BZB Gear BG-DA-12GS1X8 User manual

BG-DA-12GS1X8
1x8 12G/6G/3G/HD/SD-SDI Distribution Amplifier with
Reclocking
User Manual

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 2

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
TABLE OF CONTENTS
Statement 4
Safety Precaution 4
Introduction 5
Features 5
Packing List 5
Specifications 6
Operation Controls and Functions 7
Hardware Installation 8
Signal Measurement 8
Application Example 9
Tech Support 10
Warranty 10
Mission Statement 11
Copyright 12
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 3

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Statement
Please read these instructions carefully before connecting, operating, or configuring this
product. Please save this manual for future reference.
Safety Precaution
●Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
●Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to
persons.
●To prevent damaging this product, avoid heavy pressure, strong vibration, or immersion
during transportation, storage, and installation.
●Do not dismantle the housing or modify the module.
●Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
●Do not put any heavy items on the extension cable in case of extrusion.
●Install the device in a place with fine ventilation to avoid damage caused by overheat.
●Do not twist or pull by force ends of the optical cable. It can cause malfunction.
●The housing of this product is made of organic materials. Do not expose to any liquid,
gas, or solids which may corrode the shell.
●Unplug this device during lightning storms.
●Do not use liquid or aerosol cleaners to clean this unit. Clean only with a soft dry
microfiber cloth.
●Always unplug the power to the device before cleaning.
●If an object or liquid falls or spills on to the housing, unplug the module immediately.
●To prevent the risk of electric shock, do not open the case. Installation and maintenance
should only be carried out by qualified technicians.
●Do not use the product beyond the specified temperature, humidity, or power supply
specifications.
●This product does not contain parts that can be maintained or repaired by users.
Damage caused by dismantling the product without authorization from BZBGEAR is not
covered under the warranty policy.
●Installation and use of this product must strictly comply with local electrical safety
standards.
●Product specifications may be subject to technical upgrades without further notice.
●Unplug the power cord when left unused for a long period of time.
●Information on disposal for scrapped devices: do not burn or mix with general household
waste, please treat them as normal electrical wastes.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 4

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Introduction
The BG-DA-12GS1X8 is a 1x8 12G/6G/3G/HD/SD-SDI distribution amplifier with reclocking
that receives one SDI input, perfectly duplicates it, and re-transmits eight SDI outputs for
real time multi-viewing. It is a reliable video device splitting a SDI video source to eight SDI
compliant displays at the same time.
Features
●12G/6G/3G/HD/SD-SDI distribution
●Eight separately buffered and reclocked outputs*
●Cable equalization and signal retiming
●LED indication of signal lock and video rate
●Passes ancillary data and embedded audio
●Provides automatic input cable equalization (Belden 1694A) up to 180m (594ft)@3G,
100m (330ft)@6G and 70m(230ft) @12G
●Reclocking SDI signals for cascading and thus longer transmission
●Inter-locked power supply for a secure connection
* Note: Due to the super high frequency and lower jitter requirement for 12G SDI signals, to
have the best performance, it is strongly recommended to use one 75 ohm terminator if the
paired SDI is not in use.
Please see the following table for 12G SDI output pairing.
Packing List
●1x BG-DA-12GS1X8
●1x 5V power adapter
●1x BNC 75 ohm terminator
●1x User Manual
●1х Quick Start Guide
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 5

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Specifications
Technical
SDI standard
SD/HD/3G/6G/12G-SDI
Multi-Rate Support
Auto detection of SD, HD, 3G, 6G or 12G Signals
SDI Compliance
SMPTE 424M, SMPTE 292M, SMPTE 344M, SMPTE 259M,
DVB-ASI, ST-2081(6G), ST2082(12G)
SDI Data rates
1.485 / 2.97 / 5.94 / 11.88Gbps
Video bandwidth
[11.88Gpbs & 11.88/1.001Gbps]
Output impedance
75Ω
Reclocking
Yes
Cable equalization
[12G] up to 70m (230ft)
[6G] up to 100m (330ft)
[3G] up to 180m (594ft)
Audio support
Yes
RP-198 pathological patterns
Immune
PCB stack-up
4-layer board [impedance control — differential 100Ω; single 75Ω]
Input
1x BNC [SDI]
Output
8x BNC [SDI]
BNC connector
75Ω inter-locked socket
Eye pattern characteristics[12G]
Amplitude: Within 800mV (<10%)
Rise/Fall time: Less than 35ps
Timing jitter: <1.0 UI (10Hz to 1188MHz)
Alignment jitter: <0.3 (100KHz to 1188MHz)
Mechanical
Housing
Metal enclosure
Dimensions [L x W x H]
Model: 5.2" x 2.1" x 1.1" [133 x 53 x 28 mm]
Package: 7.8" x 5.4" x 2.9" [198 x 137 x 74 mm]
Carton: 1'4"x 1'3" x 11.8" [420 x 400 x 300 mm]
Weight
Model: 7 oz [198g]
Package: 0.9 lbs [425g]
Fixedness
Wall-mounting case
Power supply
5V 2A DC
Power consumption
2.5 Watts [max]
Operation temperature
32~104°F / 0~40°C
Storage temperature
-4~140°F / -20~60°C
Relative humidity
20~90% RH [no condensation]
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 6

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Operation Controls and Functions
Front Panel
1. 12G/6G/3G/HD/SD-SDI Output 5-8: Connect to an SDI display.
2. Micro-USB: For updating firmware.
3. 5V DC power jack: Connect to provided power supply.
Rear Panel
4. 12G/6G/3G/HD/SD-SDI input: Connect to an SDI source.
5. Power LED indicator: Illuminates when connected to power.
6. 12G Signal LED indicator: Illuminates when connected to a 12G source.
7. 6G Signal LED indicator: Illuminates when connected to a 6G source.
8. 3G Signal LED indicator: Illuminates when connected to a 3G source.
9. HD Signal LED indicator: Illuminates when connected to a HD source.
10. SD Signal LED indicator: Illuminates when connected to a SD source.
11. 12G/6G/3G/HD/SD-SDI Output 1-4: Connect to an SDI display.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 7

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Hardware Installation
1. Connect a camera or other devices equipped with 12G/6G/3G/HD/SD-SDI outputs
to BG-DA-12GS1X8 12G/6G/3G/HD/SD-SDI input.
2. Connect devices equipped with 12G/6G/3G/HD/SD-SDI inputs (e.g. monitors or
video processors) to BG-DA-12GS1X8 12G/6G/3G/HD/SD-SDI outputs.
3. Plug power adapter cable into 5V DC power jack.
Signal Measurement
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 8

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Application Example
The following diagram illustrates the typical input and output connection of the splitter:
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 9

BZBGEAR BG-DA-12GS1X8 PRODUCT MANUAL
Tech Support
