C & K Systems System 236i User manual

P/N 5-051-371-00 Rev D
System 236 System 236i

2
ThankyouforpurchasingthisC&Kalarmsystem. Yoursystemisoneofthemostpowerful
andadvancedalarmsystemsonthemarkettoday,designedtoprovideyouwithyearsof
reliableoperation.
Thismanualexplainshowtooperateyouralarmsystem. Basicoperatinginstructionsarealso
printedonthelabelinsideyourkeypad(s)door.
Ifyouhaveanyquestionsorneedhelpwith
youralarmsystem,call:
______________________________________
______________________________________
(AlarmCompanyName)
Ifyouhavemonitoringquestionsorincases
ofaccidentalalarms,call:
______________________________________
______________________________________
(MonitoringStationName)
Whencallingthemonitoringcompany,knowthefollowing:
MyAccountNumberis:_______________________ My Password is:____________________

3
Table of contents
Gettingacquainted...............................................4-5
Whatthelightsmean...........................................6-7
Whatthesoundsmean........................................8
Armingthesystem...............................................9-15
Bypassingzones ...........................................14-15
Armingoptions .....................................................16
Disarmingthesystem ..........................................17
Afteranalarm ......................................................18
Options.................................................................19-24
ChangingaPIN .............................................20-21
DeletingaPIN ...............................................21
Resettingsmokedetectors ...........................22
Doorchime/Keypadtones...........................23-24
Testingyoursystem ............................................25-27
Telephonetrouble ................................................28
Smokedetectorplacement ..................................29
Emergencyevacuation ........................................30
Definitions ............................................................31
Limitationsofyouralarmsystem .........................32
Keypadoperations ...............................................33-35
TestProcedureIndex ..........................................36
Zonedescriptionlist .............................................37
FCCNotice ..........................................................38
IndustryCanada ..................................................39

4
What your alarm system is...
Youralarmsystemismadeupofacontrolpanelandseveraldetectiondeviceslikemotionsensors,
magneticcontacts,andsoon. Specificareasofdetectionarecalledzones. Zonescanbeprogrammedto
havedifferentcharacteristics. Somezonesmaybe24-hourzones,thatis,theyremainarmedevenwhen
thealarmsystemisoff. Zonesusedforfiredetection,forexample,arealways24-hourzones. Inaddition,
somezonescanbeprogrammedtoallowbypassing. Whenyoubypassazone,youtemporarilyremove
itfromthealarmsystem. Alwaysremember,however,that bypassedzonesarenotprotected.
How your alarm system works...
Whenadetectiondeviceistriggered,thestatusofitszonegoesfromnormaltoFAULTED. Ifarmed,
thecontrolpanelrespondsbyreportinganalarmconditiononsite---flashingkeypadlights,sounding
bells---andifprogrammed,bytransmittinganalarmsignaloverthetelephonewirestoacentral
monitoringstation. Themonitoringstationthendispatchestheappropriateauthorities.
Someofyoursystem'soperationsrequireyoutoenteryourpersonalidentificationnumber(PIN)onthe
keypad. TheseincludeARMINGandDISARMING.
Alongwithitsmanyotherfeatures,yoursystemcanbeprogrammedtoARMINSTANTLYortoARM
WITHTIMEDELAY(i.e.,aftergivingyoutimetoleavethepremises).

5
Eachalarmsysteminthe23XXfamilyisdesignedtomeetthespecificneedsofavarietyofapplications. TheSystem
236isdesignedforapplicationsrequiringprotectionofsixzones.
Someoftheavailablefeaturesofyouralarmsystemarealsooptional,andwillonlybeinstalledifappropriatefor
yourinstallation. Inaddition,somesystemfeatureswillrequireyoutoenteryourpersonalidentificationnumber
(PIN).
Asyoureadthroughthismanual,watchforboxeslikethese:
Ifanoptionalfeaturehasbeeninstalledinyoursystem,its
OPTION INSTALLED box will be checked.
.
.Ifafeatureofyoursystemrequiresyoutoenteryourpersonal
identificationnumber,itsPINREQUIREDboxwillbechecked.
OPTION
INSTALLED PIN REQUIRED

6
off onsteady Powerfail.Systemonbattery.
onsteady Readytoarm.
off onsteady Oneormorezonesarefaulted.
off* onsteady *Readylightwillbeonuntilsystemisarmed.
off slowflash Armedwith 7# .
on* off *Readylightisonifallzonesarenormal.
slowflash onsteady slowflash* Armedwith 4# .
*Flashingzonesarebypassed.
AC FAILURE
SYSTEM IS READY
(ALL ZONES NORMAL)
FAULTED ZONE
WHILE DISARMED
SYSTEM IS ARMED
(ALL PROTECTION ON)
PERIMETER ARMED
WITH DELAYS INTACT
POWER
LIGHT READY LIGHT ARMED LIGHT REMARKS
SYSTEM IS DISARMED
(ALL PROTECTION OFF)
SYSTEM IS ARMED
WITH DELAY ZONES
CONVERTED TO INSTANT
SERVICE
LIGHT ZONES LIGHTS

7
slowflash slowflash slowflash Systemisinprogrammingmode.
fastflash Callforservice.
onsteady Callforservice.
slowflash onsteady Callforservice.
slowflash slowflash Readyandbypassedzoneflashatthe
samerate.
slowflash slowflash Serviceandzoneintrouble.
Flashatthesamerate.
slowflash slowflash slowflash* Armedwith
4 7# .
*Flashingzonesarebypassed.
COMMUNICATIONS
FAILURE
WATCHDOG RESET
BELL FUSE FAILURE
LOW BATTERY
ZONE BYPASSED
ZONE(S) IS OR
WAS IN ALARM
ZONE TROUBLE
PERIMETER ARMED
WITH DELAY ZONES
CONVERTED TO INSTANT
POWER
LIGHT READY
LIGHT ARMED LIGHT REMARKS
SERVICE
LIGHT ZONES LIGHTS
PROGRAMMING
MODE
slowflash on* fastflash Analarmhasoccurredonthiszone.
*Armedlightisonifthesystemisarmed.
slowflash Panelhasresetitself.SystemOK.Toresetthe
Service Light, press * 1 #.

8
SOUND MEANING
2beeps(confirmationtones) systemarmedordisarmed
.successfulcentralstationtestorbatterytest
.
pulsedtone(2secondson,2secondsoff) zoneprogrammedforpulsedbellorsirenisinalarm
.
continuoustone zoneprogrammedforsteadybellorsirenisinalarm
circuitmalfunction(troubleonsupervisedloopsonly)
.
.
.
5beeps(errortones) invalidfunction
unauthorizedcommandattempted
errorchangingPINnumber
wrongPINnumberentered
.
.
.
zoneprogrammedforchirpingbellorsirenisinalarm
.
chirping(1secondon,4secondsoff)
zonefaultedduringwalk-test
.
2secondbeep doorchime
.
continuousbeeping,speedingupforlasttenseconds exitdelaytime
.
.
continuoustone,beepingfastforlasttenseconds entrydelaytime

9
Make sure the green READY light is on.
Faultedzonesmustbeclearedorbypassedbeforethesystemcanbearmed. Formore
information,refertothesectionsBypassingZonesandAfterAnAlarmOccurs.
TO ARM THE SYSTEM / AUTO HOME ARMING:
.
Ifprogrammed,theredZONElightswillautomaticallyturnoffafterfiveminutes(asa
securitymeasure). PressinganykeyonthekeypadwillturntheZONElightsbackon.
.
OPTION
INSTALLED
YourPINnumberisfourdigitslong.
Don'tpauseformorethan5secondswhileenteringthedigitsorthecontrolpanelwill
rejectyourPINnumber.
Enter your PIN and push the
#key.
.
.
PIN
REQUIRED
IfyoumakeamistakewhileenteringyourPINnumber,thekeypadwillbeepfivetimes.
Afterthefifthbeep,enteryourPINnumberagain.
.
Make sure the red ARM light comes on.
Thekeypadwillbeeptwicetoconfirmthatthesystemisarmed.
.

10
Exit through any TIME DELAY DOOR within seconds.
Theexitdelaytimecanbeprogrammedfrom10secondsto150seconds.
.
.Oncetheexitdelaytimehasexpired,thekeypadwillbeeptwicetoconfirmthatthe
systemisarmed.
IftheEXITPRE-ALARMoptionisinstalled,thekeypadwillbeepslowlyuntil10seconds
beforethedelaytimeexpires,thenrapidlyforthelast10seconds.
.
OPTION
INSTALLED
TherestoftheARMINGTHESYSTEMsectionexplainshowtobypasszonesbeforearmingthesystem,aswellas
certainarmingoptionsourinstallercaninstall. However,it'simportantforyoutorememberthatnomatterhowyour
system is programmed, you will always disarm it in the same way: enter your PIN, then push the # key.
OPTION
INSTALLED TheAUTOHOMEARMINGoptionenablesthesystemtoautomatically
bypassinteriorzonesifyouarmthesystembutdonotleavethepremises.
Theperimeterzoneswillbearmedandtheentrydelaywillremainintact.
With this option installed, arm the system (enter your PIN and push the # key).
.Ifyoudonotexitbeforetheexitdelaytimeexpires,thesystemwillautomaticallyarm
perimeterzonesandbypassinteriorzones.
.Ifyouexitthroughanexitdelaydoor,thesystemwillautomaticallyarminteriorand
perimeterzones.

11
INSTANT ARMING
InstantArmingconvertsalltimedelayedzonestoINSTANTzones.
Make sure the green READY light is on.
PIN
REQUIRED
.
.
OPTION
INSTALLED ExitDelayDisable(seepage16).
.
HomeArmingorbypassinginteriorzoneswillallowyoutomoveaboutfreelyinsidethe
premiseswhilethesystemisarmed. Refertothenextthreesections:HOMEARMING,
INSTANT HOME ARMING, and BYPASSING ZONES.
.
CAUTION: WhenthesystemisInstantArmed,youwillnotbeabletoenterthroughany
perimeterdoororwalkthroughanyprotectedareawithoutsettingoffanalarm.
Enter your PIN (if required),
push the key, enter the digit "7",
then push the # key.
TheredARMlightwillflashwhilethesystemisInstantArmed.
Thekeypadwillbeeptwicetoconfirmthatthesystemisarmed. 7

12
Enter your PIN (if required),
push the key, enter the digit "4",
then push the # key.
Thekeypadwillbeeptwicetoconfirmthatthesystemisarmed.
HomeArmingarmsperimeterzones,whilebypassinginteriorzones.
HOME ARMING
Make sure the green READY light is on.
TheredARMlightwillbeonwhilethesystemisarmed.
PIN
REQUIRED
.
4
.
HomeArmingallowsyoutomoveaboutfreelyinsidethepremiseswhilethesystemis
armed.
.
Youcanenterthepremiseswithoutsettingoffanalarmthroughanytimedelayentry.
(Don'tforgettodisarmthesystemafterentering!)
.TheredZONElight(s)ofbypassedzoneswillflashslowly.
.
OPTION
INSTALLED ExitDelayDisable(seepage16).
.

13
INSTANT HOME ARMING
InstantHomeArmingarmstheperimeterzonesandbypassesinteriorzones.
EntrytimedelaysareconvertedtoINSTANT.
Make sure the green READY light is on.
Thekeypadwillbeeptwicetoconfirmthatthesystem
isarmed.
Enter your PIN (if required),
push the key, enter the digit "7",
the digit "4", then push the # key.
PIN
REQUIRED
.
.TheredARMlightwillflashwhiletheperimeterzonesareInstantArmed.
OPTION
INSTALLED
TheredZONElight(s)ofbypassedzoneswillflashslowly.
.
47
7 4
ExitDelayDisable(seepage16).
.
CAUTION: WhenthesystemisInstantHomeArmed,youwillnotbeabletoenter
throughanyperimeterdoorwithoutsettingoffanalarm.
OR

14
BYPASSING ZONES
Thisprocedureallowsyoutobypassoneormorezoneswhileyoursystemis
DISARMED1. (See NOTE pg. 15)
NOTE:SystemprogrammingdetermineswhichPINscanbypasszones,alsowhich
zonescanbebypassed. Tolearnifazonecanbebypassed,seetheZONEDESCRIP-
TION LIST on page 37.
Enter your PIN (if required).
PIN
REQUIRED
2ZONE #
OPTION
INSTALLED
Push the key, enter the digit "2", enter
the zone to be bypassed, then push the
#key.
Push the key, enter the zone to be
bypassed, then push the # key.
OPTION
INSTALLED ZONE #
OR

15
Toindicatethatzonesarebypassed,thezoneLEDforthebypassedzonewill
flashslowly.
.
.Theproceduresforaddingabypassandremovingabypassareidentical.
1NOTE:Zonescanbealsobebypassedbyremoteprogramming. Whenremotepro-
grammingisused,thesystemcaneitherbearmedordisarmed.
.Toremoveabypass:
Enter your PIN, push the key, enter the digit "2", enter the zone
from which the bypass is to be removed, then push the # key.
NOTE: Disarming your alarm system REMOVESall bypasses.
OR
Enter your PIN, push the key, enter the zone from which the
bypass is to be removed, then press the # key.

16
Youralarmsystemhasbeenprogrammedforoneofthefollowingtwoarmingtypes:
GOOF-PROOF ARMING
Ifanyzoneotherthana24-hourzoneisfaulted(openwindow,malfunction-
ingsensor,etc.),yoursystemwillnotarm. Youwillnotbeabletoarmthe
systemuntilthefaultedzoneisclearedormanuallybypassed.
FORCE ARMING
Anyzone(exceptfor24-hourzones)thatisviolatedduringtheEXITDELAY
timewillautomaticallybebypasseduntilthesystemisdisarmed.
Warning: bypassed zones are not protected.
OPTION
INSTALLED
OPTION
INSTALLED
EXIT DELAY DISABLE
Ifthisoptionisinstalled,theexitdelaywillbeeliminatedwhenarmingyour
systemusingInstantArming(page11),HomeArming(page12),orInstant
HomeArming(page13).
OPTION
INSTALLED

17
TO DISARM THE SYSTEM:
Enter only through a TIME DELAY door.
IftheENTRYPRE-ALARMoptionisinstalled,thekeypadwillsoundconstantlyuntil10
secondsbeforethedelaytimeexpires(orthepanelisdisarmed),thenbeeprapidlyfor
thelast10seconds.
.
OPTION
INSTALLED
Enter your PIN within
seconds and push the # key.
PIN
REQUIRED
Make sure the red ARM light on the keypad goes off.
IftheARMlightdoesnotgooff,waitforthekeypadtobeepfivetimes,thenenteryour
PINagain.
.
Thekeypadwillbeeptwicetoconfirmthatthesystemhasbeendisarmed.
.Allbypassesareremoved.
.

18
AFTER AN ALARM OCCURS:
Enter your PIN and push the
#key.
Thiswillsilencethebell/sirenanddisarmthesystem.
.
TheredZONElightsonthekeypadwillflashfasttohelpyourememberwherethe
violationsoccurred.
.
PIN
REQUIRED
If this is a false alarm and no emergency response is needed, call
our central station IMMEDIATELY at to
cancelthealarm.
Writedownthenumberofthefaultedzonestohelpusserviceyou.
.
Clear the alarm memory and red ZONE lights
by pushing the key, entering the digit "1",
then pushing the # key.
1

19
24-HOUR MONITORING
Withthisoptioninstalled,youralarmsystemwilltransmitalarmsignalsto
ourcentralstation.
OPTION
INSTALLED
POLICE/PANIC KEY
Whenthisoptionisinstalled,holdingdownthe keyforthree
secondswilltriggeranalarm. Thekeypadwillbeeptwicetoconfirm
thealarmcondition.
OPTION
INSTALLED
DURESS ALARM
Shouldanintruderforceyoutoturnyoursecuritysystemonoroff,
youcansendasilentDURESSsignaltoourcentralstationbyenter-
ingUserCode6-acodedesignatedexclusivelyforaDURESS
signal.Yoursystemwillappeartobeoperatingnormally.Thereisno
indicationofanalarmcondition.
OPTION
INSTALLED (AvailableonSystems236iONLY)

20
User 1 can use his Master PIN to change the PINs of Users 1 - 6.
CHANGING A SYSTEM 236 USER PIN
Enter your Master PIN, push
the key, enter the digit "0", then
push the # key. 0
MASTER PIN
REQUIRED
The READY, SERVICE, and ARM lights will flash slowly.
.
Enter the User number (1 - 6), and push
the # key. USER #
Enter that User's new PIN and push
the # key.
ThenewPINmustbefourdigitslong.
.
