Cabletron Systems HSIM-FE6 User manual

Title Page
HSIM-FE6
FEPIM 1 FEPIM 2
SP
9032555-03
HSIM-FE6
User’s Guide

HSIM-FE6 User’s Guide i
NOTICE
Cabletron Systems reserves the right to make changes in specifications and other information
contained in this document without prior notice. The reader should in all cases consult Cabletron
Systems to determine whether any such changes have been made.
The hardware, firmware, or software described in this manual is subject to change without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FORANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT
NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR
THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN
ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH
DAMAGES.
 1998 by Cabletron Systems, Inc., P.O. Box 5005, Rochester, NH 03866-5005
All Rights Reserved
Printed in the United States of America
Part Number: 9032555-03 July 1998
Cabletron Systems and LANVIEW are registered trademarks of Cabletron Systems, Inc.
All other product names mentioned in this manual may be trademarks or registered trademarks of
their respective companies.
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment uses, generates, and can radiate radio frequency energy and if not installed in
accordance with the operator’s manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause interference in which case the user
will be required to correct the interference at his own expense.
WARNING: Changes or modifications made to this device which are not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.
Only qualified personnel should perform installation
procedures.
Printed on Recycled Paper

Notice
ii HSIM-FE6 User’s Guide
INDUSTRY CANADA NOTICE
This digital apparatus does not exceed the ClassA limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.
VCCI NOTICE
This is a Class A product based on the standard of the Voluntary Control Council for Interference by
Information Technology Equipment (VCCI). If this equipment is used in a domestic environment,
radio disturbance may arise. When such trouble occurs, the user may be required to take corrective
actions.
CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT
IMPORTANT: Before utilizing this product, carefully read this License Agreement.
This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”)
that sets forth your rights and obligations with respect to the Cabletron software program (the
“Program”) contained in this package. The Program may be contained in firmware, chips or other
media. BY UTILIZING THE ENCLOSED PRODUCT,YOU ARE AGREEING TO BECOME
BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND
THE LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IFYOU DO NOT
AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN THE UNUSED
PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND.

Notice
HSIM-FE6 User’s Guide iii
CABLETRON SOFTWARE PROGRAM LICENSE
1. LICENSE. You have the right to use only the one (1) copy of the Program provided in this
package subject to the terms and conditions of this License Agreement.
You may not copy, reproduce or transmit any part of the Program except as permitted by the
Copyright Act of the United States or as authorized in writing by Cabletron.
2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or disassemble the
Program.
3. APPLICABLE LAW. This License Agreement shall be interpreted and governed under the laws
and in the state and federal courts of New Hampshire. You accept the personal jurisdiction and
venue of the New Hampshire courts.
EXCLUSION OF WARRANTY AND DISCLAIMER OF LIABILITY
1. EXCLUSION OF WARRANTY. Except as may be specifically provided by Cabletron in
writing, Cabletron makes no warranty, expressed or implied, concerning the Program (including
its documentation and media).
CABLETRON DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE SUPPLIED TO
YOU BY CABLETRON IN WRITING, EITHER EXPRESSED OR IMPLIED, INCLUDING
BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THE PROGRAM, THE
ACCOMPANYING WRITTEN MATERIALS, AND ANY ACCOMPANYING HARDWARE.
2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL
CABLETRON OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS,
PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL,
INCIDENTAL, CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS)
ARISING OUT OF THE USE OR INABILITY TO USE THIS CABLETRON PRODUCT,
EVEN IF CABLETRON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR
ON THE DURATION OR LIMITATION OF IMPLIED WARRANTIES, IN SOME
INSTANCES THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO
YOU.
UNITED STATES GOVERNMENT RESTRICTED RIGHTS
The enclosed product (a) was developed solely at private expense; (b) contains “restricted computer
software” submitted with restricted rights in accordance with Section 52227-19 (a) through (d) of the
Commercial Computer Software - Restricted Rights Clause and its successors, and (c) in all respects
is proprietary data belonging to Cabletron and/or its suppliers.
For Department of Defense units, the product is licensed with “Restricted Rights” as defined in the
DoD Supplement to the Federal Acquisition Regulations, Section 52.227-7013 (c) (1) (ii) and its
successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in
subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at
252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505.

Notice
iv HSIM-FE6 User’s Guide
SAFETY INFORMATION
CLASS 1 LASER TRANSCEIVERS
THE HSIM-FE6 GIGABIT ETHERNET MODULES USE
CLASS 1 LASER TRANSCEIVERS. READ THE FOLLOWING
SAFETY INFORMATION BEFORE INSTALLING OR OPERATING
THESE ADAPTERS.
The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This
control loop eliminates the need for maintenance checks or adjustments. The output is factory set, and
does not allow any user adjustment. Class 1 laser transceivers comply with the following safety
standards:
• 21 CFR 1040.10 and 1040.11 U.S. Department of Health and Human Services (FDA).
• IEC Publication 825 (International Electrotechnical Commission).
• CENELEC EN 60825 (European Committee for Electrotechnical Standardization).
When operating within their performance limitations, laser transceiver output meets the Class 1
accessible emission limit of all three standards. Class 1 levels of laser radiation are not considered
hazardous.
SAFETY INFORMATION
CLASS 1 LASER TRANSCEIVERS
LASER RADIATION AND CONNECTORS
When the connector is in place, all laser radiation remains within the fiber. The maximum amount of
radiant power exiting the fiber (under normal conditions) is -12.6 dBm or 55 x 10
-6
watts.
Removing the optical connector from the transceiver allows laser radiation to emit directly from the
optical port. The maximum radiance from the optical port (under worst case conditions) is
0.8 W cm
-2
or 8 x 10
3
W m
2
sr-1.
Do not use optical instruments to view the laser output. The use of optical instruments to view
laser output increases eye hazard. When viewing the output optical port, power must be
removed from the network adapter.

Notice
HSIM-FE6 User’s Guide v
DECLARATION OF CONFORMITY
Application of Council Directive(s): 89/336/EEC
73/23/EEC
Manufacturer’s Name: Cabletron Systems, Inc.
Manufacturer’s Address: 35 Industrial Way
PO Box 5005
Rochester, NH 03867
European Representative Name: Mr. J. Solari
European Representative Address: Cabletron Systems Limited
Nexus House, Newbury Business Park
London Road, Newbury
Berkshire RG13 2PZ, England
Conformance to Directive(s)/Product Standards: EC Directive 89/336/EEC
EC Directive 73/23/EEC
EN 55022
EN 50082-1
EN 60950
Equipment Type/Environment: Networking Equipment, for use in a
Commercial or Light
Industrial
Environment.
We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged
with this notice conforms to the above directives.
Manufacturer Legal Representative in Europe
Mr. Ronald Fotino Mr. J. Solari
___________________________________ ___________________________________
Full Name Full Name
Principal Compliance Engineer Managing Director - E.M.E.A.
___________________________________ ___________________________________
Title Title
Rochester, NH, USA Newbury, Berkshire, England
___________________________________ ___________________________________
Location Location

Notice
vi HSIM-FE6 User’s Guide

HSIM-FE6 User’s Guide vii
CONTENTS
CHAPTER 1 INTRODUCTION
1.1 Using This Manual.......................................................................1-1
1.2 Overview......................................................................................1-2
1.2.1 Connectivity ....................................................................1-2
1.2.2 Local Management .........................................................1-2
1.2.3 Full Duplex Switched Ethernet........................................1-2
1.2.4 LANVIEW Diagnostic LEDs............................................1-2
1.3 FEPIM Options............................................................................1-3
1.4 Document Conventions...............................................................1-3
1.5 Getting Help.................................................................................1-4
1.6 Related Documentation...............................................................1-5
CHAPTER 2 INSTALLATION
2.1 Unpacking the HSIM-FE6............................................................2-1
2.2 Installing Fast Ethernet (Port) Interface Modules........................2-2
2.3 Installing the HSIM-FE6...............................................................2-5
2.3.1 Installing the HSIM-FE6 in an Interface Module .............2-5
2.3.2 Installing the HSIM-FE6 in a Standalone Device............2-8
2.4 Connecting to the Network..........................................................2-9
2.4.1 Connecting a Fiber Optic Segment to the FEPIM.........2-10
2.4.2 Connecting a Twisted Pair Segment
to the FE-100TX ...........................................................2-11
CHAPTER 3 LANVIEW LEDs
3.1 HSIM-FE6 LEDs..........................................................................3-1
3.2 FE-100TX LED............................................................................3-2
3.3 HSIM-FE6 Local Management....................................................3-3
APPENDIX A SPECIFICATIONS
A.1 Physical Properties......................................................................A-1
A.2 Environmental Requirements......................................................A-1
A.3 FEPIM Options............................................................................A-1
A.4 Regulatory Compliance...............................................................A-2
APPENDIX B FEPIM SPECIFICATIONS
B.1 FE-100TX....................................................................................B-1
B.2 FE-100FX....................................................................................B-2
B.3 FE-100F3.....................................................................................B-3

Contents
viii HSIM-FE6 User’s Guide

HSIM-FE6 User’s Guide ix
FIGURES
Figure Page
1-1 HSIM-FE6.................................................................................1-1
2-1 Removing the FEPIM Coverplate.............................................2-3
2-2 Installing the FEPIM.................................................................2-4
2-3 Removing the HSIM Coverplate...............................................2-6
2-4 Installing the HSIM-FE6 ...........................................................2-7
2-5 FE-100TX Crossover Switch..................................................2-11
2-6 Twisted Pair Cabling ..............................................................2-12
3-1 HSIM-FE6 LANVIEW LEDs......................................................3-1
3-2 FE-100TX LED.........................................................................3-2
B-1 FE-100TX Pinouts....................................................................B-1
B-2 FE-100FX.................................................................................B-2
B-3 FE-100F3 .................................................................................B-3

x HSIM-FE6 User’s Guide
TABLES
Table Page
1-1 FEPIM Options .........................................................................1-3
3-1 HSIM-FE6 LEDs.......................................................................3-2
3-2 10/100 LED Indications When RX LED Is On...........................3-3
3-3 10/100 LED Indications When RX LED Is Off...........................3-3

HSIM-FE6 User’s Guide 1-1
CHAPTER 1
INTRODUCTION
Welcome to the Cabletron Systems HSIM-FE6 User’s Guide . This
manual describes the HSIM-FE6 and provides information concerning
features, installation, troubleshooting, and specifications.
A general working knowledge of Ethernet and data communications
networks and their physical layer components is helpful when installing
this device.
The HSIM-FE6 has two Fast Ethernet ports in which Cabletron Systems
Fast Ethernet (Port) Interface Modules (FEPIMs) can be installed.
Figure 1-1 shows the HSIM-FE6.
Figure 1-1 HSIM-FE6
1.1 USINGTHIS MANUAL
Reading through this manual completely will help you understand the
features and capabilities of the HSIM-FE6. The following list provides an
overview of each section of this manual:
Chapter 1, Introduction , outlines the contents of this manual, describes
the HSIM-FE6 features and concludes with a web site address where
related manuals can be obtained.
Chapter 2, Installation , describes how to install an HSIM-FE6 into an
interface module or a standalone device (host platform).
NOTE
The term “host platform” is used to describe the interface
module, or standalone device, into which the HSIM-FE6 can be
installed.
Ports 1 and 2
fepim_ports
HSIM-FE6
FEPIM 1 FEPIM 2
SP

Chapter 1: Introduction
1-2 HSIM-FE6 User’s Guide
Chapter 3, LANVIEW LEDs , describes how to use the HSIM-FE6 LEDs
to monitor the HSIM performance and status.
Appendix A, Specifications , lists the operating specifications and
regulatory compliance of the HSIM-FE6.
Appendix B, FEPIM Specifications , describes the FEPIM specifications
and regulatory compliance.
1.2 OVERVIEW
The HSIM-FE6 extends the functionality of certain Cabletron Systems
interface modules or standalone devices by providing high-speed uplink
capability through Fast Ethernet technology with different types of media.
1.2.1 Connectivity
The HSIM-FE6 module supports Fast Ethernet technology, using
interchangeable Fast Ethernet Port Interface Modules (FEPIMs). The
FEPIMs support three types of media connectivity: RJ45 Category 5
unshielded twisted pair, and SC connectors for either single or multimode
fiber. The FEPIMs support an uplink to 100 Mbps Fast Ethernet
backbones or a high speed connection to a local server.
1.2.2 Local Management
The HSIM-FE6 is managed through the host device in which it is
installed. For information concerning Local Management for the
HSIM-FE6, refer to the manual for the host platform. For details on
obtaining the host platform manual, refer to Section 1.6.
1.2.3 Full Duplex Switched Ethernet
The optional Fast Ethernet (Port) Interface Modules for the HSIM-FE6
can be configured to operate in Full Duplex Switched Ethernet mode.
1.2.4 LANVIEW Diagnostic LEDs
Cabletron Systems provides a visual diagnostic and monitoring system
called LANVIEW. The HSIM-FE6 LANVIEW LEDs help you quickly
identify transmit and receive status. Chapter 3 provides information on
the HSIM-FE6 LEDs and the FE-100TX LED.

FEPIM Options
HSIM-FE6 User’s Guide 1-3
1.3 FEPIM OPTIONS
The FEPIM options for the HSIM-FE6 are listed in Table 1-1. Check the
Release Notes with the host platform for changes or additions to this list.
1.4 DOCUMENT CONVENTIONS
The following conventions are used throughout this document:
Table 1-1 FEPIM Options
Part Number Connector Media type
FE-100TX RJ45 category 5 unshielded twisted pair
FE-100FX SC fiber multimode fiber
FE-100F3 SC fiber single mode fiber
NOTE
Note symbol. Calls the reader’s attention to any item of
information that may be of special importance.
!
CAUTION
Caution symbol. Contains information essential to avoid
damage to the equipment.
Electrical Hazard Warning symbol.Warns against an action
that could result in personal injury or death due to an electrical
hazard.
TIP
Tip symbol. Conveys helpful hints concerning procedures or
actions.

Chapter 1: Introduction
1-4 HSIM-FE6 User’s Guide
1.5 GETTING HELP
For additional support related to this device or document, contact the
Cabletron Systems Global Call Center:
Before calling the Cabletron Systems Global Call Center, have the
following information ready:
• Your Cabletron Systems service contract number
• A description of the failure
• A description of any action(s) already taken to resolve the problem
(e.g., changing mode switches, rebooting the unit, etc.)
• The serial and revision numbers of all involved Cabletron Systems
products in the network
• A description of your network environment (layout, cable type, etc.)
• Network load and frame size at the time of trouble (if known)
• The device history (i.e., have you returned the device before, is this a
recurring problem, etc.)
• Any previous Return Material Authorization (RMA) numbers
World Wide Web http://www.cabletron.com/
For technical support, select Service and Support
Phone [phone]
Internet mail suppor[email protected]
FTP ctron.com (134.141.197.25)
Login
anonymous
Password your email address
BBS [phone]
Modem setting 8N1: 8 data bits, No parity, 1 stop bit
To send comments or suggestions concerning this document, contact the
Cabletron SystemsTechnical Writing Department via the following
email address: [email protected]
Make sure to include the document Part Number in the email message.

Related Documentation
HSIM-FE6 User’s Guide 1-5
1.6 RELATED DOCUMENTATION
The documentation for the host device in which the HSIM-FE6 is to be
installed provides additional information about the setup of the
HSIM-FE6. This user’s guide references procedures in these documents,
where appropriate, but does not repeat them.
These documents can be obtained on the World Wide Web in Adobe
Acrobat Portable Document Format (PDF) at the following site:
http://www.cabletron.com/

Chapter 1: Introduction
1-6 HSIM-FE6 User’s Guide

HSIM-FE6 User’s Guide 2-1
CHAPTER 2
INSTALLATION
To install the HSIM-FE6 the following items are required:
• Antistatic wrist strap
• Phillips screwdriver
• Fast Ethernet (Port) Interface Modules (FEPIMs) in the appropriate
media
2.1 UNPACKING THE HSIM-FE6
Unpack the HSIM-FE6 as follows:
1. Remove the HSIM-FE6 from the shipping box.
2. Leave the module in its antistatic bag until you are ready to install it.
3. Attach the antistatic wrist strap (refer to the instructions on the
antistatic wrist strap package for proper use).
4. After removing the module from its antistatic bag, visually inspect the
device. If you notice any sign of damage, contact the Cabletron
Systems Global Call Center immediately. Refer to Section 1.5 for
instructions. Save the antistatic bag in the event the module must be
reshipped.
NOTE
Before attempting to use the HSIM-FE6 you should be familiar
with the IEEE 802.3, 802.3 10BASE-T, and 802.3u 100BASE-T
Specifications.
!
CAUTION
The HSIM-FE6 and the host platform are sensitive to static
discharges.Use an antistatic strap and observe all static
precautions during this procedure. Failure to do so could result
in damage to the HSIM-FE6, host module or device.

Chapter 2: Installation
2-2 HSIM-FE6 User’s Guide
2.2 INSTALLINGFASTETHERNET(PORT)INTERFACE
MODULES
Fast Ethernet (Port) Interface Modules (FEPIMs) must be installed in the
HSIM-FE6 before installing the HSIM-FE6 in the host device. The
FEPIMs provide connectivity to the network.At least one FEPIM must be
installed in either port one or port two. To install an FEPIM in the
HSIM-FE6, proceed as follows:
1. Remove the coverplate from the port slot where the FEPIM will be
installed.
To remove the coverplate, refer to Figure 2-1 and proceed as follows:
a. Remove the two screws fastening the coverplate to the standoffs.
Save the screws.
b. Lift and remove the coverplate from the top of the front standoffs.
Only qualified personnel should perform installation
procedures.
!
CAUTION
The FEPIM and the HSIM-FE6 are sensitive to static
discharges.Use an antistatic wrist strap and observe all static
precautions during this procedure. Failure to do so could
damage the FEPIM or the HSIM-FE6.
The FE-100F3 uses Class 1 lasers.Do not use optical
instruments to view the laser output.The use of optical
instruments to view laser output increases eye hazard.When
viewing the output optical port, power must be removed from
the network adapter.
