Cable Electronics Celabs Distribution Hub and Receiver Installation instructions

WARRANTY
Cable Electronics, Inc. warrants this product to be free from defects in material and
workmanship, under normal use and service, for a period of one year from the
purchase by the original purchaser. If this product is defective or malfunctions,
Cable Electronics will replace or repair this unit (at their option) within a reasonable
time. No expressed or implied warranty is made for any dects caused by immersion
or exposre to liquids, abuse, neglect, improper operation of unit, excess wear and
tear and defects resulting from unauthorized disassembly and or modification.
Cable Electronics, Inc. http://www.celabs.net
3209 Wood Drive
Garland, Texas 75041
[phone] Fax [phone]
Document: CAT5_INFO_B.cdr Rev. B
CE labs can support many areas of your audio and
video distribution needs.
We manufacture RF modulators, RF amplifiers, HD
distribution amplifiers, and cables of all types.
See our full product line at www.celabs.net.
Component Video/Audio
HDTV Distribution Amplifier
Cat 5 Distribution Hub
And Receiver
Distribute a High Definition Video/Audio
Source to multiple locations over extended
distances using economical Cat 5 cable.
Cable Electronics, Inc.
3209 Wood Drive
Garland, Texas 75041
[phone] Fax [phone]

Installation / Operation Instructions
Unpack the amplifier and power supply from each box. Place the transmitter amplifier in a
dry location, usually behind the shelf where the source is located.
Connect the source device outputs to the appropriate input jacks on the CAT5TX. The
loop out jacks can be used to feed a local monitor or a second transmitter if installed.
Connect Cat5 cables A1 and B1 to the Transmitter RJ-45 jacks. At the other end of the
same cables, connect A1 and B1 to the CAT5RX. The RCA outputs are used to connect
to the remote monitor.
Insert the power supply connector into the power jacks of both units. Plug the wall
transformer into a 120Vac outlet. The power LED should be on and the unit is ready to
use. The CAT5RX will have 3 LEDs on to indicate continuity of the CAT5 cable. If one of
the Continuity LEDs is not on, there could be a problem with the A cable. Both A and B
cables should be installed for the detector to work properly.
Adjust the equalization control to the approximate length of the Cat5 cable. View the
picture on the monitor and fine tune the equalization control for the most pleasing picture.
There are 1/8” mini-jacks available to allow the transport of IR signals. This requires
optional external IR system.
Installation is complete.
Do not connect the Loop Out cable unless it is plugged into a monitor.
CAT5 Distribution Hubs
The Cat5 TX has one set of RCA inputs and one set of RCA loop-thru connectors to go to the
next Transmitter if installed. The unit allows any Audio/Video source, with Y, Cb, Cr, or Y, Pb,
Pr Outputs (component), to distribute Audio and Video to distant locations with excellent
picture quality. The amplifier also supports digital audio.
The Cat5 RX supports one monitor with component video, right and left audio, and digital
audio. The RX has an adjustable equalizer to correct for the signal loss caused by long
cables. An optional external IR system can be used with IR jacks.
SPECFICATIONS
VIDEO
AUDIO
Analog:
Digital:
POWER
Nominal Input level: 1 Volt peak to peak
Gain: 1 Volt into 75 ohms
Input Impedance: 75 ohms
Output Impedance: 75 ohms
Isolation port to port: >65 dB
Isolation out to input: >80 dB
Return loss: >30 dB
Video bandwidth: > 50 MHz (HDTV requires 37MHz min.)
Distance: 300 feet @ 1080i (500 feet with Cat6 cable)
Nominal Input level: 1 Volt peak to peak
Gain: Unity (one to one)
Input impedance: 22k ohm
Output impedance: 1k ohm
Frequency Response: 20Hz to 20kHz
Signal to Noise: 80dB @ 1 Volts out
Supports Standard SPDIF digital audio. (Not compatible with analog input signals)
Requirement: External 9 or 10 Volt AC @ 600mA with a ( 2.1mm center) Coaxial connector. Power Supply
is included.
