat pump must be installed by a professional team. The users are not qualified to
install by themselves, otherwise the heat pump might be damaged and risky for users’
safety.
MODEL MP-IHP 50 MP-IHP 62 MP-IHP 80 MP-IHP 96 MP-IHP 125 MP-IHP 165
Breaker
Rated Current
A 8.0 8.0 9.5 11.5 15.0 20.5
Rated Residual
Action Current
mA
30 30 30 30 30 30
Fuse A 8.0 8.0 9.5 11.5 15.0 20.5
Power Cord (mm2) 3×1.5 3×1.5 3×1.5 3×2.5 3×2.5 3×4
Signal cable (mm2) 3×0.5 3×0.5 3×0.5 3×0.5 3×0.5 3×0.5
For power supply: 230V 50Hz
Distribution Box
(Customer prepare) Power Cord
Swimming Pool Heat Pump Wiring Board
Power Supply
230V 50Hz Breaker Fuse
Earthing

A. Installation
1) The inlet and outlet water unions can’t bear the weight of soft pipes. The heat pump
must be connected with hard pipes!
ϮͿ /Ŷ ŽƌĚĞƌ ƚŽ ŐƵĂƌĂŶƚĞĞ ƚŚĞ ŚĞĂƚŝŶŐ ĞĨĨŝĐŝĞŶĐLJ ƚŚĞ ǁĂƚĞƌ ƉŝƉĞ ůĞŶŐƚŚ ƐŚŽƵůĚ ďĞ чϭϬŵ
between the pool and the heat pump.
B. Installation instruction
1) Location and size
The heat pump should be installed in a place with good ventilation
* MINIMUM DISTANCE
Filter
Water processor
Water switch

2) The frame must be fixed by bolts (M10) to concrete foundation or brackets. The
concrete foundation must be solid and fastened; the bracket must be strong enough
antirust treated;
3) Please don’t stack substances that will block air flow near inlet or outlet area, and
there is no barrier within 50cm behind the main machine, or the efficiency of the
heater will be reduced or even stopped;
4) The machine needs an appended pump (Supplied by the user). The recommended
pump specification-flux: refer tŽdĞĐŚŶŝĐĂůWĂƌĂŵĞƚĞƌDĂdžůŝĨƚшϭϬŵ
5) When the machine is running, there will be condensation water discharged from the
bottom, please pay attention to it. Please hold the drainage nozzle (accessory) into
the hole and clip it well, and then connect a pipe to drain the condensation water
out.
Cˊ
ˊ
Wiring
1) Connect to appropriate power supply, the voltage should comply with the rated
voltage of the products.
2) Earth the machine well.
3) Wiring must be handled by a professional technician according to the circuit diagram.
4) Set leakage protector according to the local code for wiring (leakage operating
ĐƵƌƌĞŶƚчϯϬŵͿ
5) The layout of power cable and signal cable should be orderly and not affecting each
other.
D
ˊ
Switch on after finishing all wiring construction and re-checking.

VI. Operation instruction
SYMBOL DESIGNATION OPERATION
Power ON/OFF Press to power on or off the heat pump
Mode
Press to select Smart/Silence mode
Smart mode:100%-20% capacity
Silence mode:80%-20% capacity
Heat/Cool/Auto Press to shift among cooling, heating and auto
Up/ Down Press to set desired water temperature
Note:
You may set the desired water temperature from 12 to 40ć.
The center of the screen shows the inlet pool temperature, when the up
and down keys are pressed, the digital flashing displays the set
temperature.
After you turn on the heat pump, the fan will start to run in 3 minutes. In
another 30 seconds, the compressor will start to run.
During heating, the will be light. During cooling, will be
light.

2.2.1. Mode selections
will be light as standard when you turn on the heat pump.
Press the button to enter the Silence mode, the will be
light.
Press the button again to exit and enter the SMART mode.
2.2.2. Compulsory defrosting
When the heat pump is heating and the compressor is working
continuously for 10 minutes, press both “ ” and “ ” buttons for 5
seconds to start compulsory defrosting. (Note: the interval between
compulsory defrosting should be more than 30 minutes.)
The heating light will be twinkling when heat pump is in compulsory or
auto defrosting.
The running process and ending of compulsory defrosting are the same
as auto-defrosting.

VII. Testing
1. Inspection before use
A. Check installation of the whole machine and the pipe connections
according to the pipe connecting drawing;
B. Check the electric wiring according to the electric wiring diagram and
earthing connection;
C. Make sure that the main machine power switch is off;
D. Check the temperature setting;
E. Check the air inlet and outlet.
2. Trial
A. The user must “Start the Pump before the Machine, and Turn off the
Machine before the Pump”, or the machine will be damaged;
B. The user should start the pump, check for any leakage of water; and then
set suitable temperature in the thermostat, and then switch on power
supply;
C. In order to protect the swimming pool heater, the machine is equipped
with a time lag starting function, when starting the machine, the blower
will run 1 minutes earlier than the compressor;
D. After the swimming pool heater starts up, check for any abnormal noise
from the machine.
VIII.Precautions
1. Attention
A. Set proper temperature in order to get comfortable water temperature to
avoid overheating or overcooling;
B. Please don’t stack substances that can block air flow near inlet or outlet
area, or the efficiency of the heater will be reduced or even stopped;

C. Please don’t put hands into outlet of the swimming pool heater, and
don’t remove the screen of the fan at any time;
D. If there are abnormal conditions such as noise, smell, smoke and
electrical leakage, please switch off the machine immediately and contact
the local dealer. Don’t try to repair it yourself;
E. Don’t use or stock combustible gas or liquid such as thinners, paint and
fuel to avoid fire;
F. In order to optimize the heating effect, please install heat preservation
insulation on pipes between swimming pool and the heater. During
running period of the swimming pool heater, please use a recommended
cover on the swimming pool;
G. ŽŶŶĞĐƚŝŶŐƉŝƉĞƐŽĨƚŚĞƐǁŝŵŵŝŶŐƉŽŽůĂŶĚƚŚĞŚĞĂƚĞƌƐŚŽƵůĚďĞчϭϬŵ
or the heating effect of the heater cannot be ensured;
H. This series of machines can achieve high efficiency under air temperature
of +15ć+25ć.
2. Safety
A. Please keep the main power supply switch far away from the children;
B. When a power cut happens during running, and later the power is
restored, the heater will start up automatically. So please switch off the
power supply when there is a power cut, and reset temp when power is
restored;
C. Please switch off the main power supply in lightning and storm weather
to prevent from machine damage that caused by lightning;
D. If the machine is stopped for a long time, please cut off the power supply
and drain water clear of the machine by opening the tap of inlet pipe.

IX. Maintenance
AˊIn winter season when you don’t swim:
1. Cut off power supply to prevent any machine damage
2. Drain water clear of the machine.
3. Cover the machine body when not in use.
BˊPlease clean this machine with household detergents or clean water,
NEVER use gasoline, thinners or any similar fuel.
CˊCheck bolts, cables and connections regularly.
“Cut off” power supply of the heater before
cleaning, examination and repairing
Caution: Dan
g
er of electric shock
!!Important:
Unscrew the water nozzle of inlet pipe to let
the water flow out.
When the water in machine freezes in winter season,
the titanium heat exchanger may be damaged.

X. Trouble shooting for common faults
FAILURE REASON SOLUTION
Heat pump doesn’t
run
No power Wait until the power recovers
Power switch is off Switch on the power
Fuse burned Check and change the fuse
The breaker is off Check and turn on the breaker
Fan running but
with insufficient
heating
evaporator blocked Remove the obstacles
Air outlet blocked Remove the obstacles
3 minutes start delay Wait patiently
Display normal, but
no heating
Set temp. too low Set proper heating temp.
3 minutes start delay Wait patiently
If above solutions don’t work, please contact your installer with detailed information and your
model number. Don’t try to repair it yourself.
Note: If the following conditions happen, please stop the machine immediately, and cut off
the power supply immediately, then contact your dealer:
a˅Inaccurate switch action;
b˅The fuse is frequently broken or leakage circuit breaker jumped.

Failure code
NO. DISPLAY NOT FAILURE DESCRIPTION
1 E3 No water protection
2 E5 Power supply excesses operation range
3 E6
Excessive temp difference between inlet and outlet water(Insufficient water
flow protection)
4 Eb Ambient temperature too high or too low protection
5 Ed Anti-freezing reminder
NO. DISPLAY FAILURE DESCRIPTION
1 E1 High pressure protection
2 E2 Low pressure protection
3 E4 3 phase sequence protection (three phase only)
4 E7 Water outlet temp too high or too low protection
5 E8 High exhaust temp protection
6 EA Evaporator overheat protection (only at cooling mode)
7 P0 Controller communication failure
8 P1 Water inlet temp sensor failure
9 P2 Water outlet temp sensor failure
10 P3 Gas exhaust temp sensor failure
11 P4 Evaporator coil pipe temp sensor failure
12 P5 Gas return temp sensor failure
13 P6 Cooling coil pipe temp sensor failure
14 P7 Ambient temp sensor failure
15 P8 Cooling plate sensor failure
16 P9 Current sensor failure
17 PA Restart memory failure
18 F1 Compressor drive module failure
19 F2 PFC module failure
20 F3 Compressor start failure
21 F4 Compressor running failure
22 F5 Inverter board over current protection
23 F6 Inverter board overheat protection
24 F7 Current protection
25 F8 Cooling plate overheat protection
26 F9 Fan motor failure
27 Fb Power filter plate No-power protection
28 FA PFC module over current protection

XI. Appendix 1: Heating priority (Optional)

XII. Appendix 2: Heating priority (Optional)
