Cables Unlimited Pro-A/V SWB-7865 User manual

Pro-A/V Series™, P/N: SWB-7865
USER MANUAL
Table ofContents
1.0 Introduction……………………………………………………..1
2.0 Specifications………………………………………………..…2
3.0 Package Contents…….........................................................3
4.0 Panel Descriptions…………………………………………..…3
5.0 Connection and Operation……...........................................3

MiNi HDMI Amplifier Switcher 5×1
１
MINI HDMI Amplifier Switcher
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This is a kind of high performance MINI HDMI Amplifier Switcher. This kind of
HDMI Amplifier Switcher not only has the key-press-switching function, but also
has the IR remote control and intelligent function. That is to say, as soon as the
power supply of the source equipment is switched, this switcher will respond
automatically. In addition, it is equipped with standard IR extender receiver: safe
and convenient.
This kind of HDMI Amplifier Switcher routes high definition video (in multiple
resolutions up to 1080p) and digital audio from any one of the several sources to
display units. All inputs accommodate the connections of the high definition video
sources simultaneously, compatible well for HD-DVD,SKY-STB, PS3, Xbox360
etc. The output sends the high definition audio/video signals to a high definition
display.
1.1 INTELLIGENT FUNCTION
1) When supplied with power, this switcher will select the power-on source device
depending on the sequence automatically (input1>inout2>input3>input4>input5)
2) Once the source device is turned on or plugged in (should stay power-on
mode), the switcher will automatically select this source.
3)Once the source device is turned off or plugged out, the switcher will
automatically select the next power-on source depending on the sequence
automatically(input1>inout2>input3>input4>input5 )
Note:
1) When the source devices are on the stand-by mode, its power supply should
be turned off, otherwise this switcher can not meet intelligent function.
2) When plugged in or out, this switcher is completely intelligent.
1.2 FEATURES
This MiNi HDMI Amplifier Switcher has many features that enable it to perform in
a superior manner. Among those features you will find:
zMultifunctional on switching : intelligent or mechanical
zIR extender receiver (included)
zIR remote(included)
zSupport HDMI1.3b
zSupport highest video resolution 1080p.

MiNi HDMI Amplifier Switcher 5×1
２
zSupport 250MHz/2.5Gbps per channel (7.5Gbps all channel) bandwidth.
zSupport 12bit per channel (36bit all channel) deep color.
zHDCP pass-through.
zSupport uncompressed audio such as LPCM.
zSupport compressed audio such as DTS Digital, Dolby Digital（including
DTS-HD and Dolby True HD）.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input DDC Signal 5 volts p-p (TTL)
Maximum Single Link Range 1920X1080p
Output Video HDMI 1.3b
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplifier Bandwidth 2.5Gbps/250MHz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical
Size(L-W-H) 80×58×18mm
Weight(Net) 55g
Warranty
Limited Warranty 1 Year Parts and Labor
Environmental
Operating Temperature 0 ℃to +70℃
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10℃to +80℃
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
External Power Supply 5V@2A
Power consumption (Max) 5W
Accessories Adapter
IR extender receiver
IR remote
User Manual English Version
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
zMain unit.

MiNi HDMI Amplifier Switcher 5×1
３
zRemote control
zIR extender receiver
zUser's Manual
zPower Adapter
4.0 PANEL DESCRIPTIONS
I n p u t 5 I n p u t 1 O u t p u t
I n p u t 4 I n p u t 2 I n p u t 3
5.0 CONNECTION AND OPERATION
1) Connect the HDMI input source into the HDMI switch. (Input cables are
optional)
*Please refer to connection diagram section.
2) Insert the DC side of 5v power supply into the HDMI switch and then connect
the AC side of the power supply into the wall outlet.
3) Turn on the power.
Attention: Insert / Extract cable gently.

MiNi HDMI Amplifier Switcher 5×1
４
5.1 CONNECTION DIAGRAM
P/N2003
