BZ-TECH Argox AS-9500 User manual

Leitor Argox
AS-9500 Imager
O novo Leitor de Código de Barras Manual Argox AS-
9500g Imager 2D é pequeno, leve, portátil e fácil de usar.
Além de fazer a leitura de todos os tipos de código de
barra, ele também lê códigos bidimensionais, Maxi Code,
Data Matrix, Aztec, Qr Code e vários outros.
www.bztech.com.br

AS-9500 2D Area-Imaging Scanner Quick Installation Guide
49-95002-001
Interface Setting
Restore to Default Setting Turn on All Symbologies
The green aiming beam should be centered over the bar code, but it can be positioned in
any direction for a good read.
Programming Barcodes
Scanning Mode
● Image: VGA is On, the image is 640x480 pixels. VGA is Off, the image is 752x480 pixels.
● Manual Trigger: The Imager scans until a bar code is read, or until the trigger is released.
● Presentation: The LEDs are either off or at the lowest power for ambient conditions until a bar code
is presented to the imager.
Centering
Scan Centering On, the imager only reads codes that intersect the centering window and specify
the area by the Top, Bottom, Left, or Right barcodes
This QIG provides demonstration, installation and programming barcode for AS-9500 2D Area-
Imaging Scanner. Product safety information is also included.
Get Connected
AS-9500 2D Area-Imaging scanner can connect to a PC for operation.
1. Power off the PC.
2. Connect the proper interface cable to AS-9500 and to the matching port on the computer.
RS-232:
i. Connect the serial interface cable to the AS-9500 and to the serial port on the computer.
ii. Connect the power supply to the serial interface cable then plug in the power socket.
USB-HID & USB-Virtual COM :
Connect the USB interface cable to the AS-9500 and to USB port on the computer.
3. Power on the PC.
4. Configure the proper interface for AS-9500 by scanning the interface barcode below:
(Intsall the driver from CD-ROM if USB Virtual COM interface is configured.)
Linear bar code 2D Matrix symbol
CenteringScanning Mode
This device complies with the requirement of FCC Part 15 Rules. Operation shall be subject to the
following two conditions: 1) This device maynot cause harmful interface, and 2) this device must accept
that may cause undesirable operation.
This product conforms to the following standards
EMC: EN55022:2006+A1:2007,class B / EN55024:1998+A1:2001+A2:2003
This device is compliant with the requirements of the European Union Restriction on the use of Hazardous
Substances (RoHS) Directive, 2002/95/EC.
This device is compliant with requirement of BSMI and granted ID No. R3A078
*USB Virtual COM
RS-232 Interface
USB HID (PC)
USB HID (MAC)
Default Setting All Symbologies On
*VGA On
*Manual Trigger
Manual Trigger, Low Power
VGA Off
Centering On
Top of Centering Window
Left of Centering Window
*Centering Off
Bottom of Centering Window
Right of Centering Window
Presentation Mode
Safety Information
