C-Nav C-NaviGator III User manual

C-NaviGator III
Mounting Reference Guide
Revision 3
Revision Date: March 29, 2018
C-Nav Positioning Solutions
730 E. Kaliste Saloom Road
Lafayette, LA 70508 U.S.A.
www.oceaneering.com/cnav

C-NaviGator III Mounting Reference Guide
Revision 2 Page 2 of 20 3/29/2018
Release Notice
This is the March 29 release of the C-NaviGator III Mounting Reference Guide.
Revision History
3
3/29/2018
Updated to new web domain
L.Cortes
2
7/19/2013
Added additional mounting options
J. Hauschildt
1
3/1/2013
Added Panel Cut Out Guide & cleaning
Instructions
J. Hauschildt
0
2/14/2013
Initial Release
J. Hauschildt
Revision
Date
Description
Author
Trademarks
The oceaneering logo is a trademark of Oceaneering International, Inc.
C-Nav, C-Nav3050, and C-NaviGator are trademarks of Oceaneering
International, Inc. All other brand names are trademarks of their respective
holders.
Disclaimer of Warranty
EXCEPT AS INDICATED IN “LIMITED WARRANTY” HEREIN, OCEANEERING
INTERNATIONAL, INC. SOFTWARE, FIRMWARE AND DOCUMENTATION
ARE PROVIDED “AS IS” AND WITHOUT EXPRESSED OR LIMITED
WARRANTY OF ANY KIND BY EITHER OCEANEERING INTERNATIONAL,
INC., OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION,
PRODUCTION, OR DISTRIBUTION INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THE ENTIRE RISK, AS TO THE QUALITY AND
PERFORMANCE OF THE OCEANEERING INTERNATIONAL, INC.
HARDWARE, SOFTWARE, FIRMWARE AND DOCUMENTATION, IS WITH
YOU. SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED
WARRANTIES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
Limitation of Liability
IN NO EVENT WILL OCEANEERING INTERNATIONAL, INC., OR ANY
PERSON INVOLVED IN THE CREATION, PRODUCTION, OR DISTRIBUTION
OF THE OCEANEERING INTERNATIONAL, INC. SOFTWARE, HARDWARE,
FIRMWARE AND DOCUMENTATION BE LIABLE TO YOU ON ACCOUNT OF
ANY CLAIM FOR ANY DAMAGES, INCLUDING ANY LOST PROFITS, LOST

C-NaviGator III Mounting Reference Guide
Revision 2 Page 3 of 20 3/29/2018
SAVINGS, OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR
EXEMPLARY DAMAGES, INCLUDING BUT NOT LIMITED TO ANY DAMAGES
ASSESSED AGAINST OR PAID BY YOU TO ANY THIRD PARTY, RISING OUT
OF THE USE, LIABILITY TO USE, QUALITY OR PERFORMANCE OF SUCH
OCEANEERING INTERNATIONAL, INC. SOFTWARE, HARDWARE, AND
DOCUMENTATION, EVEN IF OCEANEERING INTERNATIONAL, INC., OR
ANY SUCH PERSON OR ENTITY HAS BEEN ADVISED OF THE POSSIBILITY
OF DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY. SOME STATES
DO NOT ALLOW THE LIMITATION OR EXCLUSION OF LIABILITY FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES SO, THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.

C-NaviGator III Mounting Reference Guide
Revision 2 Page 4 of 20 3/29/2018
Table of Contents
C-NaviGator III......................................................................................................1
Mounting Reference Guide...................................................................................1
Table of Contents..................................................................................................4
List of Figures .......................................................................................................4
Manual Organization.........................................................................................6
Conventions ......................................................................................................6
Section 1 –Overview............................................................................................7
Introduction .......................................................................................................7
Section 2 –Installation and Mounting Instructions................................................8
Installation and Mounting ..................................................................................8
General Mounting Instructions...........................................................................9
Section 3- Mounting Options...............................................................................11
OPTION #1......................................................................................................11
OPTION #2......................................................................................................11
OPTION #3......................................................................................................12
OPTION #4......................................................................................................12
Section 4- Cleaning Instructions .........................................................................15
“Dry” (Clean Screen) Method ..........................................................................15
“Wet” Method...................................................................................................15
Section 5- Physical Dimensions..........................................................................17
Section 6- Panel Cut-Out Guide .........................................................................18
Section 7 - Mechanical Drawings........................................................................19
List of Figures
Figure 1: C-NaviGator III Control and Display Unit ...............................................7
Figure 2: Flat Screen Table Stand for C-NaviGator III/ CHIFSB0108BLK ..........11
Figure 3: C-NaviGator III 19” Rack Mounting Plate (P/N CNVJH 13TAP STD-A1)
............................................................................................................................11
Figure 4: Tilting VESA Wall Mount for C-NaviGator III (P/N PEEST630)............12
Figure 5: RAM VESA Plate KIT (P/N CNV-D-246U-IN1KIT1).............................12
Figure 6: RAM 100/75 VESA mount Plate (P/N CNVRAM-D-246U-IN1) .........13

C-NaviGator III Mounting Reference Guide
Revision 2 Page 5 of 20 3/29/2018
Figure 7: RAM 3.68" Diameter Base (P/N CNVRAM-D-202U-IN1)..................13
Figure 8: RAM Double Ball Adapter (P/N CNVRAM-D-230U).............................13
Figure 9: RAM Double Socket Arm, Short (P/N CNVRAM-D-201U-C)...........13
Figure 10: RAM Double Socket Arm, Regular (P/N RAM-D-201U) ................14
Figure 11: RAM Double Socket Arm, Long (P/N CNVRAM-D-201U-E)..............14
Figure 12: RAM 11" x 3" Additional Heavy Duty Base (P/N CNVRAM-D-111B-
IN1U) ..................................................................................................................14
Figure 13: Spacer, washer, screw set (P/N CNVRAM-RPR-WASHS2)..............14
Figure 14: Screen Cleaning Mode ......................................................................15

C-NaviGator III Mounting Reference Guide
Revision 2 Page 6 of 20 3/29/2018
Manual Organization
This section describes how the manual is laid out. It gives one or two sentence
descriptions about each major section.
Section 1 –Overview (Page 7) gives a brief overview of the purpose of this
document.

C-NaviGator III Mounting Reference Guide
Revision 2 Page 7 of 20 3/29/2018
Section 2 –Installation and Mounting Instructions (Page 8) contains installation
and mounting instructions.
Section 3- Mounting Options (Page 11) provides two mounting options.
Section 4- Cleaning Instructions (Page 15) Provides instructions on how to clean
the front glass of the C-NaviGator III.
Section 5- Physical Dimensions (Page 17) contains the physical dimensions of
the C-NaviGator III.
Section 6- Panel Cut-Out Guide (Page 18), include a guide and drawing on how
to cut out a panel for the C-NaviGator III.
Section 7 - Mechanical Drawings (Page 19) has mechanical drawings.
Conventions
Arial font is used for plain text in this document.
Arial Italic font is used to show user settings
Arial Blue font is used for cross-references.
Arial Blue Underline font is used for hyperlinks.
Important notes are displayed in shaded text boxes
Section 1 –Overview
Introduction
This guide is used as a reference for installing and mounting the C-NaviGator III
control and display unit. It also shows the mounting options for the C-NaviGator
Please note:
Such note box displays important information which should not be ignored.

C-NaviGator III Mounting Reference Guide
Revision 2 Page 8 of 20 3/29/2018
III, as well as their dimensions. For further information, contact C-Nav support
([email protected]).
Figure 1: C-NaviGator III Control and Display Unit

C-NaviGator III Mounting Reference Guide
Revision 2 Page 9 of 20 3/29/2018
Section 2 –Installation and Mounting
Instructions
Installation and Mounting
1. Most of our products are intended for various methods of installation or
mounting (panel mounting, bracket mounting, ceiling/wall, console
mounting etc.); for details, please see the relevant mechanical drawings.
2. Adequate ventilation is a necessary prerequisite for the life of the product.
The air inlet and outlet openings must definitely be kept clear; coverings
which restrict ventilation are not permissible.
3. Generally, do not install the unit in a horizontal position (lying down), as
this will cause heat to build up inside the unit which will damage the LCD
ATTENTION:
To prevent damage to chassis corners and / or breaking the front glass, please
review the illustrations below before handling the units!

C-NaviGator III Mounting Reference Guide
Revision 2 Page 10 of 20 3/29/2018
Panel. To prevent this problem we recommend installing the unit in a
vertical position (±30 degrees) to improve the airflow through the unit.
4. To further improve the cooling of the unit we recommend installing Cooling
Fans underneath blowing upwards into the unit air inlet. This may be
required in high temperature applications and also when there is reason to
expect temperature problems due to a non-optimal way of mounting.
5. Exposure to extreme direct sunlight can cause a considerable increase in
the temperature of the unit and might under certain circumstances lead to
over-heating. This point should already be taken into consideration when
the bridge equipment is being planned (sun shades, distance from the
windows, ventilation, etc.)
6. Space necessary for ventilation, for cable inlets, for the operating
procedures and for maintenance, must be provided.
7. If the push buttons of the product are not illuminated, an external,
dimmable illumination (IEC 60945 Ed. 4, 4.2.2.3, e.g. Goose neck light) is
required for navigational use. The illumination shall be dazzle-free and
adjustable to extinction.
8. Information about necessary pull-relievers for cables is indicated in the
Physical Connection section of this manual. Attention must be paid to this
information so that cable breaks will not occur, e.g. during service work.
9. Do not paint the product. The surface treatment influences on the excess
heat transfer. Painting, labels, or other surface treatments that differ from
the factory default might cause overheating.
10.Expose to heavy vibration and acoustic noise might under certain
circumstances affect functionality and expected lifetime. This must be
considered during system assembly and installation. Mounting position
must carefully be selected to avoid any exposure of amplified vibration.
General Mounting Instructions
1. The useful life of the C-NaviGator III generally decreases with increasing
ambient temperature; it is therefore advisable to install such units in air-
conditioned rooms. If there are no such facilities these rooms must at
least be dry, adequately ventilated, and kept at a suitable temperature in
order to prevent the formation of condensation inside the display unit.
2. Cooling of the C-NaviGator III takes place via the surface of the casing.
The cooling must not be impaired by partial covering of the unit or by
installation of the unit in a confined cabinet.
3. In the area of the wheel house, the distance of the C-NaviGator III from
the magnetic standard compass or the magnetic steering compass must
not be less than the permitted magnetic protection distance. This distance
is measured from the center of the magnetic system of the compass to the
nearest point on the C-NaviGator III. The compass safe distance of the C-

C-NaviGator III Mounting Reference Guide
Revision 2 Page 11 of 20 3/29/2018
NaviGator III is at least 80cm (31.5”) from a standard compass; at least
45cm (18”) from a steering compass.
4. When selecting the site of a display unit, the maximum cable lengths have
to be considered.
5. When a product is being installed, the surface base or bulkhead must be
checked to ensure that it is flat in order to avoid twisting of the unit when
the fixing screws are tightened, because such twisting would impair
mechanical functions. Any unevenness should be compensated for by
means of spacing-washers.
6. The grounding screws of the units must be connected to the body of the
ship (ground); the wire used should have a cross sectional area of at least
6 mm2 (10AWG).
7. Transportation damage, even if apparently insignificant at first glance,
must immediately be examined and be reported to the freight carrier. The
moment of setting-to-work of the equipment is too late, not only for
reporting the damage but also for the supply of replacements.
8. The classification is only valid for approved mounting brackets provided by
C & C Technologies. The unit shall be mounted stand-alone without any
devices or loose parts placed at or nearby the unit. Any other type of
mounting might require test and re-classification.

C-NaviGator III Mounting Reference Guide
Revision 2 Page 12 of 20 3/29/2018
Section 3- Mounting Options
This section shows the four mounting options for the C-NaviGator III.
OPTION #1
Flat Screen Table Stand (P/N CNVCHIFSB018BLK) (See Fig. 2)
Figure 2: Flat Screen Table Stand for C-NaviGator III/ CHIFSB0108BLK
OPTION #2
C-NaviGator III 19” Rack Mounting Plate (P/N CNVJH 13TAP STD-A1) (See Fig.
3)
Figure 3: C-NaviGator III 19” Rack Mounting Plate (P/N CNVJH 13TAP STD-A1)

C-NaviGator III Mounting Reference Guide
Revision 2 Page 13 of 20 3/29/2018
OPTION #3
Tilting VESA Wall Mount for C-NaviGator III (P/N PEEST630) (See Fig. 4)
Figure 4: Tilting VESA Wall Mount for C-NaviGator III (P/N PEEST630)
OPTION #4
RAM VESA Ball Mounts- allows the C-NaviGator III to be mounted to the ceiling,
wall or desktop with fully adjustable positioning. Here are the following RAM
VESA Ball Mount parts and accessories (Figures 5 through 13):
RAM VESA Plate KIT (P/N RAM-D-246U-IN1 KIT) (Fig. 5). Comes with
plate, screws, washers and bushings.
Figure 5: RAM VESA Plate KIT (P/N CNV-D-246U-IN1KIT1)

C-NaviGator III Mounting Reference Guide
Revision 2 Page 14 of 20 3/29/2018
RAM VESA mount Plate (P/N CNVRAM-D-246U-IN1) (See Fig. 6)
Figure 6: RAM 100/75 VESA mount Plate (P/N CNVRAM-D-246U-IN1)
RAM 3.68" Diameter Base (P/N CNVRAM-D-202U-IN1) (See Fig. 7)
Figure 7: RAM 3.68" Diameter Base (P/N CNVRAM-D-202U-IN1)
RAM Double Ball Adapter (P/N RAM RAM-D-230U) (See Fig. 8)
Figure 8: RAM Double Ball Adapter (P/N CNVRAM-D-230U)
RAM Double Socket Arm, Short (P/N CNVRAM-D-201U-C) (See Fig. 9)
Figure 9: RAM Double Socket Arm, Short (P/N CNVRAM-D-201U-C)
RAM Double Socket Arm, Regular (P/N CNVRAM-D-201U) (See Fig. 10)

C-NaviGator III Mounting Reference Guide
Revision 2 Page 15 of 20 3/29/2018
Figure 10: RAM Double Socket Arm, Regular (P/N RAM-D-201U)
RAM Double Socket Arm, Long (P/N CNVRAM-D-201U-E) (See Fig. 11)
Figure 11: RAM Double Socket Arm, Long (P/N CNVRAM-D-201U-E)
RAM 11" x 3" Additional Heavy Duty Base (P/N CNVRAM-D-111B-IN1U)
(See Fig. 12)
Figure 12: RAM 11" x 3" Additional Heavy Duty Base (P/N CNVRAM-D-111B-IN1U)
Spacer, washer, screw set (P/N CNVRAM-RPR-WASHS2) (See Fig. 13)
Figure 13: Spacer, washer, screw set (P/N CNVRAM-RPR-WASHS2)

C-NaviGator III Mounting Reference Guide
Revision 2 Page 16 of 20 3/29/2018
Section 4- Cleaning Instructions
The front surface of the display glass has a special coating which can be
scratched and damaged with improper cleaning. There are two methods to
cleaning the front of the C-NaviGator III. There is the “Dry” (Clean Screen)
method and the “Wet” method.
“Dry” (Clean Screen) Method
The “Dry” (Clean Screen) Method is performed when the C-NaviGator III is on.
The user can select Clean Screen in General Settings. By choosing this option
(See Fig.13), the display will ignore input from the touch screen for 10 seconds.
The user can wipe the screen using a dry soft fabric cloth. As a promotion, C-Nav
provides a soft fabric cloth with every C-NaviGator III.
Figure 14: Screen Cleaning Mode
“Wet” Method
Please note:
The C-NaviGator III must be powered down before using this method
It is recommended to use only >90% pure Isopropyl alcohol (Isopropanol) and a
soft fabric cloth.
“Wet” Method Instructions:
1) Turn off the C-NaviGator III and allow it to cool down prior to cleaning.

C-NaviGator III Mounting Reference Guide
Revision 2 Page 17 of 20 3/29/2018
2) Fold a cloth into a small pad, dampen the cloth with alcohol, and wipe the
glass from one edge to the other in one direction with one continuous
motion.
3) The soft cloth & alcohol wipe is recommended to clean fingerprints and
oils off the glass.
4) Liquid stains (e.g. water, coffee, tea & soda) should be first cleaned off the
glass with a soft fabric cloth wet with water, immediately followed with
wiping using an alcohol wetted cloth

C-NaviGator III Mounting Reference Guide
Revision 2 Page 18 of 20 3/29/2018
Section 5- Physical Dimensions
355.00 (W) x 248.50 (H) x 58.00 (D) mm
13.98” (W) x 9.78” (H) x 2.28” (D)
4 x M4 VESA mounting 75x75mm, Max 8mm deep
Built-in Console mounting 4 x M5x15mm screws
Weight: 4.4kg / 9.7lbs

C-NaviGator III Mounting Reference Guide
Revision 2 Page 19 of 20 3/29/2018
Section 6- Panel Cut-Out Guide
A link to the drawing below can be found HERE. A full sized cut out template for
the C-NaviGator III can be found HERE (Requires print out on a sheet of ANSI
size B (11” x17”) paper).

C-NaviGator III Mounting Reference Guide
Revision 2 Page 20 of 20 3/29/2018
Section 7 - Mechanical Drawings
