C-Data FD612H User manual

1
1FE+1GE+1POTs GPON ONT
User Manual

2
Contens
1. Introduce .....................................................................................................................................3
1.1 Applications.......................................................................................................................3
1.2 Function.............................................................................................................................3
1.3 Interface............................................................................................................................4
1.4 LED Description...............................................................................................................4
1.5 Environmental parameter...............................................................................................5
2. Introduce configuring the network...........................................................................................5
2.1 Prepare for login the ONT web management..............................................................5
2.2 Login ONT.........................................................................................................................6
2.3 ONTAuthentication .........................................................................................................8
2.3 LAN Configuration...........................................................................................................9
2.4 WAN Configuration..........................................................................................................9
2.4.1 Add WAN Connection PPPOE .........................................................................10
2.4.2 Add WAN Connection IPOE..............................................................................13
2.4.2 Add WAN Connection As Bridging...................................................................14
2.5 Voice Configuration.......................................................................................................15
2.5.1 Select Protocol....................................................................................................15
2.5.2 H.248 Setting......................................................................................................15
2.5.3 SIP Setting...........................................................................................................16
2.6IPTVConfiugration ..........................................................................................................18
2.6.1IGMP Proxy..........................................................................................................18
2.6.2 IGMP Snooping...................................................................................................18
2.6.3 IGMP Snooping...................................................................................................19

3
1. Introduce
The 1FE+1GE+1POTs terminal devices ONT are designed for fulfilling FTTH and dual
play service demand of fixed network operators or cable operators. These boxes are
based on the mature GPON technology, which have high ratio of performance to price,
Layer 2/3, and high quality VoIP as well. They are highly reliable and easy to maintain,
with guaranteed QoS for different service. And they are fully compliant with technical
regulations such as ITU-T G.984 and technical requirement of GPON Equipment from
China Telecom
1.1 Applications
1.2 Function
Interfaces
►GPON interface standard, SC/PC
►Ethernet interface: one FE and one GE interfaces, RJ-45, comply with IEEE802.3
and IEEE802.3u standards.
►POTS interface: RJ-11
Technical Features
1FE+1GE+1POTS has the following features.

4
►Broadband service access: connected to Internet through the GPON access method.
►Ethernet service access: Provides GE/FE Ethernet interfaces, connected to
thethereto devices, such as the user PC. Provides the Internet access and IPTV
services.
►POTS service access: Supports SIP, H.248 protocol.
►Security: Provides multi-level authentication based on the device, user and service,
and provides the data channel encryption for safety.
►QoS: Provides QoS services meeting the requirements of various services for the
local devices and network
►Network management: Provides multi-mode network management.
1.3 Interface
Rear Panel
Port Type Function
TEL Connect the telephone with FXS port by telephone wire.
FE/GE Connect PC with GPON HGU Ethernet port byRJ-45 Cat5 cable.
POWER Connect with power adapter(DC12 V)
ON/OFF Power turn on/off
PON Connect port with GPON network by SC/PC type, single mode
optical fiber cable
1.4 LED Description
Indicator Description
LOS GPON optical signals On: Optical power lower than receiver sensitivity ;

5
Off: Optical in normal
PON ONT Register On: Success to register to OLT; Blinking: In process of registering to OLT;
Off: In process of registering to OLT;
TEL Telephone port status
On：The connection between the TEL port and the
voice server has been set up
Blinking：The voice service of the TEL port is
established;
Off：The connection between the TEL port and the
voice server is not set up.
FE/GE LAN port status
On: Ethernet connection is normal;
Blinking: Data is being transmitted through the
Ethernet port;
Off: Ethernet connection is not set up;
PWR Power status On: The ONT is power on;
Off: The ONT is Power off;
1.5 Environmental parameter
ItemSpecification
Dimension 160mm(L) x 120mm(W) x 33mm (H)
Rated current 1.0 A
Rated voltage 12 V DC
Operation temperature 0℃—50℃
Operation humidity 5%—95%
2. Introduce configuring the network
2.1 Prepare for login the ONT web management
Before you login the ONT, you should confirm the connect between the ONT and your PC
is normal.
Step 1 Configuring the IP address of your PC to 192.168.100.X（2~254）, subnet mask
is 255.255.255.0，.
Step 2 Ping IP address of the ONT (Default address is 192.168.100.1). If the PC can get
right reply from Ping command, it is mean the connecting between the PC and ONT is
normal.
【Figure 1】

6
Note：
Please don’t power off the ONT in the process of manage the ONT by the WEB
interface.
2.2 Login ONT
Step 1 Open the explore browser and input the IP address “http://192.168.100.1”
（ONTdefault IP）。
Step 2You need the user name and password for login. The default user name and
password are on the label of the ONT bottom. Default administrator user name and
password is “CUAdmin” and “CUAdmin”
【Figure 2】

7
After you login the ONT as the administrator, you can check, configure and change the
configuration of the ONT. Some of configuring and changing will take effect only after
restart the ONT.
Login success, a “Device Info” windows will show as bellow. There are eight item of the
status function. It is Summary, WAN, Statistics, Route, ARP, DHCP, Voice and optic.

8
2.3 ONT Authentication
1. In the navigation tree on the left, choose Management> ONT Authentication. In the
pane on the right, you can view or change the authentication mode for the registration of
theONT on the OLT, as shown in Figure.
2. LOID authentication mode.
As the previous figure, you should enter the LOID and Password. This will be used in the
authentication with the OLT.
3. Password authentication mode.
Enter the password and SN.
2. Click Apply to apply the configuration
Note: Suggest you use the Chrome Internet Explorer to avoid display problem.
1
2
3

9
2.3 LAN Configuration
1. In the navigation tree on the left, chooseAdvanced Setup> LAN Port Work Mode. In the
pane onthe right, determine whether the LAN port works mode.
1) RG: LAN port works in layer 3 mode, that is, the gateway mode;
2) ONT: LAN port works in layer 2mode, that is, the bridge mode;
Note: As the LAN Port configure to ONT mode, the port can’t visit the ONT WEB interface
after you connect the ONT with OLT.
2.4 WAN Configuration
WAN in route mode: The ONT functions as a gateway. The IP address of the ONT can
be obtained through DHCP, Static, or PPPoE. The IP address of the PC connected to the
ONT can be obtained from the DHCP address pool of the ONT or can be set manually.
WAN in bridge mode: The ONT functions as a relay and does not process data. The
ONT does not obtain the IP address allocated by the upper-layer device and it does not
allow manual configuration of a static IP address. The IP address of the device connected
to the ONT can be obtained through DHCP, PPPoE, or static.

10
2.4.1 Add WAN Connection PPPOE
Step 1: Add WAN service interface by click the “ADD” button on WAN configuration page.
Step 2: Select the WAN connection and Click “Next” to enter the WAN service
configuration page as below.
Step 3: Chose the PPPoE and select the service type, enter the priority and VLAN ID.
Click “NEXT” button to go to the next page.

11
Step 4:Enter the PPP Username and Password provide by ISP.
Step 5: Select default gateway.

12
Step 6: Select the DNS.
Step 7: Show the WAN configuration, click the “Apply/Save” button.
Step 8: Show the all WAN connection.

13
2.4.2 Add WAN Connection IPOE
Step 1-2: it is the same as the WAN Connection PPPoE.
Step 3: Select the IPoverEthernet, configure the VLAN and priority.
Step 4: Select the dynamic or static IP mode.

14
Step 5: Configure the NAT, Firewall and IGMP multicast.
Step 6-8: It is same as PPPoE configure process.
2.4.2 Add WAN Connection As Bridging
Step 1-2: it is the same as the WAN Connection PPPoE.
Step 3: Select the Bridging mode
Step 4: Next configure process is the same as PPPoE.

15
2.5 Voice Configuration
This topic describes how to configure the voice service through the Web page.
2.5.1 Select Protocol
2.5.2 H.248 Setting
Selected Voice -> H.248 Setting，configure the binding WAN interface, MGC address and
Port, codec in this page.

16
2.5.3 SIP Setting
1. Selected Voice > SIP Basic Seething> Service Provider0, configuring the SIP Registrar,
SIP Proxy, SIPAccount, Password etc.

17
2. Selected Voice> SIP Advance seething> Service Provider0, to configure the Call
waiting, Call forwarding number,Anonymous Calling ect.

18
2.6IPTVConfiugration
2.6.1IGMP Proxy
In the WAN Connection creating page, you can enable the IGMP Porxy when the WAN
Connection is not setting to bridging.
2.6.2 IGMP Snooping
In theAdvanced Setup >LAN , you can configure the IGMP Snooping.
Standard Mode: Before the IGMP Report send, the multicast data will send to all bridging
port, and after the IGMP Report have sent, only the ports in the IGMP Report can receive

19
multicast.
Blocking Mode: Only after the IGMP Report sent, the Report Port can receive multicast.
2.6.3 IGMP Snooping
You can set the IGMP Version, Query Interval, Maximum Multicast Groups in this page.
