C-TEC FP4E User manual

FP4E 4 Zone Economy Fi e Ala m Cont ol Panel (Pa t No. FF384-3)
Installation Inst uctions
FI E ALA M
ancillaries 1 of 4
Approved Document No. DFU0384011 Rev 2 Draft 4
THIS EQUIPMENT MUST ONLY BE INSTALLED AND MAINTAINED BY A SUITABLY SKILLED AND TECHNICALLY
COMPETENT PE SON. THIS EQUIPMENT IS A PIECE OF CLASS 1 EQUIPMENT AND MUST BE EA THED.
DO NOT CHANGE ANY PANEL CONNECTIONS WITH THE PANEL’S POWE APPLIED (MAINS O BATTE Y POWE ).
DETECTOR
DETECTOR
CALL POINT
CPR
CALL POINT
CPR
DO NOT SPUR -
CIRCUIT NOT MONITORED!
-
+
PANEL ZONE
TERMINALS
DETECTOR DETECTOR
CPR
CALL POINT
CPR
+
-
-+
EMU PANEL MODULE
BF378 or
BF378M
ELECTRONIC MONITORING UNIT (EMU)
CALL POINT
Fig 5
SOUNDERS
++
EOLR
+ +
+ +
DO NOT make off
more than 2 circuits
in the panel
EOLR
SOUNDERS
EOLR
EOLR = End of Line Resistor (6k8Ω, 0.25W) -supplied
CPR = Call Point Resistor (470 - 680Ω, 0.5W) - supplied with call point
PANEL ZONE
TERMINALS
PANEL SOUNDER
TERMINALS
TYPICAL ZONE CIRCUIT - Call points wired before detectors
- Detector base diodes not needed.
TYPICAL ZONE CIRCUIT - With mixed order call points and detectors
- Detector bases fitted with continuity diodes and negative connection linked out.
TYPICAL SOUNDER CIRCUITS
Only use polarised sounders!
Remove EOLR from
terminal block and
fit to last detector.
DO NOT SPUR -
CIRCUIT NOT MONITORED!
Remove EOLR from
terminal block(s) and
fit to last sounder.
+
+
-
-
5
6
7
8
INSTALLATION PROCEDURE
All cables must be installed in accordance with all applicable national, regional or local standards. In the UK this is BS 7671 IEE
Wiring Regulations and BS 5839-1, Fire detection and alarm systems for buildings: Code of practice for system design, installation
and maintenance. Fire resistant, screened cable should be used throughout the installation and ains wiring should be
segregated from extra low voltage field wiring.
For PER ANENTLY CONNECTED equipment, a readily accessible disconnect device shall
be incorporated external to the equipment.
The general requirement for the ains supply to the panel is fixed wiring, using 3 core
cable, (no less than 1mm2and no more than 2.5mm2), or a suitable three conductor
system fed from an isolating switched fused spur, fused at 3A. The ains supply must
be exclusive to the panel.
HINT. As an alternative to a switched
fused spur, a double pole isolating
device (B) may be used in the ains
feed from the ain Distribution
Board (A) to the panel (C), providing
it meets the appropriate wiring
regulations – see Fig 1.
• Remove the panel’s lid (disconnect attached loom connector).
• Fit the panel’s back box securely to a wall using the mounting holes provided and
suitable screw fixings. Remove required number of knockouts and fill holes with good
quality cable glands – see Fig 2.
• Gland field cables and terminate all screens to the panel.
CAUTION: DO NOT use an insulation tester (Megger) with any electronic devices
connected as the test voltage will totally destroy the devices.
• Test field cables and ensure they are fault-free, i.e. check continuity of cable runs
(including screens).
• Connect external ains cable to the panel’s fused ains terminal block (with ains
isolated) – see Fig 2.
CAUTION: ISK OF EXPLOSION IF BATTE Y IS EPLACED BY AN INCO ECT TYPE.
DISPOSE OF USED BATTE IES ACCO DING TO THE INST UCTIONS.
Also, if the battery leads are connected in reverse, the battery fuse (F1) will blow
which may damage the panel and invalidate the warranty.
• Position and connect the panel’s two internal 12V sealed lead acid batteries (with
battery supply isolated) – see Fig 3 & Fig 4.
• Connect zone circuits to the panel – see Fig 5.
• Connect sounder circuits to the panel – see Fig 5.
• Connect ancillary connections to the panel.
• Refit the panel’s lid (re-connect loom connector).
• Apply ains and battery supply to power up the panel.
• The panel should be in normal mode. If not, investigate and rectify any faults
indicated on the panel.
• Finally, test the panel – see pages 2 & 3.
Shorting Link
(supplied)
+
–
12V Battery
Connections
to Panel
+
12V Battery
–
+
12V Battery
–
+–
12V Battery
Fig 4
Black
Wire
Black
Wire
(supplied)
Red
Wire
Red
Wire
(supplied)
OR
Fig 3
space for batteries
(bottom of back box)
Fig 2
AA
AA
BBBBB
BBBBB
B
B
A = Mounting Holes, B = Cable Knockouts
Mains cable
L(LIVE), N(NEUTRAL), (EARTH)
Power Rating
A
3A
≥1.0mm2 <2.5mm2
B
C
Fig 1

TESTING THE PANEL
When testing the panel with the panel lid open, always isolate the Mains and disconnect the batteries. The panel
can be tested before connecting field wiring. If testing before installation, ensure the end-of-line resistors are
fitted in the panel’s sounder and detector terminal blocks.
Position and connect two suitable 12V batteries in the panel as shown in Fig 3 and Fig 4 (page 1). When the
batteries are connected, the POWER SUPPLY FAULT indicator will light and the warning beeper will sound.
Connect the ains wiring and turn the ains supply on. The AINS ON indicator will light, the POWER SUPPLY
FAULT indicator will go out and the warning beeper will silence (providing the batteries are not flat).
WITH THE KEYSWITCH AT NO MAL POSITION
The AINS ON indicator is lit. No other indicators are lit. No sounders are active. The pushbuttons are inoperative.
TU N THE KEYSWITCH TO A M CONT OLS POSITION
Note: None of the panel’s pushbuttons are operative unless the keyswitch is in the AR CONTROLS position.
Press RESET/RESOUND/TEST ZONE LA PS. The ZONE FIRE and ZONE FAULT indicators light and the warning beeper
will sound. The AINS ON indicator will remain lit. All the other indicators will NOT light. Release the pushbutton
and the panel will return to normal.
TEST THE POWE SUPPLY MONITO ING CI CUIT
Switch off the ains. The POWER SUPPLY FAULT indicator will light, the AINS ON indicator will extinguish, and
the warning beeper will sound. Press SILENCE FAULT SOUNDERS and the warning beeper will silence but the
POWER SUPPLY FAULT indicator will remain lit. Reconnect the ains and the panel will revert to normal.
Disconnect the battery. The POWER SUPPLY FAULT indicator will light and the warning beeper will sound.
Reconnect the battery and after a short time the panel will revert to normal (i.e. only the AINS ON indicator
light on). Note: This test should be carried out with a set of new and fully charged batteries – deteriorated cells
will show a fault even when connected and charged up.
TEST THE SOUNDE MONITO ING CI CUITS
DO NOT carry out this test with the ZONE FIRE indicators lit as sounder fuses F2 & F3 could blow. Ensure the end-
of-line resistor is connected across each of the sounder circuits on terminals 5 & 6, 7 & 8. Short the sounder
terminals 5 & 6. The SOUNDER FAULT indicator will light and the warning beeper will sound.
Press SILENCE FAULT SOUNDERS and the warning beeper will silence but the SOUNDER FAULT indicator will stay
on. Remove the short and the panel will revert to normal. Open circuit the sounder terminals 5 & 6 by
disconnecting one leg of the end-of-line resistor. The SOUNDER FAULT indicator will light and the warning beeper
will sound. Press SILENCE FAULT SOUNDERS and the warning beeper will silence but the SOUNDER FAULT indicator
will stay on. Remake the circuit and the panel will revert to normal.
Repeat the test for the other sounder circuit via terminals 7 & 8.
TEST THE DETECTO MONITO ING CI CUITS
ake sure an end-of-line device (EOLD) is connected across each pair of detector terminals (9 & 10, 11 & 12, etc.).
The EOLD would either be a 6.8kΩ resistor or Electronic onitoring Unit (E U) and associated Panel odule,
depending on the installation. Refer to Fig 5 (page 1) & E U instructions for connections.
The following four conditions can exist on the detector monitoring circuits:
1. Normal Condition: Current flows round the detector loop via the EOLD to monitor the wiring.
2. Open Circuit Fault: The wiring is broken at some point and the monitoring current cannot flow through the EOLD.
3. Short Circuit Fault: A short circuit exists at some point and too much monitoring current flows.
4. Fire Condition: A partial short exists and the monitoring current increases but not enough to show a short circuit
fault. ost smoke detectors make a partial short when they are triggered but manual call points and other
normally open switches need to have 470 or 680Ωresistors connected in series in order to give a partial short.
(Check - Resistor may be built into the Call Point - see Fig 5, page 1.)
OPEN CI CUIT FAULT TEST
Open circuit the zone circuit terminals 9 & 10 by disconnecting one wire of the EOLD. The ZONE 1 FAULT indicator
and internal ZONE 1 OPEN CIRCUIT FAULT indicator will light. The warning beeper will also sound. Press SILENCE
FAULT SOUNDERS and the warning beeper will silence but the indicators will stay on. Reconnect the EOLD and the
panel will revert to normal.
SHO T CI CUIT FAULT TEST
Short circuit the zone circuit terminals 9 & 10. The ZONE 1 FAULT indicator and internal ZONE 1 SHORT CIRCUIT
FAULT indicator will light. The warning beeper will also sound. Press SILENCE FAULT SOUNDERS and the warning
beeper will silence but the indicators will stay on. Remove the short and the panel will revert to normal.
Repeat the test for the other zone circuit via terminals 11 & 12.
FI E ALA M
ancillaries
2 of 4 Approved Document No. DFU0384011 Rev 2 Draft 4

FI E CONDITION
Simulate a Fire condition by connecting and activating a Call Point, or by fitting a 470 to 680Ωresistor across
terminals 9 & 10. The sounder output relay will operate. The ZONE 1 FIRE indicator lights and warning beeper sounds.
Press SILENCE ALAR SOUNDERS. The sounder outputs return to normal but the ZONE 1 FIRE indicator will still be lit
and the warning beeper will still sound. Press RESET/RESOUND/TEST ZONE LA PS and the panel will go back into
alarm as the Fire condition is still present. Remove the Fire condition. Press SILENCE ALAR SOUNDERS, then
RESET/RESOUND/TEST ZONE LA PS, and the panel reverts to normal. Repeat the test for the other zone terminals.
Notes:
1) Pressing RESET/RESOUND/TEST ZONE LA PS when in the unsilenced Fire condition (i.e. Sounder Outputs
energised) has no effect. The sounders UST be Silenced first before Reset is active.
2) When the Alarm Sounders are silenced, the warning beeper will sound and cannot be silenced.
3) Resetting the system from the Silenced Fire state with the fire condition still existing will retrigger the alarm.
EVACUATE
Press EVACUATE. The Sounder Outputs will operate, the ZONE FIRE indicators will light and the warning beeper
will sound. Press SILENCE ALAR SOUNDERS and the Sounder Outputs will return to the normal state. The ZONE
FIRE indicators will still be lit and the warning beeper will still be active. Press RESET/RESOUND/TEST ZONE LA PS
to return the panel to normal state.
TESTING THE SYSTEM
Check each detector and sounder on the system, and check the functions of the panel. Check all circuits for open
and short circuit faults. If continuity diodes are fitted remove each head in turn and check that call points are still
operative. When testing is complete return the keyswitch to NOR AL position.
ANCILLARY FACILITIES (Links and internal features are shown in Fig 6 below)
ENGINEE S TEST (NON-LATCH TEST) FACILITY
This range of panels has a non-latching test facility
which allows manual call points and smoke detectors
to be tested and reset automatically. To set this facility
move the link marked ‘PL1’ on the main PCB from the
lower to the upper position and the adjacent
indicator will light, the warning beeper will sound
and cannot be silenced. When an alarm condition is
caused the alarm sounders will operate for about half
a second and will silence for three seconds before
resounding. This will continue until the cause of the
alarm is removed by the smoke clearing from a
detector or the call point being reset. When testing is
complete, replace the link to the lower position.
ZONE ISOLATION FACILITY
Each Detector Zone can be isolated individually by moving the links (PL2/PL4/PL5/PL6) from the lower to the upper
position. The adjacent indicator and relevant ZONE FAULT indicator will light to show that the zone is isolated. The
warning buzzer will sound and cannot be silenced. When testing is complete, replace the link to the lower position.
TO EVE T TO SHO T CI CUIT = FI E
This facility overrides the short circuit fault monitoring for each zone and allows the panel to be used on
installations which do not have Call Point Resistors fitted. It produces a short circuit Fire condition when activated.
To enable this facility cut the wire links (LK1/LK2/LK3/LK4) on the main PCB.
AUXILIA Y EXPANSION PLUG (PL10)
This plug connector offers facilities for driving Repeater Panels, Fire and Fault relays and a "Class Change" input.
These facilities require various ancillary devices to be added to the panel (not included).
AUX 24V +VE
This output is a regulated, unmonitored, output fused at 1A (F4), available from terminal 1 in the panel’s base
connections. With link ‘PL3’ on the main PCB linked in position furthest from the F4 fuse this output is continuous.
If linked nearest to the F4 fuse then the output is present when the panel is normal but is switched off when the
relay is activated. This facility can be used to provide a fail-safe output via AUX 24V, that "switches off" when the
sounders are activated, or if power to the panel fails.
Note: Any load provided by this output increases the quiescent drain on the panel’s supply which in turn affects
the stand-by time of the system. It is not intended to supply door release systems.
VOLTAGE F EE ELAY CONTACTS
These single pole relay outputs, available via terminals 2 (normally closed), 3 (common), and 4 (normally open) in
the panel’s base connections, change over when the sounders are activated. They must not be used to switch
ains potentials, the contacts being rated at 30Vdc and 1.0A.
PL
9
PL13
Zone
Expansion
AuxiliaryExpansion
PL10
Keyswitch
Connector
PL11
DO NOT
ADJUST
VR1
Fig 6
F1
PL3
F4
AUX 24V
Output Fuse
Battery Fuse
PL7
RED
F3
F2
Sounder
Circuit Fuses
Cut links for
short circuit = fire condition
PL2 PL1PL4
PL8
PL6
notused
PL5
Primary Loom
Connector
FI E ALA M
ancillaries 3 of 4
Approved Document No. DFU0384011 Rev 2 Draft 4

FI E ALA M
ancillaries
4 of 4 Approved Document No. DFU0384011 Rev 2 Draft 4
FP4E TECHNICAL SPECIFICATION
E&OE. No responsibility can be accepted by the manufacturer or distributors of this equipment for any misinterpretation of this instruction, or for the compliance of the system as a
whole. The manufacturers policy is one of continuous improvement and we reserve the right to make changes to product specifications at our discretion and without prior notice.
POWER SPECIFICATION
MAINS SUPPLY VOLTAGE
INTERNAL POWER SUPPLY
TOTAL OUTPUT CURRENT LIMITED TO
AUXILIARY POWER OUTPUT
MAINS SUPPLY MONITORED FOR FAILURE
BATTERY CHARGER MONITORED FOR FAILURE
BATTERIES MONITORED FOR DISCONNECTION / FAILURE
DETECTOR CIRCUIT SPECIFICATION
NUMBER OF CIRCUITS
LINE FAULT MONITORED FOR OPEN CIRCUIT
LINE FAULT MONITORED FOR SHORT CIRCUIT
LINE FAULT MONITORED FOR DETECTOR REMOVAL
END OF LINE RESISTOR (SUPPLIED)
DETECTOR CONTINUITY DIODES
CALL POINT RESISTOR (NOT SUPPLIED)
MAXIMUM NUMBER OF SMOKE/HEAT DETECTORS PER ZONE
MAXIMUM NUMBER OF MANUAL CALL POINTS PER ZONE
SOUNDER CIRCUIT SPECIFICATION
NUMBER OF CIRCUITS
END OF LINE RESISTOR (SUPPLIED)
LINE FAULT MONITORED FOR OPEN CIRCUIT
LINE FAULT MONITORED FOR SHORT CIRCUIT
OUTPUTS FUSED AT
MAXIMUM TOTAL OUTPUT CURRENT (ALL OUTPUTS)
MAXIMUM NO. OF BELLS @ 25 mA EACH
MAXIMUM NO. OF ELECTRONIC SOUNDERS @ 20 mA EACH
FUSES - ALL FUSES COMPLIANT TO IEC (EN 60127 PT2)
MAINS TERMINAL BLOCK
SOUNDER OUTPUTS (F2, F3)
BATTERY FUSE (F1)
DOOR RETAINING MAGNETS
CONNECTION BLOCK
LARGEST ACCEPTABLE CONDUCTOR SIZE
SMALLEST ACCEPTABLE CONDUCTOR SIZE
PHYSICAL
ENCLOSURE (WIDTH x HEIGHT x DEPTH)
WEIGHT (WITHOUT BATTERIES)
These quantities are examples only.
}
FP4E (0.8A SUPPLY)
27 V d.c. nominal
800 mA
27 V d.c. nominal
YES
YES
YES
4
YES
YES (can be disabled)
Yes, if End of Line Monitoring Unit fitted in place of End of Line Resistor
6800 Ω, 5% tolerance, 0.25 W (colour code - blue, grey, red, gold)
Silicon 1N4001 or Schottky type (required if End of Line Monitoring Unit fitted)
470 to 680 Ω, 0.25 or 0.5 W
No limit
2
6800 Ω, 5% tolerance, 0.25 W (colour code - blue, grey, red, gold)
YES
YES
1 A
800 mA
32
40
200 mA T 20 mm
1 A F 20 mm
1.6 A F 20 mm
DO NOT USE PANEL POWER SUPPLY AS YOU WILL DRASTICALLY REDUCE BATTERY STAND-BY TIME.
2.5 mm2
0.75 mm2
322 x 267 x 92 mm
4.3 Kg
Important: Exceeding the fuse ratings may render the equipment
unsafe and damage the output of this equipment. This damage
is factory detectable and is not covered under warranty.
20 (maximum detector current = 2 mA)
DETECTOR CIRCUIT SPECIFICATION
POWER SPECIFICATION
SOUNDER CIRCUIT SPECIFICATION
FUSES
- ALL FUSES COMPLIANT TO IEC (EN 60127 PT2)
CONNECTION BLOCK
PHYSICAL
IP RATING (to EN 60529) IP30 (when correctly installed)
}
QUIESCENT CURRENT / BATTERY STAND-BY TIME (HRS)
0.8
STAND-BY TIME (HRS) 2.0 Ah BATTERIES 32
44STAND-BY TIME (HRS) 2.6 Ah BATTERIES
50QUIESCENT CURRENT (mA)
The quiescent currents listed are for the following conditions - Mains Supply
failed, detector and sounder End of Line resistors fitted, no other loads
supplied by the panel. The battery stand-by times are guidelines only based
on the above conditions and a full sounder load for 30 minutes.
Additional loads that increase the quiescent current in the normal alarm state
and sounder loads must be considered when calculating stand-by time.
Batteries in poor condition greatly reduce stand-by time.
MAX. LOAD CURRENT (A)
72STAND-BY TIME (HRS) 4.0 Ah BATTERIES
AUXILIARY RELAY CONTACTS (DO NOT CONNECT MAINS VOLTAGES) 1A 30 V d.c. max. Voltage-Free
AUXILIARY OUTPUT (F4) 1 A F 20 mm
ANCILLARIES (Individual datasheets available on request)
ANCILLARIES
(Individual datasheets available on request)
REPEATER PANEL Up to three Repeaters per control panel. Wiring = five cores plus one per zone.
Maximum cable length = 200 metres. Facilities = Common fault light; one fire light per zone;
warning buzzer; test button (test lights, buzzer & interconnecting wiring).
4 ZONE MONITORED SOUNDER EXTENDER KITS
RLP-24 5A RELAY ON PLATE (fits single gang back boxes)
Connects to existing sounder circuits to provide four additional monitored sounder circuits.
General purpose polarised and suppressed relay for use with 24 volt fire alarm systems. Can switch Mains loads.
CONTROLS
EXTERNAL PUSHBUTTONS (KEYSWITCH ACTIVATED)
RESET / RESOUND / TEST ZONE LAMPS
SILENCE ALARM SOUNDERS EVACUATE
INTERNAL
Revert to short circuit = fire (no resistors in Call Points)
OUTPUTS
2 sounder circuits (Alarm relay contacts can be obtained
by connecting an RLP-24 relay to a sounder circuit).
Ancillary connections for expansion modules will allow the
following: (1) Repeater Panels; (2) Multiple sounder outputs;
(3) Connection to Landlord’s Panel.
EXTERNAL INDICATORS
MAINS ON ZONE FIRE ZONE FAULT
SOUNDER FAULT POWER SUPPLY FAULT
INTERNAL INDICATORS
OPEN CIRCUIT ZONE FAULT
SHORT CIRCUIT ZONE FAULT
SILENCE FAULT SOUNDERS
Engineer Detector Test
Zone Isolate
ZONE ISOLATED ENGINEER TEST SELECTED
Part No. FF384-3
OPERATING TEMPERATURE
HUMIDITY
-10oC to +40oC
5% to 95% RH (non-condensing)
ENVIRONMENTAL
ENVIRONMENTAL
FREQUENCY RATED CURRENT 220 - 230 V a.c. 50 Hz / 60 Hz 185 mA
