c.k Lektro LOS 150 User manual

C.K Ref.: E10866 LOS 15 0
Operating Instructions
Orbital Sander
GB
Anleitung LOS 150 24.10.2001 9:52 Uhr Seite 1

AB
2
USE
The orbital sander is designed for the
sanding of wood, metal, plastic and
similar materials when using the cor-
rect sanding paper.
Technical data
Voltage 230 Volts
Power consumption 150 Watts
Grinding surface area 185 x 90
Sandpaper size 230 x 90
Vibrations per minute 20,000
Sound pressure level LPA 87 dB(A)
Sound power level LWA 92 dB(A)
Vibration aw8,5 m/s2
Weight 1,4 kg
Totally insulated
Included in pack
LOS 150,
Dust extraction connectors ø 32, ø 36,
3 sheets of sandpaper
General safety notes
– Always remove the plug from the
power supply socket before carrying
out any maintenance or repair work
such as cleaning the sander or
changing the sandpaper!
– Always disconnect the machine by
removing the plug from the socket,
not by pulling on the mains cable.
– Always wear safety goggles and
dust mask when working.
– Keep the workplace clean and well
illuminated.
– Ensure that the workpiece is suffi-
ciently secured so that you are able
to work safety and effectively.
– Keep children away from the
machine.
– Always keep your machine clean,
and check for possible defects of
damage after every job.
– Always ensure that the switch is
switched off before you insert the
plug into the power supply socket.
– Ensure that any platforms you are
working on are sturdy and stable.
Warning!
– The pad sander is not designed
for wet sanding.
– When using a cable reel, be sure
to unroll the cable completely
(wire diameter min. 1,5 mm2).
– Disconnect the sander from the
power supply when work has
been completed.
– If the machine is defective, have
it serviced by a qualified dealer
immediately.
ON/OFF switch
Switching on: Press in switch A
Continuous duty: Secure switch A with
lock button B
Switching off: Press in switch A
briefly
GB








1 Front gripp
2 Machine identification
plate
3 On/Off trigger
4 Locking button
5 Main grip
6 Vibration plate
7 Clamping device
8 Vacuum cleaner
attachment
9 Electrical cord
Fitting the dust bag
Important!
It is imperative to use the dust bag for
health reasons.
Anleitung LOS 150 24.10.2001 9:52 Uhr Seite 2

3
Note!
Always wear safety goggles and a
dust mask.
Always keep the dust extraction holes
in the vibrating plate free of dirt or
other obstructions.
Vibration measured according ISO
8662-8.
Attaching sandpaper
– Remove the plug from the mains
supply.
– Insert the end of the sandpaper and
close the clamping mechanism.
– Draw the sandpaper tight over the
vibrating plate and clamp the other
end.
– Ensure that the holes match with the
vibrating plate.
Maintenance
– Always keep your orbital sander
clean.
– Do not use caustic cleaning agents
to clean the plastic housing.
– Check the carbon brushes if an
excessive amount of sparks is gene-
rated when working.
– Always keep the dust extraction
holes in the vibrating plate free of
dirt or other obstructions.
– Water must never come into contact
with the machine.
GB
Anleitung LOS 150 24.10.2001 9:52 Uhr Seite 3

4

EG Konformitätserklärung Der Unterzeichnende erklärt im Namen der Firma
Achivierung / For archives: SSG-0558-22-832-E
LOS 150
– Seriennummer auf
dem Produkt – der
EG Niederspannungs-
richtlinie 73/23 EWG
EG Richtlinie Elektro-
magnetische Verträglichkeit 89/336 EWG mit Änderungen entspricht.
Pwllheli Gwynedd, den
03.07.2000
Meyerratken
Product-Management
Typ
Marke
daß die
Maschine/Produkt

EC Declaration of Conformity The Undersigned declares, on behalf of
– Serial number specified on
the product - is in accordance with the
EC Directive regarding
low-voltage equipment 73/23 EEC;
EC Directive regarding
electromagnetic compatibility 89/336 EEC, as amended.
Pwllheli Gwynedd, (date)
03.07.2000
Meyerratken
Product-Management
Pwllheli Gwynedd, (date)
03.07.2000
Meyerratken
Product-Management
Pwllheli Gwynedd, datum
03.07.2000
Meyerratken
Product-Management
Pwllheli Gwynedd
03.07.2000
Meyerratken
Product-Management
Pwllheli Gwynedd
03.07.2000
Meyerratken
Product-Management
Type
produced by:
that the
Machine / Product

Déclaration de Conformité CE Le soussigné déclare, au nom de
– no. série indiqué sur le
produit - correspond(ent) à la
Directive CE relative aux
basses tensions 73/23 CEE;
Directive CE relative à la
compatibilité électro- magnétique 89/336 CEE avec les modifications y apportées.
– serienummer op het produkt-
conform de volgende richtlijnen is:
EG laagspanningsrichtlijn
73/23 EWG
EG richtlijn Elektro-
magnetische compatibiliteit 89/336 EWG met wijzigingen
Type
du fabricant
que
la machine / le produit

EC Conformiteitsverklaring De ondertekenaar verklaart in naam van de firma
type
merk
dat de
machine/produkt

Declaracion CE de Conformidad Por la presente, el abajo firmante declara en nombre de la empresa
– No. de serie en el producto:
satisface las disposiciones pertinentes siguientes:
Disposición de baja tensión
de la CE 73/23 CEE
Disposición de la
compatibilidad electro- magnética de la CE 89/336 CEE con modificaciones.
tipo
marca
que el/la
máquina/producto

Declaração de conformidade CE O abaixo assinado declara em nome da empresa
– cujo número de série
encontra-se no produto - corresponde à
Directiva da CE de baixa
tensão 73/23 CEE
Directiva da CE de
compatibilidade electro- magnética 89/336 CEE, com alterações
tipo
marca
que
a máquina/o produto
Ceka Works Ltd. • Pwllheli Gwynedd • North Wales • LL 53 5LH
EN 50144-1; EN 50144-2-4; EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3
Elektro-
Schwingschleifer Orbital Sander Ponceuse vibrante
électrique Elektro-
vlakschuurmachine Lijadora vibratoria Lixadeira orbital
eléctrica
Anleitung LOS 150 24.10.2001 9:52 Uhr Seite 4

5
 WARRANTY CERTIFICATE
The guarantee period begins on the sales date
and is valid for 2 years.
Responsibility is assumed for faulty construction
or material or functional defects.
Any necessary replacement parts and necessary
repair work are free of charge.
We do not assume responsibility for consequen-
tial damage.
Ceka Works Ltd.
Pwllheli
North Wales
LL53 5LH
