SSIM-T5-04 Token Ring
SmartStack Interface Module
Introduction
The SmartStack SSIM-T5-04 provides four additional Token
Ring ports for the base SmartStack STS16-20RM or STS16-
20FRM Token Ring switch. Theseports can be configuredjust
like the 20 fixed Token Ring portson the base switch. Each or
all of the interface module ports can be configured (in
combination with any of thefixed ports on the base switch) to
be used in CrossLink connections, and configured to be
included in virtual LANs. The interface module ports support
address filters and BOOTP/TFTP, Telnet or SNMP sessions.
Figure 1. SSIM-T5-04 interface module Front Panel
The ports on the SSIM-T5-04 interface module support Token
Ring twisted-pair (UTP/STP) media via RJ-45 connectors.
The interfacemodule ports can be configured just like the base
switch ports to provide either shared (half-duplex) 4 or 16
Mbps Token Ring connections or dedicated (full-duplex) 32
Mbps connections.
In addition to the RJ-45 Token-Ring connectors, there are 10
LEDs on the faceplate of the interface module(a set of two for
each port plus two for the interface module general status).
These LEDs indicate the operational status of the interface
module and of the ports.
SSIM-T5-04 Module Package Contents
The interface module package contains the following items:
•One SSIM-T5-04 SmartStack interface module for the
Token Ring Switch
•One SSIM-T5-04 SmartStack Interface Module
Installation Guide (this document)
Installation
1. Power off the base switch by unplugging it.
2. Remove the plate covering the expansion slot on the front
of the base switch by unscrewing the two retaining
thumbscrews. Keep the plate for use in the event that the
interface module is removed.
3. Carefully insert the interface module into the rails on each
side of the expansion slot, sliding it back until the
connector on the interface module is seated into the
connector at the back of the slot.When the interface
module is fully seated, the interface module faceplate will
be flush with the front of the base switch.
4. Secure the interface module with the two attached
thumbscrews.
Cabling
For specifications and directions about cabling the UTP/STP
universal expansion modules, see Appendix B in SmartStack
STS16-20RM/STS16-20FRM Token Ring Switches,
Installation and User Guide.
LEDs
The interface module has 10 LEDs.
Table 1 lists the two status LEDs on the left front of the
interface module and their meanings.
Table 1. Status LEDs and their meanings
Table 2 lists the port LEDs above each RJ-45 and their
meanings.
Table 2. Port LEDs and their Meanings
Testing the interface module
1. Power on the base switch to start diagnostics. The STS16-
20RM Token Ring switch indicates that diagnostics are in
progress by turning on its DIAG LED. After about a
minute, the interface module DIAG LED will also be
turned on.
2. Verify that the base switch diagnostics have been
completed successfully. On the STS16-20RM, this is
indicated when its DIAG LED is turned off, and the ERR
LED stays turned off. Diagnostics can take up to four
minutes to complete.
3. Verify that the ERR LED on the interface module is off. If
it is off, diagnostics have been successfully completed, and
the interface module is ready for configuration.
Configuration
The interfacemodule ports canbe configured just like the base
switch ports. They will appear as additional ports on any
configuration panel where ports are listed. The port numbers
will begin where the numbers of the base switch stop.
If for example the base switch has 20 ports and an interface
module in the left front panel slot, the interface module ports
will appear after Port 20 on the various port configuration
panels and be designated 21, 22, 23 and 24. If the module is in
the right front panel slot, the ports will be designated 25, 26,
27 and 28.
Follow the instructions contained in the SmartStack STS16-
20RM/STS16-20FRM Token Ring Switches, Installation and
User Guide for configuring the interface module ports.
ERR
DIAG
234
1
LED Position State Meaning
DIAG
(green) Top On Diagnostics are in progress.
Off The interface module is
working correctly.
ERR
(yellow) Bottom On An interface module failure has occurred.
Off The interface module is
working correctly.
LED Position State Meaning
INSRT
(green) Left On The attached device is connected to the interface
module port.
TX/RX
(green) Right On or blinking Data is being transmitted or received by the port.

4
Troubleshooting
•If you are installingthe interface module andthe LEDs do
not come on when the base switch is powered on, verify
that the interface module is properly seated in the slot.
•During diagnostics, the interface module DIAG LED is
on. If the ERR LED is on at any time, it indicates that the
interface module is defective and needs to be serviced.
The individual interface module ports are like the base switch
ports for the purposes of troubleshooting. See theSmartStack
STS16-20RM/STS16-20FRM Token Ring Switch, Installation
and User Guide for troubleshooting hints.
❏
Getting in Touch With Technical Support
For additional support related to this device or document,
contact Cabletron Systems using one of the following
methods:
World Wide Web http://www.cabletron.com/
Phone [phone]
Internet mail [e-mail]
FTP ftp://ftp.cabletron.com/
Login
anonymous
Password your email address
To send comments or suggestions concerning this
document, contact the Cabletron Systems Technical
Writing Department via the following email
address: [e-mail]
Make sure to include the document Part Number in the
email message.
SSIM-T5-04
Token Ring
SmartStack Interface Module
for
SmartStack
Token Ring Switch
Installation Guide
Trademarks
SmartStack is a trademark of Cabletron Systems, Inc. All other product names are trademarks or
registered trademarks of their respective holders.
Copyrights
Cabletron reserves the right to modify the information given in this publication without prior notice. The
warranty terms and conditions applicable for your purchase of this equipment are given at the time of
purchase. Please consult them for details.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise,
without the prior written permission of the publisher.
Publication: OC-7055 v. 1.0, 710001711
Part Number: 9032969
© February 1999 byCabletron Systems, Inc.
FCC Compliance
This equipment has beentested and found tocomply with the limitsfor aClass A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Caution
The RJ-45 connectors may only be connected to SELV circuits (LAN communication).
