C-me UF400e User manual

Firewire Audio Expansion Board
User’s Manual
CME UF400e
English Manual
Version 1.0, last revised: July 2005

Thank you for choosing CME UF400e — Firewire Audio Expansion Board
Please keep all the important information here
Attach your invoice or receipt here
for reference
Purchase date
Serial
Dealer’s name and addr.
Dealer’s tel.
Warning:
• Improper connection may cause damage to the device.
Copyright
• Copyright of the manual belongs to Central Music Co. Anyone must get a
written permission from Central Music Co. before copying any part of the
manual to any kind of media.
© Central Music Co. 2005
UF400e Firewire Audio Expansion Board Users Manual
1

UF400e Firewire Audio Expansion Board Users Manual
2
CE Declaration
We:
CME (Brand under Central Music Co.)
hereby declare that the product:
UF400e
to which this declaration refers is in compliance with the following standards or
standardizing documents:
EN 55022, EN 55024
The following are the stipulated operating and environmental conditions for said
compliance:
residential, business and commercial environments and small-company environments.
This declaration is based on:
Test report(s) of the EMC testing laboratory
The information in this document is subject to change without notice and shall not be
deemed as a warranty by the seller. No warranties, express or implied, are made with
regard to the quality, suitability or accuracy of this document. The manufacturer reserves
the right to change the contents of this document and/or the associated products at any
time without the provision of prior notice to speci c persons or organizations. The
manufacturer shall not be held liable for damages of any kind arising from the use, or
the inability to use this product or its documentation, even if the possibility of such
damage is known. The information in this document is subject to copyright. All rights
are reserved. No part of this manual may be reproduced or transmitted in any form or
for any purpose without the express written permission of the copyright holders. Product
and brand names contained in this document are used for identi cation purposes only.
All registered trademarks, product designations or brand names used in this document
are the registered property of their respective owners.
© Central Music Co. 2005
. All rights reserved.

UF400e Firewire Audio Expansion Board Users Manual
3
Contents
From opening the package to installation...........................................................6
Scope of delivery.......................................................................................................6
Hardware installation..........................................................................................7
Windows installation—step by step.....................................................................8
Which operating system?..........................................................................................8
Installing the UF400e drivers in Windows XP...........................................................8
The UF400e as a system audio device (Windows)..................................................11
Which operating system?........................................................................................11
Installing the UF400e driver in OS X......................................................................12
The UF400e as a system audio device (Mac OS X).................................................12
The FireWire™ port..........................................................................................13
The connections of the UF400e Firewire Audio Expansion Board.................14
MIDI IN S.W...........................................................................................................14
Analog outputs........................................................................................................14
Analog inputs..........................................................................................................15
Digital interface (S/PDIF).......................................................................................16
MIDI interface........................................................................................................16
Drivers................................................................................................................17
The Windows drivers............................................................................................17
The MME wave driver.........................................................................................17
The ASIO driver and the ASIO Control Panel......................................................17
The GSIF driver...................................................................................................18
The MIDI driver...................................................................................................18
In detail—special properties of the drivers.........................................................18
DirectSound & WDM..........................................................................................19
WDM sample rate (SR) interpolation...................................................................19
WDM kernel streaming........................................................................................19
The Mac OS X drivers...........................................................................................19
The UF400e Control Panel...............................................................................21
Inputs (Analog In, Digital In)..................................................................................21
Outputs (Wave Play 1/2, 3/4, Digital Play)..............................................................22
Master......................................................................................................................22
Master Clock...........................................................................................................22
Routing...................................................................................................................23
Analog Out 3/4 (Line / Headphone)........................................................................23
The ASIO panel.......................................................................................................23
Colors......................................................................................................................24
Scenes.....................................................................................................................24

4
About......................................................................................................................25
Appendix A—Technical Data............................................................................26
Technical data.........................................................................................................26
Software..................................................................................................................26
System requirements / recommendations................................................................26
UF400e Firewire Audio Expansion Board Users Manual

Safety information
Please ensure that UF400e Firewire Audio Expansion Board
devices are turned off before plugging them in. This will protect
you from any possible—albeit weak—electrical shocks, as well as
protect your speakers and your hearing from sudden peaks.
For digital devices, be sure to at least lower the volume on your
playback equipment.
Connecting the device to the FireWire™ port of your computer
may also cause a noise—please turn down the volume of your
playback system accordingly.
Welcome!
We’re pleased that you’ve chosen the UF400e Firewire Audio Expansion Board by
CME for your musical endeavors and would like to congratulate you on your decision.
With the UF400e Firewire Audio Expansion Board, you’ve purchased a sophisticated
product representing the state of the art of studio technology—and we’re convinced this
innovative development will prove extremely useful to you in the coming years and,
above all, provide you with a great deal of entertainment.
We hope that this brochure is helpful to you while using the product. It is designed
to illustrate technical relationships based on practical examples from the studio
environment. This brochure is not only designed to help beginners with this complicated
subject—advanced musicians will also  nd the occasional bit of useful information.
We hope you  nd this manual both informative and entertaining to read, and hope you
 nd lots of pleasure in the UF400e.
Sincerely,
Your CME Team
5
UF400e Firewire Audio Expansion Board Users Manual

6
Technology and design. UF400e
—the perfect internal Firewire Audio Expansion
Board by CME. Fantastic specs like 24-bit/192 kHz, FireWire™ port, MIDI
IN/OUT/THRU, a MIC or Instrument IN (high-quality and DI, with an adjustable level),
S/PDIF digital I/O, two Headphone OUT (with an adjustable level), analog 2 IN and 2
OUT (TRS) make the UF an ideal tool for musicians.
The drivers provided for the
UF400e audio expansion Board, too, leave nothing to be
desired. Our sophisticated software architecture guarantees trouble-free deployment in
Windows XP (Service Pack 1 or higher) and MAC OS X Panther 10.3.4 (or higher).
The ASIO drivers—thoroughly proven throughout years of studio application—allow the
lowest possible latency between the software-based sound generation and audio output.
From opening the package to installation
Before connecting the UF400e into UFX, take note of any special points pertaining to
the con guration of your computer. Also refer to the manual of your computer and UF
devices for their settings.
The installation should run without any problems, especially in recent systems. If you
are experiencing dif culties all the same, please review carefully the relevant chapter in
this manual. If you are still having problems, please call our service hotline, or seek help
from our web: www. cme-pro. com.
Scope of delivery
Start by making sure that the contents of the package are complete.
The UF400e package should contain the following items:
• 1 UF400e expansion Board (the UF400e hardware)
• 1 IEEE 1394 FireWire™ cable 6-pin/6-pin
• 1 UF400e CD
• 1 manual (Here you are reading it)
UF400e Firewire Audio Expansion Board Users Manual

7
Hardware installation
Connect the UF keyboard with UF400e
First, remove the backboard from the back of UF
Connect pre-reserved connectors to UF400e Board
UF400e Firewire Audio Expansion Board Users Manual

Put the Board into the groove of UF
Tighten the screws
Windows installation—step by step
Which operating system?
The UF400e can be used only under Windows XP (Home and Professional editions).
Older Windows versions are not supported. Please ensure that you have applied the
current service packs and updates to your Windows installation (Service Pack 1 or
higher).
Installing the UF400e drivers in Windows XP
1. Before you start, ensure that your Windows XP version is up to date. Right-click
the “My Computer” icon and choose “Properties” from the context menu. If you’
re still using the default Teletubbyland XP wallpaper, you can access these menu
item by clicking : Start -> Settings -> Control Panel -> System. Service Pack 1—
or SP1 for short—must be installed on your computer. If it is not, please contact
Microsoft (www.microsoft.com) to obtain an update for your system. The service
pack is generally free of charge.
2. Insert the included UF400e CD and wait for the autorun application to launch.
If the autorun application on the CD does not launch automatically, start the
application manually by double-clicking “Autorun.exe” in the root folder of
the CD. Click the “Installation” button in the autorun application to install the
UF400e driver and Control Panel in your operating system.
3. Choose a language for the setup wizard and click “Next” to continue with the
8
Please perform the following steps in the stated order. Do not
connect the UF400e Firewire Audio Expansion Board to the
computer until instructed to do so.
installation.
UF400e Firewire Audio Expansion Board Users Manual

9
The InstallShield Wizard will now display its welcome message.
4. The default destination for the installation is speci ed in the following window. If
you prefer a different location, please click “Change…”.
UF400e Firewire Audio Expansion Board Users Manual

10
5. Now you are ready for the installation. Click “Install” to continue.
6. The driver is now installed in your system. As soon as the message shown below
appears, connect the UF400e to your computer’s FireWire™ port using the
included cable. Windows XP will automatically recognize the device as new
hardware and will open the driver installation dialog.
7. You may ignore the dialog box that will appear to inform you that the software
that you are installing has not passed the Windows logo test.
UF400e Firewire Audio Expansion Board Users Manual

11
8. Click “Finish” to complete the driver installation.
9. Once the driver installation is complete, the UF400e should appear as the
following entry in the Device Manager. The Device Manager can be found on the
Control Panel under “System” > “Hardware”. Then click the “Device Manager”
button.
The UF400e as a system audio device (Windows)
If you would like to use the UF400e not only for speci c audio applications, but as
your default Windows audio device, select the UF400e audio driver in the Control
Panel under “Sounds and Audio Devices” > “Audio” as the default device for the
desired functions.
As the UF400e is a professional audio interface, its levels can only be adjusted
using its included Control Panel. The Windows mixer is disabled to prevent it from
adversely affecting the signal quality.
Which operating system?
The UF400e can only be used under Mac OS 10.3.4 (OS X) or higher. It can be
integrated easily using OS X CoreAudio and CoreMIDI.
UF400e Firewire Audio Expansion Board Users Manual

12
Installing the UF400e driver in OS X
As mentioned above, the UF400e uses the operating system’s CoreAudio and
CoreMIDI drivers. It’s therefore not necessary to install a device-speci c driver.
Simply plug the device into your FireWire™ port and it’s available immediately.
However, to take full advantage of advanced routing, samplerate switching and other
features, please install the included Control Panel. Simply run the installer in the
Driver & Control Panel\MAC folder.
The UF400e as a system audio device (Mac OS X)
If you would like to use the UF400e not only for speci c audio applications, but as
your default Mac OS X audio device, select the UF400e audio driver in the “Sound”
control panel as the default device for audio output.
UF400e Firewire Audio Expansion Board Users Manual

13
The FireWire™ port
FireWire™ is a serial PC interface similar to USB that was developed by Apple in 1995,
and which was originally intended for digital video data and for external mass storage
and audio devices. It has since been given many names that all refer to the same port: for
example, Sony calls FireWire™ “i.LINK?”, Texas Instruments refers to it as “Lynx?”,
and one also frequently sees the mysterious abbreviation “1394”. The latter designation
actually refers to the common IEEE 1394 standard, which is notable for its high data
rates (IEEE 1394a = 400 Mbps and IEEE 1394b = 800, 1600 and 3200 Mbps). (For
those of you who are sticklers for detail, IEEE stands for the US “Institute of Electrical
and Electronic Engineers”.)
Like USB, FireWire™ also supports hot plugging—in other words, you do not need to
shut down your computer to add or remove devices. However, you should take care not
to interrupt any applications that may be accessing the UF400e to prevent possible data
losses or blue screens. Also please note that it may take the operating system a while to
process the new situation—after all, machines are only human :-)
One standardtwo sockets
The socket on your PC can have two different forms, with either 4 or 6 conductors.
According to the standard, in the 6-pin version the two extra pins are used to supply
7.5 – 30V / 1.5A per port. Unfortunately, this is often not the case due to the poor
quality of some controllers that are unable to provide a constant operating voltage
—despite the requirements of the speci cation. So if you’d like to avoid any
unexpected failures of the UF400e, please use the D.C. or USB port on UF keyboard
to supply power—better safe than sorry. If your computer “only” has a 4-pin port,
you must use the D.C. or USB port. To connect the UF400e to your PC in this case,
please use the adapter (6-pin to 4-pin).
UF400e Firewire Audio Expansion Board Users Manual

14
The connections of the UF400e Firewire
Audio Expansion Board
The UF400e offers you numerous connections for connecting professional studio
peripherals and HiFi devices. Following is a detailed overview of its technical and
electrical characteristics:
UF400e panel
MIDI IN S.W.
MIDI IN S.W. is a key to switch the original MIDI signal. The signal comes from
UF keyboard when the key locates on KB. The signal comes from UF400e when the
key locates on 1394.
Analog outputs
Panel (Out L/R)
The UF400e features two high-quality analog mono outputs on its panel. The
connections have been realized as balanced 1/4” jacks. Unbalanced cables can also
be plugged into the outputs, of course.
Panel (Out Phone 1/2)
Two further analog output (stereo) is available on the panel that can be used either
at Line level (2.0 Vrms) or as a hardware-controlled headphone output (with an
adjustable level). The mode for this output can be selected in the Control Panel.
On the driver side
all of the outputs are grouped in a multi-channel device. The relevant driver is
UF400e Firewire Audio Expansion Board Users Manual
The analog outputs operate with music-compatible levels of 2.0
Vrms. Here, you can connect a mixing Board, active speakers, or
ampli ers.
CAUTION!
As the UF400e can deliver an output of up to 2.0
Vrms in Line mode and even more in headphone mode, a very
high (loud) level will be available depending on the impedance of
your headphones. Take care of your ears, you only have one pair!

15
called “UF400e(0) MC Out”. The channels can be addressed individually using
common audio applications.
Analog inputs
In L/R
The UF400e System features two high-quality analog stereo inputs on its panel,
which are named “LINE IN L/R” and “MIC/GT IN”. The connections have been
realized as unbalanced stereo 1/4” jacks. Unbalanced mono sources can also be
plugged into the outputs, of course.
There is only one connection can be used at same time. The “LINE IN L/R” will
be disabled as long as guitar or microphone hooks up “MIC/GT IN”. In the mean
time UF400e receives the signal comes from “MIC/GT IN” only. It has to keep “
MIC/GT IN” un-plugged if you want to record signal from “LINE IN L/R”. The “
LINE IN L/R” can only recognize line level signal.
It can be chosen between MIC and Guitar by the control panel of Analog In.
Three different gain levels can be set in the Control Panel via high-quality relays:
Guitar
:
maximum level at 0.5 Vrms input level
Mic
:
maximum level at 1.3 Vrms input level
On the driver side
The inputs are viewed as a stereo pair (1+2). The driver is called “UF400e(0) In 1”
Practical tip:
Make full use of the 24-bit support of up-to-date
software applications and connected digital peripherals—even if
you are planning to “just” release your production on CD. The
admittedly subtle increase in audio quality pays off noticeably in
the total signal and especially in digital editing.
Practical tip:
While recording, try to achieve as high a recording
level as possible to get the greatest bene t from the wide dynamic
range of the 24-bit converter. Always remember that a clean take
is far more valuable than the best corrective plugin.
. Both channels can be used in mono mode in most audio editors.
UF400e Firewire Audio Expansion Board Users Manual

16
Digital interface (S/PDIF)
Use the digital interface of your UF400e Board to transfer music digitally from your
computer to other devices, or to record audio data with your computer. There are two
separate coaxial jacks (cinch) for recording and playback. The interface can send and
receive sample rates of up to 24-bit / 96 kHz. The recording driver is called “UF400e
(0) SPDIF In”, and the routing must be set to the digital output in the Control Panel
for playback.
Synchronization.
When recording from a digital source, make sure that the
sampling rates of both devices (e.g. DAT recorder and laptop) are synchronized.
The S/PDIF protocol contains a signal for this purpose. If such a signal is
applied to the digital input and the Master Clock switch is set to “External”, the
UF400e will automatically synchronize to it and the “Digital In” channel will be
available in the mixer.
ASIO applications such as Cubase SX often have an option to switch the
hardware from an internal to an external (sometimes also called S/PDIF) clock
source. This changeover currently has no effect on the UF400e. The switch to
an external clock is not to be confused with external synchronization to MIDI
devices, video equipment or tape decks and therefore cannot be found in the
Sync, MIDI Clock, MTC or SMPTE settings of the applications.
AC3
and
DTS
can also be played back via the digital output. Select “NonAudio
DTS can also be played back via the digital output. Select “NonAudioDTS
” for the digital output in the Control Panel under “Routing”. This setting mutes
the Digital Play path in the digital mixer so that the non-audio signals are not
also sent to the analog outputs.
MIDI interface
MIDI IN/OUT/THRU is available for suitably-equipped peripherals such as MIDI
keyboards, DAW controllers and other devices. The cables for MIDI connections are
Practical tip:
For an absolutely clean and jitter-free signal path
(when mastering, for example), use special shielded RCA cables
to transfer digital data.
Devices that can process the S/PDIF protocol can be connected
to the coaxial digital interface (RCA sockets on the panel). These
include DAT recorders and a wide range of HiFi components, as
well as other computers.
UF400e Firewire Audio Expansion Board Users Manual

17
always connected “crosswise”, meaning OUT to IN and vice-versa. MIDI sequencer
software usually offers you to loop MIDI data through, using the Through function.
Drivers
The Windows drivers
The UF400e audio interface features a range of drivers for a variety of applications.
The audio drivers support all bit rates between 8 and 32 bits with all common sample
rates between 32 and 192 kHz. (Digital I/O up to 96 kHz)
The MME wave driver.
In most Windows programs, you will encounter drivers with the designation “
UF400e (0) MC Out” for recording and playback. These are multichannel drivers
that support all six outputs (4 analog and 2 digital). The speci c routing options for
these drivers can be found in the UF400e Control Panel.
The ASIO driver and the ASIO Control Panel
The abbreviation ASIO stands for “Audio Streaming Input Output” and refers to a
32-bit driver model developed by Steinberg. The advantage of the ASIO driver is
the extremely low audio recording and playback delay times, also known as latency.
Values signi cantly under 10 ms—and less than 4 ms on fast, cleanly-con gured
systems—at sample rates exceeding 96 kHz are quite realistic. The format also
supports sound Boards with multiple inputs and outputs—so-called multi-I/O Boards
—as well as direct monitoring and multi-client mode (ASIO 2.0 or later).
Programs that make use of Steinberg’s ASIO interface indicate in the corresponding
dialogs the ASIO drivers of the UF400e. The ASIO driver is listed in compatible
programs under “ASIO for UF400e FireWire series”.
Device con guration in Cubase SX 2
UF400e Firewire Audio Expansion Board Users Manual

18
The inputs and outputs (generally called “busses” or “channels”) available in the
individual programs are generally called “Out 1 UF400e”, “Out 2 UF400e”, etc.
ASIO audio connections in WaveLab 5
The GSIF driver
The GSIF driver of the audio interfaces is also visible only in certain programs.
The GigaStudio sampler application and other Tascam / Nemesys products can also
access the hardware in a very fast and direct manner. The outputs available in each
program are called here “UF400e (0)” and lead directly to the outputs of the UF400e
audio system.
The MIDI driver
For the recording and playback of MIDI data via the MIDI IN and OUT jacks, a
separate driver is available. The driver designated as “UF400e(0) Midi In 1 or Out
1” in this system, and it can be selected in any situation in which its use would be
appropriate.
In detailspecial properties of the drivers.
DirectSound & WDM
It goes without saying that the drivers of the UF400e also support Microsoft’
s DirectSound or DirectSound 3D interface. What’s more, the software complies
strictly with Microsoft’s WDM speci cation. For example, the drivers are able to
play back audio data streams from multiple applications in parallel (multi-client, a “
Practical tip:
If MIDI  les, which can be played back using
Windows’ media players, are also to be transferred to externally
connected devices, open the “Sounds and Multimedia Properties
” dialog window from the Windows Control Panel and set the “
MIDI Music Playback” device to the driver mentioned above.
UF400e Firewire Audio Expansion Board Users Manual
