CableCreation CD0787 User manual

CableCreation 6-in-1 USB-C Hub
User Manual

Type-C to HDMI(4K/60Hz)/USB-Ax2/RJ45/USB-C Data/Type-C PD Charging with DP1.4 Alt mode
Contents
1.0 INTRODUCTION............................................................. 1
2.0 FEATURES......................................................................... 1
3.0 SPECIFICATIONS........................................................... 1
4.0 PACKAGE CONTENTS................................................... 3
5.0 CONNECTION DIAGRAM............................................. 3

Type-C to HDMI(4K/60Hz)/USB-Ax2/RJ45/USB-C Data/Type-C PD Charging with DP1.4 Alt mode
1
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before using and
kindly keep this manual for future reference. Please keep this manual
for future reference.
1.0 INTRODUCTION
This is a Type-C 6-in-1 hub with HDMI, 2 USB-A, RJ45, Type-C data
and Type-C PD charging female ports, providing an ideal solution for
extending the port of Type-C or Thunderbolt 3 host (PC/Laptop/Mobile
phone,etc), especially for those host with a single Type-C port. This
hub adopts DP1.4 Alt mode supported IC, enabling to output HDMI
video with max 4k/60Hz and meanwhile transfer USB 3.1 data with
max 5Gbps. 2 USB-A and Type-C data ports allow you to connect 3
USB devices simultaneously. RJ45 ports allows the host to get access
to Gigabit Ethernet. Besides, the Type-C female supports PD 3.0 with
max 100W PD Charging. It can work on all Type-C and ThunderboltTM3
host that supports DP Alt mode(including DP1.2 and DP1.4 Alt mode).
2.0 FEATURES
Support DP1.4 Alt mode
Support HDMI max 4k/60Hz
Support High Dynamic Range(HDR)
Support HDCP2.3, HDCP2.2 and HDCP1.4
Max 5Gbps data transmission
Max 1.5A downstream charging
Support Gigabit Ethernet,10M/100M/1000M
RJ45 supports to work with Nintendo Switch
Support max 100W PD charging, max 85W PD charging for PC
3.0 SPECIFICATIONS
Input/Output Connector
Input
Type-C Male x1
Output
HDMI x1
Type-C Datax1
USB-Ax2
RJ45 X1
Type-C PD Chargingx1
Type-C Malex1(Connect to host)
Support DP1.4 Alt mode

Type-C to HDMI(4K/60Hz)/USB-Ax2/RJ45/USB-C Data/Type-C PD Charging with DP1.4 Alt mode
2
HDMIx1
Support HDMI max 4k/60Hz
Support High Dynamic Range(HDR)
Support multiple color formats: RGB; YCbCr4:4:4; YCbCr4:2:2;
YCbCr4:2:0；8/10/12/16 bpc;
Support HPD
Support HDCP2.3, HDCP2.2 and HDCP1.4
Type-C Datax1(close to HDMI)
Max 5Gbps data transmission
Max 900mA downstream charging
Support short-circuit, over-current, over-voltage protection
USB-Ax2
Max 5Gbps data transmission per port
The port close to RJ45 supports max 5V/1.5A downstream
charging, another port supports max 900mA downstream
charging
Support short-circuit, over-current, over-voltage protection
RJ45x1
Support Gigabit Ethernet,10M/100M/1000M
Support to work with Nintendo Switch
Support Wake-On-LAN
Light indicator indicates the state, no light when no Internet
connected, orange light turns on when network connection is
established, green light flashes when transmitting data
Type-C PD Chargingx1
Support max 100W PD charging, max 85W PD charging for PC
(15w is dedicated to the functioning of this product)
Support PD3.0 Fast Role Swap, the connected device will not get
disconnected while plugging in and out PD Adapter
Physical
Weight
66g
Size
134.3*22.9*16.8 (mm)
Warranty
Limited Warranty
1 Year
Environmental
Operating Temperature
0℃to +45℃

Type-C to HDMI(4K/60Hz)/USB-Ax2/RJ45/USB-C Data/Type-C PD Charging with DP1.4 Alt mode
3
Operating Humidity
10% to 90 % RH (no
condensation)
Storage Temperature
-10℃to +70℃
Storage Humidity
10% to 90 % RH (no
condensation)
Power Supply
USB-C PD Charging Port
100W(20V/5A)
Regulatory Approvals
Certifications
FCC,CE
Accessory
User Manual
English Version
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the package and
make sure the following items are contained:
Main unit x1
User Manual x1
5.0 CONNECTION DIAGRAM

Type-C to HDMI(4K/60Hz)/USB-Ax2/RJ45/USB-C Data/Type-C PD Charging with DP1.4 Alt mode
4
Dear There,
Have a nice day! Thank you for your purchase. Here are some tips for you to get the
most out of our product:
1. Two USB C ports one is for charging only, and the other is for data only (Close to
the HDMI port).USB-C data ports do not support media display or charging.
2. 4K@60Hz is only available for laptops with DisplayPort 1.4 and 8K enabled.
For 4K@60Hz resolution, please make sure your device supports DP 1.4 Alt
Mode. To do this, please consult your device's user manual, contact the seller, or
check the manufacturer's website.
3. We recommend using a 100W PD (Power Delivery) charger: 85W for charging the
connected laptop and 15W for powering the hub. (Tips: The USB-C PD port, without
data function)
4. Hub may become heat while working, this is normal for products of this kind, in the
condition the ambient temperature is 77°F, as long as the temperature of the hub
does not exceed 140°F when full-loaded, it is safe and please rest assured to use.
5. You could charge an iPhone through the USB 3.0 interface, but please note that the
USB ports are mainly for data transfer and do not support high-performance phone
charging.
6. To achieve the full 1 Gbit / s via the network connection, please use an Ethernet
cable according to CAT5E standard or higher.
7. If you want the hub to work with the iPad Pro, you need to update to the latest
version of the iPad operating system.
8. To ensure a stable connection, avoid connecting devices that exceed a total of 900
mA.
9. Due to the performance limitations of some laptops, it is recommended that you
only connect one HDD / SDD at a time.
10. USB 3.0 interferes with WiFi and other wireless devices due to the similar
frequencies of 2.4 GHz. According to Microsoft, the problem only occurs for the 2.4
GHz wireless band, but not for 5 GHz. Please set your router to 5 GHz to avoid the
problem.
Should you have any questions or difficulties, feel free to contact us, and we will
resolve them for you as soon as possible and we will do everything we can to help.
We look forward to seeing you again.
Sincerely,
Mia from CableCreation

Type-C to HDMI(4K/60Hz)/USB-Ax2/RJ45/USB-C Data/Type-C PD Charging with DP1.4 Alt mode
5
FREQUENTLY ASKED QUESTIONS:
1. If you can't get the HDMI port to work
Try some of the following steps:
1) Confirm if the connected USB-C port of your device supports DP Alt Mode. To do
this, please consult your device's user manual, or check the manufacturer's website.
2) Try a different computer and HDMI cable to see if the issue still persists.
3) Plug your HDMI cable directly into your device and see if you get a stable
connection. If you can't get a stable connection, then the problem is with your HDMI
cable.
4) Verify that your monitor is configured to the correct input (HDMI).
2. If you can't get the HDMI port to 4K 60HZ
The hub supports 4K@60Hz, but kindly note that 4K@60Hz is only available for
laptops with DP 1.4 Alt Mode enabled! If your host just supports DP1.2, it will
only output max 4K@30Hz!
For 4K@60Hz resolution, please make sure your device supports DP 1.4 Alt
Mode.
3. If you can't get the Ethernet port to work
Try some of the following steps:
1) Reinstall the Ethernet driver.
2) Try this device with a different computer or different ethernet cable and see if the
issue persists.
BRAND GUARANTEE:
CableCreation Focus on the Ideal Design of All of Our Quality Cables.
CableCreation is a Creative Team With its Own Factory manufacturing, Using
innovative design and high-quality materials.
CableCreation is Confident to Offer All Buyers with Items 24 Months warranty,
lifetime technical support, and friendly customer service. If you have any further
problem about our product or service, kindly contact at any time.
